WARNING!
The traction grade assigned to this tire is based on
straight-ahead braking traction tests, and does not
include acceleration, cornering, hydroplaning, or
peak traction characteristics.
Temperature Grades
The Temperature grades are A (the highest), B, and C,
representing the tire’s resistance to the generation of
heat and its ability to dissipate heat, when tested under
controlled conditions on a specified indoor laboratory
test wheel.
Sustained high temperature can cause the material of
the tire to degenerate and reduce tire life, and excessive
temperature can lead to sudden tire failure. The grade C
corresponds to a level of performance, which all pas-
senger vehicle tires must meet under the Federal Motor
Vehicle Safety Standard No. 109. Grades B and A
represent higher levels of performance on the laboratory
test wheel, than the minimum required by law.
WARNING!
The temperature grade for this tire is established for
a tire that is properly inflated and not overloaded.
Excessive speed, under-inflation, or excessive load-
ing, either separately or in combination, can cause
heat buildup and possible tire failure.
STORING THE VEHICLE
The preferred way of storing your vehicle for a long period
of time is to leave it attached to a Level 1 or Level 2 charger.
The vehicle has a wake-up feature that will wake the
system every 3 weeks and do a maintenance charge on the
12 Volt battery and also top off the high voltage battery if
necessary.
Anytime you store your vehicle, or keep it out of service
(e.g., vacation) for two weeks or more, run the air condi-
tioning system at idle for about five minutes in the fresh air
and high blower setting. This will ensure adequate system
lubrication to minimize the possibility of compressor dam-
age when the air conditioning system is started again.
248 SERVICING AND MAINTENANCE

INTERIORS
Seats And Fabric Parts
Use Mopar Total Clean to clean fabric upholstery and
carpeting.
WARNING!
Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in closed
areas they may cause respiratory harm.
Seat Belt Maintenance
Do not bleach, dye or clean the belts with chemical solvents
or abrasive cleaners. This will weaken the fabric. Sun
damage can also weaken the fabric.
If the belts need cleaning, use a mild soap solution or
lukewarm water. Do not remove the belts from the vehicle
to wash them. Dry with a soft cloth.
Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
WARNING!
A frayed or torn belt could rip apart in a collision and
leave you with no protection. Inspect the belt system
periodically, checking for cuts, frays, or loose parts.
Damaged parts must be replaced immediately. Do not
disassemble or modify the system. Seat belt assemblies
must be replaced after a collision if they have been
damaged (i.e., bent retractor, torn webbing, etc.).
Plastic And Coated Parts
Use Mopar Total Clean to clean vinyl upholstery.
CAUTION!
•Direct contact of air fresheners, insect repellents,
suntan lotions, or hand sanitizers to the plastic,
painted, or decorated surfaces of the interior may
cause permanent damage. Wipe away immediately.
• Damage caused by these type of products may not be
covered by your New Vehicle Limited Warranty.
8
SERVICING AND MAINTENANCE 251

force required to slow or stop, and activation of the Brake
Warning Light and the ABS Warning Light during brake
use.
WHEEL AND TIRE TORQUE SPECIFICATIONS
Proper lug nut/bolt torque is very important to ensure that
the wheel is properly mounted to the vehicle. Any time a
wheel has been removed and reinstalled on the vehicle, the
lug nuts/bolts should be torqued using a properly cali-
brated torque wrench using a high quality six sided (hex)
deep wall socket.
Torque Specifications
Lug Nut/Bolt Torque **Lug Nut/Bolt SizeLug Nut/
Bolt Socket Size
66 Ft-Lbs (90 N·m)
Steel Wheels Only
74 Ft-Lbs (100 N·m) Aluminum Wheels Only M12 x 1.25 17 mm
**Use only your authorized dealer recommended lug nuts/
bolts and clean or remove any dirt or oil before tightening. Inspect the wheel mounting surface prior to mounting the
tire and remove any corrosion or loose particles.Wheel Mounting Surface9
TECHNICAL SPECIFICATIONS 255

Tighten the lug nuts/bolts in a star pattern until each
nut/bolt has been tightened twice.After 25 miles (40 km), check the lug nut/bolt torque to be
sure that all the lug nuts/bolts are properly seated against
the wheel.
WARNING!
To avoid the risk of forcing the vehicle off the jack, do
not tighten the lug nuts/bolts fully until the vehicle has
been lowered. Failure to follow this warning may
result in personal injury.
FLUID CAPACITIES
Systems
U.S.Metric
Power Electronics Cooling System 3.6 Quarts3.4 Liters
Battery Thermal Management Cooling System 7.0 Quarts6.6 Liters
Single-Speed Transmission 0.8 Quart750 ml
Torque Patterns
256 TECHNICAL SPECIFICATIONS

UCONNECT SYSTEMS
For detailed information about your Uconnect system,
refer to your Uconnect Owner ’s Manual Supplement.
NOTE:Uconnect screen images are for illustration pur-
poses only and may not reflect exact software for your
vehicle.
CYBERSECURITY
Your vehicle may be a connected vehicle and may be
equipped with both wired and wireless networks. These
networks allow your vehicle to send and receive informa-
tion. This information allows systems and features in your
vehicle to function properly.
Your vehicle may be equipped with certain security fea-
tures to reduce the risk of unauthorized and unlawful
access to vehicle systems and wireless communications.
Vehicle software technology continues to evolve over time
and FCA US LLC, working with its suppliers, evaluates
and takes appropriate steps as needed. Similar to a com-
puter or other devices, your vehicle may require software
updates to improve the usability and performance of your
systems or to reduce the potential risk of unauthorized and
unlawful access to your vehicle systems. The risk of unauthorized and unlawful access to your
vehicle systems may still exist, even if the most recent
version of vehicle software (such as Uconnect software) is
installed.
WARNING!
•
It is not possible to know or to predict all of the
possible outcomes if your vehicle’s systems are
breached. It may be possible that vehicle systems,
including safety related systems, could be impaired
or a loss of vehicle control could occur that may
result in an accident involving serious injury or
death.
• ONLY insert media (e.g., USB, SD card, or CD) into
your vehicle if it came from a trusted source. Media
of unknown origin could possibly contain malicious
software, and if installed in your vehicle, it may
increase the possibility for vehicle systems to be
breached.
• As always, if you experience unusual vehicle behav-
ior, take your vehicle to your nearest authorized
dealer immediately.
260 MULTIMEDIA

WARNING!
Engine exhaust (internal combustion engines only),
some of its constituents, and certain vehicle compo-
nents contain, or emit, chemicals known to the State of
California to cause cancer and birth defects, or other
reproductive harm. In addition, certain fluids con-
tained in vehicles and certain products of component
wear contain, or emit, chemicals known to the State of
California to cause cancer and birth defects, or other
reproductive harm.
WARRANTY INFORMATION
See the Warranty Information Booklet for the terms and
provisions of FCA US LLC warranties applicable to this
vehicle and market.
MOPAR PARTS
Mopar fluids, lubricants, parts, and accessories are avail-
able from an authorized dealer. They are recommended for
your vehicle in order to help keep the vehicle operating at
its best.
REPORTING SAFETY DEFECTS
In The 50 United States And Washington, D.C.
If you believe that your vehicle has a defect that could
cause a crash or cause injury or death, you should
immediately inform the National Highway Traffic
Safety Administration (NHTSA) in addition to notifying
FCA US LLC.
If NHTSA receives similar complaints, it may open an
investigation, and if it finds that a safety defect exists in
a group of vehicles, it may order a recall and remedy
campaign. However, NHTSA cannot become involved
in individual problems between you, an authorized
dealer or FCA US LLC.
To contact NHTSA, you may call the Vehicle Safety
Hotline toll free at 1-888-327-4236 (TTY: 1-800-424-9153);
or go to http://www.safercar.gov; or write to: Admin-
istrator, NHTSA, 1200 New Jersey Avenue, SE., West
Building, Washington, D.C. 20590. You can also obtain
other information about motor vehicle safety from
http://www.safercar.gov.11
CUSTOMER ASSISTANCE 285

Adding Washing Fluid...................... .215
AirBag ................................ .124
Advance Front Air Bag ....................124
Air Bag Operation ....................... .126
Air Bag Warning Light .....................123
Driver Knee Air Bag ..................... .127
Enhanced Accident Response .............133, 208
Event Data Recorder (EDR) .................208
FrontAirBag .......................... .124
If Deployment Occurs .....................132
Knee Impact Bolsters ..................... .127
Maintaining Your Air Bag System .............134
Maintenance ........................... .134
Side Air Bags .......................... .127
Transporting Pets ....................... .151
Air Bag Light ...................... .92, 123, 152
Air Conditioner Maintenance ..................222
Air Conditioner Refrigerant ...................222
Air Conditioner System ..................... .222
Air Conditioning Filter .......................73
Air Conditioning, Operating Tips ................72
Air Pressure Tires................................. .235
Alarm Security Alarm ...........................42 Alarm System
Security Alarm ...........................42
Alterations/Modifications Vehicle .................................5
Anti-Lock Brake System (ABS) .................102
Anti-Lock Warning Light .................95, 98, 99
Arming System Security Alarm ...........................42
Audio Systems (Radio) ...................... .260
Automatic Dimming Mirror ....................56
Automatic Transmission ..................... .160
Gear Ranges ........................... .161
Auxiliary Driving Systems ....................107
Battery .............................. .93, 215
Charging ...............................16
Charging System Light .....................93
Belts, Seat ............................... .152
Body
Mechanism Lubrication ..................223
B-Pillar Location .......................... .230
Brake Assist System ........................ .103
Brake Fluid .............................. .257
Brake, Parking ............................ .158
Brake System ............................ .225
Anti-Lock (ABS) ........................ .102
288 INDEX

Fluid Check........................... .225
Master Cylinder ........................ .225
Parking .............................. .158
Warning Light ...........................92
Bulb Replacement ......................... .182
Bulbs, Light .......................... .154, 182
Camera, Rear ............................ .172
Capacities, Fluid .......................... .256
Car Washes .............................. .249
Cellular Phone ........................... .273
Certification Label ......................... .173
Chains, Tire ............................. .245
Changing A Flat Tire ....................... .226
Charging .................................22
AC Level 1 ..............................22
AC Level 2 ..............................35
Cordset ................................24
Indicator ...............................32
Times ..................................36
Troubleshooting ..........................28
Checking Your Vehicle For Safety ...............152
Checks, Safety ............................ .152
Child Restraint ........................... .135Child Restraints
Booster Seats ........................... .139
Child Seat Installation .....................148
How To Stow An unused ALR Seat Belt ........145
Infant And Child Restraints .................138
Lower Anchors And Tethers For Children .......141
Older Children And Child Restraints ...........138
Seating Positions ........................ .140
Cleaning Wheels ............................... .244
Climate Control ............................65
Automatic ........................... .66, 71
Compact Disc (CD) Maintenance ................279
Compact Spare Tire ........................ .242
Contract, Service .......................... .284
Cooling System Cooling
Capacity........................ .256
Selection Of Coolant (Antifreeze) .............257
Corrosion Protection ....................... .249
Cruise Control (Speed Control) .................165
Cruise Light ...............................99
Cupholders ...............................80
Customer Assistance ....................... .282
Customer Programmable Features ...............261
Cybersecurity ............................ .260
12
INDEX 289
