2018 MAZDA MODEL CX-9 engine

▼Outside Temperature Display
When the ignition is switched ON, the
outside temperature is displayed.

NOTE
•Under the following conditions, the
outside temperature display may differ
from the actual outside temperature
depending on the surroundings and
vehicle conditions:
•Significantly cold or hot temperatures.
•Sudden changes in outside
temperature.
•The vehicle is parked.
•The vehicle is driven at low speeds.
Changing the Temperature Unit of the
Outside Temperature Display
The outside temperature unit can be
switched between Celsius and Fahrenheit.
Settings can be changed by operating the
center display screen.
Refer to Personalizat ion Features on page
9-11.
NOTE
When the temperature unit indicated in the
outside temperature display is changed,
the temperature unit indicated in the
engine coolant gauge display changes in
conjunction with it.
▼ Distance-to-empty
This displays the approximate distance
you can travel on the remaining fuel based
on the fuel economy.
The distance-to-empty will be calculated
and displayed every second.

NOTE
•Even though the distance-to-empty
display may indicate a sufficient amount
of remaining driving distance before
refueling is required, refuel as soon as
possible if the fuel level is very low or
the low fuel warning light illuminates.
•The display will not change unless you
add more than approximately 9 L (2.3
US gal, 1.9 Imp gal) of fuel.
•The distance-to-empty is the
approximate remaining distance the
vehicle can be driven until all the
graduation marks in the fuel gauge
indicating the remaining fuel supply
disappear.
•If there is no past fuel economy
information such as after first
purchasing your vehicle or the
information is deleted when the battery
cables are disconnected, the actual
distance-to empty/range may differ from
the amount indicated.
When Driving
Instrument Cluster and Display
4-24
CX-9_8GC3-EA-17G_Edition1
2017-5-29 10:13:38

NOTE
•If any of the INFO switch is pressed
while a message is displayed, it will no
longer be displayed the next time the
ignition is switched ON.
•After the vehicle is serviced and the
remaining time/distance is reset, the
message for the next maintenance
period will be displayed when the
remaining distance or time to the next
maintenance period approaches 0
(displays when engine is started).
•If there are multiple messages, they are
displayed according to their order.
•If OFF is set for Messages, messages
are not displayed.
▼Blind Spot Monitoring (BSM)
Display
Displays the system status.

Refer to Blind Spot M
onitoring (BSM) on
page 4-91.
▼ Distance Recognition Support
System (DRSS) Display*
Displays the distance between your
vehicle and the vehicle ahead.

Refer to Distance Recognition Support
System (DRSS) on page 4-104.
▼Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) Display
*
Displays the currently set system status.

Refer to Mazda Radar
Cruise Control with
Stop & Go function (MRCC with Stop &
Go function) on page 4-110.
When Driving
Instrument Cluster and Display
4-26*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

▼Warning Indication/Warning Lights
These lights turn on or flash to notify the user of the system
operation status or a system
malfunction.
Signal Warning Page
Brake System Warning Indication/Warning Light*1*27-30
ABS Warning Light*1
Electronic Brake
Force Distribu- tion System
Wa r n i n g 7-30
ABS warning 7-33
Charging System Warning Indication/Warning Light*17-30
Engine Oil Warning Light*17-30
(Red) High Engine Coolant Temperature Warning Indication/Warning Ligh
t
*17-30
Power Steering Malfunction Indication/Malfunction Indicator Light*17-30
Master Warning Indication/Warning Light*17-33
Electric Parking Brake (EPB) Warning Indication/Warning Light 7-33
*Engine Oil Level Warning Indication 7-33
Check Engine Light*17-33
Automatic Transaxle Warning Indication/Warning Light*17-33
When Driving
Instrument Cluster and Display
4-32*Some models.
CX-9_8GC3-EA-17G_Edition1
2017-5-29 10:13:38

SignalWarning Page
*Check Fuel Cap Warning Indication/Warning Light*17-38
Seat Belt Warning Light 7-38
Engine Oil Level Warning Light7-38
*Low Washer Fluid Level Warning Indication/Warning Light7-38
*Door-Ajar Warning Indication7-38
*Liftgate-Ajar Warning Indication7-38
*Door-Ajar Warning Light7-38
*1 The light turns on when the ignition is switched on for an ope
ration check, and turns off a few seconds later or
when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is applied.
When Driving
Instrument Cluster and Display
4-34*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

▼Indication/Indicator Lights
These lights turn on or flash to
notify the user of the system operation status or a system
malfunction.
Signal Indicator Page
Front Passenger Air Bag Deactivation Indicator Light*12-73
(Green)KEY Indicator Light 4-5
Security Indicator Light*13-45
Wrench Indication/Indicator Light*14-39
(Blue)
*Low Engine Coolant Tempe
rature Indicator Light 4-39
Shift Position Indication
4-42
Lights-On Indication/Indicator Light 4-49
Headlight High-Beam Indicator LightHeadlight
High-Low Beam 4-52
Flashing the Headlights 4-52
Turn Signal/Hazard Warning Indicator Lights Turn and
Lane-Change Signals4-54
Hazard Warning Flasher4-61
Brake Pedal Operation demand Indicator Light 4-67
When Driving
Instrument Cluster and Display
*Some models.4-35
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

▼Wrench Indicator Light
When the ignition is switched ON, the
wrench indicator light turns on and then
turns off after a few seconds.

The wrench indicator light turns on under
the following conditions:
•When the preset maintenance period has
arrived.
•When it’s time to replace the engine oil.
Refer to Maintenance Monitor on page 6-
18.
▼ Low Engine Coolant Temperature
Indicator Light (Blue)*
The light illuminates continuously when
the engine coolant temperature is low and
turns off after the engine is warm.

When Driving
Instrument Cluster and Display
*Some models.4-39
CX-9_8GC3-EA-17G_Edition1
2017-5-29 10:13:38

Automatic Transaxle Controls
Lock-release button
Indicates the selector lever can be shifted freely into any position.
Indicates that you must hold in the lock-release button to shift.
Indicates that you must depress the brake pedal and hold in the lock-release
button to shift (The ignition must be switched ON).
Various Lockouts:
NOTE
The Sport AT has an option that is not included in the traditional automatic transaxle that
gives the driver the option of selecting each gear instead of leaving it to the transaxle to
shift gears. Even if you intend to use the automatic transaxle functions as a traditional
automatic, you should also be aw are that you can inadvertently shift into manual shift mode
and an inappropriate gear may be retained as the vehicle speed increases. If you notice the
engine speed going higher or hear the engine racing, confirm you have not accidentally
slipped into manual shift mode (page 4-43).
When Driving
Automatic Transaxle
4-40
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Shift-Lock System
The shift-lock system prevents shifting out
of P unless the brake pedal is depressed.

To shift from P:
1. Depress and hold the brake pedal.
2. Start the engine.
3. Press and hold the lock-release button.
4. Move the selector lever.
NOTE
•When the ignition is switched to ACC or
the ignition is switch ed off, the selector
lever cannot be shifted from P.
•The ignition cannot be switched to OFF
if the selector lever is not in P.
▼ Shift-Lock Override
If the selector lever will not move from P
using the proper shift procedure, continue
to hold down the brake pedal.
1. Remove the shift-lock override cover
using a cloth-wrapped flat head
screwdriver.
2. Insert a screwdriver and push it down.
Cover
3. Press and hold the lock-release button.
4. Move the selector lever.
Take the vehicle to an Authorized Mazda
Dealer to have the system checked.
Transaxle Ranges
•The shift position indication in the
instrument cluster illuminates. Refer to
Warning/Indicator Lights on page 4-31.
•The selector lever must be in P or N to
operate the starter.
P (Park)
P locks the transaxle and prevents the
front wheels from rotating.
WA R N I N G
Always set the selector lever to P and set
the parking brake:
Only setting the selector lever to the P
position without using the parking brake to
hold the vehicle is dangerous. If P fails to
hold, the vehicle could move and cause an
accident.
CAUTION
 Shifting into P, N or R while the vehicle is
moving can damage your transaxle.
 Shifting into a driving gear or reverse
when the engine is running faster than
idle can damage the transaxle.
When Driving
Automatic Transaxle
4-41
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38
