2018 FIAT 500 navigation system

77
Connected services that can be
accessed on the vehicle
The Uconnect™ LIVE services
available in the radio menu can change
according to the market.
The eco:Drive™ and my:Car
applications were developed to
improve the customer’s driving
experience, therefore they are available
in all markets, where the Uconnect™
LIVE services can be accessed.
For further information visit the
www.DriveUconnect.eu website.
If the navigation system is installed in
the radio, accessing the Uconnect™
LIVE services enables use of the
TomTom LIVE services. Further
information about the LIVE functions is
available in the dedicated chapter.
eco:Drive™
The eco:Drive™ application allows you
to display your driving behaviour in real
time, in order to help you reach a more
efficient driving style as far as
consumption and emissions are
concerned.In addition, the data can be saved on a
USB flash drive, and the data analysis
can be made on your personal
computer thanks to the eco:Drive™
desktop application, available on
www.fiat.it or www.DriveUconnect.eu.
Driving style is evaluated by means of
four indices which monitor the
following parameters:
❒ Acceleration
❒ Deceleration
❒ Shifting
❒ Speed
eco:Drive™ display
Press the eco:Drive™ button to
interact with the function.
A screen will be displayed on the radio,
showing the 4 indices described
above. These indices are grey until the
system has enough data to evaluate
the driving style.
Once sufficient data are available, the
indices will have 5 colours depending
on the evaluation: dark green (very
good), light green, yellow, orange and
red (very bad).“Current trip index” refers to the entire
value calculated in real time based on
the average of the described indices.
It represents eco-friendliness of the
driving style: from 0 (low) to 100 (high).
In the event of extended inactivity the
display will show the average of the
indices up to that moment (”Average
index”) then the indices will be
coloured again in real time as soon as
the vehicle is restarted.
To check the data average of previous
trip (a “trip” is a cycle starting from
when the ignition key is turned on until
it is turned off), select the “Previous
Trip” button (fig. 4).
The details of the previous trip can also
be displayed by pressing the “Details”
button, in which duration (time and
mileage) and average speed will be
shown.

79
❒ SiriusXM Setup
(for versions/markets, where
provided);
❒ Radio Setup;
❒ Restore settings;
❒ Clear Personal Data.
Navigation
(Uconnect™ 5” Radio
Nav LIVE only)
Planning a route
WARNING In the interest of safety and
to reduce distractions while you are
driving, you should always plan a route
before you start driving.
Press the “Nav” button to show the
navigation map on the display.
To plan a route, do the following:
❒ touch the screen to open the main
Menu;
❒ Touch “Navigate to”.
❒ Touch “Address”. You can change
the country or state setting by
tapping the flag before you select a
city.❒ Enter the town or city name, or the
zip code. Towns with similar names
are shown in the list while you type.
❒ Enter the street name. Towns with
similar names are shown in the list
while you type.
Touch the required street to select
the destination when it appears in
the list.
❒ Enter the house number and then
touch “Done”.
❒ If in the Advanced settings menu
the “Show location preview” option
is active, your position is shown on
the map. Touch “Select” to
continue or tap “Back” to enter
another address.
❒ When the new route is shown,
touch “Done”.
For further information about the
route, tap “Details”.
To change your route, for example,
to travel via a particular location or
to select a new destination, tap
“Change route”;You are guided to your destination,
using spoken instructions and on-
screen directions.
NOTE: The navigation system volume
can only be adjusted during navigation
when the system provides voice
indications.
Updating the map
The map can be updated in two ways:
❒ Most recent maps guarantee: if a
new map is available for your
system within 90 days of initial use,
it can be downloaded once free of
charge.
❒ Map update: it is possible to
purchase a new version of the map
installed on the system.
To check availability or purchase a
map, make sure that you have
prepared a USB device and installed
TomTom HOME on your computer.
Preparing a USB device
To update the map, use a USB device
that meets the following requirements.
❒ Ideally, the USB device should be
empty.
❒ The USB device must have at least
8 GB of memory free.

KNOWING YOUR CAR
80
❒ The USB device must use a FAT-32
file system.
❒ The USB device must not be locked
and it must be possible to save files
on it.
NOTE It is advisable to use a memory
stick, while the use of mass storage
devices, such as mobile phones or
multimedia players, is not
recommended.
To prepare a USB device, proceed as
follows:
❒ Select “Navigation updates” in the
“Settings” menu.
You are asked whether you wish to
prepare a USB device for downloading
updates.
❒ Select "Yes".
❒ Insert the USB device.
NOTE If the system continues to ask
you to insert the USB device, check
that the device meets the requirements
indicated previously, then retry.
The system starts to prepare the USB
device.
When the USB device is ready, the
following message is displayed.Remove the USB device and connect it
to the computer.
The new map can now be downloaded
to the USB device.
TomTom HOME installation
To install TomTom HOME and create a
MyTomTom account, proceed as
follows:
❒ Download and install the TomTom
HOME application on the computer.
On the computer, access
tomtom.com/getstarted. Select
“Download TomTom HOME”, then
follow the instructions provided.
❒ Connect the USB device prepared
using the computer. TomTom
HOME is started automatically.
❒ Select “Log in” in the top right
corner of TomTom HOME.
❒ Select “Create account” and enter
the required details to create a
MyTomTom account. A MyTomTom
account is required to receive map
updates.After the account is created, you are
asked whether you wish to connect the
Uconnect™ system to your account.
The USB device prepared represents
your Uconnect™ system.
❒ Select “Link device”, then select
“Close”.
A map can now be downloaded to the
USB device.
Downloading a map
Connect the USB device to the
computer.
If a map update is available for the
system, this update is included in the
list of updates available.
NOTE If the most recent map is already
installed on the system, the update is
not proposed.
Select the map that you wish to
download, then select
“Update and install”.
The map is downloaded and copied to
your USB device.
Select “Done” when the process is
complete.

KNOWING YOUR CAR
82
Voice commands
Note For languages not supported by
the system, voice commands are not
available. To use the voice commands,
press the button on the steering wheel
}(”Voice” button) and say out loud the
command you want to activate.
Global
The following voice commands can be
given after pressing the button on the
steering wheel
}:
❒ Help
❒ Cancel
❒ Repeat
❒ Voice Prompts
Phone
The following voice commands can be
given after pressing the
}button on
the steering wheel and saying “Go to
telephone”:
❒ Call
❒ Dial
❒ Redial
❒ Call back
❒ Last calls
❒ Outgoing calls
❒ Missed calls❒ Incoming calls
❒ Phonebook
❒ Search
❒ Show text
Radio
The following voice commands can be
given after pressing the button on the
steering wheel
}:
❒ Tune to XXX FM
❒ Tune to XXX AM
❒ Tune to Radio XXX
❒ Tune to DAB channel
Media
The following voice commands can be
given after pressing the button on the
steering wheel
}:
❒ Play song...
❒ Play album…
❒ Play artist…
❒ Play genre…
❒ Play playlist…
❒ Play podcast…
❒ Play audiobook…
❒ Select source
❒ View
Navigation
(Uconnect™5” Radio Nav LIVE
only)
The following voice commands can be
given after pressing the button on the
steering wheel
}:
❒ Go home
❒ 2D view
❒ 3D view
❒ Clear route
❒ Add favourite
❒ Repeat instruction

85
ButtonFunctionsMode
Radio Access Radio mode Short press
Media Source selection: USB, AUX (where provided), Bluetooth® Press graphic button
Phone Show Phone data Press graphic button
Uconnect™ Access to the system functions Press graphic button
(Audio, Media, Phone, Radio etc)
Nav (*) Access Navigation function Press graphic button
Settings Access Settings menu Press graphic button
Trip Access Trip menu Press graphic button
(*) Uconnect™7” HD Nav LIVE versions only
SUMMARY TABLE OF DISPLAY BUTTONS

KNOWING YOUR CAR
88
Switching the
system on/off
The system is switched on/off by
pressing the gbutton/knob.
Turn the button/knob clockwise to
increase the radio volume or
anticlockwise to decrease it. The
electronic volume adjustment control
rotates continuously (360°) in both
directions, without stop positions.
Radio mode
After the desired radio station is
selected, the following information is
shown on the display:
At the top: the list of radio stations
stored (presets) is displayed; the
station currently playing is highlighted.
In the middle: display of the name of
the current radio station and the
buttons for selecting the previous or
next radio station.
On the left: display of the “AM”, “FM”,
“DAB” buttons for selecting the desired
frequency band (reconfigurable button
depending on the selected band: AM,
FM or DAB);On the right : display of the following
buttons:
❒ “Info”: additional information on the
source being listened to;
❒ “Map”: navigation map view
(Uconnect™ 7” HD
Nav LIVEversions only).
At the bottom: display of the following
buttons:
❒ “Browse”: list of the radio stations
available;
❒
÷/ ˜: selection of the
previous/next radio station;
❒ “Tune”: manual radio station tuning;
❒ “Audio”: access to the
❒ “Audio Settings” screen.
Audio menu
To access the “Audio” menu press the
“Audio” button located at the bottom
of the display. The following adjustments can be
carried out using the “Audio” menu:
❒ “Balance & Fader” (left/right and
front/rear audio balance
adjustment);
❒ “Equalizer” (where provided);
❒ “Speed Adj Volume” (speed-
dependent automatic volume
control);
❒ “Loudness” (where provided);
❒ “AUX Volume Offset”
(where provided) (off in radio mode,
selectable only with the AUX
source active);
❒ “AutoPlay”;
❒ “Auto-On Radio”.
Media mode
Press the "Media" button to select the
desired audio source among those
available: USB, Bluetooth®, AUX
(where provided).
IMPORTANT Applications used on
portable devices may be not
compatible with the Uconnect™
system.
After Media mode is selected, the
following information is shown on the
display:

89
In the upper part: information on the
track being played and the following
graphic buttons:
❒ “Repeat”: to repeat the track being
played;
❒ “Shuffle”: to play the tracks in
random order.
In the middle: information on the
track being played.
On the left: display of the following
buttons:
❒ Selected device or audio source;
❒ “Select source”: select the required
audio source.
On the right: display of the following
buttons:
❒ “Info”: additional information on the
track being played;
❒ “Tracks”: list of available tracks.
❒ “Map”: navigation map view
(Uconnect™7” HD Nav LIVE
versions only).At the bottom: information on the
track being played and the following
graphic buttons:
Active device or audio source;
❒
÷/ ˜: select previous/next
track;
❒
II: pause track being played;
❒ “Audio”: access to the “Audio
Settings” screen.
Track selection (Browse)
The “Tracks” function allows you to
open a window with the list of tracks
being played.
The choices available depend on the
device connected.
For example, on a USB device, you
can also use the SCROLL TUNE
button/knob to browse the list of
artists, genres and albums available on
the device, depending on the
information available on the tracks.
NOTE This button may be disabled for
some Apple®devices.
Turn the SCROLL TUNE button/knob
to select the desired category and then
press it to confirm the selection.NOTE The "Tracks" button does not
allow any operation on the AUX device
(where provided).
NOTE The indexing time of a USB
device can vary according to the
media inserted (in some cases it can
take a few minutes).
Bluetooth® SOURCE
This mode is activated by pairing a
Bluetooth® device containing music
tracks with the system.
PAIRING A Bluetooth®
AUDIO DEVICE
To pair a Bluetooth®audio device,
proceed as follows:
❒ activate the Bluetooth®function
on the device;
❒ press the “Media” button on the
display;
❒ press the “Select Source” button;
❒ select the Bluetooth® Media
source;
❒ press the “Add Device” graphic
button;

93
SIRI EYES FREE
(available with iPhone 4S and higher
and compatible iOS only)
After having paired the Siri enabled
device to Uconnect™ hold the
}button
on the steering wheel pressed and then
release it.
After the double beep, you can start
interacting with Siri, to listen to music,
make calls, read text messages and
more.
Uconnect™ LIVE
SERVICES
Press the Uconnect™ button to
access the Uconnect™ LIVEapps.
The services available depend on the
car configuration and the market.
To use the Uconnect™ LIVE
services, you need to download the
Uconnect™ LIVEapp from Google
Play or Apple Store and register using
the app or on www.DriveUconnect.eu.
First access to the vehicle
Once you have launched the
Uconnect™ LIVEapp and entered
your details, you have to pair the
Bluetooth® with your smartphone and
the radio, as described in the “Pairing
a mobile phone” chapter, to access
the Uconnect™ LIVEservices in your
vehicle.When pairing is complete, the
connected services can be accessed
by pressing the Uconnect™ LIVE
icon on the radio.
Before you can use the connected
services, you must first do the
Bluetooth®pairing, then complete
the activation procedure by following
the instructions that appear in the
Uconnect™ LIVEapp.
Setting of Uconnect™ LIVE
services that can be managed
through the radio
In the Uconnect™ LIVEradio menu
the “Settings” section can be accessed
by pressing the icon . In this
section the user can check the system
options and change them according to
their preferences.
System updates
If an update for the Uconnect™ LIVE
system is available while the
Uconnect™ LIVEservices are being
used, you will be informed with a
message on the radio screen.
Connected services that can be
accessed on the vehicle
The eco:Drive™ and my:Car
applications were developed to
improve the customer’s driving
experience, therefore they are available
in all markets, where the Uconnect™
LIVEservices can be accessed.
If the navigation system is installed in
the radio, accessing the Uconnect™
LIVE services enables use of the
“Live” services.
eco:Drive™
The eco:Drive™ application allows you
to display your driving behaviour in real
time, in order to help you reach a more
efficient driving style as far as
consumption and emissions are
concerned.
In addition, the data can be saved on a
USB flash drive, and the data analysis
can be made on your personal
computer thanks to the eco:Drive™
desktop application, available on
www.DriveUconnect.eu.
Driving style is evaluated by means of
four indices which monitor the
following parameters: acceleration,
deceleration, gearchange, speed.
