2019 LEXUS RX350 glove box

530 6-4. Using the storage features
RX350/RX350L_U Open (press the button)
Unlock with the mechanical key
Lock with the mechanical key
The glove box light turns on when the tail lights are on.
Push the knob. Lift by hand to fully open the console
box.
●
The console box light turns on when the tail lights are on.Glove box 1
2
3
Console box ●
A pen can be stored in the pen holder on the
underside of the lid.
●
Remove the tray to access a storage space
under the tray.

618 7-3. Do-it-yourself maintenance
RX350/RX350L_U Turn the engine switch off.
Open the glove box. Slide off the
damper.
Push in the glove box on the vehicle’s
outer side to disconnect the claws.
Then pull out the glove box and dis-
connect the lower claws.
Remove the cover.Air conditioning filter The air conditioning filter must be ch anged regularly to maintain air condi-
tioning efficiency.
Removal method 1
2
3
4

6678-2. Steps to take in an emergency
8
When trouble arises
RX350/RX350L_U 
RX350
* : Documentation relating to the wheel lock key, such as the registration and I.D. card, is
inside the glove box.Location of the spare tire, jack and tools
Jack handle
Wheel nut wrench
Spare tire Jack
Towing eyelet (if equipped)
Wheel lock key* (if equipped)1
2
3 4
5
6

764 Alphabetical index
RX350/RX350L_U Garage door opener .......................... 557
Gauges ........................................................ 86
Glove box ................................................530
Grocery bag hooks ............................. 537
Hands-free system
(for cellular phone) ........................... 455
Head restraints ........................................ 177
Head-up display..................................... 108
Headlight cleaner...................................261
Headlights ............................................... 252
Automatic headlight leveling .......254
Automatic High Beam ....................256
Light switch ........................................... 252
Replacing light bulbs ....................... 630
Wattage ................................................. 705
Windshield wiper linked
headlight illumination................... 255
Heated steering wheel ....................... 522 Heaters
Automatic air conditioning
system .......................................503, 518
Heated steering wheel ................... 522
Outside rear view mirrors ..............513
Seat heaters .............................. 522, 523
High mounted stoplight
Replacing ...............................................630
Hill-start assist control ....................... 378
Hood ......................................................... 592
Hooks
Cargo hooks .......................................536
Cargo net hooks ...............................536
Front passenger footwell
hooks....................................................554
Grocery bag hooks ......................... 537
Retaining hooks (floor mat)............. 28
Horn............................................................ 180
HUD (Head-up display)..................... 108G
H
