2019 VAUXHALL ADAM Owner's Manual

Seats, restraints47Notice
Do not affix anything on the child
restraint systems and do not cover
them with any other materials.
A child restraint system which has
been subjected to stress in an
accident must be replaced.

48Seats, restraintsChild restraint installation locations
Permissible options for fitting a child restraint system
Weight class
On front passenger seat
On rear seats
activated airbagdeactivated airbagGroup 0: up to 10 kgXU 1U*Group 0+: up to 13 kgXU1U*Group I: 9 to 18 kgXU1U2
*Group II: 15 to 25 kgU **XU *Group III: 22 to 36 kgU **XU *1:if the child restraint system is being secured using a three-point seat belt, adjust seat backrest to a vertical position
to ensure that the belt is tight on the buckle side. Move seat height to the uppermost position.2:remove rear head restraint when using child restraint systems in this group 3 31*:move the respective front seat ahead of the child restraint system to one of the foremost adjustment positions**:move the front passenger seat to the rearmost adjustment position. Move seat height to the uppermost position and
the headrest to the lowest position. Adjust seat backrest as far as necessary to a vertical position to ensure that vehicle seat belt runs forwards from the upper anchorage pointU:universal suitability in conjunction with three-point seat beltX:no child restraint system permitted in this weight class

Seats, restraints49Permissible options for fitting an ISOFIX child restraint systemWeight classSize classFixtureOn front passenger seatOn rear seatsGroup 0: up to 10 kgEISO/R1XIL *Group 0+: up to 13 kgEISO/R1XIL *DISO/R2XXCISO/R3XXGroup I: 9 to 18 kgDISO/R2XXCISO/R3XXBISO/F2XIL, IUF**B1ISO/F2XXIL, IUF**AISO/F3XIL, IUF**Group II: 15 to 25 kgXILGroup III: 22 to 36 kgXILIL:suitable for particular ISOFIX restraint systems of the "specific-vehicle", "restricted" or "semi-universal" categories.
The ISOFIX restraint system must be approved for the specific vehicle typeIUF:suitable for ISOFIX forward-facing child restraint systems of universal category approved for use in this weight classX:no ISOFIX child restraint system approved in this weight class*:move the respective front seat ahead of the child restraint system to one of the foremost adjustment positions**:remove respective rear head restraint when using child restraint systems in this size class 3 31

50Seats, restraintsISOFIX size class and seat deviceA – ISO/F3:forward-facing child restraint system for children of maximum size in the weight class 9 to 18 kgB – ISO/F2:forward-facing child restraint system for smaller children in the weight class 9 to 18 kgB1 – ISO/F2X:forward-facing child restraint system for smaller children in the weight class 9 to 18 kgC – ISO/R3:rear-facing child restraint system for children of maximum size in the weight class up to 18 kgD – ISO/R2:rear-facing child restraint system for smaller children in the weight class up to 18 kgE – ISO/R1:rear-facing child restraint system for young children in the weight class up to 13 kg

Storage51StorageStorage compartments................51
Glovebox ................................... 51
Cupholders ................................ 51
Front storage ............................. 52
Load compartment .......................53
Rear storage .............................. 54
Load compartment cover ...........54
Rear floor storage cover ............55
Lashing eyes ............................. 56
Warning triangle ........................57
First aid kit ................................. 57
Roof rack system .........................58
Roof rack ................................... 58
Loading information .....................58Storage compartments9Warning
Do not store heavy or sharp
objects in the storage
compartments. Otherwise, the
storage compartment lid could
open and vehicle occupants could be injured by objects being thrown
around in the event of hard
braking, a sudden change in
direction or an accident.
Glovebox
Pull lever to open the glovebox cover.
The glovebox features a coin holder
and an adapter for the locking wheel
bolts.
The glovebox should be closed whilst
driving.
Cupholders
Cupholders are located in the console between the front seats. They are
designed for cups of different sizes.

52Storage
Door pockets in both doors are
designed to carry bottles.
Additional cupholders or bottle
holders are located in the rear side
panels.
Flexible cupholder strap
A movable rubber strap is located in
the storage compartment in front of
the selector lever. Pull out the strap to fix a cup or ashtray.
Front storage
Storage compartments are located
below the light switch, in the centre
console in front of the selector lever,
in the door pockets and in the side
panels near the rear seats.

Storage53Load compartment
The rear seat backrest is divided into
two parts. Both parts can be folded
down separately.
Load compartment extension
Remove the load compartment cover
if necessary.
Press the catch and push down the
head restraint.
Insert seat belt latch plate into side
holder to protect the belt against
damage.
Pull the loop on one or both backrests and fold them down onto the seat
cushion.
To fold up, raise the backrests into
upright position and let them engage
audibly.
The backrests are properly engaged
when the red marks on both release
loops are not visible.
9 Warning
When folding up, ensure that
backrests are securely locked in
position before driving. Failure to
do so may result in personal injury or damage to load or vehicle in the event of heavy braking or collision.
Hook for carrier bags
Use the hook at the right sidewall of
the load compartment for hanging up carrier bags. Maximum load: 5 kg.

54StorageRear storage
Storage box A closable storage box is located in
the load compartment. The cover is
lockable by turning the knob. It must be locked while driving.
To open, unlock and lift up the cover.
To remove the cover, open it and slide
sideways to the left.
The box can be separated by a
divider.
The storage box cover can be loaded with max. 20 kg.
Removal
To gain access to emergency
breakdown equipment or for bulb
replacement of the tail lights, the
storage box must be removed:
● Remove the load compartment cover 3 54.
● Fold down the rear backrests 3 53.
● Open the storage box.
● Turn the lock hooks on both sides
to the rear and push down the
lashing eyes in the recesses.
● Raise the storage box and place it on the folded backrests.
● Remove the storage box out of the load compartment.
Installation ● Place the storage box on the folded backrests.
● Lower the box in the load compartment.
● Open the storage box.
● Raise the lashing eyes on both sides and turn the lock hooks to
the front to fix the box to the
lashing eyes.
● Raise the rear backrests and install the load compartment
cover.
● Stow the suitcase with tyre repair
kit in a chamber of the storage
box.
● Close and lock the cover.
Load compartment cover
Do not place any objects on the cover.
Opening
