If you see this symbol, it means“Do not do
this”or“Do not let this happen”.
If you see a symbol similar to these in an
illustration, it means the arrow points to the
front of the vehicle.
Arrows in an illustration that are similar to
these indicate movement or action.
Arrows in an illustration that are similar to
these call attention to an item in the illustra-
tion.
[]:
Square brackets are used to indicate mes-
sages, keys, or items displayed on a screen.
<>:
Chevrons or angle brackets are used to indi-
cate texts on controls like buttons or
switches inside or on the vehicle.
CALIFORNIA PERCHLORATE
ADVISORY
Some vehicle parts, such as lithium batteries,
may contain perchlorate material. The fol-
lowing advisory is provided: “Perchlorate
Material - special handling may apply, See
www.dtsc.ca.gov/hazardouswaste/
perchlorate.”
© 2018 NISSAN MOTOR CO., LTD.
All rights reserved. No part of this Owner’s
Manual may be reproduced or stored in a
retrieval system, or transmitted in any form,
or by any means, electronic, mechanical, pho-
tocopying, recording or otherwise, without
the prior written permission of Nissan Motor
Co., Ltd.

Table of contents
Illustrated table of contents
Safety — seats, seat belts and supplemental restraint system
Instruments and controls
Pre-driving checks and adjustments
Display screen, heater and air conditioner, and audio system
Starting and driving
In case of emergency
Appearance and care
Do-it-yourself
Maintenance and Schedules
Technical information
Index
0
1
2
3
4
5
6
7
8
9
10
11

1. Ventilators (P. 4-28)
2. Center display* (P. 4-2**)
3. Meters and gauges (P. 2-4)
4. Light switch (P. 2-65)
5. Parking brake (P. 3-27)6. Steering wheel
— Power steering system (P. 5-89)
— Horn (P. 2-72)
— Driver’s supplemental front-impact air
bag (P. 1-37)
7. Audio system (P. 4-2**)8. Ignition switch (P. 5-13)
— Push button ignition switch* (P. 5-14)
9. Heater and air conditioner (P. 4-29)
10. Switch panel
— Seat heater switches* (P. 2-73)
— Hazard indicator flasher switch
(P. 6-2)
— Idle Stop/Start system on/off switch
(P. 5-30)
— Front passenger air bag status light
(P. 1-45)
11. Vehicle Information Display (P. 2-15)
12. Glove box (P. 2-80)
13. Front passenger supplemental air bag
(P. 1-37)
*: if equipped
** refer to the INFINITI InTouch Owner’s
Manual
NIC2898
INSTRUMENT PANEL
Illustrated table of contents0-7

1. Speedometer (P. 2-4)
2. Vehicle information display (P. 2-15)
— Odometer/twin trip odometer (P. 2-15)
3. Upper information display (P. 2-15)
4. Tachometer (P. 2-6)5. Engine coolant temperature gauge
(P. 2-6)
6. Fuel gauge (P. 2-7)
NIC2651
METERS AND GAUGES
0-8Illustrated table of contents

occupant is too close to, or is against, the
front air bag module during inflation. The
front air bags deflate quickly after a collision.
The front air bags operate only when the
ignition switch is placed in the ON position.
After placing the ignition switch in the ON
position, the supplemental air bag warning
light illuminates. The supplemental air bag
warning light will turn off a few seconds af-
ter the engine starts if the system is opera-
tional.
Front passenger air bag and status
light
WARNING
The front passenger air bag is designed to
automatically turn OFF under some condi-
tions. Read this section carefully to learn
how it operates. Proper use of the seat,
seat belt and child restraints is necessary
for most effective protection. Failure to
follow all instructions in this manual con-
cerning the use of seats, seat belts and
child restraints can increase the risk or se-
verity of injury in an accident.
1indi-
cator light
2in-
dicator light
Status light
The front passenger seat is equipped with an
occupant classification sensor (pressure sen-
sor) that turns the front passenger air bag on
or off depending on the weight applied to the
front passenger seat. The indicator lights in-
form you whether the front passenger front
air bag is disabled or enabled.
Place the ignition in the ON position. The
system carries out a self-diagnosis.The and SENGER AIRBAG ON> indicator lights will
light up simultaneously for approximately six
seconds.
The indicator lights display the status of the
front passenger front air bag:
• lights up: the
front passenger front air bag is enabled. If,
in the event of an accident, all deployment
criteria are met, the front passenger front
air bag is deployed.
• lights up:
the front passenger front air bag is dis-
abled. It will then not be deployed in the
event of an accident.
If the status of the front passenger front air
bag changes while the vehicle is in motion, an
air bag display message appears in the ve-
hicle information display. When the front
passenger seat is occupied, always pay at-
tention to the
and indicator
lights. Be aware of the status of the front
passenger front air bag both before and dur-
ing the journey.
If neither the
or the indicator
lights light up, or if either indicator light only
lights up intermittently during the journey, the
front passenger seat may not be used for a
NIC2740
Safety — seats, seat belts and supplemental restraint system1-45

2 Instruments and controls
Cockpit............................2-2
Instrument panel......................2-3
Meters and gauges.....................2-4
Speedometer and odometer.............2-4
Outside temperature display.............2-5
Tachometer.......................2-6
Engine coolant temperature gauge.........2-6
Fuel gauge........................2-7
Warning lights, indicator lights and audible
reminders...........................2-8
Checking lights.....................2-8
Warning lights......................2-9
Indicator lights.....................2-13
Audible reminders...................2-14
Vehicle information display...............2-15
Menus and submenus................2-16
Display Messages...................2-29
Security system......................2-60
Immobiliser.......................2-60
Anti-theft alarm system (if equipped)......2-60
Wiper and washer switch................2-61
Switching the windshield wipers on/off.....2-62
Switching the rear window wiper on/off. . . .2-63
Rear window and outside mirror defroster
switch............................2-64
Windshield de-icer switch (if equipped).......2-64
Headlight and turn signal switches..........2-65Headlight switch...................2-65
Combination switch.................2-67
Adaptive front lighting system
(LED headlight only) (if equipped).........2-67
High beam assist (LED headlight only)......2-69
Headlights misted up on the inside........2-71
Instrument brightness control...........2-71
Fog light switch (If so equipped)............2-71
Front fog lights....................2-71
Rear fog light......................2-72
Horn.............................2-72
Seat heating (if equipped)................2-73
Windows..........................2-74
Power windows....................2-74
Fixed glass roof (if equipped)..............2-78
Sunshade operation.................2-78
Clock.............................2-79
Adjusting time.....................2-79
Power outlet........................2-79
Storage...........................2-80
Glove box........................2-80
Front console compartment............2-81
Console box......................2-81
Card holder.......................2-81
Cup holders.......................2-82
Coat hooks.......................2-83
Cargo tie-down hooks................2-83

1. Ventilators (P. 4-28)
2. Center display* (P. 4-2**)
3. Meters and gauges (P. 2-4)
4. Light switch (P. 2-65)
5. Parking brake (P. 3-27)6. Steering wheel
— Power steering system (P. 5-89)
— Horn (P. 2-72)
— Driver’s supplemental front-impact air
bag (P. 1-37)
7. Audio system (P. 4-2**)8. Ignition switch (P. 5-13)
— Push button ignition switch* (P. 5-14)
9. Heater and air conditioner (P. 4-29)
10. Switch panel
— Seat heater switches* (P. 2-73)
— Hazard indicator flasher switch
(P. 6-2)
— Idle Stop/Start system on/off switch
(P. 5-30)
— Front passenger air bag status light
(P. 1-45)
11. Vehicle Information Display (P. 2-15)
12. Glove box (P. 2-80)
13. Front passenger supplemental air bag
(P. 1-37)
*: if equipped
** refer to the INFINITI InTouch Owner’s
Manual
NIC2898
INSTRUMENT PANEL
Instruments and controls2-3

1. Speedometer (P. 2-4)
2. Vehicle information display (P. 2-15)
— Odometer/twin trip odometer (P. 2-15)
3. Upper information display (P. 2-15)
4. Tachometer (P. 2-6)5. Engine coolant temperature gauge
(P. 2-6)
6. Fuel gauge (P. 2-7)NOTE
The needle indicators may move slightly af-
ter the ignition switch is put in the “OFF”
position. This is not a malfunction.
CAUTION
•For cleaning, use a soft cloth, dampened
with water. Never use a rough cloth,
alcohol, thinner or any kind of solvent or
paper towel with a chemical cleaning
agent. They will scratch or cause discol-
oration to the lens.
•Do not spray any liquid such as water on
the meter lens. Spraying liquid may
cause the system to malfunction.
SPEEDOMETER AND
ODOMETER
This vehicle is equipped with a speedometer
and odometer. The speedometer is located
on the right side of the meter cluster. The
odometer is located below the vehicle infor-
mation display.
NIC2651
METERS AND GAUGES
2-4Instruments and controls
