goes out when deactivated.
Troubleshooting
ESC or ASR faulty/deactivated by the system illuminates

Pedestrian detection system
Functionality
Pedestrian recognition helps to prevent a collision
with crossing pedestrians by enabling automatic
braking interventions.
Status display in the instrument cluster display or
lights up - Danger of collision
Risk of collision in a speed range of 5-30 km/h
The system triggers automatic braking.
Risk of collision in a speed range of 30-60 km/h
The system warns of a collision hazard first. If the
driver does not respond, the vehicle is automatically
braked.
Operating conditions
q Front Assist activated.
q Driving speed between 5-60 km/h.
Speed limiter Functionality
The speed limiter controls the maximum driving
speed according to the set speed limit.
If the limit is exceeded when driving downhill, brake
the vehicle with the brake pedal.
Status display in the instrument cluster display illuminated - the cruise control is activated.
When the control starts,
is highlighted and the
set limit is displayed.
illuminated - cruise control is active
flashing - the set limit is exceeded
Operating conditions
q The driving speed is higher than 30 km/h.
Operation
Variant without GRA
A Activate limiter (control inactive)
Deactivate limiter
Interrupt control (sprung position)
B Resume control 1)
/Increase limitC Start control with current speed/Reduce
limit
Variant with GRA
A Activate GRA (condition for the subsequent
activation of the limiter).
To enable the speed limiter , press the key D
and in the instrument cluster choose the menu
item
Speed limit
.
Deactivate limiter
Interrupt control (sprung position)
B Resume control 1)
/Increase limitC Start control with current speed/Reduce
limitD Show menu of assist systems - Possibility of
switching between GRA and speed limiter
Switching to GRA interrupts the control.
Adjusting the speed limit with the buttons
B
and
C
By pressing in steps of 1 km/h.
By holding in steps of 10 km/h.
1)
If no speed limit is set, the current speed is set as the speed limit.
176Driver assist systems

Variant with ACCActivate ACC (condition for the subsequent
activation of the limiter). To enable the speed
limiter, press the key
and in the instru-
ment cluster choose the menu item
Speed limit
.
Resume control 1)
/Increase limit in steps of 1
km/h (sprung position)Interrupt control (sprung position)Deactivate the limiterIncrease limit in steps of 10 km/hDecrease limit in steps of 10 km/hStart control/Reduce limit in steps of 1 km/h
Limit exceeded

Troubleshooting
Cruise control system faultyilluminates

Line A appears in the
display, indicating the
change in distance.

Settings
Activation/deactivation in the instrument cluster
In the display in the Assist systems menu item
Setting in Infotainment
In the following menu.

Or:

Troubleshooting
Message regarding system unavailability
