2018 LEXUS LS500 Owners Manual

3055-1. Remote Touch/Display
LS500_OM_OM50F54U_(U) 5
Interior features  Double tap Tap the touchpad twice, quickly. Select the
button on the screen.
 Flick Quick and short movement along the
touchpad with you finger. Move the list
screen.
 Pinch in/Pinch out Slide fingers toward each other or apart on
the touchpad. Change the scale of the
map. NOTICE■
To prevent damage to the Remote
Touch
Observe the following precautions. Fail-
ure to do so may cause damage to the
Remote Touch. ●
Do not allow food, liquid, stickers or lit
cigarettes to contact the Remote
Touch. ●
Do not subject the Remote Touch to
excessive pressure or strong impact. ●
Do not push the touchpad with a
strong force or use a sharp pointed
object to operate the pad.

306 5-1. Remote Touch/Display
LS500_OM_OM50F54U_(U) ■
Menu screen
Press the “MENU” button on the
Remote Touch to display the menu
screen.
The displays shown in the illustrations
are used for example only and may dif-
fer from the actual vehicle. *1
: Refer to the “NAVIGATION AND
MULTIMEDIA SYSTEM OWNER’S
MANUAL”. *2
: This function is not available on some
models.
■
Split-screen display
Different information can be displayed on the left and right sides of the screen. For
example, air conditioning system screen can be displayed and operated while the
fuel consumption information screen is be ing displayed. The large screen on the
left of the display is called the main display, and the small screen to the right is
called the side display.Center Display
Center Display overview
Switch Function
Select to display the
“Destination”
screen. *1
Select to display the
radio control
screen. *1 Select to display the
media control
screen. *1
Select to display the
hands-free control
screen. *1
Select to display the
“Apps” screen. *1, 2
Select to display the
information screen. *1

( → P.87)
Select to display the
setup screen. *1
Select to display the
air conditioning con-
trol screen.
( → P.316)Switch Function

3075-1. Remote Touch/Display
LS500_OM_OM50F54U_(U) 5
Interior features ■
Main display
For details about the functions and
operation of the main display, refer to
the respective section and “NAVIGA-
TION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”. ■
Side display
The following functions can be dis-
played and operated on the side dis-
play.
Select or to display the desired
screen.
Navigation system *
Audio *
Vehicle information ( → P.89)
Air conditioning system ( → P.319) Show/hide the side display **
: Refer to the “NAVIGATION AND
MULTIMEDIA SYSTEM OWNER’S
MANUAL”.
■
Screen display during low temperatures
When the ambient temperature is
extremely low, screen response may be
delayed even if the Remote Touch is oper-
ated.
A
B
C
D E

308 5-1. Remote Touch/Display
LS500_OM_OM50F54U_(U) *
:If equipped
■
Home screen
Touch to display the audio control
screen.
Refer to “NAVIGATION AND
MULTIMEDIA SYSTEM
OWNER’S MANUAL”.
Touch to display the rear air condi-
tioning control screen. ( → P.324)
Touch to display the rear seat
adjustment screen. ( → P.124)
Touch to display the relaxation seat
(if equipped) control screen.
( → P.126)
Touch to display the rear sunshade (if equipped)/rear interior light con-
trol screen. ( → P.346)
Touch to display the Rear Multi
Operation Panel settings screen.
( → P.308)
Show the progress of unlocking the
Rear Multi Operation Panel.
Touch and hold to unlock the Rear
Multi Operation Panel.
Shortcut button Shortcut screen is displayed. Touch to dis-
play/hide commonly used buttons for a
selected mode on the bottom portion of
the screen.
buttonPress to display the home screen. ■
Rear Multi Operation Panel set-
tings screen
Screen operation settings and the
brightness of the screen can be
changed.Rear Multi Operation Panel *
The Rear Multi Operation Panel
built-into the rear armrest can be
used to operate the rear audio sys-
tem, air conditioning system, etc.
Rear Multi Operation Panel
overview
A
B
C
D
E F
G
H
I
J

3095-1. Remote Touch/Display
LS500_OM_OM50F54U_(U) 5
Interior features Touch to turn the screen off.
Touch to lock the Rear Multi Oper-
ation Panel.
Touch to adjust the brightness of
the screen.
Touch to display the automatic
screen transition settings screen.
( → P.309)
Touch to display the rear seat
return function settings screen.
( → P.125)■
Auto screen change settings
screen
Touch to turn the automatic screen
transition function on/off.
Touch to set whether the screen will
transition to the home screen or
turn off when the automatic screen
transition function operates.
Touch to set the amount of time (10/30/60/120 seconds) the Rear
Multi Operation Panel must be idle
before the automatic screen transi-
tion function operates. ■
Operating the Rear Multi Operation
Panel ●
When operating the Rear Multi Opera-
tion Panel, only use the tip of a finger. The
Rear Multi Operation Panel cannot be
operated with a fingernail, pen, etc. ●
Use only one finger when operating the
Rear Multi Operation Panel. The Rear
Multi Operation Panel cannot be oper-
ated with multiple fingers. ●
When the engine swit ch is changed to
ACCESSORY or IGNITION ON mode,
if a hand object, liquid or foreign matter is
touching the Rear Multi Operation Panel,
it may not operate correctly. In this case,
remove anything touching the Rear Multi
Operation Panel and wait for approxi-
mately 30 seconds be fore operating it
again.
If the Rear Multi Operation Panel still
cannot be operated normally, press and
hold the button to turn the Rear
Multi Operation Panel off, and then press
the button again to turn it back
on and operate it. ●
In the following situations, the Rear Multi
Operation Panel may not operate prop-
erly:
• If wearing gloves during operation, non
response may occur.
• If a wet hand is used to operate the Rear
Multi Operation Panel.
• If a screen cover or coating is applied to
on the Rear Multi Operation Panel.
• If the Rear Multi Operation Panel is dirty
or has liquid attached to it, incorrect
operation or non-response may occur.
• If the Rear Multi Operation Panel
receives electro magnetic waves, incor-
rect operation or non-response may
occur.
• If a mobile phone or other wireless com-
munication device br ought near the Rear A
B
C
D
E
A
B
C

310 5-1. Remote Touch/Display
LS500_OM_OM50F54U_(U) Multi Operation Panel.●
If the a metal object, such as the follow-
ing, is touching or covering the Rear
Multi Operation Panel:
•Coins
•Keys
• Metallic wallets or bags
• Magnetic isolation cards
• Metallic foil, such as the inner packaging
of a cigarette box
• Disposable heat packs
• Discs, such as a CD or DVD, Cables,
such as a USB cable
• Mobile devices, such as smartphones,
mobile phones, tablets, etc.●
Make sure to keep the Rear Multi Oper-
ation Panel clean. If the Rear Multi Oper-
ation Panel is dirty, it may not operate
correctly. (When cleaning the Rear Multi
Operation Panel, turn the screen off to
avoid unexpected operation.)
NOTICE■
To prevent damage to the Rear Multi
Operation Panel
Observe the following precautions. Fail-
ure to do so may cause damage to the
Rear Multi Operation Panel. ●
Keep the Rear Mult i Operation Panel
free of liquids, such as drinks or rain, as
they may cause a short circuit.
●
Do not sit on or set heavy objects on
the Rear Multi Operation Panel.
●
Do not push the Rear Multi Operation
Panel with a strong force or use a
sharp pointed object to operate the
panel.

3115-2. Lexus Climate Concierge
LS500_OM_OM50F54U_(U) 5
Interior features 5-2.Lexus Climate Concierge
Select The indicator on the Lexus Climate Con-
cierge control screen illuminates, and the
automatic air conditioning system, seat
heaters and ventilators, and heated steer-
ing wheel operate in automatic mode.
If any of the system is operated manually,
the indicator turns off. However, all other
functions continue to operate in automatic
mode. ■
Changing Lexus Climate Con-
cierge control screen between
front/rear (vehicles with 4-ZONE
climate control)
Select “Rear” to display the rear air
conditioning system screen. Select “Front” to display the front air condi-
tioning system screen.
■
When using the Lexus Climate Con-
cierge
Lexus Climate Concierge can be operated
on the sub function menu or option control
screen. ( → P.316)
■
Automatic air conditioning system
( → P.313, 323)
The temperature can be adjusted inde-
pendently for each seat. ■
Seat heaters and ventilators (if
equipped) ( → P.326)
Heating or ventilation is automatically
selected according to the set tempera-
ture of the air conditioning system, the
outside temperature, etc. ■
Heated steering wheel (if
equipped) ( → P.326)
Heated steering wheel operates auto-
matically according to the set tempera-Lexus Climate Concierge The seat heaters (if equipped), seat
ventilators (if equipped) and heated
steering wheel (if equipped) are
each automatically controlled
according to the set temperature of
the air conditioning system, the out-
side and cabin temperature, etc.
Lexus Climate Concierge allows a
comfortable condition to be main-
tained without adjusting each sys-
tem.
Press the “MENU” button on the
Remote Touch to display the main
menu and move the cursor to
to display the climate control short-
cut buttons. Then, select to dis-
play the Lexus Climate Concierge
control screen.
Turning on Lexus Climate Con-
cierge Operation of each system

312 5-2. Lexus Climate Concierge
LS500_OM_OM50F54U_(U) ture of the air conditioning system, the
outside temperature, etc. ■
Passenger detection functions●
When a passenger is detected in the
front passenger seat, the seat heater and
ventilator will operate automatically.●
When a passenger is detected in a rear
seat, the seat heater and ventilator will
operate automatically. (vehicles with
4-ZONE climate control)■
Seat heater/ventilator operation
When automatic mode is selected using the
seat heater/ventilator switch, passenger
detection is not performed. ■
Rear seat heater operation (vehicles
with DUAL-ZONE climate control)
The rear seat heaters are not controlled by
the Lexus Climate Concierge.
