2018 INFINITI QX30 check engine

Problems with the transmission:
ProblemPossible causes/consequences and solutions
The transmission has problems shifting gear The transmission is losing oil.
Have the transmission checked immediately. It is recommended you visit an
INFINITI retailer for this service.
The acceleration ability is deteriorating The transmission no longer shifts into
all of the gears Reverse gear can no longer be engagedThe transmission is in emergency mode.
•Stop.•Shift the transmission to position P (Park).•Switch off the engine.•Wait at least ten seconds before restarting the engine.•Shift the transmission to position D (Drive).•Have the transmission checked immediately. It is recommended you visit an
INFINITI retailer for this service.
5-26Starting and driving

Before driving, check that the brake warning
lightgoes out. For additional informa-
tion, see "Warning lights, indicator lights and
audible reminders".
The electric parking brake can only be re-
leased when the ignition switch is in the ON
position.
APPLYING AUTOMATICALLY
(VEHICLES WITH AUTOMATIC
TRANSMISSION)
The electric parking brake is automatically ap-
plied if Intelligent Parking Assist (if equipped) is
keeping the vehicle stationary.
The redindicator light lights up in the
combination meter.
The electric parking brake is not automati-
cally applied if the engine is switched off by
the Idle Stop/Start function.
RELEASING AUTOMATICALLY
The electric parking brake can only be re-
leased automatically in vehicles with auto-
matic transmission.
The electric parking brake of your vehicle is
released automatically when all of the fol-
lowing conditions are fulfilled:
•The engine is running.
•The transmission is in position D (Drive) or
R (Reverse).
•The seat belt is fastened.
•You depress the accelerator pedal.
If the transmission is in position R, the lift
gate must be closed.
If your seat belt is not fastened, the following
conditions must be fulfilled to automatically
release the electric parking brake:
•The driver's door is closed
•You have shifted out of transmission posi-
tion P (Park) or you have previously driven
faster than 2 MPH (3 km/h).
Ensure that you do not depress the accelera-
tor pedal unintentionally. Otherwise, the
parking brake will be released and the vehicle
will start to move.
EMERGENCY BRAKING
The vehicle can also be braked during an emer-
gency by using the electric parking brake.
While driving, push handle1of the electric
parking brake. The vehicle is braked as long as
you keep handle
1of the electric parking
brake pressed. The longer the electric parking
brake handle
1is depressed, the greater the
braking force.
During braking:
•A warning tone sounds.
•The [Please Release Parking Brake] mes-
sage appears.
•The redindicator light in the combi-
nation meter flashes.
When the vehicle has been braked to a stand-
still, the electric parking brake is applied.
5-28Starting and driving

1Steering wheel mounted controls
2Vehicle information display
ADisplay area
BMenu bar
LDW SYSTEM TEMPORARILY
UNAVAILABLE
Under the following conditions, the LDW
system will be canceled automatically, and
the message [Lane Departure Warning Cur-
rently Unavailable See Operator's Manual] isdisplayed in the vehicle information display
2. The LDW system is temporarily unavail-
able.
•The windshield is dirty in the camera's field
of vision.
•Visibility is impaired due to heavy rain,
snow or fog.
•There have been no lane markings for an
extended period.
•The lane markings are worn, dark, or cov-
ered by dirt or snow, etc.
Action to take:When the above conditions
no longer exist, the message goes out and the
LDW system is operational again. If the mes-
sage continues to appear, stop the vehicle in
a safe location, press the P (Park) button , and
clean the windshield.
SYSTEM MALFUNCTION
If the LDW system malfunctions, it will cancel
automatically, and the message [Lane De-
parture Warning Inoperative] will appear.
Action to take:Stop the vehicle in a safe
location, engage P (Park), turn the engine off
and restart the engine. If the message contin-
ues to appear, have the system checked. It is
recommended you visit an INFINITI retailer
for this service.
NSD626
Starting and driving5-35

SYSTEM TEMPORARILY
UNAVAILABLE
1Vehicle information display
If radar blockage is detected, the system will
be turned off automatically, and the [BlindSpot Warning Currently Unavailable See
Operator's Manual] message appears in the
vehicle information display1. The system is
not available until the conditions no longer
exist.The radar sensors may be blocked by tempo-
rary ambient conditions such as splashing
water, mist or fog. The blocked condition
may also be caused by objects such as ice,
frost or dirt obstructing the radar sensors.
Action to take:When the above conditions
no longer exist, the system will resume auto-
matically. If the message still appears, have
the system checked. It is recommended you
visit an INFINITI retailer for this service.
System malfunction
If the system malfunctions, it will be turned
off automatically, and the [Blind Spot Warn-
ing Inoperative] message appears in the ve-
hicle information display
1.
Action to take:Stop the vehicle in a safe
location, place the vehicle in the P (Park) po-
sition, turn the engine off and restart the
engine.
If the message still appears, have the system
checked. It is recommended you visit an
INFINITI retailer for this service.
NSD631
Starting and driving5-45

is covered with ice, a transparent or translu-
cent vinyl bag, etc., the ICC system may not
detect them. In these instances, the ICC sys-
tem may not cancel and may not be able to
maintain the selected following distance
from the vehicle ahead.
If the ICC system stops working due to a
malfunction or some other reason, one of the
following messages will be displayed in the
vehicle information display
2.
•[ICC off]
•[ICC Now Available]
•[ICC Currently Unavailable See Operator's
Manual]
•[ICC Inoperative]
•[ICC Suspended]
•[ICC– – – MPH]
[ICC off]:The ICC system has been deacti-
vated. If it was not deactivated by the driver,
a warning tone also sounds.
[ICC Now Available]:The ICC system is op-
erational again after having been temporarily
unavailable. You can now reactivate the ICC
system.[ICC Currently Unavailable See Operator's
Manual]:The ICC system is temporarily inop-
erative. Possible causes:
•The function is impaired due to heavy rain
or snow.
•The radar sensor system is temporarily in-
operative, e. g. due to electromagnetic ra-
diation emitted by nearby TV or radio sta-
tions or other sources of electromagnetic
radiation.
•The system is outside the operating tem-
perature range.
•The on-board voltage is too low.
A warning tone also sounds.
Once the causes listed above no longer apply,
the display message goes out.
If the display message does not disappear:
•Pull over and stop the vehicle safely as
soon as possible, paying attention to road
and traffic conditions.
•Secure the vehicle against rolling away.
•Restart the engine.[ICC Inoperative]:The ICC system is mal-
functioning. The adaptive brake assist func-
tion may also have failed. A warning tone also
sounds. Have the system checked. It is rec-
ommended you visit an INFINITI retailer for
this service.
[ICC Suspended]:You have depressed the
accelerator pedal. The ICC system is no lon-
ger controlling the speed of the vehicle.
The display message should disappear when
you remove your foot from the accelerator
pedal
[ICC–––MPH]:An activation condition for
the ICC system is not fulfilled.
Check the activation conditions for the ICC
system.
Starting and driving5-61

Self-test feature
The ABS includes electronic sensors, electric
pumps, hydraulic solenoids and a computer.
The computer has a built-in diagnostic fea-
ture that tests the system each time you start
the engine and move the vehicle at a low
speed in forward or reverse. When the self-
test occurs, you may hear a “clunk” noise
and/or feel a pulsation in the brake pedal.
This is normal and does not indicate a mal-
function. If the computer senses a malfunc-
tion, it switches the ABS off and illuminates
the ABS warning light on the instrument
panel. The brake system then operates nor-
mally, but without anti-lock assistance. If the
ABS warning light illuminates during the
self-test or while driving, have the vehicle
checked. It is recommended you visit an
INFINITI retailer for this service.
Normal operation
The ABS operates at speeds above 3 to 6
MPH (5 to 10 km/h). The speed varies ac-
cording to road conditions.
When the ABS senses that one or more
wheels are close to locking up, the actuator
rapidly applies and releases hydraulic pres-
sure. This action is similar to pumping the
brakes very quickly. You may feel a pulsation
in the brake pedal and hear a noise from
under the hood or feel a vibration from the
actuator when it is operating. This is normal
and indicates that the ABS is operating prop-
erly. However, the pulsation may indicate
that road conditions are hazardous and extra
care is required while driving.The Vehicle Dynamic Control (VDC) system
uses various sensors to monitor driver inputs
and vehicle motion. Under certain driving
conditions, the VDC system helps to perform
the following functions.
•Controls brake pressure to reduce wheel
slip on one slipping drive wheel so power is
transferred to a non slipping drive wheel
on the same axle.
•Controls brake pressure and engine output
to reduce drive wheel slip based on vehicle
speed (traction control function).
•Controls brake pressure at individual
wheels and engine output to help the
driver maintain control of the vehicle in the
following conditions:
– understeer (vehicle tends to not follow
the steered path despite increased
steering input)
– oversteer (vehicle tends to spin due to
certain road or driving conditions).
The VDC system can help the driver to main-
tain control of the vehicle, but it cannot pre-
vent loss of vehicle control in all driving situ-
ations.
VEHICLE DYNAMIC CONTROL (VDC)
SYSTEM
5-92Starting and driving

When the VDC system operates, the VDC
warning light in the instrument panel flashes
so note the following:
•The road may be slippery or the system
may determine some action is required to
help keep the vehicle on the steered path.
•You may feel a pulsation in the brake pedal
and hear a noise or vibration from under
the hood. This is normal and indicates that
the VDC system is working properly.
•Adjust your speed and driving to the road
conditions.
See " Vehicle Dynamic Control (VDC) warning
light".
If a malfunction occurs in the system, the
VDC warning light
illuminates in the
instrument panel. The VDC system automati-
cally turns off.
WARNING
•The VDC system is designed to help the
driver maintain stability but does not
prevent accidents due to abrupt steer-
ing operation at high speeds or by care-
less or dangerous driving techniques.Reduce vehicle speed and be especially
careful when driving and cornering on
slippery surfaces and always drive care-
fully.
•Do not modify the vehicle’s suspension.
If suspension parts such as shock ab-
sorbers, struts, springs, stabilizer bars,
bushings and wheels are not INFINITI
recommended for your vehicle or are ex-
tremely deteriorated, the VDC system
may not operate properly. This could
adversely affect vehicle handling per-
formance, and the VDC warning light
may illuminate.
•If brake related parts such as brake
pads, rotors and calipers are not
INFINITI recommended or are extremely
deteriorated, the VDC system may not
operate properly and the VDC warning
light
may illuminate.
•If engine control related parts are not
INFINITI recommended or are extremely
deteriorated, the VDC warning light
may illuminate.
•When driving on extremely inclined sur-
faces such as higher banked corners, the
VDC system may not operate properly and
the VDC warning light
may illuminate.
Do not drive on these types of roads.
•When driving on an unstable surface
such as a turntable, ferry, elevator or
ramp, the VDC warning light
may
illuminate. This is not a malfunction.
Restart the engine after driving onto a
stable surface.
•If wheels or tires other than the INFINITI
recommended ones are used, the VDC
system may not operate properly and the
VDC warning light
may illuminate.
•The VDC system is not a substitute for
winter tires or tire chains on a snow cov-
ered road.
•If VDC is malfunctioning, VDC is unable
to stabilize the vehicle. In addition,
other driving safety systems are
switched off. This increases the risk of
skidding and an accident. Drive on care-
fully. Have VDC checked. It is recom-
mended you visit an INFINITI retailer for
this service.
Starting and driving5-93

If you deactivate VDC:
•VDC no longer intervenes in understeer or
oversteer situations.
•Engine torque is no longer limited and the
drive wheels are able to spin.
The spinning of the wheels results in a
cutting action, so the tires cut through the
loose surface until the hit solid ground,
giving better traction.
•Traction control is still activated.
•VDC still provides support when you brake.
EBD (ELECTRONIC BRAKE
FORCE DISTRIBUTION)
EBD monitors and controls the brake pres-
sure on the rear wheels to help improve han-
dling during braking.
WARNING
If EBD is malfunctioning, the EBD [Inop-
erative See Operator's Manual] warning is
displayed in the vehicle information dis-
play. The
VDC warning light may also
light up.
If EBD is malfunctioning as a result of a
VDC malfunction, the rear wheels can lock,
e.g. under full braking. This increases the
risk of skidding and an accident.You should therefore adapt your driving
style to the different handling characteris-
tics. Have the brake system checked. It is
recommended you see an INFINITI retailer.
STEER CONTROL
STEER CONTROL helps you by transmitting
a noticeable steering force to the steering
wheel in the direction required for vehicle
stabilisation.
This steering support is provided in particular
if:
•Both right wheels or both left wheels are
on a wet or slippery road surface when
you brake.
•The vehicle starts to skid.
WARNING
No steering support is provided from
STEER CONTROL, if:
•VDC is malfunctioning.•The steering is faulty.
Power steering will, however, continue to
function.
WARNING
•Never rely solely on the Hill Start Assist
(HSA) system to prevent the vehicle
from moving backward on a hill. Always
drive carefully and attentively. Depress
the brake pedal when the vehicle is
stopped on a steep hill. Be especially
careful when stopped on a hill on frozen
or muddy roads. Failure to prevent the
vehicle from rolling backwards may re-
sult in a loss of control of the vehicle and
possible serious injury or death.
•The Hill Start Assist system is not de-
signed to hold the vehicle at a standstill
on a hill. Depress the brake pedal when
the vehicle is stopped on a steep hill.
Failure to do so may cause the vehicle to
roll backwards and may result in a colli-
sion or serious personal injury.
•The Hill Start Assist system may not
prevent the vehicle from rolling back-
wards on a hill under all load or road
conditions. Always be prepared to de-
press the brake pedal to prevent the
vehicle from rolling backwards. Failure
to do so may result in a collision or seri-
ous personal injury.
HILL START ASSIST (HSA)
Starting and driving5-95
