2020 OPEL ASTRA K Manual user

In brief7Seat adjustmentLongitudinal adjustment
Pull handle, slide seat, release
handle. Try to move the seat back and forth to ensure that the seat is locked
in place.
Seat position 3 49.
Manual seat adjustment 3 50.
Power seat adjustment 3 52.
Backrests inclination
Turn handwheel. Do not lean on
backrest when adjusting.
Seat position 3 49.
Manual seat adjustment 3 50.
Power seat adjustment 3 52.
Seat height
Lever pumping motion
up:seat higherdown:seat lower
Seat position 3 49.
Manual seat adjustment 3 50.
Power seat adjustment 3 52.

8In briefSeat inclination
Press switch
top:front end higherbottom:front end lower
Seat position 3 49.
Manual seat adjustment 3 50.
Power seat adjustment 3 52.
Head restraint adjustment
Press release button, adjust height,
engage.
Head restraints 3 48.
Seat belt
Pull out the seat belt and fasten in belt
buckle. The seat belt must not be
twisted and must fit close against the
body. The backrest must not be tilted back too far (maximum approx. 25°).
To unfasten belt, press red button on belt buckle.
Seat position 3 49.
Seat belts 3 58.
Airbag system 3 60.

In brief9Mirror adjustment
Interior mirror
To adjust the mirror, move the mirror
housing in the desired direction.
Manual anti-dazzle interior mirror
3 42.
Automatic anti-dazzle interior mirror 3 42.
Exterior mirrors
Select the relevant exterior mirror by
switching the rocker control to left
mirror (L) or right mirror (R). Adjust
respective mirror by the four-way control.
Convex exterior mirrors 3 40.
Electric adjustment 3 40.
Folding exterior mirrors 3 41.
Heated exterior mirrors 3 41.
Steering wheel adjustment
Unlock the lever, adjust the steering
wheel, then engage the lever and
ensure it is fully locked.
Do not adjust the steering wheel
unless the vehicle is stationary and the steering wheel lock has been
released.
Airbag system 3 60.
Ignition positions 3 152.

10In briefInstrument panel overview

In brief111Power windows .....................43
2 Exterior mirrors .....................40
3 Central locking system ..........25
4 Side air vents ...................... 149
5 Cruise control .....................176
Speed limiter ....................... 177
Adaptive cruise control .......179
Forward collision alert .........187
6 Turn lights, headlight
flash, low / high beam,
high beam assist .................136
Exit lighting ......................... 139
Parking lights ...................... 137
Buttons for Driver
Information Centre ..............115
7 Instruments ........................ 104
Driver Information Centre .... 115
8 Buttons for Driver
Information Centre ..............115
9 Windscreen wiper and
washer, rear wiper and
washer ................................. 94
10 Centre air vents ................... 14911Info Display ......................... 121
12 Anti-theft alarm system
status LED ........................... 37
13 Hazard warning flashers ....135
14 Glovebox .............................. 73
15 Controls for Info Display
operation ............................. 121
16 Climate control system ........ 141
17 Fuse box ............................ 244
18 Traction Control system .....173
Electronic Stability Control . 174
Parking assist / Advanced
parking assist .....................195
Lane keep assist ................210
Eco button for stop-start
system ................................. 157
19 Manual transmission ..........169
Automatic transmission ......166
20 Power outlet .......................... 99
21 Parking brake ......................171
22 Power button ....................... 153
23 Ignition switch .....................152
24 Steering wheel adjustment ..93
25 Horn ..................................... 9426Bonnet release lever ..........224
27 Storage compartment ...........74
28 Light switch ........................ 130
Headlight range
adjustment ......................... 133
Front / rear fog lights ..........136
Instrument illumination .......137

12In brief

In brief13Exterior lightingAUTO:automatic light control
switches automatically
between daytime running
light and headlight8:sidelights9:headlights
Automatic light control 3 131.
Front fog lights 3 136.
Rear fog light 3 136.
Headlight flash, high beam and
low beamheadlight flash:pull leverhigh beam:push leverlow beam:push or pull lever
High beam 3 133.
Headlight flash 3 133.
LED headlights 3 134.
High beam assist 3 134.
Turn lightslever up:right turn lightslever down:left turn lights
Turn lights 3 136.
Parking lights 3 137.

14In briefHazard warning flashers
Operated by pressing ¨.
Hazard warning flashers 3 135.
Horn
Press j.
Washer and wiper systems
Windscreen wiperHI:fastLO:slowINT:interval wiping
or
automatic wiping with rain
sensorOFF:off
For single wipe when the wiper is off,
press lever down to position 1x.
Windscreen wiper 3 94.
