2018 TOYOTA CAMRY HYBRID display

TABLE OF CONTENTS2
For your information....................... 6
Reading this manual .................... 12
How to search .............................. 13
Pictorial index .............................. 14
1-1. For safe useBefore driving ...................... 24
For safe driving ................... 26
Seat belts ............................ 28
SRS airbags ........................ 34
Front passenger occupant classification system ......... 47
Exhaust gas precautions ..... 52
1-2. Child safety Riding with children ............. 53
Child restraint systems ........ 54
1-3. Hybrid system Hybrid system features ....... 73
Hybrid system precautions ....................... 77
1-4. Theft deterrent system Immobilizer system ............. 84
Alarm ................................... 86
2. Instrument cluster Warning lights and indicators........................... 90
Gauges and meters............. 96
Multi-information display (4.2-inch display)............. 100
Multi-information display (7-inch display)................ 112
Head-up display ................ 128
Energy monitor/ consumption screen ........ 135 3-1. Key information
Keys................................... 146
3-2. Opening, closing and locking the doors
Doors ................................. 150
Trunk ................................. 156
Smart key system .............. 160
3-3. Adjusting the seats Front seats......................... 169
Rear seats ......................... 171
Head restraints .................. 173
3-4. Adjusting the steering wheel and mirrors
Steering wheel ................... 175
Inside rear view mirror ....... 177
Outside rear view mirrors ............................. 179
3-5. Opening and closing the windows
Power windows.................. 181
Moon roof .......................... 184
1For safety and security
2Instrument cluster
3Operation of each
component

5
1
9 7 6
5
4
3
2
8
7-1. Essential informationEmergency flashers .......... 474
If your vehicle has to be stopped in an
emergency ...................... 475
7-2. Steps to take in an emergency
If your vehicle needs to be towed ..................... 476
If you think something is wrong .............................. 479
If a warning light turns on or a warning buzzer
sounds ............................ 480
If a warning message is displayed ......................... 490
If you have a flat tire .......... 496
If the hybrid system will not start ........................... 507
If the electronic key does not operate properly ........ 509
If the 12-volt battery is discharged ...................... 512
If your vehicle overheats ... 519
If the vehicle becomes stuck................................ 523 8-1. Specifications
Maintenance data (fuel, oil level, etc.) .......... 526
Fuel information ................. 535
Tire information.................. 538
8-2. Customization Customizable features ....... 551
8-3. Items to initialize Items to initialize ................ 559
Reporting safety defects for U.S. owners ........................ 562
Seat belt instructions for Canadian owners
(in French)................................ 563
SRS airbag instructions for Canadian owners
(in French)................................ 565
What to do if... (Troubleshooting) ..................... 576
Alphabetical index ...................... 579
7When trouble arises8Vehicle specifications
9For owners
Index
For information regarding the equipment listed below, refer to “NAV-
IGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
• Navigation system
• Audio system
• Rear view monitor system• Toyota parking assist monitor
• Panoramic view monitor
• Toyota Entune

16Pictorial index
■Instrument panel
Power switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 204
Starting the hybrid system/changing the modes . . . . . . . . . . . P. 204
Emergency stop of the hybrid system . . . . . . . . . . . . . . . . . . . P. 475
When the hybrid system will not start . . . . . . . . . . . . . . . . . . . P. 507
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 213
Changing the shift position . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 213
Precautions for towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 476
When the shift lever does not move . . . . . . . . . . . . . . . . . . . . P. 217
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 96
Reading the meters/adjusting the instrument panel lights . . . . . P. 96
Warning lights/indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . P. 90
When a warning light comes on . . . . . . . . . . . . . . . . . . . . . . . . P. 480
Multi-information display . . . . . . . . . . . . . . . . . . . . . . . P. 100, 112
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 100, 11 2
When the warning messages are displayed . . . . . . . . . . . . . . P. 4901
2
3

671-2. Child safety
1
For safety and security
■Child restraint LATCH anchors
LATCH anchors are provided
for the outboard rear seats.
(Marks displaying the location
of the anchors are attached to
the seats.)
■When installing in the rear outboard seats
Install the child restraint system in accordance to the operation
manual enclosed with the child restraint system.If the head restraint interferes
with the child restraint sys-
tem installation and the head
restraint can be removed,
remove the head restraint.
(→ P. 173)
Remove the cover.
Child restraint system fixed with a child restraint LATCH anchor
1
2

781-3. Hybrid system
There is an air intake vent under
the right side of the rear seat for
the purpose of cooling the hybrid
battery (traction battery). If the
vent becomes blocked, the hybrid
battery (traction battery) may
overheat, leading to a reduction in
the hybrid battery (traction bat-
tery) output.
When a certain level of impact is detected by the impact sensor, the
emergency shut off system blocks the high voltage current and stops
the fuel pump to minimize the risk of electrocution and fuel leakage. If
the emergency shut off sy stem activates, your vehicle will not restart.
To restart the hybrid system, contact your Toyota dealer.
A message is automatically displa yed when a malfunction occurs in
the hybrid system or an improper operation is attempted.
If a warning message is shown on
the multi-information display, read
the message and follow the
instructions. ( →P. 490)
Hybrid battery (traction battery) air intake vent
Emergency shut off system
Hybrid warning message

791-3. Hybrid system
1
For safety and security
■If a warning light comes on, a warn ing message is displayed, or the 12-
volt battery is disconnected
The hybrid system may not start. In this case, try to start the system again. If
the “READY” indicator does not come on, contact your Toyota dealer.
■ Running out of fuel
When the vehicle has run out of fuel and the hybrid system cannot be started,
refuel the vehicle with at least enough gasoline to make the low fuel le\
vel
warning light ( →P. 483) go off. If there is only a small amount of fuel, the
hybrid system may not be able to start. (The standard amount of fuel is about
2.3 gal. [8.8 L, 1.9 Imp. gal.] when the vehicle is on a level surface. This value
may vary when the vehicle is on a slope. Add extra fuel when the vehicle is
inclined.)
■ Electromagnetic waves
●High voltage parts and cables on hybrid vehicles incorporate electromag-
netic shielding, and therefore emit approximately the same amount of elec-
tromagnetic waves as conventional gasoline powered vehicles or home
electronic appliances.
● Your vehicle may cause sound interference in some third party-produced
radio parts.
■ Hybrid battery (traction battery)
The hybrid battery (traction battery) has a limited service life. The lifespan of
the hybrid battery (traction battery) can change in accordance with driving
style and driving conditions.
■ Starting the hybrid system in an extremely cold environment (AXVH70
model
*)
When the hybrid battery (traction battery) is extremely cold (below approxi-
mately -22°F [-30°C]) under the influence of the outside temperature, it may
not be possible to start the hybrid system. In this case, try to start the hybrid
system again after the temperature of the hybrid battery (traction battery)
increases due to the outside temperature increase etc.
*: The model code is indicated on the Certification Label. ( →P. 527)

89
Instrument cluster2
2. Instrument clusterWarning lights and indicators .......................... 90
Gauges and meters ............ 96
Multi-information display (4.2-inch display) ............ 100
Multi-information display (7-inch display) ............... 112
Head-up display ................ 128
Energy monitor/ consumption screen ........ 135

902. Instrument cluster
4.2-inch display
7-inch display
The units used on the meters and some indicators may differ depending on
the target region.
Warning lights and indicators
The warning lights and indicators on the instrument cluster, cen-
ter panel and outside rear view mi rrors inform the driver of the
status of the vehicle’s various systems.
For the purpose of explanation, the following illustrations dis-
play all warning lights and indicators illuminated.
