2019 INFINITI QX30 display

Message Possible causes/consequences and solutions
[Emergency Brake
Currently Unavailable See
Operator's Manual]Forward Emergency Braking is temporarily inoperative.
Possible causes:
•The radar sensor system is temporarily inoperative, e.g. due to electromagnetic radiation emitted by nearby TV or radio stations
or other sources of electromagnetic radiation.
•The system is outside the operating temperature range.•The on-board voltage is too low.
Once the causes listed above no longer apply, the display message goes out.
Forward Emergency Braking is operational again.
If the display message does not disappear:
1. Pull over and stop the vehicle safely as soon as possible, paying attention to road and traffic conditions.
2. Secure the vehicle against rolling away.
3. Restart the engine.
[Emergency Brake Inopera-
tive]Forward Emergency Braking is temporarily inoperative due to a malfunction.
Have the system checked. It is recommended you visit an INFINITI retailer for this service.
Instruments and controls2-37

Message Possible causes/consequences and solutions
[Radar Sensor (See
Operator's Manual):]At least one of the following driving systems or driving safety systems is temporarily restricted or inoperative:
•Forward Emergency Braking•Intelligent Cruise Control•Blind Spot Warning
Possible causes:
•The sensors in the radiator trim and/or at the sides of the rear bumpers are dirty.•The function of the driving system and/or driving safety system is impaired due to heavy rain or snow.
A warning tone also sounds.
Once the causes listed above no longer apply, the display message goes out. All driving systems/driving safety systems are
operative again.
If the display message does not disappear:
1. Pull over and stop the vehicle safely as soon as possible, paying attention to road and traffic conditions
2. Secure the vehicle against rolling away.
3. Switch off the engine.
4. Clean the sensors in the following locations:
- In the radiator trim
- At the sides of the rear bumper
5. Restart the engine. The display message disappears.
[SRS Malfunction Service
Required]The restraint system needs servicing. The
warning light also lights up in the combination meter.
It is recommended you visit an INFINITI retailer for these services.
Unless checked and repaired, the Supplemental Restraint Systems and/or the pretensioner seat belt may not function properly.
WARNING
If this light is on, it could mean that the front air bag, side air bag, curtain air bag systems and/or pretensioner systems will not
operate in an accident. To help avoid injury to yourself or others, have your vehicle checked as soon as possible. It is recommended
you visit an INFINITI retailer for this service.
For further information about the restraint system, see "Supplemental Restraint System (SRS)".
2-38Instruments and controls

Message Possible causes/consequences and solutions
[Front Passenger Airbag
Disabled See Operator's
Manual]The front-passenger front air bag is disabled during the journey although an adult or person of corresponding stature is on the
front passenger seat.
Front passenger seat adult occupants who are properly seated and using the seat belt as outlined in this manual should not cause
the front passenger air bag to be automatically turned OFF. For small adults it may be turned OFF, however if the occupant takes
his/her weight off the seat cushion (for example, by not sitting upright, by sitting on an edge of the seat, or by otherwise being out
of position), this could cause the sensor to turn the air bag OFF. Always be sure to be seated and wearing the seat belt properly for
the most effective protection by the seat belt and supplemental air bag.
If additional forces are applied to the seat, the system may interpret the occupant's weight as lower than it actually is.
1. Stop the vehicle in a safe area away from traffic as soon as possible, paying attention to road and traffic conditions.
2. Secure the vehicle against rolling away.
3. Switch the ignition off.
4. Have the occupant on the front-passenger seat step out of the vehicle.
5. Make sure that the seat is unoccupied, close the front passenger door and switch on the ignition.
6. Observe the indicator lights in the center console and the vehicle information display and check the
following. Seat unoccupied and ignition switched on:
- The and indicator lights must light up simultaneously for
approximately six seconds.
- The indicator lights must then light up and remain lit. If the indicator light is on, the automatic
front-passenger front air bag deactivation system has disabled the front-passenger front air bag (see "Front passenger air bag
and status light")
- the [Front Passenger Airbag Enabled See Operator's Manual] or [Front Passenger Airbag Disabled See Operator's Manual]
display messages must not be shown in the vehicle information display.
7. Wait for a period of at least 60 seconds until the necessary system checks have been completed.
8. Make sure that the display messages do not appear in the vehicle information display.
If these conditions are met, the front-passenger seat can be occupied again. Whether the or
indicator light remains lit or goes out depends on how the automatic front passenger front air bag deactivation system classifies the
occupant.
If, after taking the steps above, you still believe the system is not operating properly, have it checked immediately. It is recommended
you visit an INFINITI retailer for this service.
For further information on the automatic front-passenger front air bag deactivation feature (see "Front passenger air bag and
status light").
Instruments and controls2-39

Message Possible causes/consequences and solutions
[Front Passenger Airbag
Enabled See Operator's
Manual]The front-passenger front air bag is enabled during the journey although:
•A child or child restraint as specified in U.S. regulations is located on the front-passenger seat.
or
•The front-passenger seat is not occupied.
The system may detect objects or forces that are adding to the weight applied to the seat.
1. Stop the vehicle in a safe area away from traffic as soon as possible, paying attention to road and traffic conditions.
2. Secure the vehicle against rolling away.
3. Switch the ignition off.
4. Open the front-passenger door.
5. Remove the child and the child restraint system from the front passenger seat.
6. Make sure there are no objects applying additional force to the seat. The system may otherwise detect the additional force and
interpret the seat occupant's weight as greater than it actually is.
7. Make sure that the seat is unoccupied, close the front passenger door and switch on the ignition.
8. Observe the indicator lights in the center console and the vehicle information display and check the
following. Seat unoccupied and ignition switched on:
- The and indicator lights must light up simultaneously for
approximately six seconds.
- The indicator light must then light up and remain lit. If the indicator light is on, the automatic
front-passenger front air bag deactivation system has disabled the front-passenger front air bag (see "Front passenger air bag
and status light").
- the [Front Passenger Airbag Enabled See Operator's Manual] or [Front Passenger Airbag Disabled See Operator's Manual]
display messages must not be shown in the vehicle information display.
7. Wait for a period of at least 60 seconds until the necessary system checks have been completed.
8. Make sure that the display messages do not appear in the vehicle information display.
If these conditions are met, the front-passenger seat can be occupied again. Whether the or
indicator light remains lit or goes out depends on how the automatic front passenger front air bag deactivation system classifies the
occupant.
If, after taking the steps above, you still believe the system is not operating properly, have it checked immediately. It is recommended
you visit an INFINITI retailer for this service.
For further information on the automatic front-passenger front air bag deactivation feature (see "Front passenger air bag and
status light").
2-40Instruments and controls

Lights
NOTE
Vehicles with LEDs in the light clusters: The display message for the corresponding light will only appear if all the LEDs have failed.
Message Possible causes/consequences and solutions
[Check Left Cornering
Light] or [Check Right
Cornering Light]The left or right-hand cornering light is faulty.
Have the system checked. It is recommended you visit an INFINITI retailer for this service.
[Check Left Low Beam] or
[Check Right Low Beam]The left or right-hand low beam headlight is faulty.•Check whether you are permitted to replace the bulb yourself (see "Lights").
or:
•Have the system checked. It is recommended you visit an INFINITI retailer for this service.
[Check Rear Left Turn
Signal] or [Check Rear
Right Turn Signal]The rear left or right-hand turn signal is faulty.
Have the system checked. It is recommended you visit an INFINITI retailer for this service.
[Check Front Left Turn
Signal] or [Check Front
Right Turn Signal]The front left or right-hand turn signal is faulty.•Check whether you are permitted to replace the bulb yourself (see "Lights").
or:
•Have the system checked. It is recommended you visit an INFINITI retailer for this service.
Instruments and controls2-41

Message Possible causes/consequences and solutions
[High beam assist Currently
Unavailable See Operator's
Manual]High beam assist is deactivated and temporarily inoperative. Possible causes:
•The windshield is dirty in the camera's field of vision.•Visibility is impaired due to heavy rain, snow or fog.
Clean the windshield.
If the system detects that the camera is fully operational again, the [High beam assist Available Again] message is displayed.
[High beam assist Inopera-
tive]High beam assist is faulty.
Have the system checked. It is recommended you visit an INFINITI retailer for this service.
2-44Instruments and controls

Engine
Message Possible causes/consequences and solutions
[Check Coolant Level See
Operators Manual]The coolant level is too low.CAUTIONAvoid making long journeys with too little coolant in the engine cooling system. The engine will otherwise be damaged.
Top up the coolant, observing the warning notes before doing so (see "If your vehicle overheats").
If the coolant needs topping up more often than usual. have the engine coolant system checked. It is recommended you visit an
INFINITI retailer for this service.
The fan motor is faulty.
If the coolant temperature is below 250°F (120°C), you can continue driving to the nearest place you can have the system checked.
It is recommended that you visit an INFINITI retailer for this service.
Avoid putting the engine under heavy load as you do so, e.g. driving in mountainous terrain and stop-start traffic.
[Coolant Too Hot Stop
Vehicle Turn Engine Off]The coolant is too hot.
A warning tone also sounds.CAUTIONIf the gauge indicates coolant temperature near the hot (H) end of the normal range, reduce vehicle speed to decrease tempera-
ture. If the gauge is over the normal range, stop the vehicle as soon as safely possible. If the engine is overheated, continued
operation of the vehicle may seriously damage the engine. For additional information, refer to "If your vehicle overheats" for
immediate action required.
1. Stop the vehicle immediately, paying attention to road and traffic conditions, and switch off the engine.
2. Secure the vehicle against rolling away
3. Wait until the engine has cooled down.
4. Make sure that the air supply to the engine radiator is not blocked, e.g. by frozen slush.
5. Do not start the engine again until the display message goes out and the coolant temperature is below 120°C. The engine may
otherwise be damaged.
6. Pay attention to the coolant temperature display.
7. If the temperature increases again, have the system checked immediately. It is recommended you visit an INFINITI retailer for
this service.
Under normal operating conditions and with the specified coolant level, the coolant temperature may rise to 250°F (120°C).
See "If your vehicle overheats".
Instruments and controls2-45

Message Possible causes/consequences and solutions
[See Operator's Manual]The battery is not being charged.
A warning tone also sounds.
Possible causes:•Faulty alternator.•Torn poly-V-belt.•A malfunction in the electronics.
CAUTIONDo not continue driving. The engine could otherwise overheat.
1. Stop the vehicle immediately, paying attention to road and traffic conditions, and switch off the engine.
2. Secure the vehicle against rolling away
3. Have the system checked. It is recommended you visit an INFINITI retailer for this service.
[Stop Vehicle See
Operator's Manual]The battery is no longer being charged and the battery charge level is too low.
A warning tone also sounds.
1. Stop the vehicle immediately, paying attention to road and traffic conditions, and switch off the engine.
2. Secure the vehicle against rolling away
3. Observe the instructions in the display message.
4. Have the system checked. It is recommended you visit an INFINITI retailer for this service.
[Check Engine Oil At Next
Refueling]The engine oil level has dropped to the minimum level.
A warning tone also sounds.CAUTIONAvoid long journeys when there is too little engine oil in the engine. Otherwise the engine will be damaged.
1. Check the oil level when next refueling, at the latest (see "Engine oil").
2. If necessary, top up the engine oil.
3. If the engine oil needs topping up more often than usual, have the engine checked. It is recommended you visit an INFINITI
retailer for this service.
2-46Instruments and controls
