2017 TOYOTA TACOMA fuses

5
1
9 8
7 5 4
3
2
10
6
6-1. Using the air conditioning system
Manual air conditioning system............................. 374
Automatic air conditioning system............................. 380
Seat heaters ...................... 387
6-2. Using the interior lights Interior lights list ................ 389• Interior light ................... 390
• Front personal lights ..... 390
• Cargo lamp main switch ............................ 391
6-3. Using the storage features List of storage features...... 392• Glove box...................... 393
• Front console box ......... 394
• Overhead console ......... 394
• Cup holders .................. 395
• Bottle holders ................ 396
• Storage box .................. 397
Luggage compartment features ........................... 400
6-4. Other interior features Other interior features ....... 410• Sun visors ..................... 410
• Vanity mirrors................ 410
• Clock ............................. 411
• Power outlets (12 V DC) ...................... 412
• Power outlet
(120 V AC) .................... 413
• Wireless charger ........... 418
• Assist grips ................... 423
• Camera mounting bracket .......................... 424
Garage door opener .......... 425
Compass ........................... 432 7-1. Maintenance and care
Cleaning and protecting the vehicle exterior .......... 438
Cleaning and protecting the vehicle interior ........... 441
7-2. Maintenance Maintenance requirements ................... 444
General maintenance ........ 446
Emission inspection and maintenance (I/M)
programs ......................... 449
7-3. Do-it-yourself maintenance Do-it-yourself service precautions ...................... 450
Hood .................................. 452
Engine compartment ......... 454
Tires................................... 466
Tire inflation pressure ........ 476
Wheels............................... 479
Air conditioning filter .......... 482
Wireless remote control/ electronic key battery ...... 485
Checking and replacing fuses ................................ 488
Light bulbs ......................... 491
8-1. Essential information Emergency flashers ........... 504
If your vehicle has to be stopped in
an emergency.................. 505
6Interior features7Maintenance and care
8When trouble arises

437
7Maintenance and care
7-1. Maintenance and careCleaning and protecting the vehicle exterior .......... 438
Cleaning and protecting the vehicle interior ........... 441
7-2. Maintenance Maintenance requirements ................... 444
General maintenance ........ 446
Emission inspection and maintenance (I/M)
programs ......................... 449 7-3. Do-it-yourself maintenance
Do-it-yourself service precautions ..................... 450
Hood ................................. 452
Engine compartment ......... 454
Tires .................................. 466
Tire inflation pressure ....... 476
Wheels .............................. 479
Air conditioning filter.......... 482
Wireless remote control/ electronic key battery ...... 485
Checking and replacing fuses ............................... 488
Light bulbs......................... 491

4507-3. Do-it-yourself maintenance
Do-it-yourself service precautions
If you perform maintenance by yourself, be sure to follow the
correct procedure as given in these sections.
ItemsParts and tools
Battery condition
(→ P. 463)• Warm water• Baking soda• Grease
• Conventional wrench (for terminal clamp bolts)
Brake fluid level
(→ P. 460)• FMVSS No.116 DOT 3 or SAE J1703 brake fluid
• Rag or paper towel
• Funnel (used only for adding brake fluid)
Engine coolant
level ( →P. 458)
• “Toyota Super Long Life Coolant” or a similar high
quality ethylene glycol-based non-silicate, non-
amine, non-nitrite and non-borate coolant with long-
life hybrid organic acid technology
For the U.S.A.:
“Toyota Super Long Life Coolant” is pre-mixed with
50% coolant and 50% deionized water.
For Canada:
“Toyota Super Long Life Coolant” is pre-mixed with
55% coolant and 45% deionized water.
• Funnel (used only for adding coolant)
Engine oil level
( → P. 456)• “Toyota Genuine Motor Oil” or equivalent
• Rag or paper towel
• Funnel (used only for adding engine oil)
Fuses
(→ P. 488)• Fuse with same amperage rating as original
Light bulbs
(→ P. 491)
• Bulb with same number and wattage rating as origi-
nal
• Phillips-head screwdriver
• Flathead screwdriver• Wrench
Power steering
fluid level

(
→P. 461)
• Automatic transmission fluid DEXRON® II or III
• Rag or paper towel
• Funnel (used only for adding power steering fluid)
Radiator and
condenser
(
→P. 460)
⎯
Tire inflation
pressure
( → P. 476)• Tire pressure gauge
• Compressed air source
Washer fluid
(→ P. 465)• Water or washer fluid containing antifreeze (for win-
ter use)
• Funnel (used only for adding water or washer fluid)

4887-3. Do-it-yourself maintenance
Checking and replacing fuses
Turn the engine switch off.
Open the fuse box cover.
Engine compartment
Push the tabs in and lift the
cover off.
Under the instrument panel
Remove the cover.
Remove the fuse with the pull-
out tool.
Only type A fuse can be removed
using the pullout tool.
If any of the electrical components do not operate, a fuse may
have blown. If this happens, check and replace the fuses as nec-
essary.
1
2
3

4897-3. Do-it-yourself maintenance
7
Maintenance and care
Check if the fuse is blown.Normal fuse
Blown fuse
Type A and B:
Replace the blown fuse with a new fuse of an appropriate amperage rat-
ing. The amperage rating can be found on the fuse box cover.
Type C:
Contact your Toyota dealer.
■After a fuse is replaced
●If the lights do not turn on even after the fuse has been replaced, a bulb may
need replacement. ( →P. 491)
● If the replaced fuse blows again, have the vehicle inspected by your Toyota
dealer.
■ If there is an overload in a circuit
The fuses are designed to blow, protecting the wiring harness from damage.
4
1
2
Ty p e AType B
Ty p e C

4907-3. Do-it-yourself maintenance
WARNING
■To prevent system breakdowns and vehicle fire
Observe the following precautions.
Failure to do so may cause damage to the vehicle, and possibly a fire or
injury.
● Never use a fuse of a higher amperage rating than that indicated, or use\
any other object in place of a fuse.
● Always use a genuine Toyota fuse or equivalent.
Never replace a fuse with a wire, even as a temporary fix.
● Do not modify the fuses or fuse boxes.
NOTICE
■Before replacing fuses
Have the cause of electrical overload determined and repaired by your Toy-
ota dealer as soon as possible.

630Alphabetical index
Flat tire...................................... 540
Floor mats .................................. 24
FluidAutomatic transmission......... 577
Brake .................................... 578
Power steering ...................... 578
Washer ................................. 465
Fog lights ................................. 210 Replacing light bulbs............. 497
Switch ................................... 210
Wattage ................................ 580
Four-wheel drive system ........ 247
Front passenger occupant classification system .............. 45
Front personal lights ............... 390
Front seats ............................... 129 Adjustment ............................ 129
Cleaning................................ 441
Correct driving posture ........... 26
Head restraints ..................... 134
Seat heaters ......................... 387
Front side marker lights
Light switch ........................... 206
Replacing light bulbs............. 495
Wattage ................................ 580
Front turn signal lights Replacing light bulbs............. 496
Turn signal lever ................... 204
Wattage ................................ 580
Fuel ........................................... 572 Capacity ................................ 572
Fuel gauge .............................. 88
Fuel pump shut off system.... 513
Information ............................ 581
Refueling............................... 214
Type ...................................... 572
Warning light ......................... 516
Warning message ................. 527 Fuel consumption
Average fuel consumption ................... 94, 98
Current fuel consumption ................... 94, 98
Fuel filler door ......................... 216
Fuel pump shut off system..... 513
Fuses ........................................ 488
Garage door opener ................ 425
Gas station information .......... 640
Gauges ....................................... 88
Glove box ................................. 393
Grocery bag hooks.................. 408
F
G

635Alphabetical index
ReplacingElectronic key battery ........... 485
Fuses .................................... 488
Light bulbs ............................ 491
Tires ...................................... 540
Wireless remote control battery ................................ 485
Reporting safety defects for U.S. owners ...................... 604
Resetting the remainder light
or message indicating
maintenance is required ....... 445
Seat belt reminder light........... 516
Seat belts.................................... 28 Adjusting the seat belt ............ 29
Automatic Locking Retractor (ALR) .................... 30
Child restra int system
installation ............................ 55
Cleaning and maintaining
the seat belt ........................ 442
Emergency Locking Retractor (ELR) .................... 30
How to wear your seat belt ..... 28
How your child should wear the seat belt .......................... 30
Pregnant women, proper seat belt use ......................... 31
Reminder light and buzzer .... 516
Seat belt extender................... 30
Seat belt pretensioners ........... 29
SRS warning light ................. 514 Seat heaters ............................. 387
Seating capacity ...................... 169
Seats, Front.............................. 129
Adjustment............................ 129
Adjustment precautions ........ 130
Cleaning ............................... 441
Head restraints ..................... 134
Properly sitting in the seat ...... 26
Seat heaters ......................... 387
Seats, Rear ............................... 131
Adjustment precautions ........ 133
Child seats/child restraint system installation ................ 55
Cleaning ............................... 441
Folding down ........................ 131
Head restraints ..................... 134
Raising the bottom cushion ............................... 131
Sensor
Automatic headlight system .......... ...................... 208
Inside rear view mirror .......... 142
Intuitive parking assist .......... 223
Shift lever ......................... 197, 202 Automatic transmission ........ 197
If the shift lever
cannot be shifted from P .... 200
Manual transmission............. 202
S mode ................................. 199
Shift lock system ..................... 200
Side airbags ............................... 35
S
*: For vehicles with Entune Audio Plus or Entune Premium Audio, refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”
