2018 Ram 2500 CLOCK

Remove the jack and tools by turning the wing bolt
counterclockwise, remove the wing bolt and then slide the
assembly out from under the seat.Release the tool bag straps from the jack and remove tools
from bag.
Jack And Tools (1500 Series)
Jack And Tool Bag
470 IN CASE OF EMERGENCY

2. Rotate the lug wrench handle counterclockwise untilthe spare tire is on the ground with enough cable slack
to allow you to pull it out from under the vehicle. 3. Pull the spare tire out from under the vehicle to gain
access to the spare tire retainer.
Rotating The Lug Wrench Handle
Pulling The Spare Tire Out
7
IN CASE OF EMERGENCY 473

WARNING!(Continued)
•If working on or near a roadway, be extremely
careful of motor traffic.
• To assure that spare tires, flat or inflated, are securely
stowed, spares must be stowed with the valve stem
facing the ground.
CAUTION!
Do not attempt to raise the vehicle by jacking on
locations other than those indicated in the Jacking
Instructions for this vehicle.
1. Remove the spare wheel, jack, and tools from storage.
2. Using the lug wrench, loosen, but do not remove, the wheel nuts by turning them counterclockwise one turn
while the wheel is still on the ground.
Jack Warning Label
476 IN CASE OF EMERGENCY

When changing a front wheel, place the scissor jack under the
rear portion of the lower control arm as shown below.
Rear Jacking Location
Operate the jack using the extension with jack hook and the
lug wrench. The extension tubes may be used but is not
required.
When changing a rear wheel, assemble the extension with
jack hook to the jack and connect the extension tubes. Place
the jack under the axle between the wheel and the shock
bracket with the extension with jack hook extending to the
rear.Connect the extension tubes and lug wrench.CAUTION!
Before raising the wheel off the ground, make sure that
the jack will not damage surrounding truck parts and
adjust the jack position as required.
4. By rotating the lug wrench clockwise, raise the vehicle until the wheel just clears the surface.
4X4 Front Jacking Location
Rear Jacking Location
7
IN CASE OF EMERGENCY 479

3. Attach the lug wrench to the extension tubes with thecurved angle facing away from the vehicle. Insert the
extension tubes through the access hole between the
lower tailgate and the top of the bumper and into the
winch mechanism tube. 4. Rotate the lug wrench handle clockwise until the wheel
is drawn into place against the underside of the vehicle.
Continue to rotate until you feel the winch mechanism
slip, or click three or four times. It cannot be overtight-
ened. Push against the tire several times to ensure it is
firmly in place.
NOTE: The winch mechanism is designed for use with the
extension tube only. Use of an air wrench or other power
tools is not recommended and can damage the winch.
Lug Wrench And Extension Tubes Assembled And In
Position
Rotating The Lug Wrench Handle
482 IN CASE OF EMERGENCY

Reinstalling The Jack And Tools (1500 Series)
1. Tighten the jack all the way down by turning the jackturn-screw counterclockwise until the jack is snug.
2. Position the jack and tool bag. Make sure the lug wrench is under the jack near the jack turn-screw. 3. Secure the tool bag straps to the jack.
Jack And Tool Bag
Jack And Tools Tied
7
IN CASE OF EMERGENCY 483

4. Place the jack and tools in the storage position holdingthe jack by the jack turn-screw, slip the jack and tools
under the seat so that the bottom slot engages into the
fastener on the floor.
NOTE: Ensure that the jack slides into the front hold down
location.
5. Turn the wing bolt clockwise to secure to the floor pan. Reinstall the plastic cover.
WARNING!
After using the jack and tools, always reinstall them in
the original carrier and location. While driving you
may experience abrupt stopping, rapid acceleration or
sharp turns. A loose jack, tools, bracket or other objects
in the vehicle may move around with force, resulting
in serious injury.
Jack Hold Down Fastener
Jack And Tools (1500 Series)
484 IN CASE OF EMERGENCY

Remove the jack and tools by turning the wing bolt
counterclockwise, remove the wing bolt and then slide the
assembly out from under the seat.Remove the jack and tools from the bracket assembly. Turn
the jack-turn-screw counterclockwise to release jack from
bracket assembly.
Wing Bolt/Jack And Tools (2500/3500 Series)Jack And Tools Bracket Assembly
486 IN CASE OF EMERGENCY
