2-20
Instrument sand controls
Stop/Start SystemorIdling StopSystem
reminder buzzer(ifequipped)
GUID-69B3 6B73-5D2B-4 FF6-93AE-B76 254D6E0C7
The engine willshift tothe normal stopped stateifany
of the following operations ismade during Stop/Start
System orIdling StopSystem activation, andtheStop/
Start System orIdling StopSystem buzzerwillsound
if:
. The driver's seatbeltisunfastened andthe
driver's doorisopen (MTmodels) .
. The vehicle enginehoodisopen.
Close thehood orthe driver's door,orfasten theseat
belt then restart theengine usingtheignition switch.
For more information, seeªStop/Start SystemorIdling
Stop Systemº (P.5-18) .
T32A1308 27-3610D9 C5-CE18-4 747-932A-3E 708FB2DA5B
JVI0641X
The vehicle information display
*
1
is located between
the tachometer andthespeedometer. Itdisplays such
items as:
. Vehicle settings
. Trip computer information
. Driver Assistance (ifequipped)
. Speed limiterinformation (ifequipped)
. Cruise control system information (ifequipped)
. Intelligent Key operation information (ifequipped)
. Audio information (ifequipped)
. Navigation -turn byturn (ifequipped)
. Indicators andwarnings
. Tyre pressure information (ifequipped)
. Chassis Control
. Other information
Please notethattheinformation usedinthis manual is
written inUK English. Thereareafew differences in
the information forthe UKand U.S. English versions of
the system.
For language settings,seeªLanguageº (P.2-26) .
HOW TO USE THEVEHICLE INFORMA-
TION DISPLA Y
GUID-70 381C67-CDD B-4575-A232-0CA687BCF4A0
T ype A:
JVI0887X
The vehicle information displaycanbechanged using
the switches
and ENTER
*
1
located onthe
steering wheel.
*
1
- navigate throughtheitems invehicle
information display
- select/enter theVehicle information menu
items ortochange fromonedisplay screento
the next (i.e.trip, Fuel economy)
ENTER -change orselect anitem inthe vehicle
information display
*
2
- go back tothe previous menu
VEHICLE INFORMA TIONDISPLA Y
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
22. Battery Voltage LowCharge Battery
warning
GUID-1F3B1 DD2-74A2-40F0-99DD -0C12928BF4BE
This warning appears whenthebattery voltage islow
and thebattery needstobe charged.
23. Shipping ModeOnPush Storage Fuse
warning
GUID-EF187 6C4-3B83-41A8-8C73-D10D23C4 3B8F
This warning mayappear ifthe extended storagefuse
switch isnot pushed in(switched on).When this
warning appears, pushin(switch on)theextended
storage fuseswitch toturn offthe warning. Formore
information, seeªExtended storagefuseswitchº (P.8-
26) .
24. Headlight systemfaultwarning (if
equipped)
GUID-CB55 8F6A-E537-4F05-9A4F-E8 9B7379F99C
This warning appears ifthe LED headlights are
malfunctioning. Havethesystem checked bya
NISSAN dealer.
25. Power willturn offtosave thebattery
warning
GUID-3C3 13D28-5CF D-467B-9FC2 -AD5A25FA3340
This warning appears afteraperiod oftime ifthe shift
lever hasnotmoved fromtheªPº (Park) position while
the ignition isin the ON position foracertain periodof
time.
26. Power turned offtosave thebattery
warning
GUID-097 0ABC5-CB 0F-4B5F-A53 3-E364CA5A37F0
This warning appears aftertheignition switchis
automatically turnedOFFtosave thebattery .
27. Turn offheadlights warning
GUID-DB 00B5D9-C8 87-4399-9B3 9-3A515068CC94
This warning appears whenthedriver sidedoor is
opened withtheheadlight switchisleft ON and the
ignition switchisplaced inthe ªOFFº orªLOCKº
position. Placetheheadlight switchinªOFFº or
ª AUT Oº(ifequipped) position.Foradditional informa-
tion, seeªHeadlight andturn signal switchº (P.2-39) .
28. Press brakepedalwarning (forelectronic
parking brakeequipped models)
GUID-3E24 20B9-A238 -4616-97EB -11057AE20 0E0
This indicator appearsinthe following situations:
. The driver triestorelease theelectronic parking
brake manually withoutdepressing thebrake
pedal.
. Thevehicle isstopped onasteep hilland there is
a possibility ofmoving backward, evenifthe
electronic parkingbrakeisapplied.
29-30. Timeforadriver break? indicator
GUID-5B 6EF421-7 42A-4370-B6 98-64A84139A090
This indicator appearswhenthesetªTime foradriver
break?º indicator activates. You can setthe time forup
to 6hours.
31. Low outside temperature warning(if
equipped)
GUID-634E FF16-8C9D-4 93C-A41A-0932E824F6C 2
This warning appears ifthe outside temperature is
below 38C(378F) .The warning canbeset not tobe
displayed.
32. Chassis controlsystem faultwarning
GUID-F718EB 94-63B5-48EE-A64D-71 D88651FC6D
This warning appears ifthe chassis controlmodule
detects anerror inthe chassis controlsystem. Have
the system checked byaNISSAN dealer.(See
ªChassis controlº(P.5-28) .)
33. Speed limiterindicator (ifequipped)
GUID-E39 2035D-EAB2 -4999-AC5F-53B566DC 53DF
This indicator showsthespeed limitersystem status.
The status isshown bythe color.
For more details, seeªSpeed limiterº(P.5-41) .
34. Cruise indicator (ifequipped)
GUID-B56BF2 89-E01D-4B32-9422-29430209390 4
This indicator showsthecruise control system status.
The status isshown bythe color.
See ªCruise controlº (P.5-43) fordetails.
35. Continuously Variable Transmission (CVT)
position indicator (Continuously Variable
T ransmission (CVT)models)
GUID-9E3 23961-6ABA- 4FB7-B081-E0ED83362DE3
This indicator showstheautomatic shiftposition.
In the manual shiftmode, whenthetransmission does
not shift tothe selected gearduetoatransmission
protection mode,theCVT position indicator willblink
and achime willsound.
See ªDriving withContinuously Variable Transmission
(CVT)º (P.5-13) forfurther details.
36. ECO mode system indicator (ifequipped)
GUID-B9 E98019-342F -40AE-9C95-C4EB5F3AEDA6
The ECO mode indicator appearswhentheECO
mode system isturned on.
(See ªECO modesystemº (P.5-47) .
37. System faultwarning (ifequipped)
GUID-18 8904A7-896 7-4328-9B5E-8F5DDC 264F2B
This warning appears whentheBlind SpotWarning/
Lane Departure Warning systems arenot functioning
properly .(See ªBlind SpotWarning (BSW)/Lane
Departure Warning (LDW) systemsº (P.5-31) ,ªBlind
Spot Warning (BSW) system(ifequipped forEurope)
º (P .5-36) orªLane Departure Warning (LDW) system
(if equipped forEurope)º (P.5-39) .)
Instrume ntsand controls
2-31
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
Blind SpotWarning (BSW) system(ifequipped forEurope) ....
.... 5-36
BSW system operation ....
................................................. ...............5-36
BSW driving situations ....
...................................................... ...........5-38
BSW temporary disabledstatus....
................................................ 5-39
BSW automatic deactivation ....
....................................... ...............5-39
BSW malfunction ....
................................................................ ...........5-39
Camera unitmaintenance ....
................................................. ...........5-39
Lane Departure Warning (LDW) system (ifequipped
for Europe) ....
............................................ ................................................. 5-39
LDW system operation ....
...................................................... ...........5-40
T emporary disabledstatusathigh temperature ....
..................... 5-41
Multi-sensing cameraunitmaintenance ....
................................... 5-41
Speed limiter(ifequipped) ....
................................................. ...............5-41
Speed limiteroperations ....
.............................................................. 5-41
Cruise control (ifequipped) ....
.............................................................. 5-43
Precautions oncruise control ....
..................................................... 5-43
Cruise control operations ....
................................................. ...........5-44
Forward emergency brakingsystem(ifequipped) ....
...................... 5-45
System operation ....
................................................................ ...........5-45
ECO mode system (ifequipped) ....
..................................................... 5-47
ECO Pedal Guide function ....
......................................................... 5-47
Ambient ECO....
...................................................... ............................5-47
ECO Drive Report ....
................................................. ........................5-48
Parking ....
....................................... .............................................................. 5-48
Parking sensor(sonar) system(ifequipped) ....
................................ 5-50
Parking sensor(sonar) systemOFFswitch (ifequipped) ....
.... 5-51
Parking sensor(sonar) systemsetting ....
..................................... 5-52T
railer towing (except forAustralia, NewZealand, SouthAfrica
and Europe) ....
................................................. .........................................5-52
T railer towing (forAustralia, NewZealand, SouthAfrica
and Europe) ....
................................................. .........................................5-52
Operating precautions ....
....................................... ........................5-52
Maximum loadlimits (forAustralia andNew Zealand) ....
...... 5-53
Tire pressure ....
................................................. ................................5-55
Safety chains ....
....................................... ......................................... 5-55
T railer brakes ....
....................................... ......................................... 5-55
T railer detection (ifequipped) ....
....................................... ...........5-55
Coupling deviceinstallation (forEurope) ....
.............................. 5-56
Electric powersteering system....
................................................. .......5-56
Brake system ....
................................................................ ........................5-57
Brake precautions ....
....................................... ................................5-57
Brake assist ....
...................................................... ............................5-58
Anti-lock BrakingSystem(ABS)....
............................................. 5-58
V ehicle security ....
............................................ .........................................5-59
Cold weather driving....
................................................................ ...........5-59
Battery ....
................................................................ ............................5-59
Engine coolant ....
................................................. ............................5-59
Tire equipment ....
................................................. ............................5-59
Special winterequipment ....
.......................................................... 5-60
Parking brake....
....................................... ......................................... 5-60
Corrosion protection ....
....................................... ............................5-60
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
ENTER buttontoselect ªLaneº andpress the
ENTER button.
TEMPORAR YDISABLED STATUS AT HIGH
TEMPERA TURE
GUID-67A7 ECBE-6ACC- 40A7-9D0F-1C44280C8D 44
If the vehicle isparked indirect sunlight underhigh
temperature conditions(overapproximately 408C
(1048F) andthen started, theLDW system maybe
deactivated automatically .The ªHigh cabintempera-
tureº warning message willappear inthe vehicle
information display.
When theinterior temperature isreduced, theLDW
system willresume operating automatically .
MUL TI-SENSING CAMERAUNITMAINTE-
NANCE
GUID-C19 E3F82-C5B C-4AC8-B5 4F-DD97FCD DFBCC
JVI0975X
The multi-sensing cameraunit
*
1
for the LDW system
is located onthe windshield infront ofthe inside
rearview mirror.To maintain theproper operation ofthe
LDW system andprevent asystem malfunction besure
to observe thefollowing:
. Always keepthewindshield clean.
. Donot attach asticker (including transparent
material) orinstall anaccessory nearthemulti-
sensing lanecamera unit. .
Donot place reflective materials, suchaswhite
paper oramirror, onthe instrument panel.The
reflection ofsunlight mayadversely affectthe
multi-sensing cameraunit'sdetection capability.
. Donot strike ordamage theareas around the
camera unit.Donot touch thecamera lensor
remove thescrew located onthe camera unit.If
the camera unitisdamaged duetoan accident,
contact aNISSAN dealer.
GUID-790 A193B-4EB1 -4E55-89F5-8BFBAFBA 326A
The speed limiterallows youtoset the desired vehicle
speed limit.While thespeed limiterisactivated, the
driver canperform normalbraking andacceleration,
but thevehicle willnot exceed thesetspeed.
WARNING:
. Always observe postedspeedlimits.Donot
set the speed overthem.
. Always confirm thesetting statusofthe
speed limiter onthe vehicle information
display.
When thespeed limiterison, the cruise control system
cannot beoperated.
SPEED LIMITER OPERATIONS
GUID-7D727D 12-89FC-4770-A277-89 9333D04B46
The speed limitercanbeset ataspeed between 30to
200 km/h (20to124 MPH)
.
JVS0427X
The speed limitersetswitches arelocated onthe
steering wheel.
1. CANCEL switch
2. RES/+ switch
3. SET/


> (GLW    0RGHO 7$@
5-42
Starting anddriving
5. Speed limiterMAINswitch
(When thisswitch ispushed, thespeed limiter
enters thestandby mode.Ifthe cruise control
system ison, the system willturn offand the
speed limiterenters thestandby
mode.)
JVS0284X
The speed limiteroperating conditionisshown onthe
vehicle information display.
1. Speed limiterindicator
2. Setspeed indicator
The speed unitcanbeconverted betweenªkm/hºand
ªMPHº .(See ªVehicle information displayº(P.2-20) .)
When thevehicle speedexceeds thesetspeed limit,
the setspeed indicator blinksandtheaccelerator
pedal operation willnotwork untilthevehicle speed
slows downtothe setspeed limit.
The speed limiter willnotautomatically reduce
the vehicle speedtothe setspeed limit.
T urning onspeed limiter
GUID-E3 6A4E9E-7B02 -40E6-850F-C E30FD8CA1A8
Push thespeed limiterMAINswitch. Thespeed limiter
and thesetspeed indicators illuminateonthe vehicle
information display.
Setting speedlimit
GUID-207 6BDD2-77 12-4CD9-9E7 B-EA71752B2BC2
1. Push theSET/


> (GLW    0RGHO 7$@
set speed isexceeded anddriver intervention isnot
detected.
T urning thespeed limiteroff
GUID-604082 45-BB35-4F90-884A-8 3477F15BB08
The speed limitersystem willbeturned offwhen oneof
the following operations isperformed:
. Push thespeed limiterMAINswitch. Thespeed
limiter indicator andthesetspeed indicator onthe
vehicle information displaywillbeturned off.
. Push thecruise control MAINswitch. Thespeed
limiter information onthe vehicle information will
be replaced withthecruise control information.
For details seeªCruise controlº (P.5-43) .
. When thevehicle isstopped andtheignition is
placed tothe offposition.
T urning offthe speed limiterwillerase thesetspeed
limit memory .
Speed limitermalfunction
GUID-56D 8A157-AB4B- 4429-9C83-5333E82C8D98
If the speed limitermalfunctions, thespeed limiteron
the vehicle information displaywillflash.
T urn thespeed limiterMAINswitch offand have the
system checked byaNISSAN dealer.
T32A130 827-FF5B4 88B-DD40- 465E-8AD4-B D88C01B8 0E9
JVS0180X
Models without speedlimiter
JVS0427X
Models withspeed limiter
1. CANCEL switch
2. ACCELERA TE/RESUME switch
3. COAST/SET switch
4. Cruise control MAINswitch
5. Speed limiterMAINswitch
WARNING:
. Always observe theposted speedlimitsand
do not setthe speed overthem.
. Donot use thecruise control whendriving
under thefollowing conditions. Doingso
could cause aloss ofvehicle control and result
inan accident.
Ð When itis not possible tokeep the
vehicle ataconstant speed
Ð When driving inheavy traffic
Ð When driving intraffic thatvaries speed
Ð When driving inwindy areas
Ð When driving onwinding orhilly roads
Ð When driving onslippery (rain,snow, ice,
etc .)roads
CAUTION:
On manual Transmission (MT)model, donot
shift tothe ªNº (Neutral) positionwithout
depressing theclutch pedalwhenthecruise
control isoperated. Shouldthisoccur, depress
the clutch pedalandturn thecruise control MAIN
switch offimmediately. Failuretodo somay
cause engine damage.
PRECAUTIONS ONCRUISE CONTROL
T32A1308 27-DF670F 83-9B80-4A99-B18B-0 4CB9B1ECB D9
. Ifthe cruise control system malfunctions, itwill
cancel automatically .The CRUISE indicator inthe
vehicle information displaywillthen blink towarn
the driver.
. Ifthe CRUISE indicator blinks,turnthecruise
control MAINswitch offand have thesystem
checked byaNISSAN dealer.
. The CRUISE indicator mayblink when thecruise
control MAINswitch isturned ONwhile pushing
the ACCELERA TE/RESUME, COAST/SETor
CANCEL switch.To properly setthe cruise control
system, perform thefollowing procedures.
Starting anddriving
5-43
CRUISE
CONTROL (ifequippe d)
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
5-44
Starting anddriving
CRUISE CONTROL OPERATIONS
T32A1308 27-4BD70 071-615A-4B E0-8E01-02D3FB02318A
The cruise control allowsdriving atspeeds above40
km/h (25MPH) without keeping yourfootonthe
accelerator pedal.
For gasoline enginemodels, thecruise control will
automatically becanceled ifthe vehicle slowsdown
more thanapproximately 13km/h (8MPH) below the
set speed.
For diesel engine models, thecruise control will
automatically becanceled ifthe vehicle speedslows
to less than approximately 35km/h (22MPH) .
Moving theshift lever tothe ªNº (Neutral) positionwill
cancel andtheCRUISE indicator willoff.
T urning oncruise control
T32A1308 27-D9A26350-0978 -4C2D-81F7 -A433A8DD2D61
Push theMAIN switch. TheCRUISE indicator inthe
vehicle information displaywillappear.
Setting cruising speed
T32A1308 27-C830EB 0E-975B-4C 65-891B-9EDAAA4D8E3 E
1. Accelerate tothe desired speed.
2. Push theCOAST/SET switchandrelease it.
3. Take your footoffthe accelerator pedal.
The vehicle willmaintain thesetspeed.
Passing anothervehicle:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
Depress theaccelerator pedaltoaccelerate. After
releasing theaccelerator pedal,thevehicle willreturn
to the previously setspeed.
The vehicle maynotmaintain thesetspeed when
going upordown steep hills.Insuch cases, drive
without thecruise control. Resetting
toslower speed:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
Use anyone ofthe following methodstoreset toa
slower speed.
. Lightly tapthefoot brake pedal. When thevehicle
reaches thedesired speed,pushandrelease the
COAST/SET switch.
. Push andhold theCOAST/SET switch.Whenthe
vehicle reaches thedesired speed,release the
COAST/SET switch.
. Quickly pushandrelease theCOAST/SET switch.
This willreduce thevehicle speedbyabout 1km/h
or 1MPH.
Resetting tofaster speed:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
Use anyone ofthe following methodstoreset toa
faster speed.
. Depress theaccelerator pedal.Whenthevehicle
reaches thedesired speed,pushandrelease the
COAST/SET switch.
. Push andhold theACCELERA TE/RESUME
switch. Whenthevehicle reaches thedesired
speed, release theACCELERA TE/RESUME
switch.
. Quickly pushandrelease theACCELERA TE/
RESUME switch.Thiswillincrease thevehicle
speed byabout 1km/h or1MPH.
Resuming atpreset speed:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
Push andrelease theACCELERA TE/RESUME switch.
The vehicle willresume thelast setcruising speed
when thevehicle speedisover 40km/h (25MPH) .
Cancelling cruisingspeed
T32A130 827-D50DF32 4-B09E-4323-8AC9-3 5C0187CD15 A
Use anyone ofthe following methodstocancel theset
speed.
. Push theCANCEL switch.
. Tap the foot brake pedal.
. Push thecruise control MAINswitch. TheCRUISE
indicator willturn off.
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
GUID-75 53A2A8-03 70-4910-AC8 8-82CE83F 86111
JVS0185X
The ECO mode system helpstoenhance thefuel
economy bycontrolling theengine andCVT operation
automatically toavoid rapidacceleration.
T o turn onthe ECO mode system, pushtheECO
switch. TheECO mode indicator appearsonthe
meter.
T o turn offthe ECO mode, pushtheECO switch again.
The ECO mode indicator willturn off.
. TheECO mode system cannotbeturned offwhile
the accelerator pedalisdepressed evenifthe
ECO switch ispushed toOFF .Release the
accelerator pedaltoturn offthe ECO mode
system.
. TheECO mode system willturn offautomatically if
a malfunction occursinthe system.
. Turn offthe ECO mode system whenacceleration
is required suchaswhen:
Ð driving withaheavy loadofpassengers or
cargo inthe vehicle
Ð driving onasteep uphillslope
ECO PEDAL GUIDEFUNCTION
GUID-DDE3 E3BA-F896-46E1-926E -74DCB96AEB 2E
JVS0201X
Use theECO Pedal Guide function forimproving fuel
economy .
When theECO Pedal Guide barisin the green range
*
1
, it indicates thatthevehicle isdriven withinrange
of economy drive.
If the ECO Pedal Guide barisout ofthe green range, it
indicates thattheaccelerator pedalisdepressed over
the range ofeconomy drive.
The ECO Pedal Guide barisnot displayed when:
. The cruise control system (ifequipped) isoperat-
ing.
. The vehicle speedisless than approximately 4
km/h (2MPH) .
. Theshift lever isin the ªPº (Park) ,ªNº (Neutral) or
ªRº (Reverse) position.
T o activate ordeactivate theECO Pedal Guide
function, seeªSettingsº (P.2-21) .
AMBIENT ECO
GUID-9809F FEA-AECE-41 2F-A92C-66A486882 392
JVS0200X
The ambient ECO
*
1
is displayed according tothe
accelerator pedaloperation, whiledriving thevehicle in
ECO mode.
The ambient ECOwillilluminate inthe directions of
*
2
as the driving pattern becomes moreECO friendly .
T o activate ordeactivate theambient ECO,see
ªSettingsº (P.2-21) .
The ambient ECOisnot displayed inthe following
conditions
. The vehicle speedisunder 10km/h (6MPH) .
. Theshift lever isin the ªPº (Park) ,ªNº (Neutral) or
ªRº (Reverse) position.
. The cruise control system (ifequipped) isoperat-
ing.
Starting anddriving
5-47
ECO
MODE SY STEM (ifequipped)
&RQGLWLRQ
([FHSWIRU&KLQD
