2019 CHRYSLER 300 tire pressure reset

Secondary Method Of Resetting Engine Oil Life
1. Without pressing the brake pedal, push the ENGINESTART/STOP button and place the ignition to the
ON/RUN position (do not start the engine).
2. Fully press the accelerator pedal, slowly, three times within ten seconds.
3. Without pushing the brake pedal, push the ENGINE START/STOP button once to return the ignition to the
OFF/LOCK position.
NOTE: If the indicator message illuminates when you start
the vehicle, the oil change indicator system did not reset. If
necessary, repeat this procedure.
Instrument Cluster Display Selectable Menu Items
Push and release the upordown arrow button until the
desired Selectable Menu item is displayed in the instru-
ment cluster display.
Follow the Menu or submenu prompts as desired.
Speedometer
Push and release the OKbutton to toggle between MPH
and km/h.
Vehicle Info
The Vehicle Info consists of the following submenu (push-
ing the leftorright arrow button will allow you to scroll
through the submenu):
• Tire Pressure Monitor
• Coolant Temperature
• Transmission Temperature
• Oil Temperature
• Oil Pressure
• Oil Life
• Battery Voltage
• AWD Status — If Equipped
Driver Assist
The Driver Assist menu provides the status and visuals
about the Adaptive Cruise Control and LaneSense features.
When they are both off the screen, the display will read
Adaptive Cruise Control (ACC) and LaneSense Off.
Adaptive Cruise Control (ACC) Feature — If Equipped
The instrument cluster display displays the current ACC
system settings. The information displayed depends on
ACC system status.
4
GETTING TO KNOW YOUR INSTRUMENT PANEL 125

SCHEDULED SERVICING
Your vehicle is equipped with an automatic oil change
indicator system. The oil change indicator system will
remind you that it is time to take your vehicle in for
scheduled maintenance.
Based on engine operation conditions, the oil change
indicator message will illuminate. This means that service
is required for your vehicle. Operating conditions such as
frequent short-trips, trailer tow, extremely hot or cold
ambient temperatures, and E85 fuel usage will influence
when the “Change Oil” or “Oil Change Required” message
is displayed. Severe Operating Conditions can cause the
change oil message to illuminate as early as 3,500 miles
(5,600 km) since last reset. Have your vehicle serviced as
soon as possible, within the next 500 miles (805 km).
The “Oil Change Required” message will be displayed in
the instrument cluster and a single chime will sound,
indicating that an oil change is necessary.
Your authorized dealer will reset the oil change indicator
message after completing the scheduled oil change. If a
scheduled oil change is performed by someone other than
your authorized dealer, the message can be reset by
referring to “Instrument Cluster Display” in “Getting To
Know Your Instrument Panel” for further information.NOTE:
Under no circumstances should oil change inter-
vals exceed 10,000 miles (16,000 km), 12 months or 350
hours of engine run time, whichever comes first. The 350
hours of engine run or idle time is generally only a concern
for fleet customers.
Severe Duty All Models
Change Engine Oil at 4,000 miles (6,500 km) or 350 hours of
engine run time if the vehicle is operated in a dusty and
off-road environment, or is operated predominantly at idle
or only very low engine RPM’s. This type of vehicle use is
considered Severe Duty.
Once A Month Or Before A Long Trip:
• Check engine oil level.
• Check windshield washer fluid level.
• Check tire pressure and look for unusual wear or
damage. Rotate tires at the first sign of irregular wear,
even if it occurs before your next scheduled service.
• Check the fluid levels of the coolant reservoir, brake
master cylinder, and power steering (if equipped) and
fill as needed.
• Check function of all interior and exterior lights.
8
SERVICING AND MAINTENANCE 343

Octane Rating, Gasoline (Fuel)...........407, 408, 415
Oil Change Indicator ....................... .124
Reset ................................ .124
Oil, Engine ........................... .353, 415
Capacity .............................. .414
Change Interval ........................ .353
Checking ............................. .350
Dipstick .............................. .350
Disposal .............................. .355
Filter ............................. .355, 415
Filter Disposal .......................... .355
Identification Logo ...................... .353
Materials Added To ...................... .354
Pressure Warning Light ....................134
Recommendation .....................353, 414
Synthetic ............................. .354
Viscosity ....................... .353, 354, 414
Oil Filter, Change ......................... .355
Oil Filter, Selection ......................... .355
Oil Pressure Light ......................... .134
Onboard Diagnostic System ...................142
Operating Precautions ...................... .142
Operator Manual Owner’s Manual .......................5,470
Outside Rearview Mirrors .....................61 Overheating, Engine
....................... .332
Owner ’s Manual (Operator Manual) ...............5
Paddle Shifters ........................... .237
Paddle Shift Mode ......................... .237
Paint Care ............................... .398
Panic Alarm ...............................22
Parking Brake ............................ .226
ParkSense System, Rear ..................... .264
Passive Entry ..............................39
Personalized Main Menu .....................421
Pets ................................... .212
Pinch Protection ............................
93
Placard, Tire And Loading Information ...........379
Power Brakes ............................... .405
Deck Lid Release .........................95
Distribution Center (Fuses) ..................316
Door Locks ..............................38
Mirrors ................................62
Outlet (Auxiliary Electrical Outlet) ............113
Seats ..................................46
Steering .............................. .239
Sunroof ................................90
Tilt/Telescoping Steering Column ..............58
12
INDEX 481
