2019 CHRYSLER 300 weight

Steps For Determining Correct Load Limit—
(1) Locate the statement “The combined weight of
occupants and cargo should never exceed XXX kg or
XXX lbs.” on your vehicle’s placard.
(2) Determine the combined weight of the driver and
passengers that will be riding in your vehicle.
(3) Subtract the combined weight of the driver and
passengers from XXX kg or XXX lbs.
(4) The resulting figure equals the available amount of
cargo and luggage load capacity. For example, if “XXX”
amount equals 1400 lbs. and there will be five 150 lb
passengers in your vehicle, the amount of available
cargo and luggage load capacity is 650 lbs. (1400-750
(5x150) = 650 lbs.)
(5) Determine the combined weight of luggage and
cargo being loaded on the vehicle. That weight may not
safely exceed the available cargo and luggage load
capacity calculated in Step 4.
(6) If your vehicle will be towing a trailer, load from
your trailer will be transferred to your vehicle. Consultthis manual to determine how this reduces the available
cargo and luggage load capacity of your vehicle.
Metric Example For Load Limit
For example, if “XXX” amount equals 635 kg and there will
be five 68 kg passengers in your vehicle, the amount of
available cargo and luggage load capacity is 295 kg (635-
340 (5x68) = 295 kg) as shown in step 4.
NOTE:
•
If your vehicle will be towing a trailer, load from your
trailer will be transferred to your vehicle. The following
table shows examples on how to calculate total load,
cargo/luggage, and towing capacities of your vehicle
with varying seating configurations and number and
size of occupants. This table is for illustration purposes
only and may not be accurate for the seating and load
carry capacity of your vehicle.
• For the following example, the combined weight of
occupants and cargo should never exceed 865 lbs
(392 kg).
8
SERVICING AND MAINTENANCE 381

Engine Oil............................ .412
Fuel Requirements ....................411,412
Maintenance ........................... .413
Replacement Parts ....................... .413
Starting .............................. .413
Flooded Engine Starting ..................... .224
Floor Console ............................ .107
Fluid, Brake .......................... .415, 417
Fluid Capacities ........................... .414
Fluid Leaks .............................. .215
Fluid Level Checks Brake ................................ .369
Cooling System ......................... .365
Engine Oil ............................ .350
Transfer Case .......................... .372
Fluids And Lubricants ...................... .415
Fog Lights ................................70
Fold-Flat Seats .............................44
Folding Rear Seats ..........................45
Forward Collision Warning ....................163
Four-Way Hazard Flasher .....................300
Freeing A Stuck Vehicle ..................... .335
Fuel ................................... .407
Additives ............................. .408
Clean Air ............................. .408Ethanol
........................... .409, 411
Flexible ................................411
Gasoline .............................. .407
Gauge ............................... .139
Materials Added ........................ .408
Methanol ............................. .409
Octane Rating ....................407, 408, 415
Requirements ....................... .407, 414
Specifications .......................... .415
Tank Capacity .......................... .414
Fuses .................................. .310
Garage Door Opener (HomeLink) ...............100
Gasoline,
Clean Air ........................ .408
Gasoline, Reformulated ..................... .408
Gauges Fuel ................................. .139
Gear Ranges ............................. .232
Glass Cleaning ........................... .401
Gross Axle Weight Rating .................285, 287
Gross Vehicle Weight Rating ...............285, 286
GVWR ................................. .285
12
INDEX 477

Synthetic Engine Oil....................... .354
Telescoping Steering Column ...................58
Temperature Control, Automatic (ATC) ............84
Tilt Steering Column .........................58
Time Delay Headlight ...............................69
Tire And Loading Information Placard ............379
Tire Markings ............................ .373
Tires ..................... .215, 383, 390, 391, 396
Aging (Life Of Tires) ..................... .387
Air Pressure ........................... .383
Chains ............................... .394
Changing ....................321, 324, 328, 373
Compact Spare ......................... .391
Flat Changing .......................... .328
General Information ................383, 390, 391
High Speed ............................ .385
Inflation Pressure ....................... .384
Jacking ........................... .324, 373
Life Of Tires ........................... .387
Load Capacity ...................... .379, 380
Pressure Monitoring System (TPMS) ........137, 166
Quality Grading ........................ .396
Radial ............................... .385Replacement
........................ .328, 388
Rotation .............................. .395
Safety ............................ .373, 383
Sizes ................................ .375
Snow Tires ............................ .390
Spare Tires ...................321, 390, 391, 392
Spinning .............................. .386
Trailer Towing .......................... .292
Tread Wear Indicators .....................387
Wheel Mounting ........................ .328
Wheel Nut Torque ....................... .406
Tire Safety Information ...................... .373
Tongue Weight/Trailer Weight .................290
T
o Open Hood .............................94
Towing ................................. .286
Behind A Motorhome ..................... .296
Disabled Vehicle ........................ .336
Guide ................................ .289
Recreational ........................... .296
Weight ............................... .289
Towing Behind A Motorhome ..................296
Traction ................................ .296
Traction Control .......................... .155
Trailer Towing ............................ .286
Cooling System Tips ..................... .295
12
INDEX 485

Hitches............................... .288
Minimum Requirements ....................291
Tips ................................. .295
Trailer And Tongue Weight ..................290
Wiring ............................... .293
Trailer Towing Guide ....................... .289
Trailer Weight ............................ .289
Transfer Case Fluid .......................... .372, 415, 417
Maintenance ........................... .372
Transmission ............................. .230
Automatic ......................... .230, 371
Fluid ............................. .415, 417
Maintenance ........................... .371
Shifting .............................. .228
Transporting Pets ......................... .212
Tread Wear Indicators ...................... .387
Trunk Lid (Deck Lid) .........................95
Trunk Release Remote Control ..................95
Turn Signals ........................... .70, 141
Uconnect Uconnect Settings .................21, 22, 33, 423
Uconnect 4C/4C Nav With 8.4-Inch Display ........424Uconnect Settings
Customer Programmable Features ........33, 39, 423
Passive Entry Programming ..................39
Uniform Tire Quality Grades ..................396
Universal Garage Door Opener (HomeLink) ........100
Universal Transmitter ....................... .100
Unleaded Gasoline ........................ .407
Untwisting Procedure, Seat Belt ................179
USB................................... .447
Vanity Mirrors .............................65
Vehicle Certification Label ....................285
Vehicle Identification Number (VIN) .............405
Vehicle Loading .....................285, 286, 380
Vehicle Modifications/Alterations .................5
Vehicle Security Alarm ........................35
Vehicle Storage ......................... .86,
397
Vehicle User Guide In Vehicle Help ...........................17
Navigation ..............................17
Operating Instructions ......................17
Searching User Guide ......................17
Viscosity, Engine Oil .....................353, 354
Voice Command .......................... .449
486 INDEX
