2017 YAMAHA MT09 TRACER engine

Instrument and control functions
3-5
1
23
4
5
6
7
8
9
10
11
12 comes on when the key is turned to
“ON”, and goes off after traveling at a
speed of 10 km/h (6 mi/h) or higher.
If the ABS warning light:

does not come on when the key is
turned to “ON”

comes on or flashes while riding

does not go off after traveling at a
speed of 10 km/h (6 mi/h) or higher
The ABS may not work correctly. If any
of the above occurs, have a Yamaha
dealer check the system as soon as
possible. (See page 3-21 for an expla-
nation of the ABS.)WARNING
EWA16041
If the ABS warning light does not go
off after traveling at a speed of 10
km/h (6 mi/h) or higher, or if the
warning light comes on or flashes
while riding, the brake system re-
verts to conventional braking. If ei-
ther of the above occurs, or if the
warning light does not come on at
all, use extra caution to avoid possi-
ble wheel lock during emergency
braking. Have a Yamaha dealer
check the brake system and electri-
cal circuits as soon as possible.
EAU73272
Traction control system indicator
light “ ”
In normal operation, this indicator light
is off. When traction control has en-
gaged, this indicator light will flash for a
few seconds and then go off.
When the traction control system is
turned off, this indicator light will come
on.
If the traction control system becomes
disabled while riding, or if a problem is
detected in the traction control system,
this indicator light and the engine trou-
ble warning light will come on. (See
page 3-22 for an explanation of the
traction control system.)
EAU73120
Immobilizer system indicator light
“”
When the key is turned to “OFF” and 30
seconds have passed, the indicator
light will flash steadily to indicate the im-
mobilizer system is enabled. After 24
hours have passed, the indicator light
will stop flashing, however the immobi-
lizer system is still enabled.
The electrical circui t of the indicator
light can be checked by turning the key
to “ON”. The indicator light should
come on for a few seconds, and then
go off.
If the indicator light does not come on1. Traction control system indicator light “”
2. Engine trouble warning light “ ”
1
2
2PP-9-E3.book 5 ページ ２０１６年９月１３日　火曜日　午前９時７分

Instrument and control functions
3-6
1
234
5
6
7
8
9
10
11
12
initially when the key is turned to “ON”,
if the indicator light remains on, or if the
indicator light flashes in a pattern (if a
problem is detected in the immobilizer
system, the immobili
zer system indica-
tor light will flash in a pattern), have a
Yamaha dealer check the vehicle.
TIPIf the immobilizer system indicator light
flashes in the pattern, slowly 5 times
then quickly 2 times, this could be
caused by transponder interference. Ifthis occurs, try the following.
1. Make sure there are no other im- mobilizer keys close to the main
switch. Other immobilizer system
keys may cause signal interfer-
ence and prevent the engine from
starting.
2. Use the code re-registering key to start the engine.
3. If the engine starts, turn it off, and try starting the engine with the
standard keys.
4. If one or both of the standard keys do not start the engine, take the
vehicle and all 3 keys to a Yamaha
dealer to have the standard keys re-registered.
EAU76322
Multi-function meter unitThe multi-function meter unit is
equipped with the following:
speedometer

tachometer

clock
1. “RESET” button
2. “TCS” button
3. Clock
4. Tachometer
5. Speedometer
6. Transmission gear display
7. Information display selection function
8. Information display
9. Fuel meter
10.Eco indicator “ECO”
11.Drive mode display
12.TCS display
GEARN
25
A.TEMP
°C
Lo
C.TEMP°C
0:00
TIME TRIP
89
10
11
12
12 3 4 56
7
2PP-9-E3.book 6 ページ ２０１６年９月１３日　火曜日　午前９時７分

Instrument and control functions
3-7
1
23
4
5
6
7
8
9
10
11
12

fuel meter

eco indicator

transmission gear display

drive mode display

TCS display

information display

setting mode displayWARNING
EWA12423
Be sure to stop the vehicle before
making any setting changes to the
multi-function meter unit. Changing
settings while riding can distract the
operator and increase the risk of anaccident.TIP
The select switch “ / ” and the
menu switch “MENU” are located
on the left handlebar. These
switches allow you to control or
change the settings of the
multi-function meter unit.

QS requires an accessory part and
cannot be selected.

The key must be turned to “ON”
before you can use the handlebarswitches and buttons. Speedometer
The speedometer shows the vehicle’s
traveling speed.
TIPTo switch between kilometers andmiles, see page 3-12.
Tachometer
The tachometer allows the rider to
monitor the engine speed and keep it
within the ideal power range.
When the key is turned to “ON”, the ta-
chometer will sweep across the r/min
range and then return to zero in order to
test the electrical circuit.NOTICE
ECAM1150
Do not operate the engine in the ta-
chometer high-rpm zone.
1. Menu switch “MENU”
2. Select switch “ / ”
1. Speedometer
12
1
1. Tachometer
2. High-rpm zone
12
2PP-9-E3.book 7 ページ ２０１６年９月１３日　火曜日　午前９時７分

Instrument and control functions
3-8
1
234
5
6
7
8
9
10
11
12
High-rpm zone: 11250 r/min and
above
Clock
The clock displays time in 12-hour for-
mat. To set the clock, see page 3-12.
Fuel meter
The fuel meter indicates the amount of
fuel in the fuel tank. The display seg-
ments of the fuel meter disappear from
“F” (full) towards “E” (empty) as the fuel
level decreases. When the last seg-
ment of the fuel meter starts flashing,
refuel as soon as possible.
TIP
When the key is first turned to
“ON”, all of the display segments
of the fuel meter will appear for a
few seconds before the fuel meter
shows the actual fuel level.

If a problem is detected in the fuel
meter electrical circuit, the fuel me-
ter will flash repeatedly. If this oc-curs, have a Yamaha dealer check
the vehicle.
Eco indicator
The eco indicator comes on when the
vehicle is being operated in an environ-
mentally friendly, fuel-efficient manner.
The indicator goes off when the vehicle
is stopped.
TIPConsider the following tips to reduce
fuel consumption:
Avoid high engine speeds during
acceleration.

Travel at a constant speed.

Select the transmission gear that
1. Clock
1
1. Fuel meter
1
1. Eco indicator “ECO”
1
2PP-9-E3.book 8 ページ ２０１６年９月１３日　火曜日　午前９時７分

Instrument and control functions
3-11
1
23
4
5
6
7
8
9
10
11
12 TRIP-F
 Display–1  Display–2 
Display–3  TRIP-F
After refueling, you can manually reset
the fuel reserve tripmeter immediately,
or allow it to reset automatically after
traveling 5 km (3 mi). When the fuel re-
serve tripmeter is reset, it will disappear
from the display.
Elapsed time
This timer shows the time that has
elapsed since the key was turned to
“ON”. The timer automatically resets
when the key is turned to “OFF”.
TIPThere are also “TIME–2” and “TIME–3”
elapsed time displays, but they cannot
be set to the information display. See
Setting mode on page 3-12 for more in-
formation.
Air temperature
This shows the air temperature from –9
 C to 93 C in 1  C increments. The
temperature displayed may vary from
the ambient temperature.TIP
–9 C will be displayed even if the
ambient temperature falls below
–9 C.

The accuracy of the temperature
reading may be affected when rid-
ing slowly (under 20 km/h [13
mi/h]) or when stopped at trafficsignals, railroad crossings, etc.
Coolant temperature
This shows the temperature of the cool- ant. The coolant temperature varies
with changes in the weather and en-
gine load.
If the message “Hi” flashes, stop the ve-
hicle then stop the engine and let it
cool. (See page 6-40.)
TIPThe selected information display can-
not be switched while the message “Hi”is flashing.NOTICE
ECA10022
Do not continue to operate the en-gine if it is overheating.
0:06
TIME TRIP
25
A.TEMP
˚C
Lo
C.TEMP˚C
GEAR4
Hi
C.TEMP ˚C
2PP-9-E3.book 11 ページ ２０１６年９月１３日　火曜日　午前９時７分

Instrument and control functions
3-17
1
23
4
5
6
7
8
9
10
11
12 4. Push the menu switch and the
minute digits start flashing.
5. Use the select switch to set the minutes.
6. Push the menu switch to return to the setting mode menu.
Resetting all of the display items
1. Use the select switch to highlight “All Reset”. 2. Push the menu switch.
3. Use the select switch to highlight
“YES”, and then push the menu
switch.
TIPThe odometer and the clock cannot bereset.
EAU47634
D-mode (drive mode)D-mode is an electronically controlled
engine performance system with three
mode selections (“STD”, “A”, and “B”).
Push the drive mode switch “MODE” to
switch between modes. (See page
3-19 for an explanation of the drive
mode switch.)TIPBefore using D-mode, make sure you
understand its operation along with theoperation of the drive mode switch.
Mode “STD”
Mode “STD” is suitable for various rid-
ing conditions.
Clock
5
55
AM
MENUMaintenanceTime TripUnitDisplayBrightnessClockAll Reset
All Reset
YESNO
1. Drive mode switch “MODE”
1
2PP-9-E3.book 17 ページ ２０１６年９月１３日　火曜日　午前９時７分

Instrument and control functions
3-18
1
234
5
6
7
8
9
10
11
12
This mode allows the rider to enjoy
smooth and sporty drivability from the
low-speed range to the high-speed
range.
Mode “A”
Mode “A” offers a sportier engine re-
sponse in the low- to mid-speed range
compared to mode “STD”.
Mode “B”
Mode “B” offers response that is some-
what less sharp compared to mode
“STD” for riding situations that require
especially sensitive throttle operation.
EAU1234M
Handlebar switchesLeft
Right
EAU54201
Dimmer/Pass switch “ / /PASS”
Set this switch to “ ” for the high
beam and to “ ” for the low beam.
To flash the high beam, push the pass
side “PASS” of the switch while the
headlights are on low beam.
EAU12461
Turn signal switch “ / ”
To signal a right-hand turn, push this
switch to “ ”. To signal a left-hand
turn, push this switch to “ ”. When re-
leased, the switch returns to the center
position. To cancel the turn signal
1. Select switch “ / ”
2. Menu switch “MENU”
3. Dimmer/Pass switch “ / /PASS”
4. Turn signal switch “ / ”
5. Horn switch “ ”
2
1
345
1. Stop/Run/Start switch “ / / ”
2. Drive mode switch “MODE”
3. Hazard switch “ ”
1
23
2PP-9-E3.book 18 ページ ２０１６年９月１３日　火曜日　午前９時７分

Instrument and control functions
3-19
1
23
4
5
6
7
8
9
10
11
12 lights, push the switch in after it has re-
turned to the center position.
EAU12501
Horn switch “ ”
Press this switch to sound the horn.
EAU54212
Stop/Run/Start switch “ / / ”
To crank the engine with the starter, set
this switch to “ ”, and then push the
switch down towards “ ”. See page
5-1 for starting instructions prior to
starting the engine.
Set this switch to “ ” to stop the engine
in case of an emergency, such as when
the vehicle overturns or when the throt-
tle cable is stuck.
EAU12735
Hazard switch “ ”
With the key in the “ON” or “ ” posi-
tion, use this switch to turn on the haz-
ard lights (simultaneous flashing of all
turn signal lights).
The hazard lights are used in case of
an emergency or to warn other drivers
when your vehicle is stopped where it
might be a traffic hazard.
NOTICE
ECA10062
Do not use the hazard lights for an
extended length of time with the en-
gine not running, otherwise the bat-tery may discharge.
EAU59011
Menu switch “MENU”
This switch is used to perform selec-
tions in the setting mode display of the
multi-function meter unit.
See Multi-function meter unit on page
3-6 for detailed information.
EAU59001
Select switch “ / ”
This switch is used to perform selec-
tions in the information display and set-
ting mode display of the multi-function
meter unit.
See Multi-function meter unit on page
3-6 for detailed information.
EAU77020
Drive mode switch “MODE”
WARNING
EWA15341
Do not change the D-mode while the
vehicle is moving.
Using this switch changes the drive
mode to “STD”, “A”, or “B” in the follow-
ing order:
STD
 A  B  STD
The throttle grip must be completely
closed in order to change the drive
mode. (See page 3-17 for an explana-
tion of each drive mode.)TIP
The current drive mode is saved
when the key is turned to “OFF”.

The selected mode is shown on
the drive mode display. (See page3-9.)
2PP-9-E3.book 19 ページ ２０１６年９月１３日　火曜日　午前９時７分
