2022 HYUNDAI KONA glove box

Convenient features
5-104
WARNING
Never store cigarette lighters, propane
cylinders, or other flammable/explosive
materials in the vehicle. These items
may catch fire and/or explode if the
vehicle is exposed to hot temperatures
for extended periods.
WARNING
ALWAYS keep the storage compartment
covers closed securely while driving.
Items inside your vehicle are moving as
fast as the vehicle. If you have to stop
or turn quickly, or if there is a crash, the
items may fly out of the compartment
and may cause an injury if they strike
the driver or a passenger.
NOTICE
To avoid possible theft, do not leave
valuables in the storage compartments.
Center console storage
OOS047056
To open:
Pull the lever (1).
Glove box
OOS047057
To open the glove box, pull the handle
(1) and the glove box will automatically
open. Close the glove box after use.
WARNING
ALWAYS close the glove box door after
use.
An open glove box door can cause
serious injury to the passenger in an
accident, even if the passenger is
wearing a seat belt.

Maintenance
9-24
CLIMATE CONTROL AIR FILTER
Filter Inspection
The climate control air filter should be
replaced according to the Maintenance
Schedule. If the vehicle is operated
in severely air-polluted cities or on
dusty rough roads for a long period, it
should be inspected more frequently
and replaced earlier. When you replace
the climate control air filter, replace it
performing the following procedure,
and be careful to avoid damaging other
components.
OOS077018
1. With the glove box open, remove the
stoppers on both sides.
OOS077017
2. Remove the support rod (1).
OOS077019
3. Remove the climate control air filter
case while pressing the lock on the
right side of the cover.
OPD076026
4. Replace the climate control air filter.
5. Reassemble in the reverse order of
disassembly.
NOTICE
Install a new climate control air filter
in the correct direction with the
arrow symbol () facing downwards,
otherwise, it may be noisy and the
effectiveness of the filter may be
reduced.

Maintenance
9-50
Fuse NameFuse Rating Circuit Protected
MODULE57.5A
ATM Shift Lever IND., A/V & Navigation Head Unit, Audio,
Electro Chromic Mirror, A/C Control Module, Front Air
Ventilation Control Module, Low DC-DC Converter
Driver Console Switch, Wireless Charger Unit, Data Link
Connector, Front/Rear Seat Warmer Control Module
MODULE37.5A Stop Lamp Switch, BCM, ATM Shift Lever, IAU
SUNROOF20A Sunroof Unit
TAILGATE OPEN10A Tailgate Relay
P/WINDOW LH25APower Window LH Relay, Driver Safety Power Window
Module
MULTI MEDIA15A Low DC-DC Converter
P/WINDOW RH25APower Window RH Relay, Passenger Safety Power Window
Module
P/SEAT (DRV)25A Driver Seat Manual Switch, Driver Reclining Switch
MODULE47.5A EPB Switch, BCM, Front View Camera, AWD ECM
PDM37.5A Smart Key Control Module, Immobilizer Module
POWER
OUTLET220A ICM Relay Box(Power Outlet Relay)
INTERIOR
LAMP7.5A
Glove Box Lamp, Vanity Lamp LH/RH, Room Lamp,
Overhead Console Lamp, Luggage Lamp, Foot Lamp LH/
RH
MEMORY10AA/C Control Module, Head Up Display, BCM, Driver
Console Switch, Wireless Charger Unit, Rain Sensor
S/HEATER REAR20A Rear Seat Warmer Control Module
AMP30A Low DC-DC Converter
MODULE67.5A Smart Key Control Module, BCM, IAU
MDPS7.5A MDPS Unit
MODULE17.5Akey Interlock, BCM, Hazard Switch, Data Link Connector,
Rain sensor
MODULE77.5AFront Air Ventilation Control Module, Front/Rear Seat
Warmer Control Module

Maintenance
9-66
License Plate Light Bulb
Replacement
OOS077043
1. Using a flat-blade screwdriver, gently
pry the lens cover from the lamp
housing.
2. Remove the bulb by pulling it straight
out.
3. Install a new bulb.
4. Reinstall in the reverse order.
Interior Light Bulb Replacement
Map lamp, Room lamp, Vanity mirror
lamp, Luggage compartment lamp
and Glove box lamp
Map lamp (Type A)
OOS077053
Map lamp (Type B)
OOS077044

09
9-67
Room lamp (Type A)
OOS077054
Room lamp (Type B)
OOS077045
Vanity mirror lamp
OOS077046
Luggage compartment lamp
OOS077048
Glove box lamp
OOS077047
1. Using a flat-blade screwdriver, gently
pry the lens from the interior lamp
housing.
2. Remove the bulb by pulling it straight
out.
WARNING
Prior to working on the Interior Lights,
ensure that the “OFF” button is
depressed to avoid burning your fingers
or receiving an electric shock.
3. Install a new bulb in the socket.
4. Align the lens tabs with the interior
lamp housing notches and snap the
lens into place.
NOTICE
Use care not to dirty or damage lens,
lens tab, and plastic housings.

I
I-11
Seats ....................................................................................................................... 3-3
Front seats .......................................................................................................... 3-5
Head Restraints ................................................................................................ 3-13
Rear Seats ......................................................................................................... 3-10
Safety precautions .............................................................................................. 3-4
Seat Warmers and Air Ventilation Seats ........................................................... 3-17
Smart Cruise Control (SCC) .............................................................................. 7-64
Smart Cruise Control settings ......................................................................... 7-65
Smart Cruise Control display and control ........................................................ 7-69
Smart Cruise Control malfunction and limitations .......................................... 7-74
Smart Cruise Control operation........................................................................ 7-68
Special driving conditions ................................................................................... 6-63
Driving at night ................................................................................................ 6-64
Driving in flooded areas ................................................................................... 6-65
Driving in the rain ............................................................................................ 6-64
Hazardous driving conditions........................................................................... 6-63
Highway driving............................................................................................... 6-65
Reducing the risk of a rollover ......................................................................... 6-65
Rocking the vehicle .......................................................................................... 6-63
Smooth cornering ............................................................................................. 6-64
Steering wheel ..................................................................................................... 5-36
Electric Power Steering (EPS) ......................................................................... 5-36
Heated steering wheel ...................................................................................... 5-38
Horn.................................................................................................................. 5-38
Tilt / Telescopic steering .................................................................................. 5-37
Storage compartment ......................................................................................... 5-104
Center console storage ................................................................................... 5-104
Glove box ....................................................................................................... 5-104
Luggage tray................................................................................................... 5-106
Multi Box ....................................................................................................... 5-105
Sunglass Holder.............................................................................................. 5-105
Sunroof ................................................................................................................ 5-57
Resetting the sunroof........................................................................................ 5-60
Slide open/close................................................................................................ 5-58
Sunroof Open Warning..................................................................................... 5-60
Sunshade........................................................................................................... 5-57
Tilt open/close .................................................................................................. 5-58
