2021 MAZDA MODEL 6 Owners Manual

CAUTION
When cleaning the iridium plugs, do not use a wire brush. The
fine particulate coating on the
iridium alloy and platinum tips could be damaged.
▼ Lubricant Quality
Lubricant
Classification
Engine oil Refer to Recommended Oil on page 6-22.
Coolant FL-22 type
Automatic transaxle fluid Mazda Genuine ATF FZ
Transfer case oil Mazda Long Life Hypoid Gear Oil SG1
Rear differential oil Mazda Long Life Hypoid Gear Oil SG1
Brake fluid SAE J1703 or FMVSS116 DOT-3
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your investment.
▼Capacities
(Approximate Quantities)
Item
Capacity
Engine oil SKYACTIV-G
2.5
With oil filter replacement
4.5 L (4.8 US qt, 4.0 Imp qt)
Without oil filter replacement 4.3 L (4.5 US qt, 3.8 Imp qt)
SKYACTIV-G
2.5T With oil filter replacement
4.8 L (5.1 US qt, 4.2 Imp qt)
Without oil filter replacement 4.6 L (4.9 US qt, 4.0 Imp qt)
SKYACTIV-D
2.2 With oil filter replacement
5.1 L (5.4 US qt, 4.5 Imp qt)
Without oil filter replacement 4.8 L (5.1 US qt, 4.2 Imp qt)
Coolant U.S.A. and
Canada SKYACTIV-G 2.5
7.0 L (7.4 US qt, 6.2 Imp qt)/7.1 L (7.5 US qt, 6 .2
Imp qt)
SKYACTIV-G 2.5T 8.3 L (8.8 US qt, 7.3 Imp qt)
SKYACTIV-D 2.2 8.6 L (9.1 US qt, 7.6 Imp qt)
Mexico SKYACTIV-G 2.5
7.1 L (7.5 US qt, 6.2 Imp qt)
SKYACTIV-G 2.5T 8.2 L (8.7 US qt, 7.2 Imp qt)
Automatic
transaxle
fluid SKYACTIV-G 2.5
7.8 L (8.2 US qt, 6.9 Imp qt)/8.0 L (8.5 US qt, 7.0
Imp qt)
SKYACTIV-G 2.5T, SKYACTIV-D 2.2 8.0 L (8.5 US qt, 7.0 Imp qt)
Transfer case oil 0.45 L (0.48 US qt, 0.40 Imp qt)
Rear differential oil 0.35 L (0.37 US qt, 0.31 Imp qt)
Specifications
Specifications
9-5
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

ItemCapacity
Fuel tank FWD
62.0 L (16.4 US gal, 13.6 Imp gal)
AWD 52.0 L (13.7 US gal, 11.4 Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
▼Dimensions
Item
Vehicle specification
Overall length Without license plate holder
4,865 mm (191.5 in)
With license plate holder 4,895 mm (192.7 in)
Overall width 1,840 mm (72.4 in)
Overall height 1,450 mm (57.1 in)
Front tread 17 inch wheel vehicle
1,585 mm (62.4 in)
19 inch wheel vehicle 1,595 mm (62.8 in)
Rear tread 17 inch wheel vehicle
1,575 mm (62.0 in)
19 inch wheel vehicle 1,585 mm (62.4 in)
Wheelbase 2,830 mm (111.4 in)
▼We i g h t s
U.S.A. and Canada
SKYACTIV-G 2.5
Item
Weight
GVWR (Gross Vehicle Weight Rating) 2,029 kg (4,473 lbs)
GAWR (Gross Axle Weight Rating) Front
1,078 kg (2,377 lbs)
Rear 957 kg (2,110 lbs)
SKYACTIV-G 2.5T
Item Weight
GVWR (Gross Vehicle Weight Rating) 2,065 kg (4,552 lbs)
GAWR (Gross Axle Weight Rating) Front
1,107 kg (2,440 lbs)
Rear 963 kg (2,123 lbs)
SKYACTIV-D 2.2
Item Weight
GVWR (Gross Vehicle Weight Rating) 2,185 kg (4,817 lbs)
GAWR (Gross Axle Weight Rating) Front
1,166 kg (2,571 lbs)
Rear 1,024 kg (2,258 lbs)
Specifications
Specifications
9-6
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

Mexico
SKYACTIV-G 2.5
ItemWeight
GVW (Gross Vehicle Weight) Total
2,032 kg (4,480 lbs)
Front 1,037 kg (2,286 lbs)
Rear 995 kg (2,194 lbs)
GAW (Permissible axle load) Front
1,072 kg (2,363 lbs)
Rear 1,061 kg (2,339 lbs)
SKYACTIV-G 2.5T
Item Weight
GVW (Gross Vehicle Weight) Total
2,118 kg (4,669 lbs)
Front 1,121 kg (2,471 lbs)
Rear 997 kg (2,198 lbs)
GAW (Permissible axle load) Front
1,156 kg (2,549 lbs)
Rear 1,063 kg (2,344 lbs)
▼Light Bulbs
Exterior light
Light bulb Category
Wa t t ag e UN-R*1 (SAE)
Headlights LED
― (―)
Daytime running lights LED
Parking lights LED type
LED
Bulb type 21/5
*2W21/5W (7444)
Front turn signal lightsFront side-marker lightsSide turn signal lightsHigh-mount brake lightRear turn signal lightsRear side-marker lightsBrake lightsTaillightsReverse lightsLicense plate lights LED ― (―)
*1 UN-R stands for Unite
d Nations Regulation.*2 Double-filament light bulb, how ever, only 5 W filament bulb is used in the parking lights.
Specifications
Specifications
9-7
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

Interior light
Light bulbCategory
Wat t a ge UN-R*1
Trunk light Bulb type 3 ―
LED type
LED―
Overhead light (Front)/Map lights Bulb type
8―
LED type LED―
Rear map lights Bulb type
8―
LED type LED―
Vanity mirror lights
*Bulb type 2―
LED type LED―
Courtesy lights LED―
Ambient lights
*LED ―
*1 UN-R stands for United Nations Regulation.
▼Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally
fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label fo
r tire size and inflation pressure.
Refer to Tire Pressure Label on page 9-2.
Refer to Tire Inflation Pressure on page 6-44.
Standard tire
(U.S.A. and Canada)
Tire size Inflation pressure
Front Rear
P225/55R17 95V 250 kPa (36 psi)250 kPa (36 psi)
P225/45R19 92W
*1240 kPa (35 psi) 240 kPa (35 psi)
Specifications
Specifications
9-8*Some models.
Mazda6_8JN3-EA-20H_Edition1_old 2020-6-18 17:31:27

(Mexico)
Tire sizeInflation pressure
Up to 3 persons ―Full load
225/55R17 97V Front
230 kPa (2.3 bar, 33 psi) 250 kPa (2.5 bar, 36 psi)
Rear 230 kPa (2.3 bar, 33 psi) 320 kPa (3.2 bar, 46 psi)
225/45R19 92W
*2Front 230 kPa (2.3 bar, 33 psi) 250 kPa (2.5 bar, 36 psi)
Rear 230 kPa (2.3 bar, 33 psi) 320 kPa (3.2 bar, 46 psi)
1 person's weight: About 75 kg*1P225/45R19 92W
(SKYACTIV-G 2.5, SKYACTIV-G 2.5T)
Before driving at high speeds, in crease the pressure of the front tires. For speeds above 200 km/h (124 mph),
increase the pressure of the fr ont tires by 20 kPa (0.2 bar, 2. 9 psi).
(SKYACTIV-D 2.2)
Before driving at high speeds, in crease the pressure of the front tires. For speeds above 180 km/h (111 mph),
increase the pressure of the fr ont tires by 40 kPa (0.4 bar, 5. 8 psi).
*2225/45R19 92W (SKYACTIV-G 2.5T)
Before driving at high speeds, in crease the pressure of the front tires. For speeds above 210 km/h (130 mph),
increase the pressure of the fr ont tires by 20 kPa (0.2 bar, 2. 9 psi).
Temporary spare tire
(U.S.A. and Canada)
Tire size Inflation pressure
T125/70R17 98M 420 kPa (60 psi)
T135/80D17 103M 420 kPa (60 psi)
(Mexico)
Tire sizeInflation pressure
185/55R16 87M 320 kPa (3.2 bar, 46 psi)
T125/70R17 98M 420 kPa (4.2 bar, 60 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following to rque.
108―147 N·m (12―14 kgf·m, 80―108 ft·lbf)
▼ Fuses
Refer to Fuses on page 6-52.
Specifications
Specifications
9-9
Mazda6_8JN3-EA-20H_Edition1_old
2020-6-18 17:31:27

MEMO
9-10
Mazda6_8JN3-EA-20H_Edition1_old2020-6-18 17:31:27

10Index
10-1
Mazda6_8JN3-EA-20H_Edition1_old2020-6-18 17:31:27

Index
A
Accessory Socket.............................. 5-32
Active driving display....................... 4-64
Active Driving Display..................... 4-64
Adaptive Front Lighting System
(AFS)............................................... 4-122
Add-On Non-Genuine Parts and
Accessories........................................ 8-20
Advanced Key
Advanced keyless entry system... 3-10
Operational range........................ 3-11
Advanced Keyless Entry System...... 3-10
Advanced Smart City Brake Support
(Advanced SCBS)........................... 4-175 Collision warning.... .................. 4-177
Stopping the Advanced Smart City
Brake Support (Advanced SCBS)
system operation........................ 4-177
Air Bag Systems............................... 2-53
Air Bag/Seat Belt Pr etensioner System
Warning Beep.................................... 7-45
Antilock Brake System (ABS)........ 4-111
Armrest Box...................................... 5-37
AUTOHOLD................................... 4-105
AUTOHOLD Warning Beep.............7-47
Automatic Transaxle......................... 4-67 Active Adaptive Shift (AAS)...... 4-69
Automatic transaxle controls....... 4-67
Direct mode................................. 4-76
Driving tips..................................4-77
Manual shift mode.......................4-70
Shift-lock system......................... 4-68
Transaxle ranges.......................... 4-68
B
Battery............................................... 6-39Maintenance.................................6-41
Replacement................................ 6-41
Specifications.................................9-4
Battery Runs Out.............................. 7-15
Jump-starting............................... 7-15
Blind Spot Monitoring (BSM)........ 4-126 Canceling operation of Blind Spot
Monitoring (BSM).....................4-131
Blind Spot Monitoring (BSM) Warning
Beep...................................................7-48
Body Lubrication.............................. 6-34
Bottle Holder..................................... 5-35
Brakes
Brake assist................................ 4-104
Electric parking brake (EPB).....4-101
Foot brake..................................4-100
Pad wear indicator..................... 4-103
Parking brake.............................4-101
Warning light............................. 4-103
Break-In Period................................. 3-44
C
Capacities............................................ 9-5
Cell Phones....................................... 8-21
Center Console.................................. 5-37
Child Restraint Categories of child-restraint
systems.........................................2-36
Child-restraint system
installation................................... 2-36
Child-restraint system suitability for
various seat positions table..........2-38
ISOFIX child-restraint systems
(Mexico)...................................... 2-48
LATCH child-restraint systems
(Except Mexico).......................... 2-48
Child-Restraint Child-restraint precautions.......... 2-31
Installing child-restraint
systems.........................................2-41
Climate Control System...................... 5-2 Fully Automatic Type....................5-5
Operating Tips............................... 5-2
