2020 TOYOTA PRIUS PRIME seat adjustment

PRIUS PRIME_OM_OM47C77U_(U)
Pictorial indexSearch by illustration
1For safety
and securityMake sure to read through them
2Plug-in hybrid
systemPlug-in hybrid system features, charging method,
etc.
3Instrument
clusterHow to read the gauges and meters, the variety of
warning lights and indicators, etc.
4Operation of
each componentOpening and closing the doors and windows,
adjustment before driving, etc.
5DrivingOperations and advice which are necessary for
driving
6Interior featuresUsage of the interior features, etc.
7Maintenance
and careCaring for your vehicle and maintenance
procedures
8When trouble
arisesWhat to do in case of malfunction or emergency
9Vehicle
specificationsVehicle specifications, customizable features, etc.
10For ownersReporting safety defects for U.S. owners, and seat
belt, SRS airbag and headlight aim instructions for
Canadian owners
IndexSearch by symptom
Search alphabetically

291-1. For safe use
PRIUS PRIME_OM_OM47C77U_(U)
1
For safety and security
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
●Do not adjust the position of the driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle.
● Do not place a cushion between the driver or passenger and the seatback.
A cushion may prevent correct posture from being achieved, and reduce
the effectiveness of the seat belt and head restraint.
● Do not place anything under the front seats.
Objects placed under the front seats may become jammed in the s eat
tracks and stop the seat from locking in place. This may lead t o an acci-
dent and the adjustment mechanism may also be damaged.
● Always observe the legal speed limit when driving on public roads.
● When driving over long distances, take regular breaks before you start to
feel tired.
Also, if you feel tired or sleepy while driving, do not force y ourself to con-
tinue driving and take a break immediately.

299
PRIUS PRIME_OM_OM47C77U_(U)
4-3. Adjusting the seats
4
Operation of each component
Front seats
Manual seat
Seat position adjustment lever
Seatback angle adjustment
lever
Vertical height adjustment lever
(for driver’s side)
Power seat (if equipped for driver’s side)
Seat position ad justment switch
Seat cushion (front) angle
adjustment switch
Vertical height adjustment
switch
Seatback angle adjustment
switch
Lumbar support adjustment
switch
Adjustment procedure
1
2
3
1
2
3
4
5

300
PRIUS PRIME_OM_OM47C77U_(U)
4-3. Adjusting the seats
■When adjusting the seat
Take care when adjusting the seat so that the head restraint does not touch
the ceiling.
WARNING
■When adjusting the seat position
● Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.
● Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.
■ Seat adjustment
● To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury i n the event of
an accident.
Adjustments should not be made while driving as the seat may un expect-
edly move and cause the driver to lose control of the vehicle.
● Manual seats: After adjusting the seat, make sure that the seat is locked in
position.

641
PRIUS PRIME_OM_OM47C77U_(U)
7-3. Do-it-yourself maintenance
7
Maintenance and care
Headlight aim
Adjustment bolt A
Adjustment bolt B
Make sure the vehicle has a full tank of gasoline and the area
around the headlight is not deformed.
Park the vehicle on level ground.
Sit in the driver’s seat.
Bounce the vehicle several times.
Vertical movement adjusting bolts
1
2
Before checking the headlight aim
1
2
3
4

780Alphabetical index
PRIUS PRIME_OM_OM47C77U_(U)
Front seats ............................... 299Adjustment ............................ 299
Cleaning................................ 569
Correct driving posture ........... 28
Head restraints ..................... 303
Seat heaters ......................... 526
Front side marker lights.......... 350 Light switch ........................... 350
Replacing light bulbs............. 648
Front turn signal lights ........... 348 Replacing light bulbs............. 648
Turn signal lever ................... 348
Fuel ........................................... 368 Capacity ................................ 720
Fuel gauge ............................ 209
Information ............................ 727
Refueling............................... 368
Type ...................................... 720
Warning light ......................... 664
Fuel consumption.... 231, 263, 269
Average fuel consumption .... 231
Current fuel consumption...... 269
Fuel filler door.......................... 368
Opener .................................. 370
Refueling............................... 368
When the fuel filler door cannot be opened............... 371
Fuses ........................................ 638
Garage door opener ................ 555
Glove box ................................. 532 Hands-free system (for
cellular phone)
*
Head restraints ........................ 303
Head-up display....................... 251
Headlights ................................ 350
Automatic High Beam ........... 355
Headlight aim................ 641, 766
Light switch ........................... 350
Replacing light bulbs ............ 648
Heated steering wheel ............ 526
Heaters Automatic air conditioning system.... 500, 511
Heated steering wheel .......... 526
Hybrid battery (traction
battery) ............................... 135
Outside rear view
mirrors ........................ 504, 515
Seat heaters ......................... 526
High coolant temperature
warning light.......................... 664
High mounted stoplight Replacing.............................. 648
High-voltage components ........ 98
Hill-start assist control ........... 490
Hood ......................................... 585
Hooks Coat hooks ........................... 553
Grocery bag hook ................. 537
Retaining hooks (floor mat) .... 26
Horn .......................................... 306
HV mode ..................................... 87
G
H

786Alphabetical index
PRIUS PRIME_OM_OM47C77U_(U)
Seating capacity ...................... 333
Seats ................................. 299, 301Adjustment ............................ 299
Adjustment precautions ........ 300
Armrest ................................. 553
Child seats/child restraint
system installation . ............... 60
Cleaning................................ 569
Front seats ............................ 299
Head restraint ....................... 303
Properly sitting in the seat ...... 28
Rear seats ............................ 301
Seat back pocket .................. 535
Seat heaters ......................... 526
Sensor
Automatic headlight system ......... ....................... 353
Automatic High Beam ........... 355
BSM (Blind Spot Monitor) ..... 424
Camera sensor ..................... 375
Door handle .......................... 279
Humidity sensor ............ 510, 521
Inside rear view mirror .......... 309
Intuitive parking assist .......... 433
LDA (Lane Departure Alert
with steering control) .......... 393
Parking Support Brake function ............................... 444
Radar sensor ........................ 375
Rain-sensing windshield wipers ................................. 366
RCTA (Rear Cross Traffic Alert function) ..................... 424
S-APGS (Simple Advanced
Parking Guidance
System) .............................. 484
Service plug ............................... 98
Service reminder indicators ... 201
Shift lever ................................. 342
Shift lever light......................... 528
Side airbags ............................... 36
Side doors ................................ 279 Side marker lights ................... 350
Light switch ........................... 350
Replacing light bulbs ............ 648
Side mirrors ............................. 310 Adjustment............................ 310
BSM (Blind Spot Monitor) ..... 421
Folding .................................. 310
Outside rear view mirror
defoggers ................... 504, 515
Side windows........................... 312 Water-repellent coating ........ 565
Simple Advanced Parking Guidance System
(S-APGS) ................................ 455
Smart key system .................... 290 Antenna location ................... 290
Entry functions ...................... 279
Starting the hybrid system .... 336
Smart lid & connector locking system ...................... 121
Snow tires ................................ 495
“SOS” button ............................. 76
Spark plug ................................ 723
Specifications .......................... 718
Speedometer............................ 209
SRS airbags ............................... 36
Steering wheel ......................... 306 Adjustment............................ 306
Audio switches
*
Heated steering wheel .......... 526
Meter control switches .......... 193
Talk switch
*
Telephone switches*
TRIP switch .......................... 211
Stop lights Replacing light bulbs ............ 648
Storage feature ........................ 531
Storage precautions................ 531
Stuck If the vehicle becomes stuck ................................... 714
Sun visors ................................ 540
