2020 NISSAN NV200 Owners Manual

Replacing the halogen headlight
bulb
Disconnect the negative battery cable be-
fore replacement and installation of the
headlight bulb.
1Release the clip on the connector.
2Rotate the bulb counterclockwise and
pull out to remove. Replace as neces-
sary.

∙ Only touch the base when handlingthe bulb. Never touch the glass enve-
lope. Touching the glass could signifi-
cantly affect bulb life and/or head-
light performance.
∙ High pressure halogen gas is sealed inside the halogen bulb. The bulb may
break if the glass envelope is
scratched or the bulb is dropped.
∙ Use the same number and wattage as shown in the chart.
Fog may temporarily form inside the lens
of the exterior lights in the rain or in a car
wash. A temperature difference between
the inside and the outside of the lens
causes the fog. This is not a malfunction. If
large drops of water collect inside the lens,
it is recommended that you visit a NISSAN
dealer for this service.
Aiming the headlights
The headlights on your vehicle are properly
aimed at the assembly plant. If your vehicle
has been in a collision, the alignment of
your headlights should be checked. It is
recommended that you visit a NISSAN
dealer for this service. Vertical aim adjustment
NOTE:
Due to a maximum load condition of the
vehicle, headlight aiming adjustment
may be necessary. Please perform the
following procedure:
1. Park the vehicle directly in front of a wallor screen on a level surface, approxi-
mately 25 feet (7.6 meters) away.
∙
18 feet (2.4 meters)
∙
2Center height of headlight to ground
∙
325 feet (7.6 meters)
∙
4Horizontal reference line
2. Measure the height from the center of the headlight to the ground and mark
an 8 foot (2.4 meter) horizontal refer-
ence line on the vertical wall or screen
at this height (a piece of masking tape
works well).
