2018 VOLKSWAGEN CC ignition

ignition and the driver door has been opened, the power windows
cannot be opened or closed.
A separate button for controlling the window is located in the front
passenger door.
Power windows – features

For one-touch closing: Pull the switch for the window up briefly as
far as it goes.
Stopping automatic movement: Pull/press the switch again.
Reactivating the one-touch feature
If the vehicle battery is disconnected or dead and the windows are not
completely closed, the one-touch feature will not work and must be
reactivated:
Switch on the ignition.
Close all windows and doors.
Pull up the switch for the respective window and hold it for at least
2 seconds in this position.
Release the switch, pull up and hold again. The one-touch feature
is now reactivated.
The one-touch feature can be reactivated for one or more windows at
the same time.
Convenience closing
The convenience closing feature lets you close the windows and the
power sunroof as follows:
On vehicles with Keyless Access, using the door handle sensors ⇒ 
Power locking and closing system.
From inside the vehicle, pull up and hold the switch for the driver
window until all windows and the sunroof are closed ⇒ Power locking
and closing system.
Convenience closing first closes the windows and then the power
sunroof. All turn signals blink once to confirm that the windows and
power sunroof are closed.

WARNING
Improper use of power windows can result in serious personal
injury.
Never let anyone get in the way of a power window when
closing it.
When locking the vehicle from the outside, make sure that no
one, especially children, remains in the vehicle. The windows
will not open in case of an emergency.
Always take the key with you when you leave the vehicle. You
can still use the power windows for several minutes after the
ignition is switched off as long as the driver or front passenger
door has not been opened.
Always use the safety switch when children are in the back
seat to disable the rear power windows and keep them from be-
ing opened and closed.
NOTICE
The windows must go down slightly when you unlock the vehi-
cle. Otherwise the windows and seals could be damaged when
opening the doors.
If the power windows malfunction, the one-touch feature, as well
as pinch protection may not work properly. See an authorized
Volkswagen dealer or authorized Volkswagen Service Facility right
away.
Power window pinch protection

resistance or there is something in the way, the power sunroof opens
again immediately.
Check why the power sunroof did not close.
Try to close the power sunroof again by pulling the h switch brief-
ly.
If the power sunroof still cannot close, the power sunroof will stop
where the resistance is located. The power sunroof will close the next
time without pinch protection.
Closing the power sunroof without pinch protection
Within 5 seconds after the pinch protection was triggered, pull the
switch ⇒ fig. 40 until the power sunroof closes completely.
The power sunroof will now close without pinch protection!
If the power sunroof still will not close, please see an authorized
Volkswagen dealer or an authorized Volkswagen Service Facility.
WARNING
Careless or unsupervised use of the sunroof can cause serious
injuries.
Always make sure that no one is in the way of the power sun-
roof when it is closing.
Always take all vehicle keys with you when leaving the vehi-
cle.
Never leave children or persons requiring assistance unat-
tended in the vehicle, especially if they have access to the ve-
hicle key. Unsupervised use of the remote control vehicle key
can lock the vehicle, start the engine, switch on the ignition and
operate the sunroof.
The sunroof can still be opened or closed for a short period
after the ignition has been switched off, as long as the driver or
passenger door is not opened.

The vehicle must be in operating range of the garage or outer gate
drives.
With ignition turned on or engine running, press the appropriate
button on the sun visor ⇒ .
The range of the HomeLink® Universal Transmitter roughly corre-
sponds to the range of the original remote control of the device or the
electrical drive. If the garage door or the electrical drive does not
work, this could be for one of the following reasons:

Malfunction Possible cause Possible remedy
Garage door or
electrical drive
does not work.
Distance or trans-
mission angle too
great.
Try different distances and
angles to the receiver.
Garage door or
electrical drive not
compatible.
May not comply with legal
requirements and may have
to be replaced.
Incorrect
programming.
Reprogram the garage door
opener.

DANGER
20 mm button cells and other lithium batteries will cause seri-
ous personal injury and even death within a short time if swal-
lowed.
Always keep hand-held remote control devices with batteries,
spare batteries, as well as dead button cell and larger 20 mm
batteries out of the reach of children.
Get medical attention immediately if you suspect that a bat-
tery has been swallowed.

Memory buttons
Personal settings for the front seats and outside mirrors can be as-
signed to each memory button.
These settings can be assigned to individual remote control vehicle
keys. The settings are applied after unlocking the vehicle and opening
the driver door.
Storing driver seat settings and forward driving settings for
outside mirrors
Switch on the ignition.
Manual transmission: Shift the transmission to Neutral (N) and set
the electronic parking brake.
Automatic transmission: Shift the transmission to Park (P).
Adjust the driver seat and outside mirrors.
Press the 3%4 button for at least 1 second ⇒ fig. 57.
Press the desired memory button 1 , 2 , or 3 within 10 seconds. A
chime sounds to confirm that the setting has been stored.
Storing front passenger seat settings to the front passenger seat
memory buttons
Switch on the ignition.
Adjust the passenger seat.
Press the 3%4 button for at least 1 second ⇒ fig. 57.
Press the desired memory button 1 , 2 , or 3 within 10 seconds. A
chime sounds to confirm that the setting has been stored.
Storing passenger-side outside mirror settings for backing up
Set the electronic parking brake.
Switch on the ignition.
Shift the transmission to Neutral (N).
Briefly press the desired memory button 1 , 2 , or 3 on the outside
of the driver seat.
Shift the transmission into Reverse (R).
Adjust the passenger outside mirror to provide good visibility of the
curb, for example.
The adjusted mirror position is automatically stored and assigned
to the vehicle key used to unlock the vehicle. The preselected posi-

tion will be recalled when the key assigned to that mirror adjustment
position is used again.
The passenger-side outside mirror automatically adjusts back from
the position stored for backing up when the vehicle moves forward at
about 10 mph (15 km/h) or more or when the rotary knob is rotated
from R into a different position.
Recalling stored seat memory settings
Briefly press the appropriate memory button when the vehicle is not
moving, the ignition is switched off, and the vehicle door is open.
OR: If the ignition is switched on and the door is closed, press and
hold the appropriate memory button until the stored position is
reached.
Assigning driver seat and outside mirror settings to a vehicle
key
The memory function of all vehicle keys is disabled when the vehicle
is first delivered from the factory.
To enable vehicle key memory function:
Unlock the driver door.
Press and hold a memory button ⇒ fig. 57 until memory position is
reached.
Press and hold the unlock button 0 on the vehicle key and then
press the desired memory button at the same time within about
3 seconds. A chime sounds to confirm activation.
To disable vehicle key memory function:
Press and hold the 3%4 button.
Press and hold the unlock button 0 on the vehicle key and the de-
sired memory button at the same time within about 10 seconds. A
chime sounds to confirm deactivation.
Assigning settings to an additional vehicle key
Follow the instructions ⇒  Assigning driver seat and outside mirror
settings to a vehicle key to assign the driver seat and outside mirror
settings to the vehicle key.
Unlock the vehicle with the same vehicle key.
Adjust driver seat and outside mirrors.

moving at a speed of more than about 15 mph (25 km/h), the chime
will again sound for about 6 seconds, then go off for about
24 seconds, then sound again for about another 6 seconds. The
same thing happens if one of the safety belts is fastened and then
unfastened while the vehicle is moving. The safety belt warning
light i also flashes. The warning chime continues to sound at
24 second intervals for up to 2 minutes. No chime sounds at speeds
of less than about 5 mph (8 km/h).
If the ignition is switched on, the safety belt warning light i stays on
until the driver and front passenger have both buckled their safety
belts.
WARNING
Not wearing a safety belt or wearing an improperly positioned
safety belt increases the risk of severe personal injury or death.
Safety belts offer optimum protection only when used correctly.
Frontal collisions and laws of physics

Fig. 60 A vehicle with passengers not wearing safety belts approach-
es a wall.
