3. Attach the removed cap to the innerside of the fuel-filler lid.

Fuel-filler cap
Fuel-filler lid
4. Insert the refuelin g nozzle all the way
and begin refueling. Pull out the
refueling nozzle after the refueling
stops automatically.
5. To close the fuel-filler cap, turn it
clockwise until a click is heard.
6. To close, press the fuel-filler lid until it
locks securely.

CAUTION
(U.S.A. and Canada)
If the check fuel cap warning light
illuminates, the fuel-filler cap may not be
properly installed. If the warning light
illuminates, park your vehicle safely off the
right-of-way, remove th e fuel-filler cap and
reinstall it correctly. After the cap has been
correctly installed, the fuel cap warning
light may continue to illuminate until a
number of driving cycles have been
completed. A drive cycle consists of starting
the engine (after four or more hours with
the engine off) and driving the vehicle on
city and highway roads.
Continuing to drive with the check fuel cap
warning light illuminated could cause the
check engine light to illuminate as well.
Before Driving
Fuel and Emission
3-31
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

Mirrors
Before driving, adjust the inside and
outside mirrors.
▼Outside Mirrors
WA R N I N G
Be sure to look over your shoulder before
changing lanes:
Changing lanes without taking into
account the actual distance of the vehicle
in the convex mirror is dangerous. You
could have a serious accident. What you
see in the convex mirror is closer than it
appears.
Mirror type
Flat type (driver's side)
Flat surface mirror.
Convex type (front passenger side)
The mirror has single curvature on its
surface.
Power mirror adjustment
The ignition must be switched to ACC or
ON position.

To adjust:
1. Rotate the mirror switch to the left
or
right
to choose the left or right side
mirror.
2. Press the mirro r switch in the
appropriate direction.
Center position
Mirror switch
After adjusting the mirror, lock the control
by rotating the switch in the center
position.
Folding outside mirror
WA R N I N G
Always return the outside mirrors to the
driving position before you start driving:
Driving with the outsid e mirrors folded in is
dangerous. Your re ar view will be
restricted, and you could have an accident.
Manual folding outside mirror
Fold the outside mirro r rearward until it is
flush with the vehicle.
Before Driving
Mirrors
3-32
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

Power folding outside mirror
WA R N I N G
Do not touch a power folding outside
mirror while it is moving:
Touching the power folding outside mirror
when it is moving is dangerous. Your hand
could be pinched and injured or the mirror
could be damaged.
Use the outside mirror switch to set the
mirror to the on-road position:
Setting the power folding outside mirror to
the on-road position by hand is dangerous.
The mirror will not lock in position and will
prevent effective rearview visibility.
Only operate the power folding outside
mirror with the vehicle safely parked:
Operating the power folding outside mirror
while the vehicle is moving is dangerous.
Wind blast on the mirror will cause them to
collapse and you will be unable to return it
to the on-road position, preventing
rearview visibility.
The ignition must be switched to ACC or
ON position.
To fold, rotate the outside mirror switch.
To return the mirror to the driving
position, rotate the switch to the center
position.
Fold-in position
Center position
Automatic folding function
The automatic folding function operates
when the ignition is switched to OFF.
When the outside mir ror switch is in a
position other than the fold-in position, the
outside mirrors automatically fold in and
out when the doors are locked and
unlocked.
Also, when the ignition is switched ON or
the engine is started, the outside mirrors
fold out automatically.
NOTE
The outside mirrors may not fold in and
out automatically under cold weather
conditions.
If the outside mirrors do not fold in and
out automatically, remove any ice or snow,
and then operate the outside mirror switch
to fold the outside mirrors in or out.
Before Driving
Mirrors
3-33
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

Canceling the automatic folding
function
To cancel the automatic folding function,
carry out the following procedure using
the master con trol switches.
1. Switch the ignition ON.
2. If the power window lock switch is in the unlock position, switch it to the
lock position.
3. Press and hold the front passenger's power window switch and rear left/
right power window switches on the
driver's door at t he same time for 3
seconds or longer.
NOTE
The automatic folding function cannot
be canceled if the procedure is not
completed within the specified times, or
the procedure is changed along the way.
To redo the procedure, first switch the
ignition off and proceed from the
beginning.
If you are unable to cancel the function
despite doing the cancellation
procedure, consult an Authorized Mazda
Dealer.
Restoring the au tomatic folding
function
With the automatic folding function in the
canceled state, repeat the previous
procedure for canceling the function and it
will be restored.
NOTE
If you are unable to restore the function
despite carrying out the restore procedure,
consult an Authorized Mazda Dealer.
Engine-off outside mirror operation*
The outside mirrors can be operated for
about 40 seconds after the ignition is
switched from ON to off.
▼Rearview Mirror
WA R N I N G
Do not stack cargo or objects higher than
the seatbacks:
Cargo stacked higher than the seatbacks is
dangerous. It can block your view in the
rearview mirror, which might cause you to
hit another car when changing lanes.
Rearview mirror adjustment
Before driving, adjust the rearview mirror
to center on the scene through the rear
window.

NOTE
For the manual day/night mirror, perform
the adjustment with the day/night lever in
the day position.
Before Driving
Mirrors
3-34*Some models.
CX-5_8HE3-EA-18I_Edition1
2018-6-29 13:44:47

Reducing glare from headlights
Manual day/night mirror
Push the day/night lever forward for day
driving. Pull it back to reduce glare of
headlights from vehicles at the rear.

Day/Night lever
Day
Night
Auto-dimming mirror
(With Homelink wireless control
system)
The auto-dimming m irror automatically
reduces the glare of headlights from
vehicles at the rear when the ignition is
switched ON.

(Type A)
Press the OFF button (
) to cancel the
auto-dimming function . The indicator light
will turn off.
To reactivate the auto-dimming function,
press the ON button (
). The indicator
light will illuminate.
Indicator lightOFF button
ON button

(Type B)
Press the ON/OFF button (
) to cancel the
auto-dimming function . The indicator light
will turn off.
To reactivate the auto -dimming function,
press the ON/OFF button (
). The
indicator light will illuminate.
Indicator light
ON/OFF button
(Without Homelink wireless control
system)
The auto-dimming mirror automatically
reduces the glare of headlights from
vehicles at the rear when the ignition is
switched ON.
NOTE
Do not use glass cleaner or suspend
objects on or around the light sensor.
Otherwise, light sensor sensitivity will
be affected and may not operate
normally.
(With Homelink wireless control
system)
(Type A)
Light sensor
Before Driving
Mirrors
3-35
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

(Type B)
Light sensor
(Without Homelink wireless control
system)

Light sensor
(With Homelink wireless control
system)
For information regarding the 3 buttons
(Type A
,,/Type B , , )
on the auto-dimming mirror.
Refer to HomeLink Wireless Control
System on page 4-85.
The auto-dimming function is canceled
when the ignition is switched ON and
the selector lever is in the R position.
Before Driving
Mirrors
3-36
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

Power Windows
The windows can be opened/closed by operating the power window switches.
WA R N I N G
Make sure the opening is clear before closing a window:
Closing a power window is dangerous. A person's hands, head, or even neck could be caught
by the window and result in serious injury or even death. This warning applies especially to
children.
Never allow children to play with power window switches:
Power window switches that are not locked wi th the power window lock switch would allow
children to operate power windows unintentionally , which could result in serious injury if a
child's hands, head or neck becomes caught by the window.
Make sure nothing blocks the window just before it reaches the fully closed position or while
fully holding up the power window switch:
Blocking the power window just before it reach es the fully closed position or while fully
holding up the power window switch is dangerous.
In this case, the jam-safe function cannot prevent the window from closing all the way. If
fingers are caught, serious injuries could occur.
NOTE
When driving with only 1 of the rear windows open, your ears might experience a
resonating sound. However, this does not indicate a problem. The sound can be reduced by
slightly opening a front window or by changi ng the size of the rear window opening.
Before Driving
Windows
3-37
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

▼Opening/Closing Windows
The window opens while the switch is pressed and it closes whil
e the switch is pulled up
with the ignition switched ON. Do not open or close 3 or more w indows at the same time.
The front passenger's side and rear windows can be opened/close d when the power window
lock switch on the driver's door is in the unlock position. Kee p this switch in the locked
position while children are in the vehicle.

Close
Close
Open
Open
Right rear window
Driver's
window
Power window
lock switch
Master control switches
Front passenger's
window switch
Locked position
Unlocked position
Front passenger's
window
Left rear
window
Rear window switches
NOTE
A power window may no longer open/close if you continue to press the switch after fully
opening/closing the power window. If the po
wer window does not open/close, wait a
moment and then operate the switch again.
The passenger windows may be opened or closed using the master control switches on the
driver's door.
The power window can be operated for about 40 seconds after the ignition is switched
from ON to ACC or off with all doors closed. If any door is opened, the power window
will stop operating.
For engine-off operation of the power window, the switch must be held up firmly
throughout window closure because the aut o-closing function will be inoperable.
When the power window lock switch is in th e locked position, the light on each power
window switch, except for the driver's power window switch, turns off. The light may be
difficult to see depending on the surrounding brightness.
