2021 LEXUS RX350 light

4588-1. Specifications
CrackingAny parting within the tread, sidewall, or innerliner
of the tire extending to cord material
CT
A pneumatic tire with an inverted flange tire and rim
system in which the rim is designed with rim flanges
pointed radially inward and the tire is designed to fit
on the underside of the rim in a manner that
encloses the rim flanges inside the air cavity of the
tire
Extra load tire
A tire designed to operat e at higher loads and at
higher inflation pressures than the corresponding
standard tire
GrooveThe space between two adjacent tread ribs
InnerlinerThe layer(s) forming the in side surface of a tubeless
tire that contains the inflating medium within the tire
Innerliner separationThe parting of the innerliner from cord material in
the carcass
Intended outboard sidewall
(a) The sidewall that contains a whitewall, bears
white lettering, or bear s manufacturer, brand,
and/or model name molding that is higher or
deeper than the same molding on the other sidewall
of the tire, or
(b) The outward facing sidewall of an asymmetrical
tire that has a particular side that must always face
outward when mounted on a vehicle
Light truck (LT) tire
A tire designated by its manufacturer as primarily
intended for use on lightwe ight trucks or multipur-
pose passenger vehicles
Load ratingThe maximum load that a tire is rated to carry for a
given inflation pressure
Maximum load ratingThe load rating for a tire at the maximum permissi-
ble inflation pressure for that tire
Maximum permissible inflation pres-
sureThe maximum cold inflation pressure to which a tire
may be inflated
Measuring rimThe rim on which a tire is fitted for physical dimen-
sion requirements
Open spliceAny parting at any junction of tread, sidewall, or
innerliner that extends to cord material
Tire related termMeaning

4628-2. Customization
■Gauges, meters and multi-information display (P.72, 77, 81)
*1: For details about each function: P.85
Function*1Default settingCustomized setting
LanguageEnglishFrenchOO—Spanish
Units*2miles (MPG)
km (km/L)
OO—km (L/100km)
miles (MPG Impe-
rial)
Drive information 1
Current fuel con-sumption
Customizable items: P.82—O—
Average fuel econ-
omy (after reset)
Drive information 2
Distance (driving range)
Average vehicle
speed (after reset)
Drive information 3
Average fuel econ- omy (after refuel)
Elapsed time (after start)
Clock12-hour display24-hour display—O—
Pop-up displayOnOff—O—
Accent color*3Color 1Color 2OO—
Needle*4Color 1Color 2—O—Color 3
Rev indicator*45000 r/min.
2000 - 6500 r/min.
—O—
Off
Rev peak*4OnOff—O—
Eco Driving Indicator LightOnOff—O—
Suggestion functionOnOff——O
ABC

4688-2. Customization
■Turn signal lever (P.182)
■Automatic light control system ( P.188)
■Lights ( P.188)
*1:Except for Canada
*2: If equipped
■Rain-sensing windshield wipers* ( P.194)
*:If equipped
FunctionDefault settingCustomized setting
The number of times the turn
signal lights flash automatically
when the turn signal lever is
moved to the first position
during a lane change
3
5
——O7
Off
FunctionDefault settingCustomized setting
Light sensor sensitivityStandard-2 to 2O—O
Time elapsed before head-
lights automatically turn off
after doors are closed
30 seconds
Off
O—O60 seconds
90 seconds
FunctionDefault settingCustomized setting
Daytime running lightsOnOff*1O—O
Welcome lightingOnOff——O
AFS (Adaptive Front-lighting
System)
*2OnOff——O
Windshield wiper linked head-
light illuminationOnOff——O
FunctionDefault settingCustomized setting
Wiper operation when the
wiper switch is in the “AUTO”
positionRain-sensing opera-
tion
Intermittent opera-
tion linked to vehicle speed (with interval adjuster)
——O
ABC
ABC
ABC
ABC

4728-2. Customization
■Illumination (P.309)
*:If equipped
FunctionDefault settingCustomized setting
Time elapsed before the inte-
rior lights turn off15 seconds
Off
O—O7.5 seconds
30 seconds
Operation after the engine
switch is turned offOnOff——O
Operation when the doors are
unlockedOnOff——O
Operation when you approach
the vehicle with the electronic
key on your person
OnOff——O
Footwell lights and front center
console lightOnOff——O
Instrument panel ornament
light
* and door trim ornament
lights
*
OnOff——O
Time elapsed before the outer
foot lights turn off15 seconds
Off
O—O7.5 seconds
30 seconds
Operation of the outer foot
lights when you approach the
vehicle with the electronic key
on your person
OnOff——O
Operation of the outer foot
lights when the doors are
unlocked with the power door
lock switch
OnOff——O
Operation of the outer foot
lights when a door is openedOnOff——O
Fading out of the outer foot
lights when they turn offLongShort——O
ABC

475
9
9
For owners
For owners
.9-1. For ownersReporting safety defects for U.S. owners ........................................ 476
Seat belt instructions for Cana- dian owners (in French)....... 476
SRS airbag instructions for Cana- dian owners (in French)....... 478
Headlight aim instructions for Canadian owners (in French)
........................................................ 486

4869-1. For owners
Véhicules sans phares à faisceau
uniqueBoulon de réglage A
Boulon de réglage B
Véhicules avec phares à faisceau
unique
Boulon de réglage A
Boulon de réglage B 1
Vérifiez que le réservoir de carbu-
rant du véhicule est plein et que la
zone autour des phares n'est pas
déformée.
2 Stationnez le véhicule sur une sur-
face plane.
3 Installez-vous dans le siège con-
ducteur.
4 Balancez le véhicule plusieurs fois.
1 À l'aide d'un tournevis cruciforme,
tournez le boulon A dans n'importe
quel sens.
Mémorisez le sens dans lequel vous avez
tourné et le nombre de tours.
Véhicules sans phares à faisceau
unique
Headlight aim instructions
for Canadian owners (in
French)
The following is a French explana-
tion of headlight aim instructions
from the headlight aim section in
this manual.
Boulons de réglage du mouve-
ment vertical
A
B
A
B
Avant de vérifier le réglage des
phares
Réglage du faisceau des phares

491What to do if... (Troubleshooting)
Is the engine switch in IGNITION
ON mode?
If you cannot release the shift lever by
depressing the brake pedal with the engine
switch in IGNITION ON mode ( P.179)
It is locked automatically to prevent
theft of the vehicle. ( P.175)
 Is the window lock switch pressed?
The power window except for the one at
the driver’s seat cannot be operated if the
window lock switch is pressed. ( P.146)
 The auto power off function will be
operated if the vehicle is left in
ACCESSORY or IGNITION ON
mode (the engine is not running) for
a period of time. ( P.177)
 The seat belt reminder light is flash-
ing
Are the driver and the passengers wearing
the seat belts? ( P.406)
 The parking brake indicator is on
Is the parking brake released? ( P.183)
Depending on the situation, other
types of warning buzzer may also
sound. ( P.403, 412)
 Did anyone inside the vehicle open
a door during setting the alarm?
The sensor detects it and the alarm sounds.
( P.68)
Do one of the following to stop the
alarms:
 Unlock the doors.
 Turn the engine switch to ACCES-
SORY or IGNITION ON mode, or
start the engine.
 Is the message displayed on the
multi-information display?
Check the message on the multi-informa-
tion display. ( P.412)
 When a warning light turns on or a
warning message is displayed, refer
to P.403, 412.
The steering wheel cannot be
turned after the engine is
stopped
The windows do not open or
close by operating the power
window switches
The engine switch is turned off
automatically
A warning buzzer sounds during
driving
An alarm is activated and the
horn sounds
A warning buzzer sounds when
leaving the vehicle
A warning light turns on or a
warning message is displayed
When a problem has occurred
If you have a flat tire

493Alphabetical Index
Alphabetical Index
A
A/CAir conditioning filter ............................... 376
Front automatic air conditioning system......................................................................... 292
Front seat concentr ated airflow mode
(S-FLOW)................................................ 300
Micro dust and pollen filter................... 299
Rear automatic air conditioning system .........................................................................303
ABS (Anti-lock Brake System)...............274 Warning light ...............................................405
ACA (Active Cornering Assist) ........... 275
Active Cornering Assist (ACA) ........... 275
Adaptive Front-lighting System (AFS) 190
Adaptive Variable Suspension System275
AFS (Adaptive Front-lighting System) 190
AHB (Automatic High Beam) .................. 191
Air conditioning filter ................................. 376
Air conditioning system Air conditioning filter ............................... 376
Front automatic air conditioning system......................................................................... 292
Front seat concentr ated airflow mode
(S-FLOW)................................................ 300
Micro dust and pollen filter................... 299
Rear automatic air conditioning system .........................................................................303
Airbags Airbag operating conditions................... 33
Airbag precautions for your child ........ 36
Correct driving posture ............................ 25
Curtain shield airbag operating condi- tions .................................................................. 33
Curtain shield airbag precautions ....... 36
Front passenger occupant classification system ............................................................. 39
General airbag precautions ................... 36
Locations of airbags.................................... 30
Modification and disposal of airbags . 38
Side airbag operating conditions ......... 33 Side airbag precautions ............................ 36
Side and curtain shie
ld airbags operating
conditions ...................................................... 33
Side and curtain shield airbags precau- tions .................................................................. 36
SRS airbags......................................................30
SRS warning light...................................... 404
Alarm ................................................................... 68 Warning buzzer ........................................ 403
Anchor brackets ..................................... 46, 57
Antennas (smart acc ess system with
push-button start)........................................ 115
Anti-lock Brake System (ABS)...............274 Warning light .............................................. 405
Approach warning...................................... 233
Armrest............................................................ 330
Assist grips ..................................................... 330
Audio system-linked display ...................... 85
Automatic headlight leveling system ... 189
Automatic High Beam ................................. 191
Automatic light control system............... 188
Automatic transmission ..............................178 M mode ............................................................. 181
Paddle shift switches ........................ 180, 181
Auxiliary boxes ..................................... 317, 319
Average fuel economy................................. 82
Average vehicle speed ................................ 82
AWD Control.................................................. 83
B
Back door ........................................................ 103
Back-up light Wattage ..........................................................449
Back-up lights Replacing light bulbs .....................385, 391
Battery Battery checking ........................................363
If the battery is discharged ....................433
Preparing and checking before winter......................................................................... 280
Warning light .............................................. 404
Blind Spot Monitor (BSM)....................... 236
