2020 TESLA MODEL S Owner's Manual

Fluid Reservoirs
Removing the Maintenance Panel
To check

Checking Brake FluidWarning: Contact Tesla immediately if you
notice increased movement of the brake
pedal or a significant loss of brake

Topping Up Windshield Washer
Fluid
The only reservoir into which you can add

Jacking and Lifting
Jacking Procedure
Follow the steps below to lift Model S. Ensure
that any non-Tesla repair facility is aware of
these lifting points.
1. Position Model S centrally between the lift
posts.
2. If your Model S is equipped with air
suspension, it automatically self-levels,
even when power is off. Use the
touchscreen to set the suspension as
follows:

Parts and Accessories
Parts, Accessories, and
Modifications
Use only genuine Tesla parts and accessories.
Tesla performs rigorous testing on parts to
ensure their suitability, safety, and reliability.
Purchase these parts from Tesla, where they
are professionally installed and where you can receive expert advice about modifications to
Model S. Accessories are available for
purchase from Tesla stores or online at
www.tesla.com .
Note: Some accessories may not be available
in your market region.
Tesla is unable to assess parts manufactured
by other distributors and therefore accepts no responsibility if you use non-Tesla parts onModel S.
Warning: Installing non-approved parts
and accessories, or performing non- approved modifications, can affect the
performance of Model S and the safety of
its occupants. Any damage caused by
using or installing non-approved parts, or by performing non-approved
modifications, is not covered by the
warranty.Warning: Tesla does not accept liability
for death, personal injury or damage that
occurs if you use or install non-approved
accessories or make non-approved
modifications.Body Repairs
If your Model S is in a collision, contact Tesla
or a Tesla-approved Body Shop to ensure that
it is repaired with genuine Tesla parts. Tesla
has selected and approved body shops that
meet strict requirements for training,
equipment, quality, and customer satisfaction.
Some repair shops and insurance companies
might suggest using non-original equipment
or salvaged parts to save money. However,
these parts do not meet Tesla

Specifications
Identification
Labels
Vehicle Identification Number
You can find the VIN at the following
locations:

Vehicle Loading
Load Capacity Labeling It is important to understand how much
weight your Model S can safely carry. This weight is called the vehicle capacity weight
and includes the weight of all occupants,
cargo and any additional equipment added to your Model S since it was manufactured.
Two labels attached to the center door pillar
indicate how much weight Model S can safely
carry. Labels are visible when the front door is
open.
1. Tire and Loading Information Label
2. Vehicle Certification Label
Warning: Overloading Model S has an
adverse effect on braking and handling,
which can compromise your safety or
cause damage.Caution: Never load more than 300 lbs
(136 kg) in the front trunk. Doing so can
cause damage.Caution: Never load more than 175 lbs (80
kg) on the rear load

Calculating Load Limits
1. Locate the statement “The combined
weight of occupants and cargo should never exceed XXX lbs or XXX kg” on the
“Tire and Loading Information” label.
2. Determine the combined weight of all
occupants that will ride in the vehicle.
3. Subtract the combined weight of the
occupants from XXX lbs or XXX kg (see
Step 1).
4. The resulting figure equals the available
cargo load capacity. For example, if the
“XXX” amount equals 1400 lbs (635 kg)
and there will be five 150 lb (68 kg)
passengers in the vehicle, the amount of
available cargo capacity is 650 lbs
(1400 ) 750 (5 x 150) = 650 lbs) or 295 kg
(635 ) 340 (5 x 68) = 295 kg).
5. Determine the combined cargo weight
being loaded on the vehicle. That weight
must not exceed the available cargo load
capacity calculated in Step 4.Warning: Trunks are the preferred places
to carry objects. In a collision, or during
hard braking and sharp turns, loose items in the cabin could injure occupants.
Example Load Limit Calculations
How much cargo Model S can carry depends
on the number and weight of passengers. The
following calculated load limit examples
assume passengers weigh 150 lbs (68 kg). If
passengers weigh more or less, available cargo weight decreases or increases
respectively.
Driver and one passenger
DescriptionTotalVehicle capacity weight954 lbs
(433 kg)Subtract occupant weight
(2 x 150 lbs/68 kg)300 lbs
(136 kg)Available cargo weight654 lbs
(297 kg)
Driver and four passengers
DescriptionTotalVehicle capacity weight954 lbs
(433 kg)DescriptionTotalSubtract occupant weight (5 x
150 lbs/68 kg)750 lbs
(340 kg)Available cargo weight204 lbs
(93 kg)
The cargo weight should be distributed
between the front and rear trunks.
Caution: Do not exceed the maximum
front trunk load weight of 300 lbs
(136 kg).Caution: Never load more than 175 lbs (80
kg) on the rear load
