2017 TOYOTA TACOMA remote control

4857-3. Do-it-yourself maintenance
7
Maintenance and care
Wireless remote control/electronic key bat-
tery
∗
● Flathead screwdriver
● Small flathead screwdriver
● Lithium battery CR2016 (vehicles without a smart key system), or
CR2032 (vehicles with a smart key system)
Vehicles without a smart key system
Remove the cover.
To prevent damage to the key,
cover the tip of the screwdriver with
a rag.
To prevent the buttons from being
disassembled, face the button sur-
face downward.
Remove the module.
∗: If equipped
Replace the battery with a new one if it is depleted.
You will need the following items:
Replacing the battery
1
2

4877-3. Do-it-yourself maintenance
7
Maintenance and care
■Use a CR2016 (vehicles without a sm art key system) or CR2032 (vehicles
with a smart key system) lithium battery
● Batteries can be purchased at your Toyota dealer, local electrical appliance
shops or camera stores.
● Replace only with the same or equivalent type recommended by the manu-
facturer.
● Dispose of used batteries according to local laws.
■ If the key battery is depleted
The following symptoms may occur:
●The smart key system (if equipped) and wireless remote control will not
function properly.
● The operational range will be reduced.
WARNING
■Removed battery and other parts
Keep away from children. These parts are small and if swallowed by a child,
they can cause choking. Failure to do so could result in death or serious
injury.
■ Certification for the lithium battery
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO
THE INSTRUCTIONS
NOTICE
■For normal operation after replacing the battery
Observe the following precautions to prevent accidents:
● Always work with dry hands.
Moisture may cause the battery to rust.
● Do not touch or move any other component inside the remote control.
● Do not bend either of the battery terminals.

557
8
When trouble arises
8-2. Steps to take in an emergency
If the electronic key does not operate
properly (vehicles with a smart key system)
Use the mechanical key (→P. 104)
in order to perform the following
operations:
Locks all the doors
Unlocks all the doors
Turning the key rearward unlocks
the driver’s door. Turning the key
once again unlocks the other
doors.
Ensure that the shift lever is in P and depress the brake pedal.
Touch the Toyota emblem side
of the electronic key to the
engine switch.
If any of the doors is opened or
closed while the key is being
touched to the switch, an alarm will
sound to indicate that the start
function cannot detect the key.
Press the engine switch.
In the event that the engine still ca nnot be started, contact your Toyota
dealer.
If communication between the electronic key and vehicle is
interrupted ( →P. 124) or the electronic key cannot be used
because the battery is depleted, the smart key system and wire-
less remote control cannot be used. In such cases, the doors
can be opened and the engine ca n be started by following the
procedure below.
Locking and unlocking the doors
1
2
Starting the engine
1
2
3

5618-2. Steps to take in an emergency
8
When trouble arises
■Starting the engine when the batt ery is discharged (vehicles with an
automatic transmission)
The engine cannot be started by push-starting.
■ To prevent battery discharge
●Turn off the headlights and the audio system while the engine is off.
● Turn off any unnecessary electrical components when the vehicle is running
at a low speed for an extended period, such as in heavy traffic.
■ Charging the battery
The electricity stored in the battery will discharge gradually even when the
vehicle is not in use, due to natural discharge and the draining effects of cer-
tain electrical appliances. If the vehicle is left for a long time, the battery may
discharge, and the engine may be unable to start. (The battery recharges
automatically during driving.)
■ When recharging or replacing the battery
●Vehicles with a smart key system: In some cases, it may not be possible to
unlock the doors using the smart key system when the battery is dis-
charged. Use the wireless remote control or the mechanical key to lock or
unlock the doors.
● The engine may not start on the first attempt after the battery has recharged
but will start normally after the second attempt. This is not a malfunction.
● Vehicles with a smart key system: The engine switch mode is memorized by
the vehicle. When the battery is reconnected, the system will return to the
mode it was in before the battery was discharged. Before disconnecting the
battery, turn the engine switch off.
If you are unsure what mode the engine switch was in before the battery dis-
charged, be especially careful when reconnecting the battery.

5989-2. Customization
■Door lock (→P. 109, 557)
*: Vehicles with an automatic transmission
■
Smart key system and wireless remote control* ( → P. 109)
*: If equipped
FunctionDefault settingCustomized
setting
Unlocking using a key Driver’s door
unlocked in one step, all doors
unlocked in two
steps All doors
unlocked in one step —— O
Speed-detecting auto-
matic door lock function
*On Off — O O
Shifting gears to position
other than P locks all
doors
*
Off On — O O
Shifting gears to P
unlocks all doors
*On Off — O O
Opening the driver’s door
unlocks all doors
*Off On — O O
123
FunctionDefault settingCustomized
setting
Operation signal
(Emergency flashers) On Off — O O
Operation signal
(Buzzer) On Off — — O
Operation buzzer volume Level 5 Off to level 7 O O O
Time elapsed before auto-
matic door lock function is
activated if door is not
opened after being
unlocked 60 seconds
Off
—O O
30 seconds
120 seconds
Open door warning
buzzerOnOff — —O
123

5999-2. Customization
9
Vehicle specifications
■Smart key system* (→ P. 109, 121)
*: If equipped
■
Wireless remote control* ( → P. 103, 109)
*: If equipped
FunctionDefault settingCustomized
setting
Smart key systemOnOff——O
Number of permissible
times of continuous smart
lock Twice Unlimited — — O
123
FunctionDefault settingCustomized
setting
Wireless remote control OnOff — — O
Unlocking operation Driver’s door
unlocked in one step, all doors
unlocked in two steps All doors
unlocked in
one step —O O
Automatic door lock func-
tion to be activated if door
is not opened after being
unlocked On
Off — — O
Time elapsed before auto-
matic door lock function is
activated if door is not
opened after being
unlocked 60 seconds0 seconds
—O O
30 seconds
120 seconds
Operation signal
(Emergency flashers) On
Off — O O
Operation signal
(Buzzer) On
Off — — O
Panic function OnOff — — O
Open door reminder
buzzer (When locking the
vehicle) On
Off — — O
123

626Alphabetical index
Alphabetical index
A/C .................................... 374, 380Air conditioning filter ............. 482
Automatic air conditioning system ......... ....................... 380
Manual air conditioning system ......... ....................... 374
ABS (Anti-lock Brake
System) .................................. 267 Function ................................ 267
Warning light ......................... 515
Warning message ................. 525
Active head restraints ............. 129
Active traction control ............ 256
Air conditioning filter .............. 482
Air conditioning system ............................ 374, 380
Air conditioning filter ............. 482
Automatic air conditioning system ......... ....................... 380
Manual air conditioning system ......... ....................... 374
Airbags ....................................... 34
Airbag operating conditions .... 41
Airbag precautions for your child ......................... 37
Airbag warning light .............. 514
Correct driving posture ........... 26
Curtain shield airbag operating conditions ............. 41
Curtain shield airbag precautions ........................... 38
Front passenger occupant classification syst em............. 45
General airbag precautions .... 37
Locations of airbags................ 34
Modification and disposal of airbags.............................. 40
Side airbag operating conditions ............................. 41
Side airbag precautions .......... 38 Side and curtain shield
airbags operating
conditions ............................. 41
Side and curtain shield airbags precautions .............. 38
SRS airbags ........................... 34
Alarm
Alarm ...................................... 78
Warning buzzer ............ 514, 523
Anchor brackets ........................ 55
Antennas
(smart key system) ............... 121
Anti-lock Brake System
(ABS) ...................................... 267 Function ................................ 267
Warning light......................... 515
Warning message................. 525
Assist grips .............................. 423
Audio input
*............................ 289
Audio remote control switches
*............................... 288
Audio system
*......................... 284
Antenna ................................ 303
Audio input............................ 289
Audio settings ....................... 295
AUX port/USB port ............... 289
Bluetooth
® audio .................. 332
CD player.............................. 304
Display settings .................... 296
General settings ................... 293
iPod ...................................... 309
MP3/WMA disc ..................... 304
Portable music player ........... 317
Radio .................................... 302
Setup menu .......................... 292
USB memory ........................ 313
AUTO LSD system................... 251
Automatic light control
system.................................... 206
A

628Alphabetical index
Child safety ................................ 50Airbag precautions .................. 37
Battery precautions ............... 562
Child restraint system ............. 51
How your child should wear the seat belt ................. 30
Installing child restraints ......... 55
Moon roof precautions .......... 154
Power back window precations ........................... 150
Power window lock switch .... 145
Power window precautions ... 147
Rear door child-protector ...... 113
Removed wireless remote control/electronic key
battery precautions ............. 487
Seat belt extender precautions ........................... 33
Seat belt precautions .............. 54
Seat heater precautions........ 387
Child-protectors....................... 113
Cleaning ........................... 438, 441 Aluminum wheels.................. 438
Exterior ................................. 438
Interior................................... 441
Seat belts .............................. 442
Clock
*....................................... 411
Compass .................................. 432
Condenser ................................ 460
Console box ............................. 394
Consumption screen ........... 94, 98
Cooling system ........................ 458
Capacity ................................ 575
Checking ............................... 458
Engine overheating ............... 563
Preparing and checking before winter....................... 273
Crawl Control ........................... 262
CRS ............................................. 51
Cruise control .......................... 218
Cup holders.............................. 395
Curtain shield airbags ............... 35
Customizable features ............ 595 Daytime running light
system.................................... 208
Deck hooks .............................. 403
Defogger Outside rear view mirrors ........................ 376, 383
Windshield .................... 376, 383
Differential................................ 576
Dimensions .............................. 568
Dinghy towing.......................... 189
Display Drive information .................... 94
Multi-information display ......... 93
Warning message................. 523
Do-it-yourself maintenance .... 450
Door lock Doors .................................... 109
Key ....................................... 109
Smart key system ................. 110
Wireless remote control ........ 109
Doors ........................................ 109 Automatic door locking
and unlocking system......... 113
Door lock .............................. 111
Door windows ....................... 145
Open door warning light ....... 516
Open door warning message............................. 528
Outside rear view mirrors ..... 143
Rear door child-protector ...... 113
Driving ...................................... 156
Break-in tips.......................... 158
Correct driving posture ........... 26
Driving assist system ............ 267
Procedures ........................... 156
Winter drive tips .................... 273
D
