2017 TOYOTA PRIUS PRIME lock

740
PRIUS PRIME_OM_OM47A88U_(U)
9-2. Customization
■Remote Air Conditioning System (→P. 509)
■Illumination ( →P. 515)
*: If equipped
FunctionDefault
settingCustomized setting
Operation using the “A/C” but-
ton on the wireless remote
controlPress and
hold for 0.8 seconds
Press once
––O
Press twice
Press and
hold for 2.4
seconds
Off
Stopping the operation using
the “A/C” button on the wire-
less remote control
Press twice
Press once
––O
Press and
hold for 0.8 seconds
Press and
hold for 2.4
seconds
Off
123
FunctionDefault settingCustomized setting
Time elapsed before the inte-
rior lights turn off 15 secondsOff
–OO
7.5 seconds
30 seconds
Operation after the power
switch is turned offOnOff––O
Operation when the doors are
unlockedOnOff––O
Operation when you approach
the vehicle with the electronic
key on your person
OnOff––O
Footwell lighting*OnOff––O
Interior lights illumination con-
trolOnOff––O
123

PRIUS PRIME_OM_OM47A88U_(U)
7419-2. Customization
9
Vehicle specifications
■Seat belt reminder (→P. 658)
■Vehicle customization
●When the Speed linked door locking function and the Shift position linked
door locking function are both on, the door lock operates as follows.
• When shifting the shift position to any position other than P, all the doors
will be locked.
• If the vehicle is started with all the doors locked, the Speed linked door locking function would not operate.
• If the vehicle is started with any door unlocked, the Speed linked door
locking function will operate.
● When the smart key system is off, Smart door unlocking cannot be custom-
ized.
● When the doors remain closed after unlocking the doors and the automatic
door lock function is activated, the signals will be generated in accordance
with the operation signal (buzzer) and the operation signal (emergency
flashers) settings.
■ In the following situati ons, customize mode in which the settings can be
changed through the mu lti-information display will automatically be
turned off.
● The power switch is turned off.
● The vehicle begins to move while the customize mode screen is displayed.
FunctionDefault
settingCustomized setting
Vehicle speed linked seat belt
reminder buzzerOnOff––O
WARNING
■Cautions during customization
As the hybrid system needs to be oper ating during customization, ensure
that the vehicle is parked in a place with adequate ventilation. In a closed
area such as a garage, exhaust gases including harmful carbon monoxide
(CO) may collect and enter the vehicle. This may lead to death or a serious
health hazard.
NOTICE
■ During customization
To prevent 12-volt battery discharge, ensure that the hybrid system is oper-
ating while customizing features.
123

742
PRIUS PRIME_OM_OM47A88U_(U)
9-2. Customization
■Charge settings
■Maintenance system
Charge scheduleSetting the charging timer: →P. 151
Charge currentChanging the upper limit of the charging cur-
rent:→P. 123
Charging connector lock
(if equipped)Changing the charging connector lock settings:
→P. 1 1 8
Traction battery heaterSetting “Traction Battery Heater” on/off:
→P. 126
Oil Maintenance
(U.S.A. only)Resetting the message indicating maintenance
is required: →P. 568
Tire pressure warning
systemInitializing the tire pr essure warning system:
→ P. 5 9 5

762What to do if... (Troubleshooting)
PRIUS PRIME_OM_OM47A88U_(U)
What to do if... (Troubleshooting)
●If you lose your mechanical keys, new genuine mechanical keys can be
made by your Toyota dealer. ( →P. 263)
●If you lose your electronic keys, the risk of vehicle theft increases signifi-
cantly. Contact your Toyota dealer immediately. ( →P. 266)
●Is the electronic key battery weak or depleted? (→P. 627)
●Is the power switch in ON mode?
When locking the doors, turn the power switch off. ( →P. 326)
●Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of the radio
wave. (→P. 281)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (→P. 270)
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened

763What to do if... (Troubleshooting)
PRIUS PRIME_OM_OM47A88U_(U)
●Did you press the power switch while firmly depressing the brake pedal?
(→P. 324)
●Is the shift position in P? ( →P. 331)
●Is the electronic key anywhere detectable inside the vehicle? ( →P. 279)
●Is the electronic key battery weak or depleted?
In this case, the hybrid system can be started in a temporary way.
(→P. 691)
●Is the 12-volt battery discharged? ( →P. 694)
●Is the window lock switch pressed?
The power windows except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( →P. 300)
●The auto power off function will be operated if the vehicle is left in
ACCESSORY or ON mode (the hybrid system is not operating) for a
period of time. ( →P. 326)
If you think something is wrong
The hybrid system does not start
The windows do not open or close by operating the power
window switches
The power switch is turned off automatically

766Alphabetical index
PRIUS PRIME_OM_OM47A88U_(U)
Alphabetical index
A/C .................................... 488, 498Air conditioning eco
mode .......................... 490, 501
Air conditioning filter ............. 620
Automatic air conditioning system .... 488, 498
Eco score (A/C score)........... 228
Humidity sensor ............ 494, 505
Remote Air Conditioning System ............................... 509
S-FLOW mode .............. 489, 500
ABS (Anti-lock Brake System) .................................. 476 Function ................................ 476
Warning light ......................... 654
Air conditioning filter .............. 620
Air conditioning system ............................ 488, 498 Air conditioning eco mode .......................... 490, 501
Air conditioning filter ............. 620
Automatic air conditioning system .... 488, 498
Eco score (A/C score)........... 228
Humidity sensor ............ 494, 505
Remote Air Conditioning System ............................... 509
S-FLOW mode .............. 489, 500
Air intake vent ............................ 91 Airbags ....................................... 36
Airbag operating conditions .... 44
Airbag precautions for
your child .............................. 40
Airbag warning light .............. 654
Correct driving posture ........... 28
Curtain shield airbag operating conditions ............. 45
Curtain shield airbag precautions........................... 42
Front passenger occupant
classification syst em ............ 50
General airbag precautions .... 39
Locations of airbags ............... 36
Modification and disposal of airbags ............................. 43
Side airbag operating
conditions ............................. 45
Side airbag precautions .......... 41
Side and curtain shield airbags operating
conditions ............................. 45
Side and curtain shield
airbags precautions .............. 42
SRS airbag instructions for Canadian owners ............... 749
SRS airbags ........................... 36
Anchor brackets ........................ 73
Antenna (smart key system) .................................. 278
Anti-lock brake system (ABS) ...................................... 476 Function ................................ 476
Warning light......................... 654
A

767Alphabetical index
PRIUS PRIME_OM_OM47A88U_(U)
Approach warning ................... 400
Assist grips .............................. 540
Audio input
*
Audio system*
Automatic air conditioning system ..... 488, 498 Air conditioning eco mode .......................... 490, 501
Air conditioning filter ............. 620
Automatic air conditioning system .... 488, 498
Eco score (A/C score)........... 228
Humidity sensor ............ 494, 505
Remote Air Conditioning System ............................... 509
S-FLOW mode .............. 489, 500
Automatic door locking
and unlocking systems ........ 270
Automatic High Beam ............. 343
Automatic light control system .................................... 341
AUX port
*
Auxiliary boxes ........................ 522
Back door ................................. 273
Back-up lights .......................... 635 Replacing light bulbs............. 636
Wattage ................................ 717
Battery (12-volt battery) .......... 587
Battery checking ................... 587
Exchanging ........................... 697
If the 12-volt battery is discharged .......................... 694
Preparing and checking before winter....................... 482
Warning light ......................... 653 Battery (traction battery) .......... 90
Air intake vent ......................... 91
Charging ............................... 102
Location .................................. 90
Specification ......................... 711
Status indicator ..................... 104
Blind Spot Monitor (BSM) ....... 408 Blind Spot Monitor function... 412
Rear Cross Traffic Alert
function............................... 415
Bluetooth
®*
Bottle holders .......................... 521
Brake Fluid ...................................... 716
Parking brake ....................... 337
Regenerative braking ............. 86
Warning light......................... 653
Brake assist ............................. 476
Brake Override System ........... 308
Break-in tips............................. 309
Brightness control Instrument cluster light control ......................... 182
BSM (Blind Spot Monitor) ....... 408 Blind Spot Monitor function... 412
Rear Cross Traffic Alert function............................... 415
Care .................................. 556, 561 Aluminum wheels ................. 557
Camera sensor ..................... 365
Exterior ................................. 556
Interior .................................. 561
Radar sensor ........................ 364
Seat belts.............................. 564
Water-repellent coating ........ 557
B
C
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

768Alphabetical index
PRIUS PRIME_OM_OM47A88U_(U)
Cargo capacity ......................... 321
Catch protection function ....... 301
CD player
*
Chains....................................... 483
Charging ................................... 102Charging cable...................... 107
Charging equipment ............. 102
Charging indicator................. 106
Charging messages .............. 175
Charging precautions............ 143
Charging procedure .............. 136
Charging time may increase .............................. 126
Charging timer function......... 147
High voltage components ....... 90
Information related to charging display ................. 130
Opening and closing the charging port lid .................. 103
Power sources
precautions ......................... 124
Power sources that can be used.................................... 122
Safety functions ............ 132, 141
When normal charging cannot be carried out.......... 170
Charging cable......................... 107
CCID (Charging Circuit Interrupting Device) ............ 107
If the charging cable
cannot be unlocked ............ 120
Indicator................................. 109
Maintenance ......................... 112
Safety functions .................... 108
Charging port ........................... 102 Opening and closing ............. 103
Smart lid & connector
locking system ..... ............... 113
If the charging port lid does
not open ............................. 116 Child restraint system............... 58
Fixed with a LATCH
system .......... ..................... ... 70
Fixed with a seat belt .............. 64
Front passenger occupant classification syst em ............ 50
Points to remember ................ 58
Riding with children ................ 57
Types of child restraint system installation method ............... 60
Using an anchor bracket......... 73
Child safety ................................ 57 12-volt battery precautions ... 588
Airbag precautions.................. 40
Back door precautions .......... 275
Charging precautions ........... 131
Child restraint system ............. 58
How your child should wear the seat belt ................. 32
Installing child restraints ......... 60
Power window lock switch .... 300
Power window precautions ... 302
Rear door child-protectors .... 270
Removed key battery
precautions......................... 629
Riding with children ................ 57
Seat belt extender precautions........................... 34
Seat belt precautions .............. 69
Seat heater precautions ....... 513
Child-protectors ...................... 270
Cleaning ........................... 556, 561 Aluminum wheels ................. 557
Camera sensor ..................... 365
Exterior ................................. 556
Interior .................................. 561
Radar sensor ........................ 364
Seat belts.............................. 564
Water-repellent coating ........ 557
