2020 TOYOTA PRIUS PRIME display

7128-2. Steps to take in an emergency
PRIUS PRIME_OM_OM47C77U_(U)
After stopping the hybrid system and waiting for 5 minutes or
more, start the hybrid system again and check if “Hybrid System
Overheated” is shown on the multi-information display.
If the message d oes not disappear:
Stop the hybrid system and contact your Toyota dealer.
If the message is not displayed:
The hybrid system temperature has dropped and the vehicle may
be driven normally.
However, if the message appears again frequently, contact your Toyota
dealer.
WARNING
■ To prevent an accident or injury when inspecting under the hood of
your vehicle
Observe the following precautions.
Failure to do so may result in serious injury such as burns.
● If steam is seen coming from under the hood, do not open the ho od until
the steam has subsided. The engine compartment may be very hot.
● After the hybrid system has been turned off, check that the “Ac cessory”,
“Ignition ON” or mileage display ( P. 210) on the main display and the
“READY” indicator are off.
When the hybrid system is operating, the gasoline engine may au tomati-
cally start, or the cooling fans may suddenly operate even if the gasoline
engine stops. Do not touch or approach rotating parts such as the fan,
which may lead to fingers or clothing (especially a tie, a scarf or a muffler)
getting caught, resulting in serious injury.
● Do not loosen the coolant reservoir caps while the hybrid syste m and radi-
ator are hot.
High temperature steam or coolant could spray out.
6

741
PRIUS PRIME_OM_OM47C77U_(U)
9-2. Customization
9
Vehicle specifications
Customizable features
When customizing vehicle features, ensure that the vehicle is parked
in a safe place with the parking brake set and the shift position in P.
■Changing using the multi-information display
Press or of the meter control switches, select .
Press or of the meter control switches, select
(“Vehicle Settings”), and then press .
Press or of the meter control switches, select the item,
and then press .
Press or of the meter contro l switches, select the desired
setting, and then press .
To go back to the previous screen or exit the customize mode,
press .
Your vehicle includes a variety of electronic features that can be
personalized to suit your preferences. The settings of these fe a-
tures can be changed using the multi-information display, the
navigation system, the multimed ia system, or at your Toyota
dealer.
Some function settings are changed simultaneously with other func-
tions being customized. Contact your Toyota dealer for further
details.
Customizing vehicle features
1
2
3
4

PRIUS PRIME_OM_OM47C77U_(U)
7439-2. Customization
9
Vehicle specifications
Settings that can be changed using the multi-information display
Settings that can be changed usin g the navigation system or the
multimedia system
Settings that can be chan ged by your Toyota dealer
Definition of symbols: O = A vailable, – = Not available
■Hybrid system (P. 9 3 )
■Instrument cluster ( P. 192)
Customizable features
1
2
3
FunctionDefault
settingCustomized setting
Vehicle proximity notification
system (volume of sound)Level 1Level 2––OLevel 3
123
FunctionDefault settingCustomized setting
Sensor sensitivity for darken-
ing the brightness of the
instrument cluster depending
on the outside brightness
Standard-2 to 2––O
Sensor sensitivity for returning
the brightness of the instru-
ment cluster to the original
level depending on the outside
brightness
Standard-2 to 2––O
123

744
PRIUS PRIME_OM_OM47C77U_(U)
9-2. Customization
■HUD (Head-up display)* ( P. 2 5 1 )
*: If equipped
■
Door lock ( P. 279, 699)
■Smart key system and wireless remote control ( P. 280, 290)
FunctionDefault
settingCustomized setting
Route guidance*OnOffO––
123
FunctionDefault settingCustomized setting
Automatic door lockingShift position linkedSpeed linked–OOOff
Automatic door unlockingShift position linkedDriver’s door linked
–OO
Off
Unlocking using a mechanical
key
Driver’s door unlocked in
first step, all
doors
unlocked in
second step
All doors
unlocked in first step
––O
123
FunctionDefault settingCustomized setting
Operation signal (buzzer) 5Off
–OO
1 to 7
Operation signal (emergency
flashers) On
Off – O O
Time elapsed before the auto-
matic door lock function is
activated if a door is not
opened after being unlocked
60 seconds
Off
–OO30 seconds
120 seconds
Open door reminder buzzer
(when locking the vehicle)OnOff––O
123

750
PRIUS PRIME_OM_OM47C77U_(U)
9-2. Customization
■Seat belt reminder (P. 667)
■Vehicle customization
●When the Speed linked door locking function and the Shift posit ion linked
door locking function are both on, the door lock operates as follows.
• When shifting the shift position to any position other than P, all the doors
will be locked.
• If the vehicle is started with all the doors locked, the Speed linked door locking function would not operate.
• If the vehicle is started with any door unlocked, the Speed li nked door
locking function will operate.
● When the smart key system is off, Smart door unlocking cannot be custom-
ized.
● When the doors remain closed after unlocking the doors and the automatic
door lock function is activated, the signals will be generated in accordance
with the operation signal (buzzer) and the operation signal (emergency
flashers) settings.
■ In the following situations, customize mode in which the settings can be
changed through the multi-information display will automatically be
turned off.
●The power switch is turned off.
● The vehicle begins to move while the customize mode screen is displayed.
FunctionDefault
settingCustomized setting
Vehicle speed linked seat belt
reminder buzzerOnOff––O
WARNING
■Cautions during customization
As the hybrid system needs to be operating during customization , ensure
that the vehicle is parked in a place with adequate ventilation. In a closed
area such as a garage, exhaust gases including harmful carbon monoxide
(CO) may collect and enter the vehicle. This may lead to death or a serious
health hazard.
NOTICE
■ During customization
To prevent 12-volt battery discharge, ensure that the hybrid sy stem is oper-
ating while customizing features.
123

772What to do if... (Troubleshooting)
PRIUS PRIME_OM_OM47C77U_(U)
●The seat belt reminder light is flashing
Are the driver and all the passengers wearing the seat belts? (P. 667)
●The parking brake indicator is on
Is the parking brake released? (P. 349)
Depending on the situation, other types of warning buzzer may a lso sound.
( P. 662, 672)
●Is the electronic key left inside the vehicle?
Check the message on the multi-information display. ( P. 672)
●When a warning light turns on or a warning message is displayed , refer to
P. 662, 672.
A warning buzzer sounds during driving
A warning buzzer sounds w hen leaving the vehicle
A warning light turns on or a warning message is displayed

776Alphabetical index
PRIUS PRIME_OM_OM47C77U_(U)
Cargo capacity ......................... 333
Catch protection function ....... 313
CD player
*
Chains....................................... 496
Charging ................................... 110Charging cable...................... 115
Charging equipment ............. 110
Charging indicator................. 114
Charging messages .............. 185
Charging precautions............ 153
Charging procedure .............. 146
Charging time may increase .............................. 135
Charging timer function......... 157
High voltage components ....... 98
Information related to charging display ................. 140
Opening and closing the charging port lid .................. 111
Power sources
precautions ......................... 133
Power sources that can be used.................................... 131
Safety functions ............ 142, 151
When normal charging cannot be carried out.......... 180
Charging cable......................... 115
CCID (Charging Circuit Interrupting Device) ............ 115
If the charging cable
cannot be unlocked ............ 128
Indicator................................. 117
Maintenance ......................... 120
Safety functions .................... 116
Charging port ........................... 110 Opening and closing ............. 111
Smart lid & connector
locking system ..... ............... 121
If the charging port lid does
not open ............................. 124 Child restraint system............... 58
Fixed with a LATCH
system .......... ..................... ... 70
Fixed with a seat belt .............. 64
Front passenger occupant classification syst em ............ 50
Points to remember ................ 58
Riding with children ................ 57
Types of child restraint system installation method ............... 60
Using an anchor bracket......... 73
Child safety ................................ 57 12-volt battery precautions ... 596
Airbag precautions.................. 40
Back door precautions .......... 287
Charging precautions ........... 141
Child restraint system ............. 58
How your child should wear the seat belt.......................... 32
Installing child restraints ......... 60
Power window lock switch .... 312
Power window precautions ... 314
Rear door child-protectors .... 282
Removed key battery
precautions......................... 637
Riding with children ................ 57
Seat belt extender precautions........................... 34
Seat belt precautions .............. 69
Seat heater precautions ....... 526
Child-protectors ...................... 282
Cleaning ........................... 564, 569 Aluminum wheels ................. 565
Camera sensor ..................... 377
Exterior ................................. 564
Hybrid battery (traction
battery) air intake vent........ 570
Interior .................................. 569
Radar sensor ........................ 376
Seat belts.............................. 572
Water-repellent coating ........ 565

777Alphabetical index
PRIUS PRIME_OM_OM47C77U_(U)
Clock ......................................... 192Adjustment ............................ 197
Coat hooks ............................... 553
Combination meter .................. 192 Clock adjustment .................. 197
Main display .......................... 209
Multi-information display ....... 218
Warning lights and
indicators ............................ 201
Condenser ................................ 594
Console box ............................. 532
Consumption screen ....... 263, 269
Coolant ..................................... 592 Capacity ................................ 723
Checking ............................... 592
Preparing and checking before winter....................... 495
Cooling system ........................ 592 Engine overheating ............... 709
Hybrid system overheating ... 711
Cruise control Dynamic radar cruise control with full-speed range .......... 403
Cup holders.............................. 533
Curtain shield airbags ............... 36
Customizable features ............ 741
Daytime running light system .................................... 353
Deck board ............................... 536
Defogger Outside rear view
mirrors ........................ 504, 515
Rear window ................. 504, 515
Windshield .................... 504, 514 Dimension ................................ 718
Dinghy towing.......................... 335
Display
BSM (Blind Spot Monitor) ..... 421
Drive information .................. 220
Dynamic radar cruise control with full-speed range .......... 403
Energy monitor ..... 221, 260, 266
Head-up display.................... 251
Intuitive parking assist .......... 434
LDA (Lane Departure Alert
with steering control) .......... 397
Main display.......................... 209
Multi-information display ....... 218
Parking Support Brake function............................... 448
Pre-collision warning ............ 381
S-APGS (Simple Advanced
Parking Guidance
System) .............................. 459
Warning messages ............... 672
Do-it-yourself maintenance .... 582
Door courtesy lights ............... 528 Location ................................ 528
Wattage ................................ 726
Doors ................................ 279, 285 Automatic door locking
and unlocking system......... 282
Back door ............................. 285
Door glasses......................... 312
Door lock .............................. 279
Open door warning buzzer ... 283
Open door warning light ....... 664
Outside rear view mirrors ..... 310
Rear door child-protectors .... 282
Side doors ............................ 279
Side windows........................ 312
D
*: Refer to “MULTIMEDIA OWNER’S MANUAL”.
