2018 VOLKSWAGEN CC ignition

(2) Switch
(3) Sensor for recognizing entry of light
The auto-dimming feature can be switched on and off with the switch
on the inside mirror (2) A or (2) B. When auto-dimming is activated,
the indicator light (1) is on.
If the ignition is switched on, the sensor (3) automatically darkens the
inside mirror depending on the amount of light shining into the vehicle
from the rear.
The auto-dimming feature is deactivated when you shift the transmis-
sion into reverse or switch on the interior lights or the reading light.
Do not attach external navigation devices to the windshield or in the
vicinity of the auto-dimming inside mirror ⇒ .
WARNING
The illuminated display on an external navigation device can
cause the auto-dimming inside mirror to malfunction, which
can result in crashes and serious injuries.
Malfunctions in the auto-dimming function can result in the
inside mirror being unable to evaluate the exact distance of ve-
hicles in the rear or other objects.
If the light striking the sensor is filtered or blocked (such as by a
sunshade), the auto-dimming inside mirror will not work properly or
may not work at all.

Turn the adjusting knob to the L position.
Adjust the left outside mirror. The right (passenger) outside mirror
will automatically adjust at the same time.
If needed, correct the position of the right mirror by turning the ad-
justing knob to the R position.
Auto-dimming outside mirror on the driver side
Some models are equipped with an auto-dimming outside mirror,
which is controlled together with the auto-dimming inside mirror ⇒ 
Inside mirror.
Memory for front passenger side mirror (when backing up)
On vehicles equipped with memory seats ⇒ page 136, Memory seats,
the passenger side mirror settings for backing up can be stored as
follows:
Choose the remote control vehicle key that will be used with the
settings about to be made.
Unlock the vehicle with that remote control vehicle key.
Set the electronic parking brake.
Switch on the ignition.
Activate the function Mirror down in the Settings - Convenience
menu.
Turn the adjusting knob for the side mirrors to the R position.
Shift the transmission into Reverse (R).
Adjust the passenger outside mirror for a clear view of the curb, for
example.
The adjusted mirror position is automatically stored and assigned
to the vehicle key used to unlock the vehicle. The preselected posi-
tion will be recalled when the key assigned to that mirror adjustment
position is used again.
Recalling passenger side mirror settings
Turn the adjusting knob for the side mirrors to the R position.
Shift the transmission into reverse gear with the ignition switched
on.
The mirror moves back to the regular position when the vehicle
moves forward faster than about 10 mph (15 km/h) or the adjusting
knob is turned to the O or L position.

Spare wheel or compact spare wheel
The spare wheel or compact spare wheel has no tire pressure sen-
sor. When the spare or compact spare wheel is mounted on the vehi-
cle, the Tire Pressure Monitoring System (TPMS) indicator light will
flash in the instrument cluster display. The TPMS continues to moni-
tor the other 3 wheels.
Tire storage
If the tires do not move for an extended period of time, the sensors
will not transmit tire pressures to the system. This saves sensor bat-
tery life. When the ignition is switched on, the sensors transmit sig-
nals to the Tire Pressure Monitoring System.
WARNING
Incorrect tire pressure can cause sudden tire failure, loss of
vehicle control and serious personal injury.
Always check and correct air pressure in all 4 tires, particu-
larly after changing, exchanging, or repairing tires.
After that, always make sure that all 4 tires are inflated to the
correct tire pressure for the tires installed on the vehicle.
See the tire pressure label ⇒  Tire inflation pressure and the
Owner's Literature for recommended cold tire inflation pressure
and other important information.
When replacing tires or wheel rims on vehicles equipped with
TPMS, always read and heed all of the information and WARN-
INGS ⇒  Tires and wheels.
NOTICE
The wheel electronics are attached to special aluminum valves
on the wheels. These valves are screwed on rigidly. Never bend
the valves “into position” when checking and adjusting tire
pressure.
Missing tire air valve caps could result in damage to the
valves, as well as to the sensors on the Tire Pressure Monitoring
System. Therefore, make sure your valve caps conform to the
specifications of those originally installed on the vehicle and
that they are always tightly and properly screwed on to the
valves. Do not use metallic valve caps.

12 Volt socket
The 12 Volt socket works only when the ignition is switched on.
If the ignition is on but the engine is not running, the vehicle battery
will be drained by any device that is plugged in and turned on. For
this reason, never use the electrical sockets unless the engine is run-
ning.
To help prevent damage from voltage fluctuations, switch off all elec-
trical devices connected to a 12 Volt socket before switching the igni-
tion on or off or starting the engine.
The vehicle may have 12 Volt sockets at the following places:
In the storage compartment in the front center console ⇒ page 304,
Storage compartment in the front center console.
In the rear center console ⇒ Opening the socket cover.
In the luggage compartment ⇒ fig. 130.
NOTICE
Follow the manufacturer's instructions for connected devices!
Never exceed the maximum power consumption, or the entire
vehicle electrical system may be damaged.
12 Volt socket:
– Only use equipment that has been tested for electromagnet-
ic compatibility and complies with applicable guidelines.
– Never feed current into the socket, with a solar panel, for
example.
Unshielded devices may interfere with radio reception or the ve-
hicle's electrical system.

Vehicle key positions in the ignition switch

Fig. 133 In the ignition switch: Vehicle key positions.

WARNING
Improper use of vehicle keys can result in serious personal in-
jury.
Always take the key with you when you leave the vehicle. The
engine can be started and vehicle systems such as the power
windows can be operated, leading to serious personal injury.
Never leave children, disabled persons, or anyone who can-
not help themselves in the vehicle. The doors can be locked
with the remote control vehicle key. This could result in people
being trapped in the vehicle in an emergency. For example, de-
pending on the time of year, people trapped in the vehicle can
be exposed to very high or very low temperatures.
Heat buildup in the passenger and luggage compartment of a
parked vehicle can result in temperatures in the vehicle that are
much higher than the outside temperatures, particularly in
summer. Temperatures can quickly reach levels that can cause
unconsciousness and death, particularly to small children.
Never remove the key from the ignition switch while the vehi-
cle is moving or rolling to a stop. The steering wheel will lock
and you will not be able to steer or control the vehicle.
Leaving the key in the ignition for a long time when the engine is
not running will drain the vehicle battery.
Leaving the selector lever for a long period of time in any position
other than Park (P) when the ignition is switched off can drain the
vehicle battery.
On automatic transmission vehicles, the vehicle key can be
removed from the ignition switch only when the transmission is in
Park (P). You may have to press the release button on the transmis-
sion selector lever to put the lever into Park (P).

The engine switches off automatically.
Engine restart feature
If no authorized remote control vehicle key is identified in the passen-
ger compartment after the engine has been switched off, the engine
can be restarted within about 5 seconds. A related message is shown
in the instrument cluster display.
After the 5 seconds have passed, the engine can no longer be started
without an authorized vehicle key in the passenger compartment.
WARNING
Unintended vehicle movement can cause serious personal inju-
ry.
Do not depress the brake or clutch pedals when switching on
the ignition, as the engine could otherwise start immediately.
WARNING
Improper use of vehicle keys can result in serious personal in-
jury.
Always take the key with you when you leave the vehicle.
Children or unauthorized persons may use it to lock the vehi-
cle, start the engine, and operate vehicle systems such as the
power windows, leading to serious personal injury.
Never leave children, disabled persons, or anyone who can-
not help themselves in the vehicle. The doors can be locked
using the remote control vehicle key. This could result in peo-
ple being trapped in the vehicle in an emergency. For example,
depending on the time of year, people trapped in the vehicle
can be exposed to very high or very low temperatures.
Heat buildup in the passenger and luggage compartment of a
parked vehicle can result in temperatures in the vehicle that are
much higher than the outside temperatures, particularly in
summer. Temperatures can quickly reach levels that can cause
unconsciousness and death, particularly to small children.
If the ignition is switched on or the engine is running and the driv-
er door is opened, a chime sounds. The chime is also a reminder to

switch off the engine and turn off the ignition before leaving and lock-
ing the vehicle from the outside.
Starting the engine
