2017 TOYOTA TACOMA navigation system

2855-1. Basic Operations
5
Multimedia
Entune Premium Audio
Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

2885-1. Basic Operations
Steering wheel audio switches
Radio mode:• Press: Selects a radio station
• Press and hold: Seeks up/ down
CD, MP3/WMA disc, Blue-
tooth
®, iPod or USB mode:
• Press: Selects a track/file/ song
• Press and hold: Fast-forward/rewind
Vo l u m e s w i t c h • Increases/decreases volume
• Press and hold: Continuously increases/decreases volume
“MODE/HOLD” switch • Changes audio source
• Press and hold this switch to mute or pause the current operation To cancel the mute or pause, press and hold.
Some audio features can be c ontrolled using the switches on
the steering wheel.
Operation may differ depending on the type of multimedia sys-
tem or navigation system. For details, refer to the manual pro-
vided with the multimedia system or navigation system.
Operating the multimedia system using the steering wheel
switches
1
WARNING
■ To reduce the risk of an accident
Exercise care when operating the audio switches on the steering wheel.
2
3

3435-9. Bluetooth® phone
5
Multimedia
■Receiving a message
●Depending on the cellular phone used for receiving messages, or its regis-
tration status with the navigation system, some information may not be dis-
played.
● The pop up screen is separately available for incoming e-mail and SMS/
MMS messages under the following conditions:
E-mail:
• “Incoming E-mail Display” is set to “Full Screen”. ( →P. 356)
• “E-mail Notification Popup” is set to on. ( →P. 356)
SMS/MMS:
• “Incoming SMS/MMS Display” is set to “Full screen”. (→P. 356)
• “SMS/MMS Notification Popup” is set to on. ( →P. 356)
Display the message inbox screen. (→P. 342)
Select the desired message from the list.
Check that the message is dis-
played. E-mails: Select “Mark
Unread” or “Mark Read” to
mark mail unread or read on
the message inbox screen.
This function is available when
“Update Read Status on Phone”
is set to on ( →P. 356)
Select to make a call to the sender.
Select to have messages read ou t. To cancel this function, select
“Stop”.
Select to display the previous or next message.
Select to reply the message.
Checking the messages
1
2
3
1
2
3
4
5

3715-11. Using the voice command system
5
Multimedia
■Notes about Mobile Assistant
●The available features and functions may vary based on the iOS version
installed on the connected device.
● Some Siri
® features are limited in Eyes Free mode. If you attempt to use an
unavailable function, Siri® will inform you that the function is not available.
● If Siri
® is not enabled on the cellular phone connected via Bluetooth®, an
error message will be displayed on the screen.
● While a phone call is active, the Mobile Assistant cannot be used.
● If using the navigation feature of the cellular phone, ensure the active audio
source is Bluetooth
® audio or iPod in order to hear turn by turn direction
prompts.

4116-4. Other interior features
6
Interior features
The clock is displayed on the
screen.
■Setting the clock
Vehicles with Entune Audio (Audio system types: →P. 284)
→ P. 2 9 4
Vehicles with Entune Audio Plus or Entune Premium Audio
(Audio system types: →P. 284)
Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.
■ The clock is displayed when
Vehicles without a smart key system
The engine switch is in the “ACC” or “ON” position.
Vehicles with a smart key system
The engine switch is in ACCESSORY or IGNITION ON mode.
■ When disconnecting and reco nnecting battery terminals
The clock data will be reset.
Clock

5538-2. Steps to take in an emergency
8
When trouble arises
WARNING
■When using the temporary spare tire
●Remember that the temporary spare tire provided is specifically
designed for use with your vehicle. Do not use your temporary spare
tire on another vehicle.
●Do not use more than one temporary spare tires simultaneously.
●Replace the temporary spare tire with a standard tire as soon as possi-
ble.
●Avoid sudden acceleration, abrupt steering, sudden braking and shift-
ing operations that cause sudden engine braking.
■When the spare tire is attached
The vehicle speed may not be correctly detected, and the following sys-
tems may not operate correctly:
●ABS & Brake assist
●VSC
●TRAC
●AUTO LSD
●Hill-start assist control (if equipped)
●Cruise control (if equipped)
●Active traction contro l system (if equipped)
●Multi Terrain ABS (if equipped)
●Multi-terrain Select (if equipped)
●Crawl Control (if equipped)
●Navigation system (if equipped)
Also, not only can the following system not be utilized fully, but it may
even negatively affect the drive-train components:
●4WD system
■Speed limit when using the temporary spare tire
Do not drive at speeds in excess of 50 mph (80 km/h) when a temporary
spare tire is installed on the vehicle.
The temporary spare tire is not designed for driving at high speeds. Fail-
ure to observe this precaution may lead to an accident causing death or
serious injury.

621
Index
What to do if... (Troubleshooting) .................... 622
Alphabetical index ..................... 626
For vehicles with Entune Audio Plus or Entune Premium Audio,
refer to the “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL” for information regarding the multimedia
system.
Audio system types: →P. 284

627Alphabetical index
Automatic transmissionAutomatic transmission......... 197
If the shift lever cannot be shifted from P ..................... 200
S mode ................................. 199
Power mode switch............... 198
AUX port ................................... 289
Auxiliary boxes ........................ 401
Back window
Back window ......................... 148
Power back window .............. 149
Back-up lights Replacing light bulbs............. 499
Wattage ................................ 580
Battery ...................................... 463 If the vehicle battery is discharged .......................... 559
Preparing and checking before winter....................... 273
Warning light ......................... 514
Warning message ................. 524
Blind Spot Monitor (BSM) ....... 239
Bluetooth
®*
Audio system ................. ....... 332
Hands-free system (for cellular phone) ............. 333
Bottle holders .......................... 396
Brake Fluid ...................................... 460
Parking brake........................ 205
Warning buzzer..................... 514
Warning light ......................... 514
Warning message ................. 523
Brake assist ............................. 267
Break-in tips ............................. 158
Brightness control Instrument panel light control................................... 90 BSM (Blind Spot Monitor) ....... 239
Blind Spot Monitor function............................... 241
Rear Cross Traffic Alert function............................... 244
Camera mounting bracket ...... 424
Camper information ................ 615
Care .................................. 438, 441 Aluminum wheels ................. 438
Exterior ................................. 438
Interior .................................. 441
Seat belts.............................. 442
Cargo capacity......................... 169
Cargo lamp Light switch ........................... 391
Replacing light bulbs ............ 501
CD player
*............................... 304
Certification label .................... 571
Chains ...................................... 274
Child restraint system............... 51 Booster seats, definition ......... 52
Booster seats, installation....... 62
Convertible seats, definition ... 52
Convertible seats, installation ...................... 60, 61
Front passenger occupant
classification syst em ............ 45
Infant seats, definition............. 52
Infant seats, installation .......... 60
Installing CRS with LATCH anchors ...... 58, 59
Installing CRS with seat
belts...................................... 60
Installing CRS with top tether strap........ 63, 65
B
C
*: For vehicles with Entune Audio Plus or Entune Premium Audio, refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”
