2019 INFINITI QX30 Quick Reference Guide

6
Meters and Gauges
Speedometer
Fuel gauge
Vehicle information display
Shift lever indicator
Tachometer
Engine coolant temperature gauge

7
Hood Latch
To open the hood, pull the hood release handle located
below the instrument panel . Slightly lift the hood upward
and pull the lever to the left to unlock the hood. Then insert
the support rod into the slot.
To close the hood, drop it from a height of 8-12 inches
(20-30 cm). If the hood sensor detects the hood is not
completely latched shut, the wipers will not function.
Please see your Owner’s Manual for important safety information, system
limitations, and additional operating and feature information.
Sun Visors
Pull down the sun visor to block glare from the front.
Remove the sun visor from the center mount by lifting
it slightly and swing it to the side to block glare from
the side window.
Slide the sun visor out from the mount to further
extend the visor location.
Please see your Owner’s Manual for important safety information, system
limitations, and additional operating and feature information.
To apply the parking brake, press the
electric parking brake handle
located
below the instrument panel, regardless of
the ignition switch position.
To release the parking brake, pull the
electric parking brake handle
toward
you while the ignition is on. The parking
brake will be automatically released when
you depress the accelerator pedal as long
as certain conditions are met, such as
having your seatbelt fastened.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating
and feature information.
Parking Brake

8
MANUAL SEAT ADJUSTMENTS (IF SO EQUIPPED)
Forward and backward adjustment:
Pull the lever
, located under the seat, up and hold it while sliding
the seat forward or backward and release it to lock the seat in the
preferred position. When returning the seatback to the upright position,
always be certain it is completely secured in the latched position.
Seat angle adjustment:
Turn the hand-wheel
forward or backward to adjust the angles so
that your thighs are lightly supported.
Seat lifter:
Repeatedly pull up or push down the adjusting lever
to adjust the
seat height to the desired position.
Seatback angle:
Relieve the pressure on the seatback and turn the hand-wheel

forward or backward to adjust the seatback angle.
Seat Adjustments
LUMBAR SUPPORT
Push each side of the adjusting switch
to adjust the seat lumbar area
until the desired position is achieved.
POWER SEAT ADJUSTMENTS (IF SO EQUIPPED)
Forward and backward adjustment:
Move the adjusting switch
, located on the door, forward or backward
to the desired position.
Reclining:
Move the adjusting switch
forward or backward to the desired position.
Seat lifter (if so equipped):
1.


Pull up or

push down the adjusting switch
to adjust the seat
height until the desired position is achieved.
2.


T

ilt up or down the adjusting switch
to adjust the front angle of
the seat until the desired position is achieved.
Please see your Owner’s Manual for important safety information, system limitations, and
additional operating and feature information.

9
Head Restraint Adjustment
(if so equipped)
To raise the head restraint:
Pull the head restraint up.
To lower the head restraint:
Push and hold the lock knob
and push the head
restraint down.
To move the head restraint forward:
Pull the head restraint toward the front of the vehicle until
it engages in one of the detents.
To move the head restraint backward:
Press and hold the button
and push the head
restraint backward until it is in the desired position, then
release the button.
Make sure the head restraint is fully engaged in position
after any adjustment.
Please see your Owner’s Manual for important safety information, system
limitations, and additional operating and feature information.
Lane Departure Warning (LDW)
(if so equipped)
LDW warns you if the vehicle is beginning to leave the traveling lane. If a front
wheel passes over a lane marking, LDW will warn you through a visual alert and
an intermittent vibration in the steering wheel for up to 1.5 seconds.
To enable or disable LDW:
Press the
or button on the steering wheel to select the DriveAssist
menu
in the vehicle information display.
Press the
or button on the steering wheel to select Lane Departure
Warning and press the OK button
on the steering wheel.
Press the OK button
on the steering wheel to change the selection to Off,
Adaptive or Standard
.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.

10
Wiper and Washer Switch
Left-hand parking lights switched on.
Right-hand parking lights switched on.
Side lights, license plate lights and combination meter lighting
switched on.
Automatic headlight mode (headlights switch on/off automatically
depending on ambient light conditions/daytime light system)
switched on.
Low beam/high beam headlights. Select dipped beam or high beam
headlights using the combination switch (see hereafter).
Rear fog light switch
Front fog light switch (if so equipped)
For normal headlight operation, leave the exterior light switch in the
AUTO position.
Please see your Owner’s Manual for important safety information, system limitations, and
additional operating and feature information.
Exterior Light Operation
Turn the switch to one of the following positions to operate
the windshield wipers:
Continuous wipe, fast.
Continuous wipe, slow.
Intermittent wipe, high rain sensor (if so equipped) or speed sensor sensitivity.
Intermittent wipe, low rain sensor (if so equipped) or speed sensor sensitivity.

Wipers are OFF.
Press button
in to the first detent for a single wipe, or in to the
second detent to operate the windshield washer and wipers.
REAR WIPER AND WASHER
Turn the rear wiper switch
to one of the following positions
to operate the rear wiper (shown in the order they appear on the
wiper switch):
Wipes with w asher fluid, then returns to intermittent wiping.
Intermittent wiping.
Wiper is OFF.
Wipes with washer fluid, then returns to off.
Please see your Owner’s Manual for important safety information, system limitations,
and additional operating and feature information.

11
To adjust the time and the appearance of the clock on the display:
Pr
ess the MENU button
on the Infiniti controller. Then, touch the “Settings”
key on the display.
Locate and touch the “Clock” key to adjust “On-Screen Clock”, “Daylight
Savings Time”, “Clock Format (24h)” and “Time Zone”.
The time can be adjusted through “Offset Adjustment”
by adjusting the
minutes and/or hours forward or backward. The current clock time can be set
up to a difference of 12 hours and 59 minutes.
Please see your INFINITI InTouch™ Owner’s Manual for important safety information, system limitations,
and additional operating and feature information.
Clock Set/Adjustment
Your vehicle is equipped with two USB ports, located under
the control panel, to which you can connect compatible
devices (cellular phones, iPod
® devices, other compatible
audio devices, USB memory sticks, etc.).
After connecting your device through one of the USB ports,
press the MEDIA button on the control panel to select audio
playback from the device connected through the USB ports.
A second device can be connected for charging. In order
to switch to the second device for audio playback, both
devices will need to be removed and the second device
reconnected first.
Please see your INFINITI InTouch™ Owner’s Manual for important safety
information, system limitations, and additional operating and feature information.
USB Connection Port

12
Electronic Shift Lever
Fuel-filler Door
To open the fuel-filler door,
unlock the vehicle and
gently push the front side
of the fuel-filler door.
Please see your Owner’s Manual
for important safety information,
system limitations, and additional
operating and feature information.
Opening the Liftgate
To open the liftgate, press the
button on the Intelligent
Key and then push the liftgate
release
. The liftgate also
automatically unlocks if you
are carrying the Intelligent
Key and push the liftgate
request switch
.
Please see your Owner’s Manual for
important safety information, system
limitations, and additional operating and feature information.
To put the vehicle in N (Neutral):
Push the electronic shift lever forward
until you feel resistance and release the
shift lever, or pull the electronic shift lever
back until you feel resistance and release
the shift lever.
To put the vehicle in R (Reverse):
Push the electronic shift lever forward
past the point of resistance and release
the shift lever.
To put the vehicle in D (Drive):
Pull the electronic shift lever back past
the point of resistance and release the
shift lever.
To put the vehicle in P (Park):
Make sure the vehicle is completely
stopped and press the P (Park) button
.
If you switch the ignition off with the transmission in D (Drive) or R (Reverse), the
transmission automatically shifts into N (Neutral).
If you open the driver’s door while the vehicle is stationary or moving at a very
low-speed, the vehicle automatically switches into the P (Park) position.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.

13
Idle Stop/Start (ISS)
The ISS activates when certain conditions are met to prevent
unnecessary fuel consumption, exhaust emissions and noise.
To activate the ISS system:
•

Bring the
vehicle to a complete stop.
To restart the engine when the ISS system is active:
•


When the ISS s
ystem is active, the engine will restart as soon as you
take your foot off the brake pedal.
An ISS indicator light in the vehicle information display
will inform
you of the ISS status. The system can be temporarily deactivated
by pushing the Idle Stop/Start system on/off switch
on the
instrument panel.
Please see your Owner’s Manual for important safety information, system limitations, and
additional operating and feature information.
All power windows can be operated through
the main switch on the driver’s door.
Power windows open/close.
Disable rear passenger window
operation by rear passengers.
Windows
POWER WINDOW CONVENIENCE
OPENING/CLOSING FEATURE
The vehicle can be locked/unlocked and
the power windows can be closed/opened
simultaneously from outside the vehicle
using the Intelligent Key as follows:
To lock the vehicle and close the power
windows simultaneously, touch the sensor
surface
on the door handle until the
windows are fully closed.
To unlock the vehicle and open the
windows simultaneously, press and hold
the
button on the Intelligent Key until the
windows have reached the desired position.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating
and feature information.
