Anti-puncture kit contents* Fig. 39
Standard representation: anti-punc-
t ur
e kit contents. The anti-puncture kit is located underneath
the fl
oor co
vering in the luggage compart-
ment. It includes the following components
››› Fig. 39:
Valve insert remover
A sticker to be adhered to the instrument
cluster, within the driver's visual field, to
remind that the maximum advisable
speed “max. 80 km/h” or “max. 50 mph”
Filler tube with cap
Air compressor (depending on the ver-
sion, the model may vary).
ON/OFF switch
1 2
3
4
5 Air bleed screw (it can also be integrated
in the infl
at
or tube).
Warning provided by tyre pressure moni-
toring system (it can also be integrated in
the inflator tube).
Tube for inflating tyres
12 volt connector
Bottle of sealant
Spare tyre valve
The valve insert remover 1 has a gap at
the l o
wer end for a valve insert. The valve in-
sert can only be screwed or unscrewed in this
way. This also applies to its replacement part 11 .
Sealing and inflating a tyre Sealing the tyre
Page 50 of 399
Emergencies
and request assistance from an authorised
t echnician.
Page 51 of 399
Self-help
Integral wheel trim Fig. 40
Remove the wheel cover. The wheel covers must be removed for ac-
cess t
o the wheel nuts.
R
emoving
Page 52 of 399
Emergencies
Loosening wheel nuts Fig. 43
Wheel change: loosen the wheel nuts. Fig. 44
Wheel change: tyre valve 1 and the
corr ect position f
or the anti-theft wheel locking
bolt 2 or
3 .
Use only the wheel wrench belonging to the
car t
o l
oosen the wheel nuts.
Loosen the wheel nuts only about one turn
before raising the vehicle with the jack. If the wheel bolt is very tight, carefully push
on the end of the wheel wrench with your
f
oot. Hold on to the vehicle for support and
take care not to slip during this operation.
Loosening wheel nuts
Page 53 of 399
Self-help
Raise the vehicle Fig. 45
Jack position points. Fig. 46
Cross member: positioning the jack on
the v ehicl
e.
Page 54 of 399
Emergencies
Taking off the wheel
Page 55 of 399
Self-help
Changing the windscreen
wiper bl ades
Wiper service position Fig. 47
Wipers in service position. Ensure that the wiper blades are not frozen.
The wiper arms can be r
aised when the wip-
ers ar
e in service position ››› Fig. 47
.
