2019 VOLKSWAGEN E-GOLF display

Lights
up
Warning text in the instru-
ment cluster display / Pos-
sible meaning
Proper response

Switching the ignition on and off
x Briefly press the starter button once without operating the brake or clutch pedals ⇒ .
Emergency start feature
If an authorized remote control vehicle key is in the passenger compartment but the instrument cluster displays No key in range when you push the starter button, the remote control vehicle key battery is weak or dead. You can still start the electric motor using the Emergency start feature.
x Make sure the selector lever is in the Park (P) position.
x Hold the remote control vehicle key to the right of the steering column trim immediately after press-
ing the starter button ⇒ fig. 122.
x The ignition automatically switches on and the electric motor starts.
Emergency shut-off
If the electric motor does not switch off by briefly pressing the starter button, emergency shut-off is necessary:
x Press the starter button twice within 3 seconds or press and hold the button longer than 1 second
⇒  in Stopping the electric motor
x The electric motor switches off automatically.
If no authorized remote control vehicle key is identified in the passenger compartment after the electric motor has been switched off, the electric motor cannot be restarted. A related message is shown in the instrument cluster display.
WARNING
Unintended vehicle movement can cause serious personal injury.
x Do not depress the brake or clutch pedals when switching on the ignition, as the electric motor could otherwise be activated immediately.
WARNING
Improper use of vehicle keys can result in serious personal injury.
x Always take the key with you when you leave the vehicle. Children or unauthorized per-sons may use it to lock the vehicle, start the electric motor, and operate vehicle systems such as the power windows, leading to serious personal injury.
x Never leave children, disabled persons, or anyone who cannot help themselves in the vehicle. The doors can be locked using the remote control vehicle key. This could result in people being trapped in the vehicle in an emergency. For example, depending on the time of year, people trapped in the vehicle can be exposed to very high or very low temperatures.
x Heat buildup in the passenger and luggage compartment of a parked vehicle can result in temperatures in the vehicle that are much higher than the outside temperatures, particularly in summer. Temperatures can quickly reach levels that can cause unconsciousness and death, particularly to small children.
If the ignition is switched on or the electric motor is activated and the driver door is opened, a chime sounds. The chime is also a reminder to switch off the electric motor and turn off the ignition before leaving and locking the vehicle from the outside.

Please perform these steps only in the order listed.
Step Vehicles without Keyless Ac-
cess
Vehicles with Keyless Access
7. Release the parking brake when you are ready to start driving

Noises before driving
A clicking noise may be heard when activating the electric motor.
Recognizing that the vehicle is ready to drive
The electric motor does not make any perceptible noise either when starting or when switched on. It is therefore not possible to tell that the vehicle is ready to drive based on vehicle noise. Instead, the following features indicate that the vehicle is ready to drive:
x The needle in the power display ⇒ fig. 9 (1) is positioned at .
x The illumination of the needles in the instrument cluster is switched on regardless of whether the vehicle's exterior lighting is switched on.
x The text message READY appears in the instrument cluster display ⇒ fig. 9 (3).
x An acoustic signal will sound.
Automatic deactivation of the electric motor
The electric motor is automatically deactivated if the vehicle is left with the electric motor still switched on after driving. In vehicles with Keyless Access, the ignition switches off automatically with a delay of about 30 seconds, to protect the vehicle against unauthorized usage.
Reactivating the electric motor
When the electric motor has been automatically switched off once the driver has left the vehicle, it can be switched back on again within 30 seconds.
The driver door must be closed, the brake pedal depressed and one of the following conditions ful-filled:
x Move the selector lever to position D/B/N or P and lock the safety belt.
x OR: move the selector lever to position D/B/N or P and manually release the electronic parking brake.
When the driver door is closed and no pedals are depressed, the electric motor is reactivated by applying the safety belt if one of the following additional conditions is also fulfilled:
x The selector lever is in position P or N and the electronic parking brake is switched on.
x OR: the selector lever is in position D or B, the vehicle is not crawling and the electronic parking brake is switched on.
WARNING
Never leave the vehicle unattended with the electric motor activated, especially when it is in gear. The vehicle could move suddenly or some other unexpected event could occur, result-ing in property damage, fire, or personal injury.

Power availability display

Fig. 123 In instrument cluster: power display with ranges for energy consumption A and for recuperation B

Fig. 124 In the instrument cluster: power availability

Lights up Warning text in the
instrument cluster
display
Proper response
- Please charge
battery! Limited
conv. funct.
The remaining range is
just a few miles. The
power is reduced and,
if necessary, electrical
consumers are shut
down. The Eco driving
profile is activated.
Charge the high-
voltage battery as soon
as possible
- Battery almost
drained! Limited
function.
The vehicle can only
be driven with limited
power in reserve mode.
The Eco+ driving pro-
file is activated. Charge
the high-voltage battery
as soon as possible

Displaying the driving mode
x Make sure that the ignition is switched on.
x Press the

The electric motor can therefore only be activated with an authorized and correctly coded genuine Volkswagen vehicle key. Coded vehicle keys are available from authorized Volkswagen dealers, authorized Volkswagen Service Facilities, and from certain independent repair facilities and locksmiths
who are qualified to make these vehicle keys ⇒  Vehicle key set.
If an unauthorized vehicle key is used, a message may appear in the instrument cluster display. The vehicle cannot be operated with this key.
A Declaration of Compliance with the United States FCC and Industry Canada regulations is on ⇒  Declaration of Compliance, Telecommunications and Electronic Systems.
Using genuine Volkswagen keys helps minimize the risk of malfunctions.

Selector
lever
position
Designation Meaning ⇒ 
ard driving
position)
The electric drive is in the normal program
(brake energy recuperation levels 0 - 3).
"
Very high
brake energy
recuperation
Very strong brake energy recuperation in over-
run mode (brake energy recuperation level 4).
+ Changing
gear selection
Switch between (D) and (B) by pulling the
selector lever once to the rear from gear posi-
tion D/B ⇒ fig. 127. The selector lever always
returns to gear position D/B.

Automatic Shift Lock (ASL)
The Automatic Shift Lock (ASL) in Park (P) and Neutral (N) prevents drive positions from being en-gaged inadvertently, which would cause the vehicle to move.
To release the ASL, depress and hold the brake pedal with the ignition switched on. Press the release button on the selector lever at the same time.
The ASL is not engaged if the selector lever is moved quickly through Neutral (N) (e.g., when shifting from Reverse (R) to Drive (D/B)). This makes it possible to “rock” the vehicle backwards and forwards if it is stuck in snow or mud. The ASL engages automatically if the brake pedal is not depressed and the lever is in Neutral (N) for more than about 1 second and the vehicle is traveling no faster than about 3 mph (5 km/h).
In rare cases, the ASL may not engage. If this happens, power to the drive wheels will be interrupted to prevent the vehicle from moving unexpectedly. The green indicator light K will blink and a text message will be displayed. To engage the Automatic Shift Lock (ASL):
x Depress and then release the brake pedal. Try to engage the ASL again.
WARNING
Moving the selector lever to the wrong position can cause loss of vehicle control, a collision, and serious personal injury.
x Never accelerate when moving the selector lever.
x When the electric motor is activated and a drive position is engaged, the vehicle will start to move as soon as the brake pedal is released.
x Never shift into Reverse (R) or Park (P) when the vehicle is moving.
