GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-13337776) - 2020 - CRC - 4/10/19
Vehicle Care 435
Original manufacturer replacement
parts will provide the corrosion
protection while maintaining the
vehicle warranty.
Finish Damage
Quickly repair minor chips and
scratches with touch-up materials
available from your dealer to avoid
corrosion. Larger areas of finish
damage can be corrected in your
dealer's body and paint shop.
Chemical Paint Spotting
Airborne pollutants can fall upon
and attack painted vehicle surfaces
causing blotchy, ring-shaped
discolorations, and small, irregular
dark spots etched into the paint
surface. Refer to“Finish Care”
previously in this section.
Interior Care
To prevent dirt particle abrasions,
regularly clean the vehicle's interior.
Immediately remove any soils.
Newspapers or dark garments can
transfer color to the vehicle’s
interior. Use a soft bristle brush to remove
dust from knobs and crevices on the
instrument cluster. Using a mild
soap solution, immediately remove
hand lotions, sunscreen, and insect
repellent from all interior surfaces or
permanent damage may result.
Use cleaners specifically designed
for the surfaces being cleaned to
prevent permanent damage. Apply
cleaners directly to the cleaning
cloth. Do not spray cleaners on any
switches or controls. Remove
cleaners quickly.
Before using cleaners, read and
follow all safety instructions on the
label. While cleaning the interior,
open the doors and windows to get
proper ventilation.
To prevent damage, do not clean
the interior using the following
cleaners or techniques:
.
Never use a razor or any other
sharp object to remove soil from
any interior surface.
. Never use a brush with stiff
bristles. .
Never rub any surface
aggressively or with too much
pressure.
. Do not use laundry detergents or
dishwashing soaps with
degreasers. For liquid cleaners,
use approximately 20 drops per
3.8 L (1 gal) of water.
A concentrated soap solution will
create streaks and attract dirt.
Do not use solutions that contain
strong or caustic soap.
. Do not heavily saturate the
upholstery when cleaning.
. Do not use solvents or cleaners
containing solvents.
Interior Glass
To clean, use a terry cloth fabric
dampened with water. Wipe droplets
left behind with a clean dry cloth.
If necessary, use a commercial
glass cleaner after cleaning with
plain water.

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-13337776) - 2020 - CRC - 4/10/19
436 Vehicle Care
Caution
To prevent scratching, never use
abrasive cleaners on automotive
glass. Abrasive cleaners or
aggressive cleaning may damage
the rear window defogger.
Cleaning the windshield with water
during the first three to six months
of ownership will reduce tendency
to fog.
Speaker Covers
Vacuum around a speaker cover
gently, so that the speaker will not
be damaged. Clean spots with water
and mild soap.
Coated Moldings
Coated moldings should be cleaned.
. When lightly soiled, wipe with a
sponge or soft, lint-free cloth
dampened with water.
. When heavily soiled, use warm
soapy water.
Fabric/Carpet/Suede
Start by vacuuming the surface
using a soft brush attachment. If a
rotating vacuum brush attachment is
being used, only use it on the floor
carpet. Before cleaning, gently
remove as much of the soil as
possible:
.Gently blot liquids with a paper
towel. Continue blotting until no
more soil can be removed.
. For solid soils, remove as much
as possible prior to vacuuming.
To clean: 1. Saturate a clean, lint-free colorfast cloth with water.
Microfiber cloth is
recommended to prevent lint
transfer to the fabric or carpet.
2. Remove excess moisture by gently wringing until water does
not drip from the cleaning cloth.
3. Start on the outside edge of the soil and gently rub toward the
center. Fold the cleaning cloth to a clean area frequently to
prevent forcing the soil in to the
fabric.
4. Continue gently rubbing the soiled area until there is no
longer any color transfer from
the soil to the cleaning cloth.
5. If the soil is not completely removed, use a mild soap
solution followed only by plain
water.
If the soil is not completely
removed, it may be necessary to
use a commercial upholstery
cleaner or spot lifter. Test a small
hidden area for colorfastness before
using a commercial upholstery
cleaner or spot lifter. If ring
formation occurs, clean the entire
fabric or carpet.
After cleaning use a paper towel to
blot excess moisture.

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-13337776) - 2020 - CRC - 4/10/19
Vehicle Care 437
Cleaning High Gloss Surfaces
and Vehicle Information and
Radio Displays
Use a microfiber cloth on high gloss
surfaces or vehicle displays. First,
use a soft bristle brush to remove
dirt that can scratch the surface.
Then gently clean by rubbing with a
microfiber cloth. Never use window
cleaners or solvents. Periodically
hand wash the microfiber cloth
separately, using mild soap. Do not
use bleach or fabric softener. Rinse
thoroughly and air dry before
next use.
Caution
Do not attach a device with a
suction cup to the display. This
may cause damage and would
not be covered by the vehicle
warranty.
Instrument Panel, Leather,
Vinyl, Other Plastic Surfaces,
Low Gloss Paint Surfaces and
Natural Open Pore Wood
Surfaces
Use a soft microfiber cloth
dampened with water to remove
dust and loose dirt. For a more
thorough cleaning, use a soft
microfiber cloth dampened with a
mild soap solution.
Caution
Soaking or saturating leather,
especially perforated leather, as
well as other interior surfaces,
may cause permanent damage.(Continued)
Caution (Continued)
Wipe excess moisture from these
surfaces after cleaning and allow
them to dry naturally. Never use
heat, steam, or spot removers. Do
not use cleaners that contain
silicone or wax-based products.
Cleaners containing these
solvents can permanently change
the appearance and feel of
leather or soft trim, and are not
recommended.
Do not use cleaners that increase
gloss, especially on the instrument
panel. Reflected glare can decrease
visibility through the windshield
under certain conditions.
Caution
Use of air fresheners may cause
permanent damage to plastics
and painted surfaces. If an air
freshener comes in contact with (Continued)

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-13337776) - 2020 - CRC - 4/4/19
Service and Maintenance 443
The filter should be replaced as part
of routine scheduled maintenance.
Inspect the passenger compartment
air filter every 36 000 km/
22,500 miles or two years,
whichever comes first. Replace if
necessary. More frequent
replacement may be needed if the
vehicle is driven in areas with heavy
traffic, areas with poor air quality,
or areas with high dust levels.
Replacement may also be needed if
there is a reduction in air flow,
excessive window fogging, or odors.
Power Take Off (PTO) and
Extended Idle Use
When the vehicle is used with the
PTO equipment or used in a way
that requires extended idle time,
one hour of use shall be deemed
the same as 53 km (33 mi). See
Driver Information Center (DIC)
(Base Level)0148 or
Driver Information Center (DIC)
(Midlevel and Uplevel) 0149 for
hourmeter, if equipped.
Air Conditioning Desiccant
(Replace Every Seven Years)
The air conditioning system requires
maintenance every seven years.
This service requires replacement of
the desiccant to help the longevity
and efficient operation of the air
conditioning system. This service
can be complex. See your dealer.
Tire Rotation and Required
Services Every 12 000 km/
7,500 mi
Rotate the tires, if recommended for
the vehicle, and perform the
following services. See Tire
Rotation 0396.
. Check engine oil level and oil
life percentage. If needed,
change engine oil and filter, and
reset oil life system. See Engine
Oil 0339 and
Engine Oil Life System 0341.
. If equipped with the engine air
filter life system, check the air
filter life percentage.
If necessary, replace the engine
air filter and reset the engine air filter life system. See
Engine Air
Filter Life System 0343. If the
vehicle is not equipped with the
engine air filter life system,
inspect the engine air cleaner
filter. See Engine Air Cleaner/
Filter 0344.
. Check engine coolant level. See
Cooling System 0346.
. Check windshield washer fluid
level. See Washer Fluid 0354.
. Check tire inflation pressures,
including the spare. See Tire
Pressure 0387.
. Inspect tire wear. See Tire
Inspection 0396.
. Visually check for fluid leaks.
. Inspect brake system. See
Exterior Care 0429.
. Visually inspect steering,
suspension, and chassis
components for damage,
including cracks or tears in the
rubber boots, loose or missing
parts, or signs of wear at least
once a year. See Exterior Care
0 429. If equipped with grease

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-13337776) - 2020 - CRC - 4/4/19
446 Service and Maintenance
Maintenance Schedule
Additional Required
Services - Normal12 000 km/7,500 mi
24 000 km/15,000 mi
36 000 km/22,500 mi
48 000 km/30,000 mi
60 000 km/37,500 mi
72 000 km/45,000 mi
84 000 km/52,500 mi
96 000 km/60,000 mi
108 000 km/67,500 mi
120 000 km/75,000 mi
132 000 km/82,500 mi
144 000 km/90,000 mi
156 000 km/97,500 mi
168 000 km/105,000 mi 180 000 km/112,500 mi
192 000 km/120,000 mi
204 000 km/127,500 mi
216 000 km/135,000 mi
228 000 km/142,500 mi
240 000 km/150,000 mi
For GVW over 3 900 kg (8,600 lb), change
transfer case fluid, if equipped with 4WD. (4)@ @@
Drain and fill engine cooling system. (5)@
Visually inspect accessory drive belts. (6)@
Replace brake fluid. (7)
Replace windshield wiper blades. (8)
@ @ @ @ @ @ @ @ @ @
Replace hood gas struts and tailgate
dampener. (9)@ @
Replace air conditioning desiccant. (10)
Footnotes—Maintenance
Schedule Additional Required
Services - Normal
(1) Or every two years, whichever
comes first. More frequent
replacement may be needed if the
vehicle is driven in areas with heavy
traffic, poor air quality, areas with
high dust levels or are sensitive to
environmental allergens. Filter
replacement may also be needed if you notice reduced airflow, windows
fogging up, or odors. Your local GM
Service location can help you
determine when it is the right time to
replace your filter.
(2)
Or every four years, whichever
comes first. If driving in dusty
conditions, inspect the filter at each
oil change or more often as needed.
See Engine Air Cleaner/Filter 0344. (3)
Visually check all fuel and vapor
lines and hoses for proper
attachment, connection, routing, and
condition.

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-13337776) - 2020 - CRC - 4/4/19
Service and Maintenance 449
Footnotes—Maintenance
Schedule Additional Required
Services - Severe
(1) Or every two years, whichever
comes first. More frequent
replacement may be needed if the
vehicle is driven in areas with heavy
traffic, poor air quality, areas with
high dust levels or are sensitive to
environmental allergens. Filter
replacement may also be needed if
you notice reduced airflow, windows
fogging up, or odors. Your local GM
Service location can help you
determine when it is the right time to
replace your filter.
(2) Or every four years, whichever
comes first. If driving in dusty
conditions, inspect the filter at each
oil change or more often as needed.
See Engine Air Cleaner/Filter 0344.
(3) Visually check all fuel and vapor
lines and hoses for proper
attachment, connection, routing, and
condition.
(4) Do not directly power wash the
transfer case and/or front/rear axle
output seals. High pressure water can overcome the seals and
contaminate the fluid. Contaminated
fluid will decrease the life of the
transfer case and/or drive axles and
should be replaced.
(5)
Or every five years, whichever
comes first. See Cooling System
0 346.
(6) Or every 10 years, whichever
comes first. Inspect for fraying,
excessive cracking, or damage;
replace, if needed.
(7) Replace brake fluid every five
years. See Brake Fluid 0357.
(8) Or every 12 months, whichever
comes first. See Wiper Blade
Replacement 0364.
(9) Or every 10 years, whichever
comes first. See Gas Strut(s)0365.
(10) Replace air conditioning
desiccant every seven years.Special Application
Services
. Vehicles with Dual Wheels:
Check dual wheel nut torque at
160, 1 600, and 10 000 km (100,
1,000, and 6,000 mi) of driving.
Repeat this service whenever a
tire/wheel is serviced or
removed.
. Severe Commercial Use
Vehicles Only: Lubricate chassis
components every oil change.
. Have underbody flushing service
performed. See “Underbody
Maintenance” inExterior Care
0 429.

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-13337776) - 2020 - CRC - 4/4/19
Index 495
Maintenance Schedule (cont'd)Recommended Fluids and
Lubricants . . . . . . . . . . . . . . . . . . . 453
Transfer Case . . . . . . . . . . . . . . . . 227
Malfunction Indicator Lamp . . . . . 138
Manual Mirrors . . . . . . . . . . . . . . . . . . 41
Manual Mode . . . . . . . . . . . . . . . . . . . 224
Manual Windows . . . . . . . . . . . . . . . . 49
Memory Seats . . . . . . . . . . . . . . . . . . . 59
Messages Engine Power . . . . . . . . . . . . . . . . 156
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 156
Vehicle Speed . . . . . . . . . . . . . . . . 156
Mirror
Rear Camera . . . . . . . . . . . . . . . . . . . 46
Mirrors Automatic Dimming . . . . . . . . . . . . . 44
Automatic DimmingRearview . . . . . . . . . . . . . . . . . . . . . . 46
Blind Spot . . . . . . . . . . . . . . . . . . . . . . 44
Convex . . . . . . . . . . . . . . . . . . . . . . . . . 40
Folding . . . . . . . . . . . . . . . . . . . . . . . . . 43
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 44
Manual . . . . . . . . . . . . . . . . . . . . . . . . . 41
Manual Rearview . . . . . . . . . . . . . . . 46
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Tilt in Reverse . . . . . . . . . . . . . . . . . . 45
Trailer Tow . . . . . . . . . . . . . . . . . . . . . . 41 Mirrors, Interior Rearview . . . . . . . . 46
Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 238
Driver Control . . . . . . . . . . . . . . . . . 238
Monitor System, Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 389
N
NavigationConnected Services . . . . . . . . . . 485
New Vehicle Break-In . . . . . . . . . . . 208
Noise Control System . . . . . . . . . . 362
O
Odometer . . . . . . . . . . . . . . . . . . . . . . . 132 Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Off-Road . . . . . . . . . . . . . . . . . . . . . . . 191 Driving . . . . . . . . . . . . . . . . . . . . . . . . 191
Recovery . . . . . . . . . . . . . . . . . . . . . 190
Oil Engine . . . . . . . . . . . . . . . . . . . . . . . . 339
Engine Oil Life System . . . . . . . 341
Engine Oil Pressure Gauge . . . 133
Pressure Light . . . . . . . . . . . . . . . . 146
Older Children, Restraints . . . . . . . 85
Online Owner Center . . . . . . . . . . . 466
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . 476
OnStar Additional Information . . . . . . . . . . . . . . . . . . . . 479
OnStar Emergency . . . . . . . . . . . . . 478 OnStar Overview . . . . . . . . . . . . . . . 477
OnStar Security . . . . . . . . . . . . . . . . 479
Operating Mode
Overheated EngineProtection . . . . . . . . . . . . . . . . . . . 352
Operation Fog Lamps . . . . . . . . . . . . . . . . . . . 170
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . 122
Overheated Engine Protection Operating Mode . . . . 352
Overheating, Engine . . . . . . . . . . . . 351
Overview Instrument Panel . . . . . . . . . . . . . . . . 5
P
ParkShifting Out of . . . . . . . . . . . . . . . . 218
Park Assist . . . . . . . . . . . . . . . . . . . . . 257
Parking Brake and P (Park)
Mechanism Check . . . . . . . . . . 364
Extended . . . . . . . . . . . . . . . . . . . . . 219
Over Things That Burn . . . . . . . 219
Parking or Backing Assistance Systems . . . . . . . . . . 257
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . . 137

GMC Sierra/Sierra Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-13337776) - 2020 - CRC - 4/4/19
496 Index
Passenger Compartment AirFilter . . . . . . . . . . . . . . . . . . . . . . . . . . 183
Passenger Sensing System . . . . . 78
Pedestrian Ahead Indicator . . . . . 143
Perchlorate Materials Requirements, California . . . . . . 329
Personalization
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 157
Pickup Conversion to Chassis Cab . . . . . . . . . . . . . . . . . . 326
Power
Door Locks . . . . . . . . . . . . . . . . . . . . . 26
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Outlets . . . . . . . . . . . . . . . . . . . . . . . 122
Protection, Battery . . . . . . . . . . . . 174
Retained Accessory (RAP) . . . 217
Seat Adjustment . . . . . . . . . . . . . . . . 56
Steering Fluid . . . . . . . . . . . . . . . . . 354
Windows . . . . . . . . . . . . . . . . . . . . . . . 49
Power Assist Steps . . . . . . . . . . . . . . 36
Pregnancy, Using Seat Belts . . . . 70
Privacy Vehicle Data Recording . . . . . . . 474
Program Courtesy Transportation . . . . . . 469
Prohibited Fuels . . . . . . . . . . . . . . . . 281 Proposition
65 Warning,
California . . . . . . . . . . . .329, 358, 419,
Back Cover
Publication Ordering Information . . . . . . . . . . . . . . . . . . . . 472
R
Radio Frequency Statement . . . . 472
Reading Lamps . . . . . . . . . . . . . . . . . 173
Rear Axle . . . . . . . . . . . . . . . . . . . . . . . 362Locking . . . . . . . . . . . . . . . . . . . . . . . 243
Rear Camera Mirror . . . . . . . . . . . . . 46
Rear Seats . . . . . . . . . . . . . . . . . . . . . . 63 Heated . . . . . . . . . . . . . . . . . . . . . . . . . 64
Rear Storage . . . . . . . . . . . . . . . . . . . 114
Rear Vision Camera (RVC) . . . . . 257
Rear Windows . . . . . . . . . . . . . . . . . . . 51
Rearview Mirrors . . . . . . . . . . . . . . . . 46 Automatic Dimming . . . . . . . . . . . . . 46
Reclining Seatbacks . . . . . . . . . . . . . 57
Recommended
Fuel . . . . . . . . . . . . . . . . . . . . . 280, 281
Recommended Fluids and Lubricants . . . . . . . . . . . . . . . . . . . . . 453
Records
Maintenance . . . . . . . . . . . . . . . . . . 457
Recreational Vehicle Towing . . . . 424 Reimbursement Program,
GM Mobility . . . . . . . . . . . . . . . . . . . 466
Remote Keyless Entry (RKE) System . . . . . . . . . . . . . . 13, 15
Remote Vehicle Start . . . . . . . . . . . . 24
Replacement Parts Airbags . . . . . . . . . . . . . . . . . . . . . . . . . 84
Maintenance . . . . . . . . . . . . . . . . . . 455
Replacing Airbag System . . . . . . . . 84
Replacing LATCH System Parts after a Crash . . . . . . . . . . . . 105
Replacing Seat Belt System Parts after a Crash . . . . . . . . . . . . . 72
Reporting Safety Defects Canadian Government . . . . . . . . 473
General Motors . . . . . . . . . . . . . . . 474
U.S. Government . . . . . . . . . . . . . 473
Restraints Where to Put . . . . . . . . . . . . . . . . . . . 91
Retained Accessory Power (RAP) . . . . . . . . . . . . . . . . . . 217
Reverse Tilt Mirrors . . . . . . . . . . . . . . 45
Ride Control Systems Enhanced TractionSystem (ETS) . . . . . . . . . . . . . . . 242
Roads Driving, Wet . . . . . . . . . . . . . . . . . . 196
