1
ES350_QG_OM06198U_(U)
Air Conditioning System*
Control panel ..................................................................................................................................60
Main control screen............................................................................................................ ........... 61
Option control screen .......................................................................................................... ....... 62
Side display................................................................................................................... ....................63
Using automatic mode ........................................................................................................... .....63
Audio System
*
Audio control screen ........................................................................................................... ........52
Selecting an audio source ...................................................................................................... ....52
Steering switch operation ...................................................................................................... ....53
Radio ...................................................................................................................................................55
CD........................................................................................................................................................56
DVD .................................................................................................................................................... 57
iPod/iPhone (Apple CarPlay)................................................................................................. 58
Automatic High Beam........................................................................................................... 3 3
Automatic Transmission ......................................................................................................... 19
Brake Hold ..................................................................................................................... ............25
Door Locks ..................................................................................................................... .......... 82
Engine (Ignition) Switch ....................................................................................................... ... 16
Floor Mat Installation ......................................................................................................... ...... 11
Front Seats .................................................................................................................... ..............15
Fuel Consumption Screen .................................................................................................. 43
Fuel Tank Cap .................................................................................................................. ........ 83
Garage Door Opener............................................................................................................73
Hands-free System For Cellular Phone
*
Registering/connecting Bluetooth® device ......................................................................48
Contacts transfer .............................................................................................................. .............49
Registering the contacts in the favorites list . ..................................................................... 50
Calling by favorites list ...................................................................................................... .......... 50
Calling the message sender..................................................................................................... 50
Receiving a call ............................................................................................................... ................. 51
Steering switches .............................................................................................................. .............. 51
Contents
The Quick Guide is not intended as a substitute for yourOWNER’S MANUAL. We strongly encourage you to review
the OWNER’S MANUAL and supplementary manuals so you
will have a better understanding of your vehicle’s capabilities
and limitations.

3
ES350_QG_OM06198U_(U)
■Instrument panel
Engine switch .............................................................................................................. P.16
Starting the engine/changing the mode............................................................... P.16, 17
Emergency stop of the engine .........................................................................................P.18
When the engine will not start ....................................................................................... P.90
Warning messages
*1
Shift lever .................................................................................................................... .P.19
Changing the shift position................................................................................................ P.19
Precautions against towing
*1
When the shift lever does not move*1
Meters*1
Reading the meters/adjusting the instrument panel lights*1
Warning lights/indicator lights ...................................................................................... P.85
When the warning lights come on
*1
Multi-information display ...................................................................................... P.26
Display.......................................................................................................................................P.26
When the warning messages are displayed
*1
Pictorial Index
A
B
C
D

13
ES350_QG_OM06198U_(U)
1Grip the driver’s door handle to unlock
the door. Holding the driver’s door
handle for approximately 2 seconds
unlocks all the doors. Grip the passen-
ger’s door handle to unlock all the
doors.
*
Make sure to touch the sensor on the
back of the handle.
The doors cannot be unlocked for
3 seconds after the doors are locked.
*: The door unlock settings can be
changed.
2Touch the lock sensor (the indentation on the upper part of the door handle) to lock all
the doors.
Check that the door is securely locked.
Smart Access System with Push-button Start
The following operations can be performed simply by carrying the electronic key on your
person, for example in your pocket. The driver should always carry the electronic key.
For details on starting the engine, see page 16.
Unlocking and locking the doors from the outside

16
ES350_QG_OM06198U_(U)
1Press the parking brake switch to
check that the parking brake is set.
( P.23)
Parking brake indicator will come on.
2Check that the shif t lever is in P
3Firmly depress the brake pedal.
and a message will be dis-
played on the multi-information dis-
play. If it is not displayed, the engine
cannot be started.
4Press the engine switch shortly and firmly.
When operating the engine switch, one short, firm press is enough. It is not necessary
to press and ho ld the switch.
The engine will crank until it starts or for up to 30 seconds, whichever is less. Continue
depressing the brake pedal until the engine is completely started.
The engine can be started from any engine switch mode.
Engine (Ignition) Switch
Performing the following operations when carrying the electronic key on your person
starts the engine or changes engine switch modes.
Starting the engine

17
ES350_QG_OM06198U_(U)
1Stop the vehicle completely.
2Set the parking brake (P.23), and shift the shift lever to P. ( P.19)
3Press the engine switch.
4Release the brake pedal and check that “ACCESSORY” or “IGNITION ON” is not
shown on the meter.
Modes can be changed by pressing the engine switch with the brake pedal released. (The
mode changes each time the switch is pressed.)
1Off*
The emergency flashers can be used.
2ACCESSORY mode
Some electrical components such as
the audio system can be used.
“ACCESSORY” will be displayed on
the meter.
3IGNITION ON mode
All electrical components can be used.
“IGNITION ON” will be displayed on
the meter.
*: If the shift lever is in a position other than
P when turning off the engine, the
engine switch will be turned to ACCES-
SORY mode, not to off.
Stopping the engine
Changing engine switch modes

18
ES350_QG_OM06198U_(U)
Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way,
stop the vehicle using the following procedure:
1Steadily step on the brake pedal with both feet and firmly depress it.
Do not pump the brake pedal re peatedly as this will increase the effort required to slow
the vehicle.
2Shift the shift lever to N.
 If the shift lever is shifted to N
3After slowing down, stop the vehicle in a safe place by the road.
4Stop the engine.
 If the shift lever cannot be shifted to N
3Keep depressing the brake pedal with both feet to reduce vehicle speed as much as
possible.
4To stop the engine, press and hold the
engine switch for 2 consecutive sec-
onds or more, or press it briefly 3 times
or more in succession.
5Stop the vehicle in a safe place by the road.
If your vehicle has to be stopped in an emergency

19
ES350_QG_OM06198U_(U)
While the engine switch is in IGNITION ON mode and the brake pedal
depressed
*, shift the shift lever while pushing the shift release button on the shift knob.
Shift the shift lever while pushing the shift release button on the shift knob.
Shift the shift lever normally.
When shifting the shift lever between P and D, make sure that the vehicle is completely
stopped and the brake pedal is depressed.
*: For the vehicle be able to be shifted from P, the brake pedal must be depressed before
the shift release button is pushed. If the shift release button is pushed first, the shift lock
will not be released.
Automatic Transmission
Shifting the shift lever

20
ES350_QG_OM06198U_(U)
*1: Shifting to the D position allows the system to select a gear suitable for the driving condi-
tions. Setting the shift lever to the D position is recommended for normal driving. You
can choose shift range suitable for your driving situation by operating the paddle shift
switches.
*2: Selecting shift ranges using S mode restricts the upper limit of the possible gear ranges,
controls engine braking force, an d prevents unnecessary upshifting.
To drive using temporary shift ra nge selection, operate the “-” paddle shift switch. The shift
range can then be selected by operatin g the “-” and “+” paddle shift switches.
1Upshifting
2Downshifting
The selected shift range, from D1 to D8, will
be displayed in the meter.
Shift position purpose and functions
Shift positionObjective or function
PParking the vehicle/starting the engine
RReversing
NNeutral
DNormal driving*1
SS mode driving*2 (  P.21)
Selecting shift ranges in the D position
