4649-1. Specifications
*: The engine oil capacity is a reference quantity to be used when changingthe engine oil. Warm up and turn off the engine, wait more than 5 minutes,
and check the oil level on the dipstick.
■
Engine oil selection
“Toyota Genuine Motor Oil” is us ed in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy
the following grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 5W-30
SAE 5W-30 is the best choice
for good fuel economy and
good starting in cold weather.
If SAE 5W-30 is not available,
SAE 10W-30 oil may be used.
However, it should be replaced
with SAE 5W-30 at the next oil
change.
Fuel
Fuel typeUnleaded gasoline only
Octane rating87 (Research Octane Number 91) or higher
Fuel tank capacity
(Reference)11.1 gal. (42 L, 9.2 lmp.gal.)
Lubrication system
Oil capacity
(Drain and refill
-reference
*)
With filter
Without filter 3.9 qt. (3.7 L, 3.3 Imp.qt.)
3.6 qt. (3.4 L, 3.0 Imp.qt.)
Outside temperature

4669-1. Specifications
*: The fluid capacity is the reference quantity. If replacement is necessary,contact your Toyota dealer.
Ignition system
Spark plug
MakeDENSOSK16R11
NGKIFR5A11
Gap0.043 in. (1.1 mm)
NOTICE
■ Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.
Electrical system
Battery
Open voltage* at
68°F (20°C): 12.3 V or higher
If the specific voltage is lower than the standard
value, charge the battery.
(
*: Voltage checked 20 minutes after the engine
and all the lights are turned off.)
Charging rates 5 A max.
Automatic transmission
Fluid capacity*6.8 qt. (6.4 L, 5.6 Imp.qt.)
Fluid typeToyota Genuine ATF WS
NOTICE
■Transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause
deterioration in shift quality, locking up of the transmission accompanied by
vibration and, ultimately, damage to the vehicle’s transmission.

511Alphabetical index
Child-protectors......................... 99
Cleaning ........................... 340, 344Aluminum wheels.................. 341
Exterior ................................. 340
Interior................................... 344
Seat belts .............................. 345
Clock ........................................... 87
Clutch ....................................... 467
Condenser ................................ 365
Coolant ..................................... 364
Capacity ................................ 465
Checking ............................... 364
Preparing and checking before winter....................... 221
Cooling system ........................ 364 Engine overheating ............... 453
CRS (Child Restraint System) .................................... 57
Cruise control .......................... 201
Warning lights ....................... 425
Cup holders.............................. 331
Curtain shield airbags ............... 36
Customizable features ............ 488 Deck board ............................... 335
Defogger
Outside rear view mirrors ..... 322
Rear window ......................... 322
Windshield ............................ 321
Dimensions .............................. 460
Display Drive information .................... 86
Fuel consumption information ........................... 89
Multi-information display ......... 85
Do-it-yourself maintenance .... 353
Door lock Back door ............................. 101
Side doors .............................. 96
Wireless remote control .......... 93
Doors Back door ............................. 101
Door glasses......................... 122
Door lock ................................ 96
Open door warning buzzer ... 425
Open door warning light ....... 425
Outside rear view mirrors ..... 120
Rear door child-protector ........ 99
Side doors .............................. 96
Side windows........................ 122
Driver’s seat belt reminder light ........................................ 425
Driving ...................................... 126 Break-in tips.......................... 129
Correct driving posture ........... 26
Procedures ........................... 126
Winter drive tips .................... 221D
*: For vehicles with Entune Audio Plus,
refer to the “MULTIMEDIA SYSTEM OWNER’S MANUAL”

512Alphabetical index
Eco Driving Indicator Light..... 130
Electric Power Steering (EPS)....................................... 215 Function ................................ 215
Warning light ......................... 423
Emergency flashers ................ 412
Emergency, in case of If the engine will not start ...... 448
If the vehicle battery is discharged .......................... 450
If the warning buzzer sounds ................................ 422
If the warning light
turns on .............................. 422
If you have a flat tire ............. 433
If you lose your keys ............... 94
If you think something is wrong.................................. 420
If your vehicle becomes
stuck ................................... 456
If your vehicle has to be stopped in an emergency ... 413
If your vehicle needs to be towed .................................. 415
If your vehicle overheats ....... 453 Engine
“ACC” position ...................... 146
Compartment ........................ 360
Engine switch ....................... 146
Hood ..................................... 356
How to start the engine......... 146
Identification number ............ 462
If the engine will not start ...... 448
If your vehicle has to be stopped in an emergency ... 413
Ignition switch (engine switch) ................... 146
Overheating .......................... 453
Engine coolant......................... 364 Capacity................................ 465
Checking............................... 364
Preparing and checking before winter ...................... 221
Engine coolant temperature
warning light.......................... 422
Engine immobilizer system ...... 74
Engine oil ................................. 361 Capacity................................ 464
Checking............................... 361
Preparing and checking before winter ...................... 221
Engine switch (ignition switch) .................... 146
EPS (Electric Power Steering) ................................ 215 Function ................................ 215
Warning light......................... 423
Event data recorder................... 10
E

518Alphabetical index
Tachometer ................................ 83
Tail lights .................................. 156Light switch ........................... 156
Replacing light bulbs............. 404
Wattage ................................ 470
Talk switch
*............................. 311
Telephone switch
*.................. 290
Theft deterrent system Engine immobilizer system ..... 74
Tire inflation pressure ............. 378
Maintenance data ................. 469
Warning light ......................... 426
Tire pressure warning
system .................................... 371 Function ................................ 371
Initializing .............................. 372
Installing tire pressure warning valves and
transmitters......................... 371
Registering ID codes ............ 372
Tire pressure warning reset switch ................................. 372
Warning light ......................... 426
Tires .......................................... 370 Chains................................... 222
Checking ............................... 370
If you have a flat tire ............. 433
Inflation pressure .................. 469
Replacing .............................. 433
Rotating tires......................... 371
Size ....................................... 469
Snow tires ............................. 221
Spare tire .............................. 433
Tire pressure warning
reset switch ........................ 372
Warning light ......................... 426 Tools ......................................... 434
Top tether strap ......................... 72
Towing
Emergency towing ................ 415
Dinghy towing ............... 143, 144
Towing eyelet ....................... 417
Trailer towing ........................ 142
Toyota Safety sense C ............ 171
Traction control ....................... 215
Transmission ................... 149, 153 Automatic transmission ........ 149
If the shift lever cannot be shifted from P ................ 151
Manual transmission............. 153
Trip meters ................................. 86
Turn signal lights .................... 154 Replacing light bulbs........................... 400, 404
Turn signal lever ................... 154
Wattage ................................ 470
USB memory
*.......................... 257
USB/AUX port
*........................ 232
Vanity mirrors .......................... 336
Vehicle data recordings .............. 9
Vehicle identification number ................................... 461
Vehicle Stability Control
(VSC) ...................................... 215
VSC (Vehicle Stability Control) .................................. 215
T
U
V

519Alphabetical index
Warning buzzersBrake system ....... ................. 422
Key reminder ........................ 147
Open door ............................. 425
PCS (Pre-Collision System) .............................. 177
Seat belt reminder ................ 425
Warning lights............................ 79 ABS....................................... 423
Automatic High Beam indicator .............................. 424
Brake system ....... ................. 422
Charging system ................... 422
Cruise control indicator ......... 425
Driver’s and front passenger’s seat belt
reminder light...................... 425
Electric power steering system ......... ....................... 423
High engine coolant temperature ........................ 422
LDA (Lane Departure Alert)
indicator .............................. 425
Low engine oil pressure ........ 422
Low fuel level ........................ 425
Low windshield washer fluid ..................................... 426
Maintenance required
reminder light...................... 426
Malfunction indicator lamp .... 423
Open door ............................. 425
PCS (Pre-Collision System) .............................. 424
Slip indicator ......................... 424
SRS ...................................... 423
Tire pressure......................... 426 Washer ............................. 162, 165
Checking............................... 369
Preparing and checking before winter ...................... 221
Switch ........................... 162, 165
Warning light......................... 426
Washing and waxing ............... 340
Weight ...................................... 460
Wheels ...................................... 382 Replacing.............................. 382
Size....................................... 469
Window glasses ...................... 122
Window lock switch ................ 122
Windows................................... 122 Power windows..................... 122
Rear window defogger.......... 322
Washer ......................... 162, 165
Windshield wipers ................... 162
Winter driving tips ................... 221
Wireless remote control key ............................................ 93 Locking/Unlocking .................. 93
Replacing the battery............ 388
WMA disc
*............................... 247
W
*: For vehicles with Entune Audio Plus,
refer to the “MULTIMEDIA SYSTEM OWNER’S MANUAL”
