2021 TESLA MODEL Y Owner´s Manual

As this alert is usually specific to external charging equipment and power sources, and it does not typically indicate
an issue with your vehicle that can be resolved by scheduling service, it is recommended that you:

(CP_a043)
Charge port door sensor fault
Charge port may not operate as expected
One of the charge port door sensors is not functioning normally. When this occurs, the charge port may be unable to
accurately sense the charge port door position and the charge port may not operate as expected.

(CP_a051)
Charge port may not open when pressed
Use another method to open the charge port
One of the charge port door sensors is not communicating properly. This may cause the charge port to not recognize the request to open when the charge port door is pressed.
You can still use all other usual methods to open the charge port door:

(CP_a054)
Charge port latch not engaged
Fully insert charge cable or check for obstruction
The charge port latch is unable to latch the charge cable in the charge port inlet. If the latch is not engaged, AC charging (for example, charging with a Tesla Mobile Connector or Wall Connector) will be limited to 16A and DC Fast
Charging / Supercharging will be unavailable.
The charge port light will pulse amber if this alert appears during AC charging and will be solid amber if this alert appears when attempting to DC Fast Charge / Supercharge.
If your vehicle begins charging and the charge port light pulses green, the charge cable may not have been fully
inserted before. The latch may not have engaged during previous attempts because the cable was not fully inserted.
AC charging should no longer be limited, and DC Fast Charging / Supercharging should be available.
If charging is still limited or the vehicle will not charge at all, inspect the charge port inlet and the charge cable
connector for any obstructions (use a
flashlight as needed). Debris and/or foreign objects in the charge port inlet or
the charge cable connector can prevent you from fully inserting the charge cable. If the cable is not fully inserted,
the charge port latch will not engage.
It is recommended that any debris / foreign objects be removed. Afterward, try re-inserting the cable into the charge port inlet. AC charging should no longer be limited, and DC Fast Charging / Supercharging should be available.
As this alert is usually specific to external charging equipment and power sources, and it does not typically indicate
an issue with your vehicle that can be resolved by scheduling service, it is recommended that you:

As this alert is usually specific to external charging equipment and power sources, and it does not typically indicate
an issue with your vehicle that can be resolved by scheduling service, it is recommended that you:

(CP_a058)
Unable to AC charge - Unplug and retry
Or try DC Fast Charging / Supercharging
Your vehicle is unable to AC charge because it has detected one of the following conditions and has tried to charge too many times without success:

(CP_a078)
Cable blocked - Charge port latch may be frozen
Try preconditioning on HI with Mobile App
The charge port latch cannot unlatch the charge cable, and cold ambient temperature is detected.
To remove any strain on the cable, re-insert the charge cable fully into the charge port inlet. Try again to unlatch the
charge cable.
If the charge cable still cannot be removed, the charge port latch may be frozen.
Use your Tesla Mobile App to precondition your vehicle on HI for approximately 30 - 45 minutes. This should help
thaw any ice on the charge port latch so the charge cable can be removed.
NOTE: Be sure to use your Mobile App to precondition the vehicle. Setting your climate control for the cabin to HI
using the touchscreen is not
effective.
If the charge cable still cannot be removed, try the manual release cable in your vehicle

If you have checked for and cleared any debris or foreign objects, but charging is still limited or your vehicle will not charge at all, the charge port latch may be frozen. Use your Tesla Mobile App to precondition your vehicle on HI for approximately 30 - 45 minutes. This should help thaw any ice on the charge port latch so the charge cable can be
properly inserted.
NOTE: Be sure to use your Mobile App to precondition the vehicle. Setting your climate control for the cabin to HI
using the touchscreen is not
effective.
As this alert usually indicates a temporary condition due to cold ambient temperature or a charge port inlet obstruction, and it does not typically indicate an issue with your vehicle that can be resolved by scheduling service, it is recommended that you:
