2019 NISSAN FRONTIER PRO-4X service indicator

3. While pulling up on the parking brakelever slightly, press the button
Band
lower the lever completely.
4. Before driving, be sure the brake warn- ing light goes out.
PRECAUTIONS ON CRUISE
CONTROL
1. ACCEL•RES switch
2. COAST•SET switch
3. CANCEL switch
4. ON•OFF switch
∙ If the cruise control system malfunc- tions, it cancels automatically. The SET
indicator light in the instrument panel
then blinks to warn the driver. ∙ If the SET indicator light blinks, turn the
ON•OFF switch off and have the system
checked. It is recommended that you
visit a NISSAN dealer for this service.
∙ The SET indicator light may blink when the ON•OFF switch is turned on while
pushing the ACCEL•RES, COAST•SET, or
CANCEL switch (located on the steering
wheel). To properly set the cruise con-
trol system, use the following proce-
dures.

∙ The system is designed as an aid tothe driver in detecting large station-
ary objects to help avoid damaging
the vehicle. The system will not detect
small objects below the bumper, and
may not detect objects close to the
bumper or on the ground.
∙ If your vehicle sustains damage to the rear bumper fascia, leaving it mis-
aligned or bent, the sensing zone may
be altered causing inaccurate mea-
surement of obstacles or false alarms.
The RSS sounds a tone to warn the driver of
obstacles near the rear bumper when the
shif t lever is in R (Reverse). The system may
not detect objects at speeds above 3 mph
(5 km/h) and may not detect certain angu-
lar or moving objects.
The RSS detects obstacles up to 5.9 f t
(1.8 m) from the rear bumper with a de-
creased coverage area at the outer cor-
ners of the bumper (refer to the illustration
for approximate zone coverage areas). As
you move closer to the obstacle, the rate of
the tone increases. When the obstacle is
less than 10 in (25.0 cm) away, the tone will
sound continuously. If the RSS detects a
stationary or receding object further than
10 in (25.0 cm) from the side of the vehicle, the tone will sound for only 3 seconds.
Once the system detects an object ap-
proaching, the tone will sound again.
The RSS automatically turns on when the
shif t lever is placed in R (Reverse) and the
ignition is ON. The RSS OFF switch on the
instrument panel allows the driver to turn
the RSS on and off. To turn the RSS off, the
ignition must be on, and the shif t lever in R
(Reverse). An indicator light on the switch
will illuminate when the system is turned
off. If the indicator light illuminates when
the RSS is not turned off, it may indicate a
malfunction in the RSS.
Keep the RSS sensors (located on the rear
bumper fascia) free from snow, ice and
large accumulations of dirt (do not clean
the sensors with sharp objects). If the sen-
sors are covered, it will affect the accuracy
of the RSS.FREEING A FROZEN DOOR LOCK
To prevent a door lock from freezing, apply
de-icer through the key hole. If the lock
becomes frozen, heat the key before in-
serting it into the key hole or use the re-
mote keyless entry key fob (if so equipped).
ANTIFREEZE
In the winter when it is anticipated that the
temperature will drop below 32°F (0°C),
check the antifreeze to assure proper win-
ter protection. For additional information,
refer to “Engine cooling system” in the “Do-
it-yourself ” section of this manual.
BATTERY
This vehicle is equipped with a sealed
maintenance free battery. It is recom-
mended that you visit a NISSAN dealer for
service.
DRAINING OF COOLANT WATER
If the vehicle is to be lef t outside without
antifreeze, drain the cooling system, includ-
ing the engine block. Refill before operating
the vehicle. For additional information, refer
to “Changing engine coolant” in the “Do-it-
yourself ” section of this manual.
COLD WEATHER DRIVING
Starting and driving5-43

∙ The original tires have built-intread wear indicators. When the
wear indicators are visible, the
tire(s) should be replaced.
∙ Tires degrade with age and use. Have tires, including the spare,
over 6 years old checked by a
qualified technician because
some tire damage may not be
obvious. Replace the tires as
necessary to prevent tire failure
and possible personal injury.
∙ Improper service of the spare tire may result in serious per-
sonal injury. If it is necessary to
repair the spare tire, it is recom-
mended that you visit a NISSAN
dealer for this service.
∙ For additional information re- garding tires, refer to “Impor-
tant Tire Safety Information”
(US) or “Tire Safety Information”
(Canada) in the Warranty Infor-
mation Booklet.
Replacing wheels and tires
When replacing a tire, use the same size,
tread design, speed rating and load carry- ing capacity as originally equipped. For ad-
ditional information, refer to “Wheels and
tires” in the “Technical and consumer infor-
mation” section of this manual.

Refrigerant recommendation.......10-12
Registering a vehicle in another
country .....................10-15
Remote keyless entry system ........3-6
Reporting safety defects (US only) . . . .10-44
Roofrack....................2-48
S
Safety Child safety rear door lock ........3-6
Childseatbelts.....1-28, 1-40, 1-56, 1-68
Reporting safety defects (US only) . .10-44
Seat Jumpseat...................1-7
Seat adjustment Front manual seat adjustment ......1-3
Front power seat adjustment ......1-5
Seatback pockets ...............2-41
Seat belt Childsafety.................1-25
Infants and small children ........1-26
InjuredPerson .............. .1-18
Largerchildren.............. .1-27
Precautions on seat belt usage .....1-15
Pregnant women .............1-18
Seat belt extenders ............1-24
Seat belt maintenance ..........1-25
Seatbelts................1-15, 7-7
Shoulder belt height adjustment . . . .1-24
Three-pointtypewithretractor.....1-18
Seat belt extenders ..............1-24
Seatbeltwarninglight.........1-18, 2-19
Seats Adjustment ..................1-2 Frontseats..................1-2
Manual front seat adjustment
......1-3
Rearseat...................1-6
Security indicator light ............2-22
Security system (NISSAN Vehicle Immobilizer
System), engine start ..........2-26,5-12
Security systems Vehicle security system .........2-24
Self-adjustingbrakes.............8-22
Service manual order form .........10-47
Servicing air conditioner ...........4-37
Settingbutton...............4-7,4-13
Shif ting Automatic transmission .........5-15
Manual transmission ...........5-19
Shiftlockrelease................5-17
Shoulder belt height adjustment ......1-24
Side air bag system
(See supplemental side air bag, curtain and
rollover air bag systems) ...........1-87
Siri® Eyes-Free ..............4-77,4-80
Smartphone connectivity ..........4-76
Sonar Rear system ................5-42
Spark plug replacement ...........
8
-18
Spark plugs ...................8-18
Specifications .................10-13
Speedometer ..................2-4
Speedometer and odometer ........2-4
SRS warning label ...............1-89
Stability control ................5-38
Standard maintenance ............9-7
Starting Before starting the engine ........5-13
Jumpstarting............6-12,8-16 Precautions when starting and
driving
.....................5-2
Push starting ................6-14
Starting the engine ............5-13
Starting the engine ..............5-13
Steering Powersteeringfluid............8-12
Power steering system ..........5-35
Tilting steering wheel ...........3-14
Steering wheel .................3-14
Steering wheel audio control switch . . .4-74
Stoplight....................8-30
Storage.....................2-40
Storagetray ..................2-43
Sunglasses case ................2-45
Sunglasses holder ..............2-45
Sunroof ...................2-52,7-5
Sunvisors....................3-15
Supplemental air bag warning labels . . .1-89
Supplemental air bag warning
light ....................1-90, 2-20
Supplemental front impact air bag
system......................1-81
Supplemental restraint system Information and warning labels . . . .1-89
Precautions on supplemental restraint
system ....................1-73
Supplemental restraint system
(Supplemental air bag system) .......1-73
Switch Autolightswitch..............2-30
Automatic power window switch . . .2-51
Clutch interlock (clutch start)
switch....................2-38
Electronic locking rear differential (E-Lock)
system switch ...............2-37
11-6
