2017 YAMAHA MT-09 display

low beam dashboard sat nav display trunk release oil temperature

Page 16 of 106

YAMAHA MT-09 2017 Owners Manual 3-1
1
23
4
5
6
7
8
9
10
11
12
Special features
EAU76422
D-mode (drive mode)D-mode is an electronically controlled
engine performance system. This mod-
el has three mode selections: “STD”,
“A”,

3-1
1
23
4
5
6
7
8
9
10
11
12
Special features
EAU76422
D-mode (drive mode)D-mode is an electronically controlled
engine performance system. This mod-
el has three mode selections: “STD”,
“A”, and “B”.
WARNING
EWA18440
Do not change the drive mode whilethe vehicle is moving.
With the throttle grip closed, push this
switch to change the drive mode in the
following order:
STD  A  B  STDTIP
Make sure you understand each
drive mode before operating the drive mode switch.

The current drive mode is shown in
the drive mode display (page
4-10).

The current drive mode is savedwhen the vehicle is turned off.
Mode “STD”
Mode “STD” is suitable for various rid-
ing conditions.
This mode allows the rider to enjoy
smooth and sporty drivability from the
low-speed range to the high-speed
range.
Mode “A”
Mode “A” offers a sportier engine re-
sponse in the low- to mid-speed range
compared to mode “STD”.
Mode “B”
Mode “B” offers response that is some-
what less sharp compared to mode
“STD” for riding situations that require
especially sensitive throttle operation.
EAU76432
Traction control systemThe traction control system (TCS)
helps maintain traction when accelerat-
ing on slippery surfaces, such as un-
paved or wet roads. If sensors detect
that the rear wheel is starting to slip (un-
controlled spinning), the traction control
system assists by regulating engine
power as needed until traction is re-
stored.
WARNING
EWA15432
The traction control system is not a
substitute for riding appropriately
for the conditions. Traction control
cannot prevent loss of traction due
to excessive speed when entering
turns, when accelerating hard at a
sharp lean angle, or while braking,
and cannot prevent front wheel slip-
ping. As with any motorcycle, ap-
proach surfaces that may be
slippery with caution and avoid es-pecially slippery surfaces.
1. Drive mode switch “MODE”
1
BS2-9-E0.book 1 ページ２０１６年９月８日　木曜日　午前１１時０分

Page 17 of 106

YAMAHA MT-09 2017 Owners Manual Special features
3-2
1
234
5
6
7
8
9
10
11
12
Setting the traction control system
With the throttle closed, push this
switch down to change from TCS “1” to
TCS “2”. Push up to change from “2

Page 26 of 106

YAMAHA MT-09 2017 Owners Manual Instrument and control functions
4-8
1
2
34
5
6
7
8
9
10
11
12
EAU77051
Multi-function meter unit
WARNING
EWA12423
Be sure to stop the vehicle before
making any setting changes to the
multi-function m

Page 27 of 106

YAMAHA MT-09 2017 Owners Manual Instrument and control functions
4-9
1
2
345
6
7
8
9
10
11
12
Speedometer
The speedometer shows the vehicle’s
traveling speed.
Tachometer
The tachometer allows the rider to
monitor the engine speed

Page 28 of 106

YAMAHA MT-09 2017 Owners Manual Instrument and control functions
4-10
1
2
34
5
6
7
8
9
10
11
12 “F” (full) towards “E” (empty) as the fuel
level decreases. When the last seg-
ment starts flashing, refuel as soon as
possible.

Page 29 of 106

YAMAHA MT-09 2017 Owners Manual Instrument and control functions
4-11
1
2
345
6
7
8
9
10
11
12
This display indicates which traction
control system setting has been select-
ed: “1”, “2” or “OFF”. For more details
on the

Instrument and control functions
4-11
1
2
345
6
7
8
9
10
11
12
This display indicates which traction
control system setting has been select-
ed: “1”, “2” or “OFF”. For more details
on the TCS settings and on how to se-
lect them, see page 3-1.
Multi-function display
The multi-function display is equipped
with the following:

an odometer

two tripmeters

a fuel reserve tripmeter

an instantaneous fuel consump-
tion display

an average fuel consumption dis-
play

a coolant temperature display

an air intake temperature display

a brightness control display
TIP
The odometer will lock at 999999
and cannot be reset.

The tripmeters will lock at 9999.9but can be manually reset.
Push the “SELECT” button to switch
the display between the instantaneous
fuel consumption mode “km/L” or “L/
100 km”, average fuel consumption
mode “AVE_ _._ km/L” or “AVE_ _._ L/
100 km”, coolant temperature mode
“  C”, air intake temperature mode “Air_
_ C”, odometer mode “ODO”, and trip-
meter modes “TRIP 1” and “TRIP 2” in
the following order:
km/L or L/100 km  AVE_ _._ km/L or
AVE_ _._ L/100 km   C  Air_ _ C
 ODO  TRIP 1  TRIP 2
When the display units have been set
to miles:
km/L, L/100 km or MPG  AVE_ _._
km/L, AVE_ _._ L/100 km or AVE_ _._
MPG  C  Air_ _ C  ODO 
TRIP 1  TRIP 2
TIPPush the “RESET” button to switch thedisplay in the reverse order.
If the last segment of the fuel meter
starts flashing, the display automatical-
ly changes to the fuel reserve tripmeter
mode “F-TRIP” and starts counting the
distance traveled from that point. In this
case, push the “SELECT” button to
switch the display in the following order:
F-TRIP  km/L or L/100 km  AVE_
_._ km/L or AVE_ _._ L/100 km   C
 Air_ _ C  ODO  TRIP 1  TRIP
2  F-TRIP
When the display units have been set
to miles:
F-TRIP  km/L, L/100 km or MPG 
AVE_ _._ km/L, AVE_ _._ L/100 km or
AVE_ _._ MPG   C  Air_ _ C 
ODO  TRIP 1  TRIP 2  F-TRIPTIP
To reset a tripmeter, select it by
pushing the “SELECT” button, and
1. Multi-function display
1
BS2-9-E0.book 11 ページ２０１６年９月８日　木曜日　午前１１時０分

Page 30 of 106

YAMAHA MT-09 2017 Owners Manual Instrument and control functions
4-12
1
2
34
5
6
7
8
9
10
11
12 then push the “RESET” button for
one second.

If you do not reset the fuel reserve
tripmeter manually, it resets auto-
matically

Instrument and control functions
4-12
1
2
34
5
6
7
8
9
10
11
12 then push the “RESET” button for
one second.

If you do not reset the fuel reserve
tripmeter manually, it resets auto-
matically and disappears after re-fueling and traveling 5 km (3 mi).
Instantaneous fuel consumption
mode
The instantaneous fuel consumption
display can be set to either “km/L”, “L/
100 km” or “MPG” (when the display
units have been set to miles).

“km/L”: The distance that can be
traveled on 1.0 L of fuel under the
current riding condi tions is shown.

“L/100 km”: The amount of fuel necessary to travel 100 km under
the current riding conditions is
shown.

“MPG”: The distance that can be
traveled on 1.0 Imp.gal of fuel un-
der the current riding conditions is
shown.
To switch between the instantaneous
fuel consumption display settings, push
the “SELECT” button for one second.
TIPIf traveling at speeds under 20 km/h (12mi/h), “_ _._” is displayed.
Average fuel consumption mode
This display shows the average fuel consumption since it was last reset.
The average fuel consumption display
can be set to either “AVE_ _._ km/L”,
“AVE_ _._ L/100 km” or “AVE_ _._
MPG” (when the display units have
been set to miles:).

“AVE_ _._ km/L”: The average dis-
tance that can be traveled on 1.0 L
of fuel is shown.

“AVE_ _._ L/100 km”: The average
amount of fuel necessary to travel
100 km is shown.

“AVE_ _._ MPG”: The average
distance that can be traveled on
1.0 Imp.gal of fuel is shown.
To switch between the average fuel
consumption display settings, push the
“SELECT” button for one second.
To reset the average fuel consumption,
push the “RESET” button for one sec-
ond.
TIPAfter resetting the average fuel con-
sumption, “_ _._” will be shown until thevehicle has traveled 1 km (0.6 mi).
1. Instantaneous fuel consumption display
1
1. Average fuel consumption display
1
BS2-9-E0.book 12 ページ２０１６年９月８日　木曜日　午前１１時０分

Page 31 of 106

YAMAHA MT-09 2017 Owners Manual Instrument and control functions
4-13
1
2
345
6
7
8
9
10
11
12
Coolant temperature mode
This display shows the coolant temper-
ature from 40 
C to 116 C in 1  C incre-
ments.
If the message �
