5166-1. Using the air conditioning system and defogger
6-1.Using the air conditioning system and defogger
*: If equipped
Fan speed control switch
Temperature control switch
On/off switch
Windshield defogger switch
Rear window defogger and outside rear view mirror defoggers
*
switch
Airflow mode control switch
Outside/recirculated air mode switch
“A/C” switch
“MAX A/C” switch
*: If equipped
■Adjusting the temperature
setting
To adjust the temperature set-
ting, turn the temperature con-
trol switch clockwise (warm) or
counterclockwise (cool).
If “A/C” switch is not pressed, the
system will blow a mbient tempera-
ture air or heated air.
■Fan speed setting
To adjust the fan speed, turn the
fan speed control switch clock-
wise (increase) or counterclock-
wise (decrease).
Pressing the on/off switch turns off
the fan.
When the fan is off, pressing the
on/off switch or turning the fan
speed control switch will turn on the
Manual air condi tioning system*
Air conditioning controls
A
B
C
D
E
F
G
H
I

5226-1. Using the air conditioning system and defogger
Automatic mode switch
Left-hand side temperature control knob
Right-hand side temperature control knob
“SYNC” switch
“OFF” switch
Windshield defogger switch
Rear window defogger and outside rear view mirror defoggers
switch
Eco air conditioning mode switch
Fan speed decrease switch
Fan speed increase switch
Airflow mode control switch
Outside/recirculated air mode switch
S-FLOW mode switch
“A/C” switch
■Adjusting the temperature
setting
Turn driver’s side temperature control dial clockwise to
increases the temperature and
turn the dial counterclockwise to
Automatic air co
nditioning system
Air outlets and fan speed are automatically adjusted accord-
ing to the temperature setting.
Air conditioning controls
A
B
C
D
E
F
G
H
I
J
K
L
M
N

6227-3. Do-it-yourself maintenance
5Turn the bulb base counter-
clockwise.
6 Set the new light bulb.
Align the 3 tabs on the light bulb
with the mounting, and insert. Turn
it clockwise to set.
7 Set the connector.
Shake the bulb base gently to
check that it is not loose, turn the
front fog lights on once and visually
confirm that no light is leaking
through the mounting.
8Reinstall the fender liner.
9 Reinstall the screws.
■Rear turn signal lights
1 Open the back door and
remove the cover.

736Alphabetical Index
Warning messages .............. 249
Language (multi-information dis- play) ................................. 96, 701
LATCH anchors ........................ 59
Lever Auxiliary catch lever ............. 579
Hood lock release lever........ 579
Shift lever ............................. 201
Turn signal lever................... 204
Wiper lever ................... 218, 221
License plate lights Light switch .......................... 211
Replacing light bulbs ............ 619
Light bulbs Replacing ............................. 619
Wattage ................................ 682
Lights Automatic High Beam system........................................... 214
Fog light switch .................... 217
Front interior lights ............... 532
Headlight switch ................... 211
Interior lights......................... 532
Personal lights...................... 533
Rear interior light .................. 533
Replacing light bulbs ............ 619
Turn signal lever................... 204
Vanity lights .......................... 544
Wattage ................................ 682
Linking multi-information display and the system ..................... 393
Lock steering column ............ 197
LTA (Lane Tracing Assist) ..... 240 Operation ............................. 240
Warning messages .............. 249
Luggage compartment light................................ 118, 121Wattage ................................ 682
Luggage cover........ ................ 541
M
Maintenance Do-it-yourself maintenance ..577
General maintenance ...........573
Maintenance data .................676
Maintenance requirements ...572
Malfunction indicator lamp ....639
Manual air conditioning system ...............................................516Air conditioning filter .............608
Menu icons ................................90
Menu screen............................381 Menu screen operation.........381
Meter Clock ................................82, 85
Indicators ................................76
Instrument panel light control.............................84, 88
Meter control switches............90
Meters ..............................82, 85
Multi-information display.........89
Settings ..........................94, 701
Units ...............................96, 701
Warning lights.......................638
Warning messages .........98, 649
Meter control switches.............90
Microphone ........... ..................474
Mirrors Digital Rear-view Mirror ........147
Inside rear view mirror ..........145
Outside rear view mirror defog-gers ............................517, 524
Outside rear view mirrors .....156
Vanity mirrors ..... ..................544
Mobile Assistant .....................469 Connectable devices and avail-able functions .....................469
Mobile Assistant operation ...469
Moon roof Door lock linked moon roof oper-ation....................................161
Jam protection function ........161
Operation..............................161
Warning message . ...............162
