2022 SUBARU BRZ window

Windows
1164. Hold down “ ” of the driver’s power
door locking switch, open the driver’s door
within the following 1 second, and wait 10
seconds without releasing the switch. The
setting will then be changed as follows.NOTEYou may have the above setting
change done by your SUBARU dealer.■
If You Have Accidentally
Triggered the Alarm System
▼
To stop the alarm
Do any of the following operations:
 Press unlock button on the access key
fob.
 Turn the push-button ignition switch to
the “ACC” position.
NOTEOnly registered keys will stop the
alarm. If the immobilizer transponder
is not registered, the alarm will not
stop.
2-6. WindowsNOTE In order to make opening and
closing the doors easier, completely
closed windows are linked to door
operations. Therefore, when a door is
opened, its window opens slightly. When a door is closed, its window
closes completely. However, if the
battery has discharged or is discon-
nected, this function will not operate.

If the power window system detects
resistance, an impact or abnormality,
the window operation may be automat-
ically stopped to prevent further
jamming, entrapment or malfunction.
- The closing window slides down
slightly and stops.
- The opening window stops
sliding down.
 The power window system may
detect resistance, an impact or an
abnormality in the following cases. - A substantial sized object is
caught between the window and the
roof side (between the front pillar
and a point over the rear seat).
- A foreign object is caught
between the window and the roof
side (between the front pillar and a
point over the rear seat).
- The vehicle drives over a deep
pothole.
 The window cannot be closed for a
few seconds after th e window is auto-
matically stopped by the system.
Setting status Combination
meter display (color TFT) Horn
Activate AL ON Once
Deactivate AL OFF Twice
WARNING
To avoid serious personal injury
caused by entrapment, always con-
form to the follo wing instructions
without exception. When operating the power
windows, be extremely careful to
prevent anyone’s fingers, arms,
neck, head or other objects from
being caught in the window.Always lock the passengers’
windows using the lock switch
when children are riding in the
vehicle.Always carry the key when you
leave the vehicle for safety
reasons and never allow an unat-
tended child to remain in the
vehicle. Failure to follow this
procedure could result in injury
to a child operating the power
window.
B5=B8.ERRN 116 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Windows
117
Keys and Doors2
– CONTINUED –
■
Power Window Operation
▼
Power window switches
 Driver’s side power window switches:1) For left window
2) For right window
3) Lock switchAll door windows can be controlled by the
power window switch cluster on the driver
side door. 
Passenger’s side power window
switches:
Passenger’s window can be controlled by
the power window switch located on the
door. ▼
Operating the windowWith one-touch auto up and down
feature
1) Automatically close*
2) Close
3) Open
4) Automatically open*
*: To stop the window halfway, operate the switch to the opposite side.NOTEAvoid the following.
Continuously operating a switch in
the same direction after the window is
fully closed or fully opened.
 After the windows are fully opened
or closed, if both switches of the power
window switch on the driver’s side are
operated continuously, a fuse may
1
2
3
204137
204138
202972
1 2
3
4
B5=B8.ERRN 11 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Windows
118blow and the windows will not be able
to be opened or closed. If the windows
cannot be opened or closed, check the
fuses and replace them as necessary.
Refer to "Fuses" 
P371.
Also, after replacing a fuse, make sure
to initialize the power windows. Refer
to "Initialization of Power Window"

P118.
▼Anti-entrapment function
While closing the window automatically, if
the window senses a substantial enough
object trapped between the window and
the roof side (between the front pillar and
a point over the rear seat), it automatically
moves down slightly and stops.
If a foreign object is caught while window
is opening automatical ly, the window will
stop.
NOTE If a window detects an impact
similar to that caused by trapping an
object (for example, when the vehicle
encounters a deep pothole), the anti-
entrapment func tion may operate.
 You cannot close the window for a
few seconds after the anti-entrapment
function operates.
▼
Off delay function
The windows can be operated for approx-
imately 40 seconds even after the ignition
switch is turned to the “ACC” or “OFF”
position. If a door is opened within 40
seconds, the off delay function is
canceled. ▼
Locking the passenger’s window1) Lock
2) UnlockWhen the lock switch is in the lock posi-
tion, the passenger’s window cannot be
opened or closed.■
Initialization of Power
Window
If the one-touch aut
o up and down func-
tion or off delay function does not operate
properly, operate each window according
to the following procedure in order to
initialize the pow er window system.
1. Close the door.
2. Turn the ignition switch to the “ON”
position.
CAUTION
 Never attempt to test the power
window operation using body
parts fingers, hands or other
parts of your body.If an object is caught just before
the window fully closes, the
system may not operate properly.
12
204139
B5=B8.ERRN 11 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Trunk Lid
119
Keys and Doors2
– CONTINUED –
3. Open the window completely and then
press and hold down the power window
switch for approximately 1 second.
4. Close the window completely and then
pull and hold the power window switch for
approximately 1 second.
2-7. Trunk Lid
WARNING
To prevent dangerous exhaust
gas from entering the vehicle,
always keep the trunk lid closed
while the engine is running.Check that the trunk is
completely closed before driving.
If it is not, it may suddenly open,
which could lead to an accident.Help prevent children, adults or
animals from locking themselves
in the trunk. On hot or sunny
days, the temperature in the trunk
could quickly become high
enough to cause death or serious
heat-related injuries including
brain damage to anyone locked
inside, particularly for small chil-
dren.When leaving the vehicle, close
all windows and lock all doors.
Also make certain that the trunk
is closed.
CAUTION
Be extremely careful not to catch
fingers or other objects when
closing the trunk lid.
Before opening and closing the
trunk, carefully check your
surroundings to make sure it will
not strike any people or objects.Pay attention to hot engine
exhaust gas when loading and
unloading cargo, as it could
possibly cause burns.Be careful opening the trunk
when the wind is strong. The
trunk lid could close or open
suddenly, possibly causing inju-
ries.Make sure that the trunk is
completely open when using it. If
it is not, the trunk lid may
suddenly drop and cause serious
injury. Remove snow and ice from the
trunk lid before opening it. Not
doing so could cause the trunk lid
to fall after it is opened.Under the following conditions,
the trunk lid may close unexpect-
edly, striking people or objects in
its path:
- Parking on a slope, with the
rear of the vehicle lower than
its front. In this case, make
sure the trunk lid is fully open
and secure before loading or
unloading cargo.
B5=B8.ERRN 11 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Warning and Indicator Lights
144NOTEEven when the access key fob is
within the operating ranges inside the
vehicle, the access key warning for
engine start may be provided
depending on the status of the access key fob and the environmental condi-
tions.

When the access key fob is taken
out of the vehicle through an open
window, the access key takeout
warning or passenger access key
takeout warning will not be provided.
▼
List of warnings
WARNING
Never drive the vehicle if a steering
lock warning message is displayed
on the combination meter when
starting the engine. This indicates
the status that the steering lock is
not released and could result in an
accident involving serious injury or
death.
CAUTION
 If a steering lock system malfunc-
tion warning message is
displayed on the combination
meter, there could be a steering
lock malfunction. Contact your
SUBARU dealer as soon as
possible.When the keyless access system
warning message is displayed on
the combination meter, contact a
SUBARU dealer immediately.
CAUTION
When any of the following warnings
occurs even if the access key warn-
ing indicator does not appear, take
the appropriate action.
B5=B8.ERRN 144 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Wiper and Washer
183
Instruments and Controls3
– CONTINUED –
3-14. Wiper and Washer
NOTEThe windshield wiper motor is
protected against overloads by a
circuit breaker. If the motor operates
continuously under an unusually
heavy load, the circuit breaker may trip
to stop the motor temporarily. If this
happens, park your vehicle in a safe
location, turn off th e wiper switch, and
wait for approximately 10 minutes. The
circuit breaker will reset itself, and the
wipers will again operate normally.
 Clean your blade rubbers and
window glass periodically with a
washer solution to prevent streaking,
WARNING
In freezing weather, do not use the
windshield washer until the wind-
shield is sufficiently warmed by the
defroster.Otherwise the washer fluid can
freeze on the windshield, blocking
your view.
CAUTION
 Do not operate the washer contin-
uously for more than 10 seconds,
or when the washer fluid tank is
empty. This may cause over-
heating of the washer motor.
Check the washer fluid level
frequently, such as at fuel stops.Do not operate the wipers when
the windshield is dry. This may
scratch the glass, damage the
blade rubbers and cause the
wiper motor to bu rn out. Before
operating the wiper on a dry wind-
shield always use the windshield
washer.
 In freezing weather, be sure that
the blade rubbers are not frozen
to the windshield before
switching on the wipers.
Attempting to operate the wiper
with the blade rubbers frozen to
the window glass could cause not
only the blade rubbers to be
damaged but also might cause
the wiper motor to fail. If the blade
rubbers are frozen to the window
glass, be sure to operate the
defroster before turning on the
wiper. If the wipers stop during opera-
tion because of ice or some other
obstruction on the window, this
might cause the wiper motor to
fail even if the wiper switch is
turned off. If this occurs,
promptly stop the vehicle in a
safe location, turn the ignition
switch to the “OFF” position and
clean the window glass to allow
proper wiper operation.
Use clean water if windshield
washer fluid is unavailable. In
areas where water freezes in
winter, use SUBARU Windshield
Washer Fluid or the equivalent.
Refer to "Windshield Washer
Fluid" 
P366.
Also, when driving the vehicle
when there are freezing tempera-
tures, use non-freezing type
wiper blades.
 Do not clean the wiper blades
with gasoline or a solvent, such
as paint thinner or benzine. This
will cause deterioration of the
wiper blades.
B5=B8.ERRN 13 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Wiper and Washer
184and to remove accumulations of road
salt or road film. Operate the wind-
shield washer for at least 1 second so
that washer solution will be sprinkled
all over the windshield or rear window.
Grease, wax, insects or other mate-
rial on the windshield or the blade
rubbers results in jerky wiper opera-
tion and streaking on the glass. If you
cannot remove those streaks after
operating the washer or if the wiper
operation is jerky, clean the outer
surface of the windshield or rear
window and the blade rubbers using a
sponge or soft cloth with a neutral
detergent or mild abrasive cleaner.
After cleaning, rinse the window glass
and blade rubbers with clean water.
The glass is clean if no beads form on
the glass when you rinse with water.
 If you cannot eliminate the streaking
even after followin g this procedure,
replace the wiper blades (or blade
rubbers) with new ones. For replace-
ment instructions, refer to "Replace-
ment of Wiper Blades" 
P367.
 If the wipers do not operate in the
following conditions, turn the wiper
switch to the “ ” position.
- The wiper switch is in the “ ”
position, however, it does not work.
- The wiper switch is in the “ ”
position, however, it does not work. In these cases, contact your SUBARU
dealer.
■
Windshield Wiper and
Washer Switches
The wiper operates only when the ignition
switch is in the “ON” position.
▼
Wi
ndshield wipers
To turn the wipers on, push the wiper
co ntrol lever down. To turn the wipers off, return the lever to
the “ ” position.
For a single wipe of the wipers, push the
lever up. The wipers operate until you
release the lever.
▼
Wiper intermittent
time control
When the wiper switch is in the “ ” posi-
tion, turn the dial to adjust the operating
interval of the wiper. The operating
interval can be adjusted in several steps
from the shortest inte rval to the longest.
: Mist (for a single wipe)
: Off
: Intermittent
: Low speed
: High speed
301723
301724
B5=B8.ERRN 14 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Defogger
185
Instruments and Controls3
– CONTINUED –
▼
Windshield washer
To wash the windshield, pull the wiper
control lever toward you. The washer fluid
sprays until you release the lever. The
wipers operate while you pull the lever.
3-15. Defogger1) Rear window defogger
2) Outside mirror defogger (if equipped)The defogger system is activated only
when the ignition switch is in the “ON”
position.
Rear window and outside mirror (if
equipped) defogger buttonTo activate the defogger system, press
the rear window and outside mirror
defogger button. The rear window
defogger and outside mirror defogger are
activated simultaneously. The indicator
light on the button illuminates while the
defogger system is activated.
To turn them off, press the button again.
They also turn off when the ignition switch
is turned to the “ACC” or “OFF” position.
The defogger system will automatically
shut off after approximately 15 minutes. If
the rear window and outside mirrors have
been cleared before that time, press the
button to turn them off. If defrosting or
defogging is not complete, you have to
press the button to turn them on again.
301725
1
2306818
306819
B5=B8.ERRN 15 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分
