2018 SUBARU CROSSTREK key fob

(103,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
Keys.........................................................................2-2
Key number plate................................................... 2-2
Keyless access with push-button start system
(if equipped).........................................................2-2
Safety precautions................................................. 2-3
Locking and unlocking by holding the access
key fob ................................................................ 2-6
Unlock using PIN Code Access.............................2-10
Power saving function.......................................... 2-11
Power saving function of access key fob..............2-12
Disabling keyless access function.........................2-12
Selecting audible signal operation.........................2-13
Warning chimes and warning indicator..................2-13
When access key fob does not operate properly ... 2-14
Replacing battery of access key fob......................2-14
Replacing access key fob.....................................2-14
Certification for keyless access with push-
button start system.............................................2-14
Immobilizer............................................................2-15
Security indicator light..........................................2-15
Key replacement...................................................2-15
Certification for immobilizer system......................2-16
Remote keyless entrysystem..............................2-17
Locking the doors.................................................2-18
Unlocking the doors..............................................2-18
Unlocking the rear gate.........................................2-19
Vehicle finder function..........................................2-19
Sounding a panic alarm........................................2-19
Setting audible signal operation
(models without“keyless access with push-
button start system”) ..........................................2-19Replacing the battery............................................2-20
Replacing lost transmitters...................................2-20
Certification for remote keyless entry system........2-20
Door locks.............................................................2-21
Locking and unlocking from the outside...............2-21
Locking and unlocking from the inside.................2-22
Key lock-in prevention function............................2-23
Battery drainage prevention function....................2-24
Alarm system........................................................2-24
Alarm system operation........................................2-25
Arming the system...............................................2-25
Disarming the system...........................................2-26
Alarm system setting............................................2-26
If you have accidentally triggered the alarm
system..............................................................2-27
Valet mode...........................................................2-27
Child safety locks.................................................2-28
Windows................................................................2-28
Power window operation.......................................2-28
Initialization of power window with one-touch
auto up/down function.......................................2-30
Rear gate...............................................................2-31
Lock/unlock..........................................................2-31
Open/close...........................................................2-31
Moonroof (if equipped).........................................2-32
Moonroof switches...............................................2-33
Sunshade.............................................................2-34
Keys and doors
2

(104,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
KeysNOTEFor models with“keyless access with
push-button start system”, refer to
“Keyless access with push-button start
system”F2-2.
The following keys are provided with the
vehicle.1) Master key (Main)
2) Master key (Sub)
3) Sub key
4) Key number plateAkeycanbeusedinthefollowing
locations.
.Ignition switch
.Driver’s door.Glove box
NOTELocking/unlocking using the remote
keyless entry system can also be con-
trolled with the buttons on the key. For
detailed information, refer to“Remote
keyless entry system”F2-17.
CAUTION
Do not attach a large key holder or
key case to either key. If it bangs
against your knees while you are
driving, it could turn the ignition
switch from the“ON”position to
the“ACC”or“LOCK”position,
thereby stopping the engine.&Key number plateThe key number is stamped on the key
number plate attached to the key set. Write
down the key number and keep it in
another safe place, not in the vehicle. This
number is needed to make a replacement
key if you lose your key or lock it inside the
vehicle. Refer to“Key replacement”F2-
15.
Keyless access with push-
button start system (if
equipped)The following access key fobs are pro-
vided with the vehicle.1) Access key fob (main)
2) Access key fob (sub)
3) Key number plateThe keyless access with push-button start
system allows you to perform the following
functions when you are carrying the
access key fob.
.Locking and unlocking of the doors and
rear gate. Refer to“Locking and unlocking
by holding the access key fob”F2-6.
.Starting and stopping the engine. For
detailed information, refer to“Starting and
Keys and doors/Keys
2-2

(105,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
stopping engine (models with push-button
start system)”F7-11.
.Arming and disarming the alarm sys-
tem. For detailed information, refer to
“Alarm system”F2-24.NOTE.Locking/unlocking using the remote
keyless entry system can also be con-
trolled with the buttons on the access
key fob. For detailed information, refer
to“Remote keyless entry system”F2-
17.
.Carefully store the key number plate
supplied with the access key fob. It is
necessary for vehicle repair and addi-
tional registration of access key fobs.
For details, refer to“Key replacement”
F2-15.
An emergency key is attached to each
access key fob.
1) Release button
2) Emergency keyWhile pressing the release button of the
access key fob, take out the emergency
key.
The emergency key is used for the follow-
ing operations.
.Locking and unlocking the driver’s door
.Locking and unlocking the glove boxNOTEThe glove box can be kept locked when
you leave your vehicle and the access
key fob (with the emergency key re-
moved) at a parking facility.
&Safety precautions
WARNING
If you wear an implanted pacemaker
or an implanted defibrillator, stay at
least 8.7 in (22 cm) away from the
transmitting antennas installed on
the vehicle.
The radio waves from the transmit-
ting antennas on the vehicle could
adversely affect the operation of
implanted pacemakers and im-
planted defibrillators.
If you wear electronic medical equip-
ment other than an implanted pace-
maker or an implanted defibrillator,
before using the keyless access
with push-button start system, refer
to“Radio waves used for the key-
less access with push-button start
system”mentioned later, and con-
tact the electronic medical equip-
ment manufacturer for more infor-
mation. The radio waves from the
transmitting antennas on the vehicle
could adversely affect the operation
of the electronic medical equipment.
“Radio waves used for the keyless
access with push-button start sys-
tem”
–CONTINUED–
Keys and doors/Keyless access with push-button start system
2-3
2

(106,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
.The keyless access with push-
button start system uses radio
waves of the following fre-
quency* in addition to the radio
waves used for the remote key-
less entry system. The radio
waves are periodically output
from the antennas installed on
the vehicle as shown in the
following illustrations.
* Radio frequency: 134 kHz
1) Antenna
CAUTION
.Never leave or store the access
key fob inside the vehicle or
within 6.6 ft (2 m) around the
vehicle (e.g., in the garage). The
access key fob may be locked
inside the vehicle, or the battery
may discharge rapidly. Note that
the push-button ignition switch
may not turn on in some cases
depending on the location of the
access key fob.
.The access key fob contains
electronic components. Observe
the following precautions to pre-
vent malfunctions.
–It is recommended to have the
access key battery replaced at
an authorized SUBARU dealer
to avoid the risk of damage.
–Do not get the access key fob
wet. If the access key fob gets
wet, wipe it off immediately
and let it dry completely.
–Do not apply strong impacts to
the access key fob.
–Never leave the access key
fob in direct sunlight or any-
where that may become hot,
such as on the dashboard. It
Keys and doors/Keyless access with push-button start system
2-4

(107,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
may damage the battery or
cause circuit malfunctions.
–Do not wash the access key
fob in an ultrasonic washer.
–Do not leave the access key
fob in humid or dusty loca-
tions. Doing so may cause
malfunctions.
–Keep the access key fob away
from magnetic sources.
–Do not leave the access key
fob near a personal computer
or home electrical appliance.
–Do not leave the access key
fob near a battery charger or
any electrical accessories.
–Do not apply metallic window
tint or attach metallic objects
to the windows.
–Do not fit non genuine acces-
sories or parts.
.If the access key fob is dropped,
the integrated emergency key in-
side may become loose. Be care-
ful not to lose the emergency key.
.When traveling in an airplane, do
not press the button of the ac-
cess key fob. If any button of the
access key fob is pressed, radio
waves are emitted and may affectthe operation of the airplane.
When carrying the access key
fob in a bag, take measures to
prevent the buttons from being
pressed accidentally.
NOTE.The operational/non-operational
setting for the keyless access function
can be changed. For the setting proce-
dure, refer to“Disabling keyless ac-
cess function”F2-12.
.For detailed information about the
operation method for the push-button
ignition switch while the keyless ac-
cess function is switched to the non-
operational mode, refer to“Access key
fob–if access key fob does not operate
properly”F9-17.
.The keyless access with push-but-
ton start system uses weak radio
waves. The status of the access key
fob and environmental conditions may
interfere with the communication be-
tween the access key fob and the
vehicle under the following conditions,
and it may not be possible to lock or
unlock the doors or start the engine.
–When operating near a facility
where strong radio waves are trans-
mitted, such as a broadcast stationand power transmission lines
–When products that transmit
radio waves are used, such as an
access key fob or a remote trans-
mitter key of another vehicle
–When carrying the access key fob
of your vehicle together with the
access key fob or the remote trans-
mitter of another vehicle
–When the access key fob is
placed near wireless communica-
tion equipment such as a cell phone
–When the access key fob is
placed near a metallic object
–When metallic accessories are
attached to the access key fob
–When carrying the access key fob
with electronic appliances such as a
laptop computer
–When the battery of the access
key fob is discharged
.The access key fob is always com-
municating with the vehicle and is
continuously using the battery.
Although the life of the battery varies
depending on the operating conditions,
it is approximately 1 to 2 years. If the
battery becomes fully discharged, re-
place it with a new one.
.If an access key fob is lost, it is
recommended that all of the remaining
access key fobs be reregistered. For
–CONTINUED–
Keys and doors/Keyless access with push-button start system
2-5
2

(108,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
reregistration of an access key fob,
contact a SUBARU dealer.
.For a spare access key fob, contact a
SUBARU dealer.
.Up to 7 access key fobs can be
registered for one vehicle.
.Do not leave the access key fob in
the storage spaces inside the vehicle,
such as the door pocket, dashboard,
inside the corner of the cargo area.
Vibrations may damage the key fob or
turn on the switch, possibly resulting in
a lockout.
.After the vehicle battery is dis-
charged or replaced, initialization of
the steering lock system may be re-
quired to start the engine. In this case,
perform the following procedure to
initialize the steering lock.
(1) Turn the push-button ignition
switch to the“OFF”position. For
details, refer to“Switching power
status”F3-7.
(2) Open and close the driver’s
door.
(3) Wait for approximately 10 sec-
onds.
When the steering is locked, the initi-
alization is completed.
.Do not leave the access key fob in
the following places.–On the instrument panel
–On the floor
–Inside the glove box
–Inside the door trim pocket
–On the rear seat
–In the cargo area
If you do, the following situations
may occur.
–The access key fob is mistakenly
locked inside the vehicle.
–A false warning issues although
no malfunction actually occurs.
–No warning issues even when
any malfunction occurs.
&Locking and unlocking by
holding the access key fobWhen the access key fob is carried within
the operating range, the doors and the rear
gate can be locked/unlocked just by
touching the door handle.NOTEThe vehicle can also be locked/un-
locked with the remote keyless entry
system. For details, refer to“Remote
keyless entry system”F2-17.!Operating ranges
1) Antenna
2) Operating range (approximately 16 to 32
in (40 to 80 cm))1) LED indicator
Keys and doors/Keyless access with push-button start system
2-6

(109,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
When the access key fob is within either of
the operating ranges of the front doors, the
LED indicator on the access key fob
flashes. When the keyless access func-
tions are disabled, the LED indicator does
not flash unless a button on the access key
fob is pressed.NOTE.If the access key fob is placed too
close to the vehicle body, the keyless
access functions may not operate
properly. If they do not operate prop-
erly, repeat the operation from further
away.
.If the access key fob is placed near
the ground or in an elevated location
from the ground, even if it is in the
indicated operating range, the keyless
access function may not operate prop-
erly.
.When the access key fob is within
the operating range, it is possible for
anyone, even someone who is not
carrying the access key fob, to operate
the keyless access function. Note that
the keyless access function can be
operated only by the door handle, door
lock sensor, rear gate opener button or
rear lock button in the operating range
in which the access key fob is detected.
.It is not possible to lock the doors
and rear gate using the keyless accessfunction when the access key fob is
inside the vehicle. However, depending
on the status of the access key fob and
the environmental conditions, the ac-
cess key fob may be locked inside the
vehicle. Before locking the vehicle,
make sure that you have the access
key fob.
.When the battery of the access key
fob is discharged, or when operating it
in a location with strong radio waves or
noise (e.g., near a radio tower, power
plant, broadcast station or an area
where wireless equipment is used), or
while talking on a cell phone, the
operating ranges may be reduced, or
the keyless access function may not
operate.
In such a case, perform the procedure
described in“Locking and unlocking”
F9-17.
.The doors may lock or unlock when
the car is being washed or exposed to a
significant amount of water that con-
tacts the door handle while the key fob
is still in the operating range.
!How to lock and unlock
It is possible to perform the following
operations when you are carrying the
access key fob.
.Lock and unlock the doors.Unlock and lock rear gate
NOTE.It is not possible to lock the doors
and rear gate using the keyless access
function when the push-button ignition
switch is in the“ACC”or“ON”position.
Refer to“Switching power status”F3-
7.
.If the door handle is gripped with a
gloved hand, the door lock may not be
released.
.If the door lock sensor is touched
three times or more repeatedly, the
system will ignore the sensor opera-
tion.
.When performing the locking proce-
dure too quickly, locking may not have
been completed. After performing the
locking procedure, it is recommended
to pull the REAR door handle to confirm
that the doors have been locked.
.If any of the doors (or the rear gate)
are not fully closed, the following will
occur to alert you that the doors (or the
rear gate) are not properly closed.
–an electronic chirp sounds five
times.
–the hazard warning flashers flash
five times.
.It is possible to lock the doors even
when one of the doors is open. After
–CONTINUED–
Keys and doors/Keyless access with push-button start system
2-7
2

(110,1)
北米Model "A1320BE-C" EDITED: 2017/ 10/ 10
performing the locking procedure,
close the opened door or rear gate to
lock it.
.Within 3 seconds after locking the
doors and the rear gate by using the
keyless access function, it is not pos-
sible to unlock doors and/or the rear
gate by using the keyless access func-
tion.
.When locking, be sure to carry the
access key fob to prevent locking the
access key fob in the vehicle.
.The setting of the hazard warning
flasher operation and the volume of the
audible signal can be changed by your
SUBARU dealer. Contact your SUBARU
dealer for details. Also, for models with
the combination meter display (color
LCD), the setting of the hazard warning
flasher operation can be changed by
operating the combination meter dis-
play (color LCD). For details, refer to
“Keyless Entry System”F3-41.!Locking with the door lock sensor
1) Door lock sensorCarry the access key fob, close all doors
including the rear gate, and touch the door
lock sensor on the door handle. All doors
including the rear gate will be locked. Also,
an electronic chirp will sound once and the
hazard warning flashers will flash once.!Locking with the rear lock button
1) Rear lock buttonCarry the access key fob, close all doors
including the rear gate and press the rear
lock button. The rear gate and all doors will
be locked. Also, an electronic chirp will
sound once and the hazard warning
flashers will flash once.
Keys and doors/Keyless access with push-button start system
2-8
