2018 MAZDA MODEL CX-9 light

Interior Equipment (View A)
ƒDoor-lock knob..................................................................................................... page 3-20
„ Turn and lane-change sig nal..................................................................................page 4-54
… Lighting control.....................................................................................................page 4-49
† Wiper and washer lever......................................... ................................................ page 4-55
‡ TCS OFF switch....................................................................................................page 4-74
ˆ Lane-keep Assist System (LAS) & Lane Departure Warning System ( LDWS) OFF
switch.................................................................................................................. page 4 -126
‰ Parking sensor switch .......................................... ............................................... page 4-174
Š Power liftgate switch.......................................... ................................................... page 3-24
‹ Outside mirror switch.......................................... ..................................................page 3-35
ΠDoor-lock switch................................................................................................... page 3-17
 Power window lock switch................................................................................... page 3-39
Ž Power window switches........................................................................................ page 3-39
Pictorial Index
Interior Overview
1-2The equipment and installatio n position varies by vehicle
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Interior Equipment (View D)
ƒSeat belts............................................................................................................... page 2-21
„ SRS air bag............................................................................................................page 2- 57
… Rear door sunshade............................................. ............................................... page 5-104
† Bottle holder.................................................. ........................................................ page 5-99
‡ Sunvisor....................................................... ..........................................................page 5-91
ˆ Vanity mirror......................................................................................................... page 5-9 1
‰ Overhead lights..................................................................................................... page 5-92
Š Moonroof switch................................................................................................... page 3-41
‹ Rearview mirror................................................ .................................................... page 3-36
ΠAccessory socket............................................... .................................................... page 5-95
 Cup holders........................................................................................................... page 5-9 7
Ž Front seat................................................................................................................. pag e 2-5
 Center console................................................. ................................................... page 5-100
 External input terminal........................................ .................................................. page 5-18
‘ Seat warmer switches........................................... ................................................. page 2-12
’ Second-row seat................................................ .................................................... page 2-11
“ USB power outlet.................................................................................................. page 5-96
” Third-row seat....................................................................................................... page 2-17
Pictorial Index
Interior Overview
The equipment and installatio n position varies by vehicle1-5
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

ƒHood........................................................... ........................................................... page 6-22
„ Windshield wiper blades........................................ ............................................... page 6-31
… Moonroof...............................................................................................................page 3- 41
† Doors and keys................................................. ..................................................... page 3-12
‡ Fuel-filler lid......................................................................................................... page 3 -32
ˆ Wheels and Tires................................................................................................... page 6-41
‰ Exterior lights................................................ ........................................................ page 6-45
Š Rear window wiper blade........................................ ..............................................page 6-34
‹ Liftgate....................................................... ........................................................... page 3-22
ΠChild safety locks............................................. ..................................................... page 3-21
 Outside mirror....................................................................................................... page 3-35
Pictorial Index
Exterior Overview
1-6The equipment and installatio n position varies by vehicle
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Seat Recline
(Manual Seat)
To change the seatback angle, lean forward slightly while raisi ng the lever. Then lean back
to the desired position and release the lever.
Make sure the lever returns to i ts original position and the seatback is locked in place by
attempting to push it forward and backward.
(Power Seat)
To change the seatback angle, pr ess the front or rear side of the reclining switch. Release the
switch at the de sired position.
Lumbar Support Adjustment (Power Seat)*
To increase the seat firmness, p ress and hold the front part of the switch to the desired
position, then release it.
Press the rear part of the switch to decrease firmness.
Essential Safety Equipment
Seats
2-6*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

▼Seat Warmer*
The front seats are electrically heated. The
ignition must be switched ON.
Press the seat warmer switch while the
ignition is switched ON to operate the seat
warmer. The indicator lights turn on to
indicate that the seat warmer is operating.
The mode changes a
s follows each time
the seat warmer switch is pressed.
OFF
High Mid
Low
WA R N I N G
Be careful when using the seat warmer:
The heat from the seat warmer may be too
hot for some people, as indicated as
follows, and could cause a
low-temperature burn.
 Infants, small children, elderly people,
and physically challenged people
 People with delicate skin
 People who are excessively fatigued
 People who are intoxicated
 People who have taken sleep-inducing
medicine such as sleeping pills or cold
medicine
Do not use the seat warmer with anything
having high moisture-retention ability such
as a blanket or cushion on the seat:
The seat may be heated excessively and
cause a low-temperature burn.
Do not use the seat warmer even when
taking a short nap in the vehicle:
The seat may be heated excessively and
cause a low-temperature burn.
Do not place heavy objects with sharp
projections on the seat, or insert needles or
pins into it:
This could cause the seat to become
excessively heated and result in injury from
a minor burn.
CAUTION
Do not use organic solvents to clean the
seat. It may damage the seat surface and
the heater.
NOTE
•If the ignition is switched off while the
seat warmer is operating (High, Mid or
Low) and then switched ON again, the
seat warmer will automatically operate
at the temperature set before switching
off the ignition.
•Use the seat warmer when the engine is
running. Leaving the seat warmer on for
long periods with the engine not running
could cause the battery power to be
depleted.
•The temperature of the seat warmer
cannot be adjusted beyond High, Mid
and Low because the seat warmer is
controlled by a thermostat.
Essential Safety Equipment
Seats
*Some models.2-7
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Second-Row Seat
▼Seat Operation

Seat Slide (Forward-back adjustment)
To move a seat forward or backward, raise the lever and slide t he seat to the desired position
and release the lever.
Make sure the lever returns to i ts original position and the seat is locked in place by
attempting to push it forward and backward.
Seat Recline
To change the seatback angle, lean forward slightly while raisi ng the lever. Then lean back
to the desired position and release the lever.
The lever can also be used when flattening down the seats.
Refer to How to Split Folding the Second-Row Seats on page 2-15 .
Make sure the lever returns to i ts original position and the seatback is locked in place by
attempting to push it forward and backward.
Third-Row Seat Access
To access to the third-row seats , pull up the lever on the side of the head restraint to fold the
seatback and slide the seat forward.
Refer to How to Third-Row Seat Access on page 2-13.
Make sure the lever returns to i ts original position and the seatback is locked in place by
attempting to push it forward and backward.
Essential Safety Equipment
Seats
2-11
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

▼Seat Warmer*
The rear seats are electrically heated. The
ignition must be switched ON.
Press the seat warmer switch while the
ignition is switched ON to operate the seat
warmer. The indicato
r lights turn on to
indicate that the seat warmer is operating.
The mode changes as follows each time
the seat warmer switch is pressed.
OFF
High
Mid
Low
WA R N I N G
Be careful when using the seat warmer:
The heat from the seat warmer may be too
hot for some people, as indicated as
follows, and could cause a
low-temperature burn.
 Infants, small children, elderly people,
and physically challenged people
 People with delicate skin
 People who are excessively fatigued
 People who are intoxicated
 People who have taken sleep-inducing
medicine such as sleeping pills or cold
medicine
Do not use the seat warmer with anything
having high moisture-retention ability such
as a blanket or cushion on the seat:
The seat may be heated excessively and
cause a low-temperature burn.
Do not use the seat warmer even when
taking a short nap in the vehicle:
The seat may be heated excessively and
cause a low-temperature burn.
Do not place heavy objects with sharp
projections on the seat, or insert needles or
pins into it:
This could cause the seat to become
excessively heated and result in injury from
a minor burn.
CAUTION
Before folding a rear seatback, make sure
that the rear seat warmer switch is off. If
a rear seatback is folded while the rear
seat warmer is in operation, it may heat
the seat excessively and damage the seat
surface.
 Do not use organic solvents to clean the
seat. It may damage the seat surface and
the heater.
NOTE
•Use the seat warmer when the engine is
running. Leaving the seat warmer on for
long periods with the engine not running
could cause the battery power to be
depleted.
Essential Safety Equipment
Seats
2-12*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Do not operate the lever on the side of the
head restraint under the following
conditions:
Operating the lever on the side of the head
restraint under the following conditions is
dangerous as the seat may move
unexpectedly and cause an injury such as a
foot getting pinched between the seat and
floor.
Occupant is seated in second-row seat

Second-row seatback is folded forward

Child is seated on child restraint in
second-row seat

Entering/exiting the third-row seat area
Pull up the lever on the side of the head
restraint to fold the seatback and slide the
seat forward.
CAUTION
 Do not operate the lever on the side of a
second-row seat while the seatback is
folded down and the seat is slid forward.
If the lever is forcefully operated, it could
damage the lever.
 After entering/exiting the third-row seat
area, return the second-row seatback to
its upright position and lock it after
sliding it rearward.
Make sure it is locked by attempting to
lightly move it back and forth.
Otherwise, it could move unexpectedly
and cause injury.
Essential Safety Equipment
Seats
2-14
