Power seat adjustment
Operating tips:
•The power seat motor has an auto-reset
overload protection circuit. If the motor
stops during the seat adjustment, wait
30 seconds, then reactivate the switch.
•If the seat motor stops during seat adjust-
ment, check for obstructions. Remove the
obstruction before continuing.
•To avoid discharge of the battery, do not
operate the power seats for a long period
of time when the engine is not running.
NOTE
You can store the seat settings using the
memory function (see " Memory function
(if equipped)").Forward and backward:
Move the adjusting switch
1forward or
backward as shown to move the seat to the
desired position.
Reclining:
Move the adjusting switch
2forward or
backward as shown to move the seatback to
the desired position.
The reclining feature allows the adjustment
of the seatback for occupants of different
sizes to help obtain the proper seat belt fit.
(See "Seat belts" later in this section.)
The seatback may be reclined to allow occu-
pants to rest when the vehicle is parked.Seat lifter (if equipped):
1. Pull up or push down the adjusting switch
3as shown to adjust the seat height until
the desired position is achieved.
2. Tilt up or down the adjusting switch
4as
shown to adjust the front angle of the
seat until the desired position is achieved.
NIC2606
1-4Safety — seats, seat belts and supplemental restraint system

irritation and choking. Those with a history of
a breathing condition should get fresh air
promptly. After the pretensioner(s)'s activa-
tion, load limiters allow the seat belt to re-
lease webbing (if necessary) to reduce forces
against the chest. The supplemental air bag
warning light is used to indicate malfunctions
in the pretensioner system. For additional
information, refer to Supplemental air bag
warning light in this section. If the operation
of the supplemental air bag warning light
indicates there is a malfunction, have the sys-
tem checked. It is recommended that you visit
an INFINITI retailer for this service. When
selling your vehicle, we request that you in-
form the buyer about the pretensioner sys-
tem and guide the buyer to the appropriate
sections in this Owner's Manual.
SUPPLEMENTAL AIR BAG
WARNING LABELS
Warning labels about the supplemental front
impact air bag system are placed in the ve-
hicle as shown in the illustration.
WARNING
Do not use a rear-facing child restraint on a
seat protected by an air bag in front of it.
If the air bag deploys, it may cause serious
injury or death.
SUPPLEMENTAL AIR BAG
WARNING LIGHT
The supplemental air bag warning light, dis-
playingin the instrument panel, moni-
tors the circuits for the air bag systems, pre-
tensioner(s) and all related wiring.
When the ignition switch is placed in the ON
position, the supplemental air bag warning
light illuminates. The air bag warning light will
turn off within a few seconds after the engine
is started, if the system is operational.
If any of the following conditions occur, the
front air bag, side air bag, curtain air bag and
pretensioner systems need servicing:
•The supplemental air bag warning light
remains on after approximately 7 seconds.
SSS1016ZSPA1097Z
Safety — seats, seat belts and supplemental restraint system1-53

2 Instruments and controls
Cockpit............................2-2
Instrument panel......................2-3
Meters and gauges.....................2-4
Speedometer and odometer.............2-4
Outside temperature display.............2-5
Tachometer.......................2-6
Engine coolant temperature gauge.........2-6
Fuel gauge........................2-7
Warning lights, indicator lights and audible
reminders...........................2-8
Checking lights.....................2-8
Warning lights......................2-9
Indicator lights.....................2-13
Audible reminders...................2-14
Vehicle information display...............2-15
Menus and submenus................2-16
Display Messages...................2-29
Security system......................2-60
Immobiliser.......................2-60
Anti-theft alarm system (if equipped)......2-60
Wiper and washer switch................2-61
Switching the windshield wipers on/off.....2-62
Switching the rear window wiper on/off. . . .2-63
Rear window and outside mirror defroster
switch............................2-64
Windshield de-icer switch (if equipped).......2-64
Headlight and turn signal switches..........2-65Headlight switch...................2-65
Combination switch.................2-67
Adaptive front lighting system
(LED headlight only) (if equipped).........2-67
High beam assist (LED headlight only)......2-69
Headlights misted up on the inside........2-71
Instrument brightness control...........2-71
Fog light switch (If so equipped)............2-71
Front fog lights....................2-71
Rear fog light......................2-72
Horn.............................2-72
Seat heating (if equipped)................2-73
Windows..........................2-74
Power windows....................2-74
Fixed glass roof (if equipped)..............2-78
Sunshade operation.................2-78
Clock.............................2-79
Adjusting time.....................2-79
Power outlet........................2-79
Storage...........................2-80
Glove box........................2-80
Front console compartment............2-81
Console box......................2-81
Card holder.......................2-81
Cup holders.......................2-82
Coat hooks.......................2-83
Cargo tie-down hooks................2-83

Anti-lock Braking System (ABS)
warning lightSeat belt (driver and front passenger)
warning lightHigh beam assist indicator light *
Brake warning light (red)Supplemental Restraint System (SRS)
air bag warning lightHigh beam indicator light
Low tire pressure warning light*Low fuel warning lightRear fog light indicator light
Malfunction indicator light (yellow)Vehicle Dynamic Control (VDC)
warning lightSide light indicator light
Distance warning light*Turn signal/hazard indicator lightsFront passenger air bag status light**
Electric parking brake warning light (red)Low beam indicator light
Electric parking brake warning light
(yellow)Vehicle Dynamic Control (VDC) OFF
indicator light
Coolant warning lightFront fog light indicator light* *: if equipped
**: located above heater and air conditioner controls
Some indicators and warnings are also dis-
played in the vehicle information display be-
tween the speedometer and tachometer see
"Vehicle information display".CHECKING LIGHTS
With all doors closed, apply the parking brake,
fasten the seat belts and place the ignition
switch in the ON position without starting the
engine. The following lights (if so equipped) will
come on, ,
,,,,
,,,,. These lights
should go out within a few seconds after start-
ing the engine. If any light fails to come on oroperates in a way other than described, it may
indicate a burned out bulb and/or a system
malfunction. Have the system checked. It is rec-
ommended you visit an INFINITI retailer for this
service.
WARNING LIGHTS, INDICATOR
LIGHTS AND AUDIBLE REMINDERS
2-8Instruments and controls

WARNING LIGHTS
Also see "Vehicle information display" later in
this section.
Anti-lock Braking System
(ABS) warning light
When the ignition switch is in the ON posi-
tion, the ABS warning light illuminates to in-
dicate that the ABS is operational. The light
then turns off within a few seconds after the
engine is started.
If the ABS light comes on while the engine is
running, it may indicate the anti-lock braking
system is not functioning properly. Have the
system checked. It is recommended that you
visit an INFINITI retailer for this service.
If the ABS warning light comes on while driv-
ing, it may indicate the ABS is not functioning
properly. Observe the additional display mes-
sages (if any) in the vehicle information dis-
play. Have the system checked by an
INFINITI retailer.
If an ABS malfunction occurs, the anti-lock
function is turned off. The brake system then
operates normally, but without anti-lock as-
sistance (see "Brake system").
BRAKE warning light (red)
WARNING
•Your brake system may not be working
properly if the warning light is on. Driv-
ing could be dangerous. If you judge it to
be safe, drive carefully to the nearest
service station for repairs. Otherwise,
have your vehicle towed because driving
it could be dangerous.
•Pressing the brake pedal when the igni-
tion switch is not in the ON position
and/or when the brake fluid level is low
may increase the stopping distance and
braking will require greater pedal effort
as well as pedal travel.
•If the brake fluid level is below the mini-
mum or MIN mark on the brake fluid
reservoir, do not drive until the brake
system has been checked. It is recom-
mended that you visit an INFINITI re-
tailer for this service.
When the ignition switch is placed in the ON
position, the light remains illuminated and
turns off when the engine is started. If the
light illuminates at any other time, it may
indicate that the brake system is not func-
tioning properly. If the BRAKE warning lightilluminates, stop the vehicle immediately and
contact an INFINITI retailer.
This light functions for both the parking brake
and the foot brake systems.
Low tire pressure warning
light (if equipped)
Your vehicle is equipped with a Tire Pressure
Monitoring System (TPMS) that monitors the
tire pressure of all its tires.
The low tire pressure warning light warns of
low tire pressure or indicates that the TPMS
is not functioning properly.
When the ignition switch is in the ON posi-
tion, the Low tire pressure warming light illu-
minates to indicate that the system is opera-
tional. The light then tuns off within a few
seconds after the engine is started.
Low tire pressure warning:
If the vehicle is being driven with low tire
pressure, the warning light will illuminate. A
tire pressure warning message also appears
in the vehicle information display.
When the low tire pressure warning light
illuminates, you should stop and adjust the
tire pressure of all 4 tires to the recom-
mended COLD tire pressure shown on the
Tire and Loading Information label located in
Instruments and controls2-9

Malfunction Indicator light
(MIL) (yellow)
When the ignition switch is turned to the ON
position, the yellow Malfunction Indicator
light illuminates. This means that the system
is operational.
If the yellow engine malfunction indicator
light lights up while the engine is running,
there may be a fault, for example:
•In the engine management
•In the fuel injection system
•In the exhaust system
•In the ignition system (for vehicles with
gasoline engines)
•In the fuel system (including a loose or
missing fuel filler cap).
•In other monitored items, for example the
automatic transmission.
The emission limit values may be exceeded
and the engine may be running in emergency
mode.
CAUTION
Continued vehicle operation without having
the engine control system checked and re-
paired as necessary could lead to poor drive-
ability, reduced fuel economy and possible
damage to the engine control system.
Incorrect setting of the engine control system
may lead to non-compliance of local and na-
tional emission laws and regulations.
Have the vehicle checked as soon as possible.
It is recommended you visit an INFINITI re-
tailer for this service.
Distance warning light
(if equipped)
This light illuminates if the distance to the
vehicle in front is too small for the speed
selected.
If a warning tone also sounds, you are ap-
proaching a vehicle or stationary obstacle in
your line of travel at too high a speed. For
additional information see " Forward emer-
gency braking (FEB) system (if equipped)".
Electric parking brake
warning light
The red indicator illuminates when the elec-
tric parking brake is engaged.
If the red indicator light for the electric park-
ing brake flashes or is lit and/or the yellow
warning light for the electric parking brake is
lit, observe the additional messages dis-
played in the vehicle information display.
For further parking brake operation informa-
tion see "Parking brake".
Seat belt (driver and front
passenger) warning light
The seat belt warning light reminds you to
fasten your seat belts. The light illuminates if
the engine is started, all doors are closed and
the driver’s and/or front passenger’s seat
belt is unfastened. It will remain illuminated
until the driver and/or front passenger fas-
tens their seat belt. A chime will sound once
the vehicle is in motion, see "Seat belt re-
minder chime" later in this section. See "Seat
belts" for precautions on seat belt usage.
The seat belt warning light may also illumi-
nate if there are objects on the front passen-
ger seat. Remove the objects and stow them
in a safe place.
Instruments and controls2-11

If the seat belt warning light flashes, together
with an intermittent warning tone, this means
that the driver or passenger has not fastened
their seat belt, and the speed of the vehicle is
exceeding 15 MPH (25 km/h).
Supplemental Restraint
System (SRS) air bag
warning light
WARNING
If the supplemental air bag warning light is
on, it could mean that the front air bag,
driver's knee air bag, side air bag, curtain
air bag and/or pretensioner systems will
not operate in an accident. To help avoid
injury to yourself or others, have your ve-
hicle checked by an INFINITI retailer as
soon as possible.
When the ignition switch is in the ON posi-
tion, the Supplemental Restraint System
(SRS) air bag warning light illuminates to in-
dicate that the system is operational. The
light then tuns off within a few seconds after
the engine is started.
If any of the following conditions occur, the
front air bag, front seat-mounted side-
impact air bag, roof-mounted curtain air bag
and pretensioner systems need servicing:
•The supplemental air bag warning light
remains on for longer than a few seconds
once the engine is running.
•The supplemental air bag warning light
flashes intermittently.
•The supplemental air bag warning light
does not come on at all.
It is recommended you visit an INFINITI re-
tailer for these services. Unless checked and
repaired, the supplemental restraint system
(air bag system) and/or the pretensioner sys-
tems may not function properly. For addi-
tional information, refer to "Supplemental
Restraint System (SRS)".
Coolant warning light
WARNING
If the coolant warning light is lit, the engine
may not be being cooled sufficiently and
may be damaged.
Never drive with an overheated engine.
Driving when your engine is overheated can
cause some fluids which may have leaked
into the engine compartment to catch fire.
In addition, steam from an overheated en-
gine can cause serious burns, which can oc-
cur just by opening the hood.
There is a risk of injuryIf the red coolant warning light lights up while
the engine is running and the coolant tem-
perature gauge is at the start of the scale, the
temperature sensor for the coolant tempera-
ture gauge is faulty. The coolant temperature
is no longer being monitored. There is a risk of
engine damage if the coolant temperature is
too high.
Stop the vehicle immediately, paying atten-
tion to road and traffic conditions, and switch
off the engine. Do not continue driving under
any circumstances.
Consult an INFINITI retailer.
If the red coolant warning light comes on
while the engine is running, with or without
an accompanying warning tone, it could
mean that:
•The coolant level is too low.
•If the coolant level is correct, the airflow to
the engine radiator may be blocked or the
electric engine radiator fan may be mal-
functioning.
•The coolant is too hot and the engine is no
longer being cooled sufficiently.
Observe the additional display messages in
the vehicle information display.
2-12Instruments and controls

Stop the vehicle immediately, paying atten-
tion to road and traffic conditions, and switch
off the engine.
Secure the vehicle against rolling away.
Leave the vehicle and keep a safe distance
from the vehicle until the engine has cooled
down.
Check the coolant level and top up the cool-
ant, observing the warning notes (see "If your
vehicle overheats").
If you have to top up the coolant frequently,
have the engine cooling system checked.
Make sure that the air supply to the engine
radiator is not blocked, e. g. by frozen slush.
Do not start the engine again until the cool-
ant temperature is below 250°F (120°C). The
engine may otherwise be damaged.
Low fuel warning light
This light comes on when the fuel level in the
fuel tank is getting low. Refuel as soon as it is
convenient, preferably before the fuel gauge
reaches 0 (Empty).There will be a small re-
serve of fuel in the tank when the fuel gauge
reaches 0 (Empty).
Vehicle Dynamic Control
(VDC) warning light
The VDC warning light blinks when the Ve-
hicle Dynamic Control (VDC) system is oper-
ating, thus alerting the driver to the fact that
the road surface is slippery and the vehicle is
nearing its traction limits.
You may feel or hear the system working, this
is normal.
The light will continue to blink for a few sec-
onds after the VDC system stops limiting
wheel spin.
Cruise control or Intelligent Cruise Control is
deactivated.
For additional information see " Vehicle Dy-
namic Control (VDC) OFF indicator light " and
"Vehicle Dynamic Control (VDC) system".
INDICATOR LIGHTS
Turn signal/hazard indicator
lights
The appropriate light flashes when the turn
signal switch is activated. Both lights flash
when the hazard switch is turned on.
Low beam indicator light
This light comes on when the switch is turned
to the position:
The headlights will come
on and front side, tail, number plate and in-
strument lights remain on.
Vehicle Dynamic Control
(VDC) OFF indicator light
The light comes on when the Vehicle Dy-
namic Control (VDC) has been disabled. This
indicates that the VDC system is not operat-
ing.
Disabling the VDC system causes the For-
ward Emergency Braking system to become
unavailable. See " Forward emergency brak-
ing (FEB) system (if equipped)" for more de-
tails.
This light also comes on briefly when the
ignition switch is turned to the ON position.
The light will turn off after approximately
1 second if the VDC system is operational.
When the VDC OFF indicator light and VDC
warning light (see " Vehicle Dynamic Control
(VDC) warning light" later in this section)
come on with the VDC system turned on, it
alerts the driver to the fact that the system's
fail-safe mode is operating. This means that
the system may not be functioning properly.
Instruments and controls2-13
