2018 VOLKSWAGEN CC lock

Driver door overview

Fig. 4 Overview of controls in the driver door.
Key to fig. 4:
(1) Door handle
(2) Power locking switch for locking and unlocking the vehicle 0

Lower center console

Fig. 7 Overview of the lower center console.
Key to ⇒ fig. 7:
(1) Lever for:
– Manual transmission
– Automatic transmission
(2) Storage compartment with cup holders in the center console
(3) Storage compartment in the center armrest
(4) Buttons for:
– Starter button (vehicles with Keyless Access locking and start-
ing system)
– Electronic parking brake G
– Anti-slip regulation (ASR) m
– Rear window sunshade j
– Park Distance Control (ParkPilot) '
(5) Storage compartment:
– with 12 Volt socket

Front passenger side overview

Fig. 8 Overview of the front passenger side.
Key to ⇒ fig. 8:
(1) Passenger front airbag location in the instrument panel (approx-
imate)
(2) Opening handle for the lockable glove compartment
(3) Air vent

▪ Speed warning --- mph
Audio ⇒ Booklet Radio or ⇒ Booklet Navigation system
Navigation ⇒ Booklet Navigation system
Phone ⇒ Booklet Mobile Phone Package
Assistants
▪ AFS
Vehicle status
Settings
▪ Language
▪ MFI data
– Travel time
– Curr. consum. (current fuel consumption)
– Av. consum. (average fuel consumption)
– Route
– Av. speed (average speed)
– Digit. speed (digital speed display)
– Oil temperature (3.6 liter engine only)
– Speed warn. (speed warning)
– Back
▪ Convenience
– ATA confirm
– Easy Open (on/off)
– Central locking
Auto lock
Auto unlock
Unlock doors
Back
– Window op. (window operation)
Off
All
Driver
Back
– Mirror down (on/off)

Settings
menu
Function
Lights &
Vision
Vehicle lighting settings
Time Set hours and minutes for the instrument cluster
clock, the Radio & Navigation System clock, and the
analog clock. The digital clocks can be set to show
the time in 12 or 24 hour format, and can also be set
to daylight savings time.
Snow tires Set up a visual and acoustic speed warning. Use the
feature only when winter tires are installed that have
a speed rating less than top vehicle speed.
Compass Calibrate the compass on vehicles without a factory-
installed navigation system. To calibrate, follow the
instructions in the instrument cluster display
Units Set the units in which temperature, fuel consumption,
and distances should be displayed (for example,
whether to show distance driven in miles or kilome-
ters).
Service View the service reminder display
Factory
setting
Reset the functions in the Settings menu back to the
factory settings.

Lights & Vision submenu

Lights &
Vision menu
Function
Coming
Home
Set how long the headlights and inside lights stay on
after locking or unlocking the vehicle. Feature can
also be switched on or off
Leaving
Home
Footwell
light
Set footwell lighting brightness or switch this feature
on or off.
Conv. turn
sig.
Enable/disable convenience turn signal (lane change
feature). When the feature is enabled, the turn signal
flashes at least 3 times when the turn signal is tapped
Factory
setting
Resets the functions in the Lights & Vision submenu
back to the factory settings.
Back The display returns to the Settings menu.

Personal convenience settings

Feature Description
Remote
Door Unlock
You can send a request to unlock the vehicle doors
through your Volkswagen Car-Net iPhone® or An-
droid® app, the Volkswagen Car-Net website or by
calling the Volkswagen Car-Net Response Center
(text and data rates apply). If none of the vehicle
doors are opened within about 30 seconds, the car will
lock again.
Remote
Honk and
Flash
You can send a honk and flash signal to the car using
the Volkswagen Car-Net website or the VW Car-Net
iPhone® or Android® app (text and data rates apply).
The car will honk the horn and blink the headlights
and emergency flashers for up to 10 seconds.
Last Parked
Location
You can locate your last parked location using your
Volkswagen Car-Net iPhone® or Android® app (text
and data rates apply).
Destinations
Only appli-
cable for
vehicles
equipped
with a facto-
ry-installed
navigation
system.
Points of Interest (POIs) or other destinations can be
imported remotely into the factory-installed navigation
system (if equipped) from a computer or the
Volkswagen Car-Net iPhone® or Android® app (text
and data rates apply). These destinations can be
called up and used by the navigation system.
Destination
Download
Only appli-
cable for
vehicles
equipped
with a facto-
ry-installed
navigation
system.
Press the • button in the 3-button module: The vehi-
cle will connect directly to the Volkswagen Car-Net
Response Center where a Volkswagen Car-Net Cus-
tomer Specialist will assist with destinations. The ad-
dress of a dealer’s location can also be sent by the
Customer Specialist to your factory-installed naviga-
tion system (if equipped).

WARNING
Improper use of vehicle keys can result in serious personal in-
jury.
Always take the key with you when you leave the vehicle. It
can be used to start the engine and operate vehicle systems
such as the power windows, leading to serious personal injury.
Children or other unauthorized persons could also lock the
doors and the luggage compartment.
Never leave children, disabled persons, or anyone who can-
not help themselves in the vehicle. The doors can be locked
with the remote control vehicle key. This could leave people
trapped in the vehicle in an emergency. Depending on the time
of year, people trapped in the vehicle can be exposed to very
high or very low temperatures.
A closed vehicle can become very hot or very cold, depend-
ing on the season. Particularly in the summer, heat buildup in
the passenger and luggage compartment of a parked vehicle
can result in temperatures in the vehicle that are much higher
than the outside temperatures. Temperatures can quickly reach
levels that can cause unconsciousness and death, particularly
to small children.
Never remove the key from the ignition switch while the vehi-
cle is moving or rolling to a stop. The steering wheel will lock
and you will not be able to steer or control the vehicle.
Remote control vehicle keys

Fig. 20 Remote control vehicle key with panic button.
