2654-6. Driving tips
4
Driving
WARNING
■Driving with snow tires
Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in a loss of vehi cle control and cause death or serious injury.
●Use tires of the specified size.
●Maintain the recommended level of air pressure.
●Do not drive in excess of 75 mph (120 km/h ), regardless of the type of snow tires
being used.
●Use snow tires on all, not just some wheels.
■Driving with tire chains
Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in the vehicle being unable to be driven safely, and may
cause death or serious injury.
●Do not drive in excess of the speed limit specified for the ti re chains being used, or 30
mph (50 km/h), whichever is lower.
●Avoid driving on bumpy road surfaces or over potholes.
●Avoid sudden acceleration, abrupt steering, sudden braking and shifting operations
that cause sudden engine braking.
●Slow down sufficiently before entering a cu rve to ensure that vehicle control is main-
tained.
●Do not use LDA (Lane Departure Alert with steering control) system. (if equipped)
NOTICE
■Repairing or replacing snow tires
Request repairs or replacement of snow tires from Lexus dealers or legitimate tire
retailers.
This is because the removal an d attachment of snow tires affects the operation of the
tire pressure warning va lves and transmitters.
■Fitting tire chains
The tire pressure warning valv es and transmitters may not function correctly when tire
chains are fitted.
■When standing the windshield wipers up
Raise the wipers in line with the windshield. ( →P. 264)
Failure to do so may result in dama ge to the wipers and/or the hood.

266
ES350_OM_OM06134U_(U)
5-1. Basic OperationsLexus Display Audio system .......................................... 268
Steering wheel audio switches....................................... 274
Mobile Assistant......................... 275
USB/AUX ports .........................277
5-2. Setup Setup menu ..................................280
General settings .......................... 281
Voice settings .............................. 284
Display settings ...........................285
5-3. Using the audio system Selecting the audio source .......................................... 286
Optimal use of the audio system .......................................... 287
Audio settings ............................ 288
Audio menu screen operation ..................................... 291
5-4. Using the radio Radio operation.......................... 294
5-5. Playing an audio CD and MP3/WMA/AAC discs
CD player operation ............... 300
5-6. Using an external device Listening to an iPod................... 307
Using USB memory device.............................................. 311
Using the AUX port .................. 315
Lexus Display Audio system
5

267
ES350_OM_OM06134U_(U)
Lexus Display Audiosystem
5
5-7. Connecting Bluetooth®
Steps for using Bluetooth®
devices .......................................... 316
Registering a Bluetooth
®
device............................................ 318
Selecting a Bluetooth
®
device............................................ 319
Connecting a Bluetooth
®
audio player .............................. 320
Connecting a Bluetooth
®
phone ............................................ 321
Displaying a Bluetooth
®
device details ............................322
Detailed Bluetooth
®
settings.........................................323
5-8. Bluetooth
® Audio
Listening to Bluetooth
®
Audio............................................326
5-9. Bluetooth
® Phone
Using a Bluetooth
®
Phone ........................................... 327
Making a call ................................329
Receiving a call ...........................332
Speaking on the phone ........... 333
Using a Bluetooth
®
phone message ....................... 335
Using the steering wheel switches ....................................... 337
Bluetooth
® phone
settings........................................ 338 5-10. Phonebook
Contact settings .........................340
Messaging setting...................... 343
5-11. Bluetooth
®
What to do if... (Troubleshooting)................... 344
Bluetooth
®...................................348
5-12. Other function “Information” screen................. 354
USB photo .................................... 356
Weather information................358
Voice command system .........359

268
ES350_OM_OM06134U_(U)5-1. Basic Operations
Lexus Display Audio system∗
Eject a disc.
Disc slot
Except radio and A/V mode: Pause or
resume playing a track or file.
Radio and A/V mode: Turn mute on/off.
“TUNE•SCROLL” knob
Select a radio station band, track or file.
Select preset radio stations, or access a desired track or file.
Display the radio top screen.
Display the media top screen.
“PWR•VOL” knob
Press to turn the audio system on/o ff, and turn to adjust the volume.
∗: If equipped
Use the following buttons to start listening to the audio system.
Lexus Display Audio operation buttons
1
2
3
4
5
6
7
8

ES350_OM_OM06134U_(U)
2695-1. Basic Operations
5
Lexus Display Audio system
■“Menu” screen
To display the “Menu” screen, press the “MENU” button on the Lexus Display
Audio controller.
*: Available in the 48 states, D.C. and Alaska
ButtonFunction
“Radio”Display the radio top screen ( →P. 294)
“Media”Display the media top screen ( →P. 300, 307, 311, 315, 320)
“Climate”Display the air conditioning control screen ( →P. 368)
“Phone”Display the phone top screen ( →P. 327)
“Connected Navi”*
If a turn-by-turn navigation application has been downloaded
to a connected phone, the appl ication will be displayed and
can be used.
“Info”Display the “Information” screen ( →P. 354)
“Setup”Display the “Setup” screen ( →P. 280)
“Display”Display the display settings screen ( →P. 285)

2705-1. Basic Operations
ES350_OM_OM06134U_(U)
By using the Lexus Display Audio controlle r, you can control the audio system,
hands-free system, etc.
Display the “Source” screen or audio top screen ( →P. 286)
Display the “Menu” screen ( →P. 269)
Back button
Display the previous screen
Turn or move the controller to select a function and number.
Move the controller to display the le ft or right side of the screen.
Push the controller to enter the selected function and number.
■Using the Lexus Display Audio controller
Select: Turn or move the control-
ler.
Enter: Push the controller.
Lexus Display Audio controller
1
2
3
4
1
2

ES350_OM_OM06134U_(U)
2715-1. Basic Operations
5
Lexus Display Audio system
■Basic screen operation
When a list is displayed, use the appropriate button to scroll through the list.
Select the list by turning the con-
troller.
Return to the previous screen.
Indicator turns on when you can
move the controller left to view
additional screen text.
Indicator turns on when you can
move the controller right to view
additional screen text.
1
2
3
4

2725-1. Basic Operations
ES350_OM_OM06134U_(U)
■Input mode
Letters and numbers are inputted via the screen. Turn the controller to select the
desired character and press the
controller to input the character.
When this indicator is shown, you
can change input fields by moving
the controller forward.
When this indicator is shown, you
can change character types by
moving the controller to the right
and then selecting the desired
character type.
Select to erase characters one by one. Select and hold to erase all charac-
ters.
Select to complete data input.
■Input field mode
When in the input field you can move the cursor to the desired position.
Turn the controller to move the
cursor left or right.
When this indicator is shown, you
can move the cursor to the right
input field by moving the control-
ler to the right.
When this indicator is shown, you
can move the cursor to the left
input field by moving the control-
ler to the left.
When this indicator is shown, you can change to input mode by moving the
controller backward.
Inputting letters and numbers
1
2
3
4
5
1
2
3
4
