2019 Lexus ES300h engine oil capacity

13Pictorial index
Precautions against winter season ............................................................................ P.244
To prevent freezing (windshield wiper de-icer)
*................................................. P.257
Precautions against car wash ....................................................................................... P.301
Fuel filler door ........................................................................................................... P.16 1
Refueling method ............................................................................................................... .P.161
Fuel type/fuel tank capacity ...... ...................................................................................P.395
Tires.......................................................................................................................... ..P.326
Tire size/inflation pressure ........................................................................................... P.399
Winter tires/tire chain .................................................................................................... P.24 2
Checking/rotation/tire pressure warning system.............................................. P.326
Coping with flat tires........................................................................................................ P .372
Hood ........................................................................................................................... P.316
Opening ........................................................................................................................ ........ P.316
Engine oil ..................................................................................................................... ......... P.396
Coping with overheating ...............................................................................................P.389
Warning messages ..........................................................................................................P.368
Headlights/side marker lights/cornering lights............................................P.150
Turn signal lights ...................................................................................................... P.145
Parking lights/daytime running lights...............................................................P.150
Tail/stop lights ..........................................................................................................P.150
License plate lights .................................................................................................P.150
Back up lights
Shifting the shift lever to R ...............................................................................................P.1 42
*:If equipped
Light bulbs of the exterior lights for driving
(Replacing method: P.344, Watts: P.400)
E
F
G
H
I
J
K
L

1314-1. Before driving
4
Driving
Cargo capacity depends on the total
weight of the occupants.
(Cargo capacity) = (Total load capac-
ity)  (Total weight of occupants)
NOTICE
●Changes in quantity and quality of oil
and fluid used for the engine, hybrid
transmission, etc.
●Lubricant condition for the bearings
and suspension joints (where possi-
ble), and the function of all joints, bear-
ings, etc.
■When parking the vehicle
Always set the parking brake, and shift
the shift lever to P. Failure to do so may
cause the vehicle to move or the vehicle
may accelerate sudden ly if the accelera-
tor pedal is accidentally depressed.
Cargo and luggage
Take notice of the following infor-
mation about storage precautions,
cargo capacity and load:
WARNING
■Things that must not be carried in the
trunk
The following things may cause a fire if
loaded in the trunk:
●Receptacles containing gasoline
●Aerosol cans
■Storage precautions
Observe the following precautions.
Failure to do so may prevent the pedals
from being depressed properly, may
block the driver’s vision, or may result in
items hitting the driver or passengers,
possibly causing an accident.
●Stow cargo and luggage in the trunk
whenever possible.
●Do not place cargo or luggage in or on
the following locations.
• At the feet of the driver
• On the front passenger or rear seats (when stacking items)
• On the package tray
• On the instrument panel
• On the dashboard
• In front of the Center Display
●Secure all items in the occupant com-
partment.
Capacity and distribution

3968-1. Specifications
■Oil capacity (Drain and refill [Ref-
erence
*])
*: The engine oil capacity is a reference quantity to be used when changing the
engine oil. Warm up the engine and turn
off the hybrid system, wait more than 5
minutes, and check the oil level on the
dipstick.
■Engine oil selection
“Toyota Genuine Motor Oil” is used in
your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor Oil”
or equivalent to satisfy the following
grade and viscosity.
Oil grade: API SN/RC multigrade
engine oil
Recommended viscosity: SAE 0W-16 SAE 0W-16 is the best choice for good
fuel economy and good
starting in cold
weather.
If SAE 0W-16 is not available, SAE
0W-20 oil may be used. However, it
must be replaced with SAE 0W-16 at
the next oil change.
Outside temperature
Oil viscosity (0W-16 is explained here
as an example):
• The 0W in 0W-16 indicates the characteristic of the oil which allows
Electric motor (traction motor)
TypePermanent magnet synchronous motor
Maximum output88 kW
Maximum torque149 ft•lbf (202 N•m, 20.6 kgf•m)
Hybrid battery (traction battery)
TypeNickel-metal hydride battery
Voltage7.2 V/cell
Capacity6.5 Ah (3HR)
Quantity34 modules
Overall voltage244.8 V
Lubrication system
With filter4.8 qt. (4.5 L, 4.0 Imp.qt.)
Without filter4.4 qt. (4.2 L, 3.7 Imp.qt.)
A

3978-1. Specifications
8
Vehicle specifications
cold startability. Oils with a lower
value before the W allow for easier
starting of the engine in cold
weather.
• The 16 in 0W-16 indicates the vis- cosity characteristic of the oil when
the oil is at high temperature. An oil
with a higher viscosity (one with a
higher value) may be better suited if
the vehicle is operated at high
speeds, or under extreme load con-
ditions. How to read oil container label:
API registered marks is added to some
oil containers to help you select the oil
you should use.
*: The fluid capacity is a reference quantity.
If replacement is necessary, contact your Lexus dealer.
■Spark plug
Cooling system
Capacity*
Gasoline engine
6.4 qt. (6.1 L, 5.4 Imp.qt.)
Power control unit
1.9 qt. (1.8 L, 1.6 Imp.qt.)
Coolant type
Use either of the following:
 “Toyota Super Long Life Coolant”
 Similar high-quality ethylene glycol-
based non-silicate, non-amine, non-
nitrite, and non-borate coolant with long-
life hybrid organic acid technology
Do not use plain water alone.
Ignition system
MakeDENSO FC16HR-Q8
Gap0.031 in. (0.8 mm)

4078-1. Specifications
8
Vehicle specifications
■Traction AA, A, B, C
The traction grades, from highest to
lowest, are AA, A, B and C, and they
represent the tire’s ability to stop on
wet pavement as measured under con-
trolled conditions on specified govern-
ment test surfaces of asphalt and
concrete.
A tire marked C may have poor traction
performance.
Warning: The traction grade assigned to
this tire is based on braking (straight
ahead) traction tests and does not include
cornering (turning) traction.
■Temperature A, B, C
The temperature grades are A (the
highest), B, and C, representing the
tire’s resistance to the generation of
heat and its ability to dissipate heat when tested under controlled condi-
tions on a specified indoor laboratory
test wheel.
Sustained high temperature can cause the
material of the tire to degenerate and
reduce tire life, and excessive temperature
can lead to sudd
en tire failure.
Grade C corresponds to a level of perfor-
mance which all passenger car tires must
meet under the Fede ral Motor Vehicle
Safety Standard No. 109.
Grades B and A represent higher levels of
performance on the laboratory test wheel
than the minimum required by law.
Warning: The temperature grades of a tire
assume that it is properly inflated and not
overloaded.
Excessive speed, unde rinflation, or exces-
sive loading, either separately or in combi-
nation, can cause heat buildup and
possible tire failure.
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation
pressureTire pressure when the vehicle has been parked for three hours or
more, or has not been driven more than 1 mile or 1.5 km under that
condition
Maximum inflation
pressureThe maximum cold inflated pressure to which a tire may be inflated,
shown on the sidewall of the tire
Recommended
inflation pressureCold tire inflation pressure recommended by a manufacturer
Accessory weight
The combined weight (in excess of those standard items which may
be replaced) of hybrid transmissi on, power steering, power brakes,
power windows, power se ats, radio and heater, to the extent that
these items are available as factory-installed equipment (whether
installed or not)
Curb weight
The weight of a motor vehicle with standard equipment, including the
maximum capacity of fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional engine

442Alphabetical index
Exterior .......................................................... 300
Interior .............................................................303
Seat belts........................................................303
Cargo capacity...............................................133
Cargo hooks ................................................... 271
Center Display ............................................. 246
Chains .............................................................. 243
Child-protectors............................................. 94
Child restraint system................................... 42 Fixed with a LATCH system .................. 49
Fixed with a seat belt................................... 46
Front passenger occupant classification system ..............................................................37
Points to remember .....................................42
Riding with children ......................................42
Types of child restraint system installation method ........................................................... 43
Using an anchor bracket ............................ 51
Child safety ....................................................... 42 12-volt battery precautions ....... 324, 387
Airbag precautions...................................... 33
Child restraint system................................. 43
Heated steering wheel and seat heater
precautions.................................................. 261
How your child should wear the seat belt ............................................................................ 25
Moon roof precautions ............................ 123
Power window lock switch.......................121
Power window precautions .....................121
Rear door child-protectors ..................... 94
Removed electronic key battery precau- tions ...............................................................340
Seat belt extender precautions ............. 25
Seat belt precautions ...................................42
Trunk precautions ........................................ 95
Cleaning.............................................. 300, 303 Aluminum wheels ..................................... 300
Exterior .......................................................... 300
Interior .............................................................303
Radar sensor.......................................163, 198
Seat belts........................................................303
Clock ........................................................ 70, 272 Coat hooks..................................................... 283
Compass ......................................................... 289
Condenser .......................................................321
Console box .................................................. 269
Console box light ........................................ 269
Cooling system............................................. 320
Engine overheating.................................. 389
Hybrid system overheating ................. 390
Cornering lights .............................................152 Replacing light bulbs ................................344
Cruise control Dynamic radar cruise control with full-
speed range ............................................... 187
Cup holder ..................................................... 269
Current fuel consumption ...........................74
Curtain shield airbags .................................. 28
Customizable features ................................ 412
D
Daytime running light system .................. 150
Defogger Outside rear view mirrors.....................254
Rear window ................................................254
Windshield ....................................................254
Dimension ...................................................... 394
Dinghy towing.................................................134
Display BSM (Blind Spot Monitor)......................197
Dynamic radar cruise control with full-
speed range ............................................... 187
Energy monitor ............................................... 81
Head-up display.............................................77
Intuitive parking assist ............................. 205
LTA (Lane-Tracing Assist) ...................... 181
Multi-information display .......................... 73
Parking Support Brake function (rear
pedestrians)............................................... 233
RCD (Rear Camera Detection) ......... 215
RCTA.................................................................. 211
Warning message .................................... 368
Distance until next engine oil change .....72
Do-it-yourself maintenance ..................... 310

444Alphabetical index
Ignition switch (power switch) ..............135
Overheating.................................................389
Power switch .................................................135
Tachometer ..................................................... 70
Engine coolant.............................................. 320 Capacity ......................................................... 397
Checking ....................................................... 320
Preparing and checking before winter......................................................................... 242
Engine coolant temperature gauge ....... 70
Engine oil ......................................................... 318 Capacity .........................................................396
Checking ........................................................ 318
Preparing and checking before winter......................................................................... 242
Warning light ...............................................359
Engine oil maintenance data .................. 320
EPS (Electric Power Steering) .............. 236 Function .......................................................... 236
Warning light ...............................................360
EV drive mode................................................139
Event data recorder (EDR) ........................... 8
EV indicator ...................................................... 54
F
Flat tire ............................................................. 372 Tire pressure warning system ............. 328
Floor mats ...........................................................22
Fluid Brake................................................................398
Hybrid transmission .................................398
Washer ........................................................... 322
Footwell light ................................................. 265
Front passenger occupant classification system ...............................................................37
Front seats ....................................................... 109
Adjustment..................................................... 109
Cleaning.........................................................303
Correct driving posture .............................23
Driving position memory .......................... 110
Head restraints .............................................. 113
Memory recall function ............................... 111 Power easy access system ...................... 110
Seat heaters ....................................................261
Seat position memory ................................ 110
Seat ventilators ..............................................261
Front side marker light ............................... 150 Light switch .................................................... 150
Front side marker lights Replacing light bulbs ....................344, 345
Front turn signal lights .................................145 Replacing light bulbs ....................344, 345
Turn signal lever .......................................... 145
Fuel ....................................................................... 161 Capacity ........................................................ 395
Fuel gauge ........................................................ 70
Information ..................................................... 401
Refueling............................................................ 161
Type ................................................................. 395
Warning light ................................................ 361
Fuel consumption Average fuel economy .............................. 74
Current fuel consumption ........................ 74
Fuel filler door .................................................. 161 If the fuel filler do or cannot be opened
........................................................................... 381
Refueling............................................................ 161
Fuel gauge ......................................................... 70
Fuses ...................................................................341
G
Garage door opener ................................. 284
Gauges ............................................................... 70
Glove box ....................................................... 269
Glove box light ............................................. 269
Grocery bag hooks ...................................... 271
H
Hands Free Power Trunk Lid .................... 98
Headlights ....................................................... 150 Adaptive Front-lighting System (AFS)........................................................................... 152
Automatic High Beam system ............. 153

452Alphabetical index
V
Vanity lights.....................................................272
Vanity mirrors ................................................272
Vehicle data recordings ..................................7
Vehicle identification number ................ 394
Vehicle Stability Control (VSC) ........... 236
Ventilators (seat ventilators)..................... 261
VSC (Vehicle Stability Control) ........... 236
W
Warning buzzers
ABS ..................................................................360
Airbags ...........................................................359
Approach warning......................................193
Brake hold.....................................................365
Brake Override System .........................360
Brake system .............................................. 358
Charging system .......................................359
Downshifting ....................................... 144, 145
Drive-Start Control ..................................360
Electric power steering ..........................360
Engine .............................................................359
High coolant temperature ................... 358
Hybrid system overheat.........................365
Hybrid system .............................................359
Intuitive parking assist....................210, 362
Low engine oil pressure.........................359
LTA (Lane Tracing Assist).......... 176, 362
Open door.............................................. 92, 94
Open hood...................................................... 94
Open trunk ...................................................... 94
Open window .................................................121
PKSA (Parking Support Alert) ........... 204
PKSB (Parking Support Brake) ......... 363
Pre-collision braking..................................169
RCD (Rear Camera Detection) ........ 363
RCTA (Rear Cross Traffic Alert) ...... 363
Seat belt ............................................................361
Warning label .................................................. 56
Warning lights...............................................358 ABS ..................................................................360 Brake hold operated indicator .......... 365
Brake Override System ........................ 360
Brake system............................................... 358
Charging system....................................... 359
Drive-Start Control.................................. 360
Electric power steering.......................... 360
High coolant temperature.................... 358
Hybrid system overheat ........................ 365
Intuitive parking assist OFF indicator362
Low engine oil pressure........................ 359
Low fuel level ................................................ 361
LTA indicator ...............................................362
Malfunction indicator lamp .................. 359
Master warning light................................ 365
Parking brake indicator ..........................364
PKSB OFF indicator ................................363
Pre-collision system..................................364
RCD OFF indicator..................................363
RCTA OFF indicator ...............................363
Seat belt reminder light............................ 361
Slip indicator .................................................364
SRS ................................................................... 359
Tire pressure ................................................362
Warning messages ..................................... 368
Washer ............................................................. 155 Checking ....................................................... 322
Preparing and checking before winter.......................................................................... 242
Switch................................................................ 155
Washing and waxing..................................300
Weight Cargo capacity ............................................ 133
Load limits ...................................................... 133
Weight.............................................................394
Wheel lock key............................................. 373
Wheels ............................................................. 336 Size ................................................................... 399
Window lock switch ...................................... 121
Windows ...........................................................120 Power windows ........................................... 120
Rear window defogger...........................254
Washer ............................................................ 155
