2019 MAZDA MODEL MX-5 MIATA RF stop start

If a Warning Light Turns On or Flashes
If any warning light turns on/flashes, take appropriate action for each light. There is no
problem if the light turns off, h owever if the light does not turn off or turns on/flashes again,
consult an Authorized Mazda Dealer.
The details for some warnings can be viewed on the center display.
1. If the warning light is turned on, select
icon on the home screen to display the
application screen.
2. Select “Vehicle Status Monitor”.
3. Select “Warning Guidance” to display the current warnings.
4. Select the applicable warni ng to view the warning details.
▼Stop Vehicle in Safe Place Immediately
If any of the following warning
lights turns on, the system may have a malfunction. Stop the
vehicle in a safe place immediately and contact an Authorized M azda Dealer.
SignalWarning
Brake System Warning
Light This warning has the
following functions:
Parking brake warning/Warning light inspection
The light illuminates when the par king brake is applied with the ignition switched to
START or ON. It turns off when the parking brake is fully relea sed.
Low brake fluid level warning
If the brake warning light remains illuminated even though the parking brake is re‐
leased, the brake fluid may be l ow or there could be a problem with the brake system.
Park the vehicle in a safe place immediately and contact an Aut horized Mazda Dealer.
WA R N I N G
Do not drive with the brake system warning light illuminated. Contact an Authorized
Mazda Dealer to have the brakes inspected as soon as possible:
Driving with the brake system warning light illuminated is dangerous. It indicates that
your brakes may not work at all or that they could completely fail at any time. If this
light remains illuminated, after checking that the parking brake is fully released, have
the brakes inspected immediately.
CAUTION
In addition, the effectiveness of the braking may diminish so you may need to depress
the brake pedal more st rongly than normal to stop the vehicle.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-33
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

SignalWarning
Electronic Brake Force
Distribution System Wa r n i n g If the electronic brake force di
stribution control unit determines that some compo‐
nents are operating incorrectly , the control unit may illuminate the brake system
warning light and the ABS warni ng light simultaneously. The problem is likely to be
the electronic brake force distribution system.
WARNING
Do not drive with both the ABS warning light and brake warning light illuminated.
Have the vehicle towed to an Authorized Mazda Dealer to have the brakes inspected as
soon as possible:
Driving when the brake system warning li ght and ABS warning light are illuminated
simultaneously is dangerous.
When both lights are illuminate d, the rear wheels could lock more quickly in an emer‐
gency stop than under normal circumstances.
Charging System Warn‐ ing Indication/Warning Light If the warning light illuminates while driving, it indicates a
malfunction of the alter‐
nator or of the charging system.
Drive to the side of the road and park off the right-of-way. Co nsult an Authorized
Mazda Dealer.
CAUTION
Do not continue driving when the charging system warning light is illuminated be‐
cause the engine could stop unexpectedly.
Engine Oil Warning Light This warning light indicates low engine oil pressure.
CAUTION
Do not run the engine if the oil pressure is
low. Otherwise, it could result in extensive
engine damage.
If the light illuminates or the w arning indication is displayed while driving:
1. Drive to the side of the road and park off the right-of-way o n level ground.
2. Turn off the engine and wait 5 minutes for the oil to drain b ack into the oil pan.
3. Inspect the engine oil level (p age 6-23). If it's low, add the appropriate amount of
engine oil while being careful not to overfill.
CAUTION
Do not run the engine if the oil level is low. Otherwise, it could result in extensive
engine damage.
4. Start the engine and check the warning light.

If the light remains illuminated even though the oil level is normal or after adding oil,
stop the engine immediately and have your vehicle towed to an Authorized Mazda
Dealer.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-34
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

After performing this emergency
measure, have the vehicle inspected at
an Authorized Mazda Dealer as soon
as possible.

CAUTION
Do not pull the screw when pulling the cap.
Otherwise, the screw may fall off and
become lost.
Hardtop model
CAUTION
Do not touch the linkage and gears. If
sharp edges and gears are touched, it could
cause injury.
Roof operates electrically
1. Remove the antenna if it is installed.Refer to Antenna on page 5-17.
2. Start the engine.
3. Continue pressing the retractable hardtop switch in the open direction
until the rear roof is completely open.
Refer to Opening the Roof on page
3-41.
Multi-information
display indication
NOTE
Stop operating the switch before the
front roof opens. If the switch is
continuously pressed, the front roof
opens and the following procedures
cannot be performed.
4. Switch the ignition OFF.
5. Remove the fasteners on the right side of the vehicle.

If Trouble Arises
When Trunk Lid Cannot be Opened
7-54
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

6. Push the stopper rubber through thecover on the right si de of the vehicle
while slightly lifting the cover up.

Cover
Stopper Rubber
7. Lift up the cover from the outside of
the vehicle.

8. Insert your hand beneath the liftedcover and loosen the cap screws until
they spin freely.

NOTE
At this point, do not pull out the cap. If
the cap is pulled out, the trunk lock
will release but the rear roof will not
operate electrically.
9. Start the engine.
10. Continue pressing the retractable hardtop switch in the close direction
until the rear roof is completely closed.
Refer to Closing the Roof on page
3-42.

Multi-information
display indication
11. Switch the ignition OFF.
12. Remove the windblocker.
Windblocker
If Trouble Arises
When Trunk Lid Cannot be Opened
7-55
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

▼Safety Practices
The way you drive has a great deal to do with your tire mileage
and safety. So cultivate
good driving habits for your own benefit.
Observe posted speed limits and drive at speeds that are safe f or the existing weather
conditions
Avoid fast starts, stops and turns
Avoid potholes and objects on the road
Do not run over curbs or hit the tire against the curb when parking
CAUTION
If you feel a sudden vibration or ride disturbance while driving or you suspect your tire or
vehicle has been damaged, immediately reduce yo ur speed. Drive with caution until you can
safely pull off the road. Stop and inspect the tire for damage. If the tire is under-inflated or
damaged, deflate it, remove the tire and rim and replace it with your spare tire. If you cannot
detect a cause, have the vehicle towed to the ne arest vehicle or tire dealer to have the vehicle
inspected.
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
8-35
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

Index
Key battery.................................. 6-33
Light bulbs...................................6-39
Tires............................................. 6-37
Wheel........................................... 6-38
Wiper........................................... 6-27
Request Switch Inoperable Warning
Beep (With the advanced keyless
function)............................................ 7-51
Retractable hardtop warning beep..... 7-50
Rocking the Vehicle.......................... 3-50
S
Safety Defects, Reporting................. 8-14
Saving Fuel and Protection of the
Environment...................................... 3-48
Scheduled Maintenance...................... 6-4
Seat...................................................... 2-4
Seats Head restraint.............................. 2-10
Seat warmer................................. 2-11
Seat Belt System Automatic locking....................... 2-14
Emergency locking...................... 2-14
Extender....................................... 2-18
Pregnant women.......................... 2-14
Seat belt precautions................... 2-12
3-point type................................. 2-15
Seat Belt Warning Beep.................... 7-49
Seat Side Box....................................5-98
Security System Immobilizer system..................... 3-44
Theft-deterrent system................. 3-46
Smart City Brake Support
(SCBS)............................................ 4-100 Collision warning...................... 4-102
Smart City Brake Support (SCBS)
Indicator Light (Red).................4-102
Stopping the Smart City Brake
Support (SCBS) System
Operation................................... 4-102
Specifications...................................... 9-4
Speedometer...................................... 4-12
SRS Air BagsHow the SRS air bags work........ 2-39
Limitations to SRS air bag.......... 2-43
Monitoring................................... 2-49
Passenger occupant classification
system.......................................... 2-45
SRS air bag deployment
criteria.......................................... 2-42
Supplemental restraint system
components.................................. 2-37
Starting the Engine..............................4-5
Steering Wheel
Horn............................................. 4-55
Storage Compartments ...................... 5-98
Back trim storage box................. 5-99
Console box................................. 5-98
Seat side box............................... 5-98
Sunvisors........................................... 5-91
T
Tachometer........................................ 4-13
Theft-Deterrent System ..................... 3-46
Tiedown Hook............................................ 7-31
Tires................................................... 6-36 Flat tire.......................................... 7-3
Replacing a tire........................... 6-37
Replacing a wheel....................... 6-38
Snow tires.................................... 3-51
Specifications.................................9-8
Tire chains................................... 3-51
Tire inflation pressure................. 6-36
Tire rotation................................. 6-37
Uniform tire quality grading system
(UTQGS)..................................... 8-23
Tire Inflation Pressure Warning
Beep...................................................7-51
Tire Information................................ 8-25
10-7
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

Index
Tire Pressure Monitoring System.... 4-114
To w i n gRecreational towing.....................3-55
Trailer towing.............................. 3-55
Towing Description........................... 7-30
Traction Control System (TCS)........ 4-65 TCS/DSC indicator light............. 4-65
Traffic Sign Recognition System
(TSR)................................................. 4-91
Transmitter.......................................... 3-4
Trip Computer................................... 4-16
Trip Meter......................................... 4-12
Trouble Battery runs out........................... 7-23
Emergency starting...................... 7-26
Emergency towing....................... 7-30
Flat tire.......................................... 7-3
Overheating................................. 7-27
Parking in an emergency............... 7-2
When fuel-filler lid cannot be
opened..........................................7-29
When the roof cannot be
closed........................................... 7-58
When trunk lid cannot be
opened..........................................7-53
Trunk Lid.......................................... 3-19 Inside trunk release lever............ 3-21
When trunk lid cannot be
opened..........................................7-53
Turn Signals...................................... 4-49
V
Vanity Mirrors................................... 5-91
Vehicle Information Labels................. 9-2
W
Warning Lights.................................. 4-26
Warning Sound is Activated............. 7-49
Air bag/seat belt pr etensioner system
warning beep............................... 7-49
Blind Spot Monitoring (BSM)
System warning beep.................. 7-51
Collision warning...... .................. 7-52
Excessive speed warning.............7-52
Ignition not switched off (STOP)
warning beep............................... 7-50
Key left-in-trunk compartment
warning beep (With the advanced
keyless function)..........................7-51
Key left-in-vehicle warning beep
(With the advanced keyless
function).......................................7-51
Key removed from vehicle warning
beep..............................................7-50
Lane Departure Warning sound... 7-52
Lights-on reminder...................... 7-49
Power steering warning buzzer....7-51
Request switch inoperable warning
beep (With the advanced keyless
function).......................................7-51
Retractable hardtop warning
beep..............................................7-50
Seat belt warning beep................ 7-49
Tire inflation pressure warning
beep..............................................7-51
Warranty............................................ 8-16
Weights................................................ 9-6
Windblocker.................................... 5-100
Windows
Power windows........................... 3-31
Windshield Washer........................... 4-53
Windshield Wipers............................ 4-50
Winter Driving.................................. 3-50
Wiper Replacing windshield wiper
blades........................................... 6-28
10-8
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16
