2019 FIAT 500E fold seats

▫Central Lock/Unlock (Switch Safe Lock Device) —
If Equipped ............................44
 DOORS ...............................45
▫ Manual Lock ...........................45
▫ Power Door Locks ......................46
 SEATS ................................47
▫ Manual Adjustment Front Seats ..............47
▫ Heated Seats — If Equipped ...............50
▫ Manual Folding Rear Seat ..................51
 HEAD RESTRAINTS ......................52
▫ Reactive Head Restraints — Front Seats ........52
▫ Rear Head Restraints .....................54
 STEERING WHEEL .......................55
▫ Tilt Steering Column — If Equipped ..........55
 MIRRORS ..............................56
▫ Inside Day/Night Mirror ..................56
▫ Automatic Dimming Mirror — If Equipped .....56▫
Power Mirrors .........................57
▫ Folding Mirrors .........................57
▫ Spotter Mirror — If Equipped ...............58
▫ Heated Mirrors — If Equipped .............58
 EXTERIOR LIGHTS .......................58
▫ Multifunction Lever ......................58
▫ Headlights ............................58
▫ Daytime Running Lights ..................59
▫ High Beams ...........................59
▫ Flash-To-Pass ..........................59
▫ Parking Lights .........................59
▫ Follow Me Home/Headlight Delay ...........60
▫ Fog Lights — If Equipped .................60
▫ Turn Signals ...........................60
▫ Lane Change Assist ......................61
 INTERIOR LIGHTS .......................61
▫ Interior Light Timing (Center Position) ........62
14 GETTING TO KNOW YOUR VEHICLE

Manual Folding Rear Seat
The rear seatbacks have a fold down feature to allow
increased cargo capacity.
Push down the release button, located at the outboard top
of the seatback and move the seatback to its folded-down
position to provide a flat load floor cargo area. When
returning the seatback to its upright position, push rear-
ward until the seatback is properly latched.
WARNING!
Do not pile luggage or cargo higher than the top of the
seatback. This could impair visibility or become a
dangerous projectile in a sudden stop or collision.
Rear Seat Release Buttons
Folded Rear Seats
3
GETTING TO KNOW YOUR VEHICLE 51

Seat belts are necessary for your protection in all collisions,
and also are needed to help keep you in position, away
from an inflating air bag.
When the ORC detects a collision requiring the front air
bags, it signals the inflator units. A large quantity of
non-toxic gas is generated to inflate the front air bags.
The steering wheel hub trim cover and the upper passen-
ger side of the instrument panel separate and fold out of
the way as the air bags inflate to their full size. The front air
bags fully inflate in less time than it takes to blink your
eyes. The front air bags then quickly deflate while helping
to restrain the driver and front passenger.
Knee Impact Bolsters
The Knee Impact Bolsters help protect the knees of the
driver and front passenger, and position the front occu-
pants for improved interaction with the front air bags.
WARNING!
•Do not drill, cut, or tamper with the knee impact
bolsters in any way.
• Do not mount any accessories to the knee impact
bolsters such as alarm lights, stereos, citizen band
radios, etc.
Supplemental Driver Knee Air Bag
This vehicle is equipped with a Supplemental Driver Knee
Air Bag mounted in the instrument panel below the
steering column. The Supplemental Driver Knee Air Bag
provides enhanced protection during a frontal impact by
working together with the seat belts, pretensioners, and
front air bags.
Supplemental Side Air Bags
Supplemental Seat-Mounted Side Air Bags (SABs)
This vehicle is equipped with Supplemental Seat-Mounted
Side Air Bags (SABs).
Supplemental Seat-Mounted Side Air Bags (SABs) are
located in the outboard side of the front seats. The SABs are
marked with “SRS AIRBAG” or “AIRBAG” on a label or on
the seat trim on the outboard side of the seats.
5
SAFETY 127

Daytime Running Lights....................58, 59
Defroster, Windshield ....................... .152
Diagnostic System, Onboard ...................100
Dimmer Switch Headlight ...............................58
Door Ajar .................................93
Door Ajar Light ............................93
Doors ....................................45
Driver ’s Seat Back Tilt ........................47
Driving Through Flowing, Rising, Or Shallow Standing
Water ................................ .177
Electrical Power Outlets .......................82
Electric Remote Mirrors .......................57
Electric Vehicle Features .......................18
Electric Vehicle Supply Equipment (EVSE) ..........24
Electronic Stability Control (ESC) ...............104
Emergency, In Case Of Hazard Warning Flasher ...................182
Jacking ............................... .226
Towing ............................... .207
Engine Compartment .......................... .214
Starting .............................. .157Enhanced Accident Response Feature
.........133, 208
Exterior Lighting ............................58
Exterior Lights ......................... .58, 154
Filters Air Conditioning ..........................73
Flashers Turn Signals ...................... .58, 99, 154
Flash-To-Pass ..............................58
Fluid Leaks .............................. .154
Fluid Level Checks Brake ................................ .225
Fluids And Lubricants ...................... .257
Fluids And Lubricants And Genuine Parts .........257
Fog Lights ............................. .58, 60
Fold-Flat Seats .............................47
Freeing A Stuck Vehicle ..................... .206
Fuses .................................. .186
Gear Ranges ............................. .161
General Information .....................112,274
General Maintenance ....................... .216
Glass Cleaning ........................... .252
GVWR ................................. .173
290 INDEX

Schedule, Maintenance.......................211
Seat Belt Reminder ..........................94
Seat Belts .............................114,152
Child Restraints ........................ .135
Energy Management Feature ................120
Extender ...............................119
Front Seat .......................114,115,117
Inspection ............................. .152
Lap/Shoulder Belt Operation ................117
Lap/Shoulder Belts .......................115
Lap/Shoulder Belt Untwisting ...............119
Operating Instructions .....................117
Pregnant Women ........................ .120
Pretensioners .......................... .120
Rear Seat ..............................115
Reminder ..............................114
Seat Belt Extender ........................119
Seat Belt Pretensioner .....................120
Untwisting Procedure .....................119
Seat Belts Maintenance ...................... .251
Seats ....................................47
Adjustment .............................47
Heated .................................50
Rear Folding .............................47
Tilting .................................47 Security Alarm
.............................42
Selection Of Coolant (Antifreeze) ...............257
Sentry Key Key Programming .........................42
Sentry Key (Immobilizer) ......................41
Service Assistance ......................... .282
Service Contract .......................... .284
Service Manuals .......................... .286
Settings Personal .............................. .261
Shoulder Belts .............................115
Side View Mirror Adjustment ...................56
Signals, Turn ..................... .58, 60, 99, 154
Snow Chains (Tire Chains) ....................245
Snow Tires .............................. .241
Spare Tires ........................ .241, 242, 243
Speed Control Cancel ............................... .168
Resume .............................. .168
Speed

Control (Cruise Control) .................165
Starting ................................ .157
Button .................................39
Steering Power ............................... .164
Tilt Column .............................55
294 INDEX
